| 1 |
I8-98179 968-1 |
|
SHAFT, TOP GEAR, TRANS |
1 |
1512- |
|
MSB5M |
Z=28 |
| 50 |
I8-97174 955-0 |
|
GEAR, 2ND, MAINSHAFT |
1 |
1512- |
|
MSB5M |
Z=34 |
| 18 |
I8-97254 728-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MYY5T |
ID=30.7 T=1.8 |
| 36 |
I8-97241 234-0 |
|
GEAR, 3RD, MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=34 |
| 313 |
I8-98189 748-0 |
|
BEARING, NEEDLE, LOW GEAR |
1 |
1512- |
|
MSB5S |
|
| 182 |
I8-98188 586-0 |
|
PLATE, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
Z=51 |
| 63 |
I8-98190 418-0 |
|
INSERT, SYN, REV & 5TH |
3 |
1512- |
|
MSB5S |
|
| 59 |
I8-97241 244-0 |
|
GEAR, REV MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=41 |
| 93 |
I8-97254 742-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY6S |
ID=30.7 T=2.3 |
| 535 |
I8-97177 133-0 |
|
SLEEVE, HUB, LOW?2ND |
1 |
1512- |
|
MSB5M |
Z=42 |
| 172 |
I8-94402 405-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.75 |
| 77 |
I8-97386 582-0 |
|
GEAR, 6TH, MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=21 |
| 180 |
I8-98189 991-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
(B) ID=38.5 |
| 177 |
I8-98189 990-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
ID=44.5 |
| 93 |
I8-97254 734-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.9 |
| 300 |
I8-97254 734-0 |
|
RING, SNAP, COUNTER SHAFT, RR END |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.9 |
| 390 |
I8-94151 521-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.80 |
| 408 |
I8-98189 347-0 |
|
SPRING |
1 |
1512- |
|
MSB5S |
(A) |
| 300 |
I8-97365 617-0 |
|
RING, SNAP, COUNTER SHAFT, RR END |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.6 |
| 325 |
I8-97252 668-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.41 |
| 173 |
I8-94157 747-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5S |
T=2.00 |
| 62 |
I8-98189 962-0 |
|
SPRING, INSERT, REV & 5TH |
2 |
1512- |
|
MSB5S |
|
| 342 |
I8-98031 640-0 |
|
FLANGE, OUTPUT |
1 |
1512- |
|
MYY5T |
|
| 1 |
I8-98031 848-0 |
|
SHAFT, TOP GEAR, TRANS |
1 |
1512- |
|
MYY5T |
Z=28 |
| 3 |
I8-94178 732-A |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MSB5M |
(IADG) |
| 136 |
I8-98188 533-0 |
|
WASHER, THRUST, REV IDLE, RR |
1 |
1512- |
|
MSB5S |
|
| 386 |
I8-98190 093-0 |
|
PIN, REV SHAFT |
1 |
1512- |
|
MSB5S |
|
| 530 |
I6-97241 306-0 |
|
RING, BLOCK, LOW |
1 |
1512- |
|
MYY6S |
(IADG) Z=45 |
| 182 |
I8-98188 585-0 |
|
PLATE, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
Z=49 |
| 40 |
I8-98189 960-0 |
|
SPRING, INSERT, LOW & 2ND |
2 |
1512- |
|
MSB5S |
|
| 500 |
I6-97241 309-0 |
|
RING, OUTSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY6S |
(IADG) |
| 408 |
I8-97366 040-1 |
|
SPRING |
2 |
1512- |
|
MYY6S |
(C) |
| 186 |
I9-09180 032-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
ID=29.6 |
| 325 |
I8-97306 190-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.23 |
| 535 |
I8-97177 133-0 |
|
SLEEVE, HUB, LOW?2ND |
1 |
1512- |
|
MSB5S |
Z=42 |
| 325 |
I8-97252 672-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.65 |
| 408 |
I8-98189 347-0 |
|
SPRING |
1 |
1512- |
|
MSB5M |
(A) |
| 66 |
I8-98190 426-0 |
|
RING, BLOCK, SYN |
1 |
1512- |
|
MSB5S |
Z=36 |
| 298 |
I8-98028 226-0 |
|
GASKET, MAINSHAFT |
1 |
1512- |
|
MYY5T |
ID=30.6 T=5.7 |
| 108 |
I8-97380 630-1 |
|
SHAFT, COUNTER |
1 |
1512- |
|
MYY5T |
Z=45-49-33-20 |
| 59 |
I8-98190 291-0 |
|
GEAR, REV MAINSHAFT |
1 |
1512- |
|
MSB5M |
Z=41 |
| 3 |
I8-97253 098-A |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MYY5T |
(IADG) |
| 39 |
I8-97177 689-0 |
|
HUB, CLU, LOW & 2ND |
1 |
1512- |
|
MSB5S |
Z=42 |
| 524 |
I6-97366 526-0 |
|
SLEEVE & HUB ASM, TOP?4TH, OD |
1 |
1512- |
|
MYY5T |
(IADG) |
| 517 |
I8-97252 935-0 |
|
BALL, SYNCHRO, INDEX |
6 |
1512- |
|
MYY6S |
|
| 135 |
I8-97169 508-0 |
|
GEAR, REV IDLER |
1 |
1512- |
|
MSB5S |
Z=29 |
| 24 |
I8-97241 313-1 |
|
BLOCK, INDEX, SYN |
6 |
1512- |
|
MYY6S |
|
| 120 |
I8-94421 871-1 |
|
SLEEVE |
1 |
1512- |
|
MYY5T |
(B) Z=45 |
| 1 |
I8-98179 969-1 |
|
SHAFT, TOP GEAR, TRANS |
1 |
1512- |
|
MSB5S |
Z=30 |
| 529 |
I8-97248 952-0 |
|
PLATE, STOPPER, 6TH |
1 |
1512- |
|
MYY6S |
|
| 325 |
I8-97306 188-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.11 |
| 527 |
I8-94448 202-2 |
|
INSERT, 6TH |
3 |
1512- |
|
MYY6S |
|
| 325 |
I8-97252 675-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.83 |
| 397 |
I8-98189 962-0 |
|
SPRING, INSERT, 4TH & 3RD |
2 |
1512- |
|
MSB5M |
|
| 511 |
I8-97254 767-0 |
|
RING, SNAP, ANTI LASH PLATE |
1 |
1512- |
|
MYY6S |
|
| 405 |
I8-98189 965-0 |
|
INSERT, SYN, LOW & 2ND |
3 |
1512- |
|
MSB5M |
|
| 273 |
I8-97254 610-0 |
|
RING, SNAP, BRG OUTER |
1 |
1512- |
|
MYY6S |
|
| 325 |
I8-97252 671-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.59 |
| 276 |
I8-98188 906-0 |
|
SPACER, BRG TO DRIVE GEAR |
1 |
1512- |
|
MSB5M |
|
| 84 |
I5-09800 062-1 |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5M |
|
| 298 |
I8-98028 226-0 |
|
GASKET, MAINSHAFT |
1 |
1512- |
|
MYY6S |
ID=30.6 T=5.7 |
| 390 |
I8-94151 522-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.85 |
| 397 |
I8-98189 962-0 |
|
SPRING, INSERT, 4TH & 3RD |
2 |
1512- |
|
MSB5S |
|
| 523 |
I8-97241 231-0 |
|
GEAR, OD, MAINSHAFT |
1 |
1512- |
|
MYY5T |
Z=22 |
| 135 |
I8-97169 508-0 |
|
GEAR, REV IDLER |
1 |
1512- |
|
MSB5M |
Z=29 |
| 177 |
I8-98189 990-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
ID=44.5 |
| 74 |
I8-98188 569-0 |
|
WASHER, THRUST, REV GEAR |
1 |
1512- |
|
MSB5M |
|
| 531 |
I6-97368 343-0 |
|
RING, BLOCK, REV |
1 |
1512- |
|
MYY6S |
(IADG) Z=45 |
| 35 |
I8-98190 426-0 |
|
RING, BLOCK, 4TH & 3RD |
2 |
1512- |
|
MSB5M |
Z=36 |
| 276 |
I8-98188 906-0 |
|
SPACER, BRG TO DRIVE GEAR |
1 |
1512- |
|
MSB5S |
|
| 501 |
I6-97241 312-0 |
|
RING, INSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY6S |
(IADG) |
| 389 |
I8-97373 144-0 |
|
HUB, CLU, REV & 5TH |
1 |
1512- |
|
MSB5S |
Z=36 |
| 408 |
I8-97366 040-1 |
|
SPRING |
2 |
1512- |
|
MYY5T |
(C) |
| 503 |
I6-97241 309-0 |
|
RING, OUTSIDE, LOW & REV |
1 |
1512- |
|
MYY5T |
(IADG) |
| 120 |
I8-94421 871-1 |
|
SLEEVE |
1 |
1512- |
|
MYY6S |
(B) Z=45 |
| 325 |
I8-97252 666-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.29 |
| 325 |
I8-97252 671-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.59 |
| 84 |
I5-09800 062-1 |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5S |
|
| 36 |
I8-97241 234-0 |
|
GEAR, 3RD, MAINSHAFT |
1 |
1512- |
|
MYY5T |
Z=34 |
| 49 |
I8-98189 747-0 |
|
BEARING, NEEDLE, 2ND GEAR |
1 |
1512- |
|
MSB5S |
NSK |
| 66 |
I8-98190 426-0 |
|
RING, BLOCK, SYN |
1 |
1512- |
|
MSB5M |
Z=36 |
| 325 |
I8-97257 622-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.89 |
| 500 |
I8-97241 309-1 |
|
RING, OUTSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY6S |
|
| 173 |
I8-94157 747-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5M |
T=2.00 |
| 109 |
I8-97095 913-1 |
|
BEARING, COUNTER SHAFT, RR |
1 |
1512- |
|
MSB5S |
|
| 82 |
I8-97253 116-3 |
|
SHAFT, MAIN, TRANS |
1 |
1512- |
|
MYY6S |
Z=28-42-42-21 |
| 173 |
I8-94151 522-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5M |
T=1.85 |
| 109 |
I8-97095 913-1 |
|
BEARING, COUNTER SHAFT, RR |
1 |
1512- |
|
MSB5M |
|
| 387 |
I8-98189 965-0 |
|
INSERT, SYN, 4TH & 3RD |
3 |
1512- |
|
MSB5M |
|
| 135 |
I8-98031 869-1 |
|
GEAR, REV IDLER |
1 |
1512- |
|
MYY6S |
Z=25 |
| 180 |
I8-98189 991-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
(B) ID=38.5 |
| 50 |
I8-97241 237-1 |
|
GEAR, 2ND, MAINSHAFT |
1 |
1512- |
|
MYY5T |
Z=38 |
| 396 |
I8-97253 110-0 |
|
BEARING, NEEDLE, MAINSHAFT |
4 |
1512- |
|
MYY5T |
(B) |
| 97 |
I8-97169 511-0 |
|
GEAR, 5TH, COUNTER |
1 |
1512- |
|
MSB5S |
Z=53 |
| 51 |
I8-98190 428-0 |
|
RING, BLOCK, LOW & 2ND |
2 |
1512- |
|
MSB5M |
Z=42 |
| 173 |
I8-94151 524-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5M |
T=1.95 |
| 393 |
I8-97207 512-1 |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MSB5S |
|
| 342 |
I8-98031 640-0 |
|
FLANGE, OUTPUT |
1 |
1512- |
|
MYY6S |
4HG1-T |
| 396 |
I8-98189 970-0 |
|
BEARING, NEEDLE, MAINSHAFT |
1 |
1512- |
|
MSB5M |
(A) |
| 386 |
I8-98190 093-0 |
|
PIN, REV SHAFT |
1 |
1512- |
|
MSB5M |
|
| 393 |
I8-97207 512-A |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MSB5S |
(IADG) |
| 314 |
I8-97253 114-0 |
|
BEARING, NEEDLE, REV GEAR |
1 |
1512- |
|
MYY6S |
|
| 524 |
I6-97366 526-0 |
|
SLEEVE & HUB ASM, TOP?4TH, OD |
1 |
1512- |
|
MYY6S |
(IADG) |
| 510 |
I9-08160 825-0 |
|
PIN, STRAIGHT, ANTI LASH |
3 |
1512- |
|
MYY5T |
|
| 500 |
I6-97241 309-0 |
|
RING, OUTSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY5T |
(IADG) |
| 36 |
I8-98180 094-1 |
|
GEAR, 3RD, MAINSHAFT |
1 |
1512- |
|
MSB5S |
Z=33 |
| 389 |
I8-97373 144-0 |
|
HUB, CLU, REV & 5TH |
1 |
1512- |
|
MSB5M |
Z=36 |
| 3 |
I8-97253 098-A |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MYY6S |
(IADG) |
| 281 |
I8-98188 466-0 |
|
WASHER, THRUST, MAINSHAFT |
1 |
1512- |
|
MSB5M |
|
| 180 |
I1-09588 177-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
(A) ID=32.2 |
| 70 |
I8-98180 095-1 |
|
GEAR, 1ST, MAINSHAFT |
1 |
1512- |
|
MSB5M |
Z=43 |
| 173 |
I8-94151 523-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5M |
T=1.90 |
| 325 |
I8-97252 667-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.35 |
| 115 |
I8-98286 084-0 |
|
BEARING, NEEDLE, 6TH, COUNTER |
1 |
1512- |
|
MYY6S |
OD=49.8 |
| 501 |
I8-97241 312-1 |
|
RING, INSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY5T |
|
| 13 |
I8-97373 011-0 |
|
GEAR, 5TH, MAINSHAFT |
1 |
1512- |
|
MSB5S |
Z=25 |
| 1 |
I8-98021 266-0 |
|
SHAFT, TOP GEAR, TRANS |
1 |
1512-1712 |
|
MYY6S |
Z=26 |
| 325 |
I8-97252 672-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.65 |
| 186 |
I9-09180 032-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
ID=29.6 |
| 120 |
I8-98258 279-0 |
|
SLEEVE |
2 |
1512- |
|
MYY5T |
(A) Z=45 |
| 526 |
I8-97253 112-0 |
|
BEARING, NEEDLE, 4TH & 5TH |
1 |
1512- |
|
MYY5T |
Z=45 |
| 325 |
I8-97257 622-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.89 |
| 80 |
I8-97253 556-0 |
|
GEAR, SPD DRIVE |
1 |
1512- |
|
MYY6S |
Z=4 |
| 393 |
I8-97207 512-A |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MSB5M |
(IADG) |
| 13 |
I8-97373 008-0 |
|
GEAR, 5TH, MAINSHAFT |
1 |
1512- |
|
MSB5M |
Z=24 |
| 3 |
I8-94178 732-2 |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MSB5S |
|
| 50 |
I8-97373 143-1 |
|
GEAR, 2ND, MAINSHAFT |
1 |
1512- |
|
MSB5S |
Z=36 |
| 524 |
I8-97366 526-0 |
|
SLEEVE & HUB ASM, TOP?4TH, OD |
1 |
1512- |
|
MYY6S |
|
| 423 |
I8-97367 022-0 |
|
SLEEVE & HUB ASM, 6TH |
1 |
1512- |
|
MYY6S |
|
| 70 |
I8-98180 095-1 |
|
GEAR, 1ST, MAINSHAFT |
1 |
1512- |
|
MSB5S |
Z=43 |
| 500 |
I8-97241 309-1 |
|
RING, OUTSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY5T |
|
| 325 |
I8-97252 669-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.47 |
| 93 |
I8-97254 740-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY6S |
ID=30.7 T=2.1 |
| 534 |
I8-97177 134-0 |
|
SLEEVE, HUB, 4TH?3RD |
1 |
1512- |
|
MSB5S |
Z=36 |
| 173 |
I8-94151 524-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5S |
T=1.95 |
| 183 |
I8-98189 380-0 |
|
SPRING, PLATE, CLUSTER GEAR |
3 |
1512- |
|
MSB5M |
|
| 3 |
I8-94178 732-A |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MSB5S |
(IADG) |
| 70 |
I8-97350 010-0 |
|
GEAR, 1ST, MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=43 |
| 109 |
I8-97095 913-A |
|
BEARING, COUNTER SHAFT, RR |
1 |
1512- |
|
MSB5M |
(IADG) |
| 335 |
I8-97254 722-0 |
|
RING, SNAP, BEARING |
1 |
1512- |
|
MYY6S |
|
| 118 |
I8-97386 580-0 |
|
GEAR, 6TH, COUNTER |
1 |
1512- |
|
MYY6S |
Z=50 |
| 507 |
I8-97253 107-0 |
|
BEARING, COUNTER SHAFT, FRT & RR |
2 |
1512- |
|
MYY6S |
|
| 183 |
I8-98189 380-0 |
|
SPRING, PLATE, CLUSTER GEAR |
3 |
1512- |
|
MSB5S |
|
| 390 |
I8-94151 520-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.75 |
| 342 |
I8-98031 862-0 |
|
FLANGE, OUTPUT |
1 |
1807- |
|
MYY6S |
4HL1-TC |
| 314 |
I8-98189 749-0 |
|
BEARING, NEEDLE, REV GEAR |
1 |
1512- |
|
MSB5S |
|
| 172 |
I8-94402 405-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.75 |
| 30 |
I8-97241 230-0 |
|
GEAR, 4TH, MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=28 |
| 93 |
I8-97254 740-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY5T |
ID=30.7 T=2.1 |
| 266 |
I8-97286 916-0 |
|
RING, SNAP, BRG INNER |
1 |
1512- |
|
MYY6S |
|
| 169 |
I8-97252 937-1 |
|
COLLAR, MAINSHAFT |
1 |
1512- |
|
MYY6S |
|
| 536 |
I8-97177 135-0 |
|
SLEEVE, HUB, REV?5TH |
1 |
1512- |
|
MSB5M |
Z=36 |
| 390 |
I8-94151 521-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.80 |
| 390 |
I8-94151 523-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.90 |
| 531 |
I8-97368 343-0 |
|
RING, BLOCK, REV |
1 |
1512- |
|
MYY5T |
Z=45 |
| 396 |
I8-97253 102-1 |
|
BEARING, NEEDLE, MAINSHAFT |
1 |
1512- |
|
MYY5T |
(C) |
| 503 |
I8-97241 309-1 |
|
RING, OUTSIDE, LOW & REV |
1 |
1512- |
|
MYY5T |
|
| 325 |
I8-97306 190-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.23 |
| 80 |
I8-97253 556-0 |
|
GEAR, SPD DRIVE |
1 |
1512- |
|
MYY5T |
Z=4 |
| 335 |
I8-97254 722-0 |
|
RING, SNAP, BEARING |
1 |
1512- |
|
MYY5T |
|
| 51 |
I8-98190 428-0 |
|
RING, BLOCK, LOW & 2ND |
2 |
1512- |
|
MSB5S |
Z=42 |
| 507 |
I8-97253 107-0 |
|
BEARING, COUNTER SHAFT, FRT & RR |
2 |
1512- |
|
MYY5T |
|
| 35 |
I8-98190 426-0 |
|
RING, BLOCK, 4TH & 3RD |
2 |
1512- |
|
MSB5S |
Z=36 |
| 325 |
I8-97306 188-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.11 |
| 49 |
I8-98189 747-0 |
|
BEARING, NEEDLE, 2ND GEAR |
1 |
1512- |
|
MSB5M |
NSK |
| 506 |
I8-97253 121-1 |
|
COLLAR, 6TH, COUNTER |
1 |
1512- |
|
MYY6S |
|
| 80 |
I8-98190 429-0 |
|
GEAR, SPD DRIVE |
1 |
1512- |
|
MSB5M |
Z=4 |
| 41 |
I8-97241 306-1 |
|
RING, BLOCK, 2ND & 3RD |
2 |
1512- |
|
MYY6S |
Z=45 |
| 3 |
I8-97253 098-1 |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MYY6S |
|
| 39 |
I8-97177 689-0 |
|
HUB, CLU, LOW & 2ND |
1 |
1512- |
|
MSB5M |
Z=42 |
| 515 |
I8-97241 298-3 |
|
HUB, CLU, 1ST & REV, 2ND & 3RD |
2 |
1512- |
|
MYY6S |
|
| 534 |
I8-97177 134-0 |
|
SLEEVE, HUB, 4TH?3RD |
1 |
1512- |
|
MSB5M |
Z=36 |
| 398 |
I8-97381 658-0 |
|
GEAR, COUNTER |
1 |
1512- |
|
MSB5S |
Z=49-34-22-14 |
| 28 |
I8-97254 743-0 |
|
RING, SNAP, 3RD GEAR |
1 |
1512- |
|
MYY6S |
ID=46.5 T=1.8 |
| 505 |
I8-97253 119-2 |
|
COLLAR, 3RD & REV |
2 |
1512- |
|
MYY5T |
|
| 390 |
I8-94151 520-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.75 |
| 530 |
I6-97241 306-0 |
|
RING, BLOCK, LOW |
1 |
1512- |
|
MYY5T |
(IADG) Z=45 |
| 135 |
I8-98031 869-1 |
|
GEAR, REV IDLER |
1 |
1512- |
|
MYY5T |
Z=25 |
| 281 |
I8-98188 466-0 |
|
WASHER, THRUST, MAINSHAFT |
1 |
1512- |
|
MSB5S |
|
| 515 |
I8-97241 298-3 |
|
HUB, CLU, 1ST & REV, 2ND & 3RD |
2 |
1512- |
|
MYY5T |
|
| 396 |
I8-97253 102-1 |
|
BEARING, NEEDLE, MAINSHAFT |
1 |
1512- |
|
MYY6S |
(C) |
| 393 |
I8-97253 105-1 |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MYY6S |
|
| 325 |
I8-97306 189-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.17 |
| 408 |
I8-94148 196-0 |
|
SPRING |
3 |
1512- |
|
MYY6S |
(B) |
| 325 |
I8-97252 673-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.71 |
| 3 |
I8-97253 098-1 |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MYY5T |
|
| 84 |
I6-09800 062-0 |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5M |
(IADG) |
| 525 |
I8-97309 532-0 |
|
RING, BLOCK, TOP & 4TH, OD |
2 |
1512- |
|
MYY6S |
|
| 120 |
I8-98258 279-0 |
|
SLEEVE |
2 |
1512- |
|
MYY6S |
(A) Z=45 |
| 132 |
I8-98189 378-0 |
|
SHAFT, REV |
1 |
1512- |
|
MSB5S |
|
| 59 |
I8-97241 244-0 |
|
GEAR, REV MAINSHAFT |
1 |
1512- |
|
MYY5T |
Z=41 |
| 503 |
I6-97241 309-0 |
|
RING, OUTSIDE, LOW & REV |
1 |
1512- |
|
MYY6S |
(IADG) |
| 300 |
I8-97254 727-0 |
|
RING, SNAP, COUNTER SHAFT, RR END |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.7 |
| 530 |
I8-97241 306-1 |
|
RING, BLOCK, LOW |
1 |
1512- |
|
MYY5T |
Z=45 |
| 390 |
I8-94151 522-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.85 |
| 33 |
I8-98189 746-0 |
|
BEARING, NEEDLE, 3RD GEAR |
1 |
1512- |
|
MSB5S |
|
| 93 |
I8-97254 734-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY5T |
ID=30.7 T=1.9 |
| 93 |
I8-97254 742-0 |
|
RING, SNAP, COUNTER FRT BRG |
1 |
1512- |
|
MYY5T |
ID=30.7 T=2.3 |
| 528 |
I8-94421 871-1 |
|
SLEEVE, 6TH |
1 |
1512- |
|
MYY6S |
Z=45 |
| 508 |
I8-97309 532-0 |
|
RING, BLOCK, 6TH |
1 |
1512- |
|
MYY6S |
Z=45 |
| 173 |
I8-94151 523-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5S |
T=1.90 |
| 325 |
I8-97252 675-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.83 |
| 40 |
I8-98189 960-0 |
|
SPRING, INSERT, LOW & 2ND |
2 |
1512- |
|
MSB5M |
|
| 24 |
I8-97241 313-1 |
|
BLOCK, INDEX, SYN |
6 |
1512- |
|
MYY5T |
|
| 82 |
I8-97368 837-0 |
|
SHAFT, MAIN, TRANS |
1 |
1512- |
|
MSB5S |
Z=27-40-37-27 |
| 314 |
I8-97253 114-0 |
|
BEARING, NEEDLE, REV GEAR |
1 |
1512- |
|
MYY5T |
|
| 501 |
I8-97241 312-1 |
|
RING, INSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY6S |
|
| 108 |
I8-97380 627-1 |
|
SHAFT, COUNTER |
1 |
1512- |
|
MYY6S |
Z=47-39-33-20 |
| 503 |
I8-97241 309-1 |
|
RING, OUTSIDE, LOW & REV |
1 |
1512- |
|
MYY6S |
|
| 132 |
I8-97252 655-0 |
|
SHAFT, REV |
1 |
1512- |
|
MYY6S |
|
| 408 |
I8-94148 196-0 |
|
SPRING |
3 |
1512- |
|
MYY5T |
(B) |
| 115 |
I8-97253 113-0 |
|
BEARING, NEEDLE, 6TH, COUNTER |
1 |
1512- |
|
MYY6S |
OD=49.75 |
| 501 |
I6-97241 312-0 |
|
RING, INSIDE, 3RD & 2ND |
2 |
1512- |
|
MYY5T |
(IADG) |
| 63 |
I8-98190 418-0 |
|
INSERT, SYN, REV & 5TH |
3 |
1512- |
|
MSB5M |
|
| 387 |
I8-98189 965-0 |
|
INSERT, SYN, 4TH & 3RD |
3 |
1512- |
|
MSB5S |
|
| 109 |
I8-97095 913-A |
|
BEARING, COUNTER SHAFT, RR |
1 |
1512- |
|
MSB5S |
(IADG) |
| 74 |
I8-98188 569-0 |
|
WASHER, THRUST, REV GEAR |
1 |
1512- |
|
MSB5S |
|
| 325 |
I8-97252 674-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.77 |
| 288 |
I8-97252 942-0 |
|
SPACER, BRG, MAINSHAFT |
1 |
1512- |
|
MYY5T |
|
| 260 |
I8-97360 410-0 |
|
NUT, MAINSHAFT END |
1 |
1512- |
|
MYY5T |
M27 H=25 |
| 4 |
I9-09180 040-0 |
|
RING, SNAP, BRG TO TOP GEAR SHAFT |
1 |
1512- |
|
MSB5S |
ID=37.0 |
| 172 |
I8-94402 407-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.85 |
| 59 |
I8-98190 291-0 |
|
GEAR, REV MAINSHAFT |
1 |
1512- |
|
MSB5S |
Z=41 |
| 390 |
I8-94151 523-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.90 |
| 531 |
I6-97368 343-0 |
|
RING, BLOCK, REV |
1 |
1512- |
|
MYY5T |
(IADG) Z=45 |
| 70 |
I8-97350 010-0 |
|
GEAR, 1ST, MAINSHAFT |
1 |
1512- |
|
MYY5T |
Z=43 |
| 504 |
I8-97241 312-1 |
|
RING, INSIDE, LOW & REV |
1 |
1512- |
|
MYY6S |
|
| 325 |
I8-97252 670-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.53 |
| 136 |
I8-98188 533-0 |
|
WASHER, THRUST, REV IDLE, RR |
1 |
1512- |
|
MSB5M |
|
| 41 |
I8-97241 306-1 |
|
RING, BLOCK, 2ND & 3RD |
2 |
1512- |
|
MYY5T |
Z=45 |
| 536 |
I8-97177 135-0 |
|
SLEEVE, HUB, REV?5TH |
1 |
1512- |
|
MSB5S |
Z=36 |
| 398 |
I8-97204 104-0 |
|
GEAR, COUNTER |
1 |
1512- |
|
MSB5M |
Z=51-34-22-14 |
| 268 |
I8-97257 300-1 |
|
PLATE, ANTI LASH, COUNTER |
1 |
1512- |
|
MYY5T |
|
| 3 |
I8-94178 732-2 |
|
BEARING, TOP GEAR SHAFT |
1 |
1512- |
|
MSB5M |
|
| 480 |
I8-97253 123-1 |
|
WASHER, THRUST, 6TH |
1 |
1512- |
|
MYY6S |
|
| 184 |
I8-98189 350-0 |
|
SPRING, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
|
| 320 |
I8-97177 690-0 |
|
HUB, CLU, 4TH & 3RD |
1 |
1512- |
|
MSB5S |
Z=36 |
| 320 |
I8-97177 690-0 |
|
HUB, CLU, 4TH & 3RD |
1 |
1512- |
|
MSB5M |
Z=36 |
| 80 |
I8-98190 429-0 |
|
GEAR, SPD DRIVE |
1 |
1512- |
|
MSB5S |
Z=4 |
| 33 |
I8-98189 746-0 |
|
BEARING, NEEDLE, 3RD GEAR |
1 |
1512- |
|
MSB5M |
|
| 273 |
I8-97254 610-0 |
|
RING, SNAP, BRG OUTER |
1 |
1512- |
|
MYY5T |
|
| 325 |
I8-97252 669-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.47 |
| 50 |
I8-97241 237-1 |
|
GEAR, 2ND, MAINSHAFT |
1 |
1512- |
|
MYY6S |
Z=38 |
| 266 |
I8-97286 916-0 |
|
RING, SNAP, BRG INNER |
1 |
1512- |
|
MYY5T |
|
| 516 |
I8-97254 835-0 |
|
SPRING, SYNCHRO, INDEX |
6 |
1512- |
|
MYY5T |
|
| 84 |
I5-09800 062-A |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5S |
|
| 173 |
I8-94151 522-0 |
|
RING, SNAP, OVERDRIVE GEAR |
1 |
1512- |
|
MSB5S |
T=1.85 |
| 4 |
I9-09180 040-0 |
|
RING, SNAP, BRG TO TOP GEAR SHAFT |
1 |
1512- |
|
MSB5M |
ID=37.0 |
| 393 |
I8-97253 105-1 |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MYY5T |
|
| 325 |
I8-97306 189-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.17 |
| 323 |
I8-94448 202-2 |
|
INSERT |
3 |
1512- |
|
MYY5T |
|
| 530 |
I8-97241 306-1 |
|
RING, BLOCK, LOW |
1 |
1512- |
|
MYY6S |
Z=45 |
| 524 |
I8-97366 526-0 |
|
SLEEVE & HUB ASM, TOP?4TH, OD |
1 |
1512- |
|
MYY5T |
|
| 185 |
I9-09180 045-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
ID=41.5 |
| 18 |
I8-97254 728-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.8 |
| 28 |
I8-97254 743-0 |
|
RING, SNAP, 3RD GEAR |
1 |
1512- |
|
MYY5T |
ID=46.5 T=1.8 |
| 325 |
I8-97252 674-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.77 |
| 393 |
I8-97207 512-1 |
|
BEARING, MAINSHAFT END |
1 |
1512- |
|
MSB5M |
|
| 519 |
I8-97252 940-0 |
|
COLLAR, MAINSHAFT END, 5TH |
1 |
1512- |
|
MYY5T |
|
| 516 |
I8-97254 835-0 |
|
SPRING, SYNCHRO, INDEX |
6 |
1512- |
|
MYY6S |
|
| 97 |
I8-97372 900-0 |
|
GEAR, 5TH, COUNTER |
1 |
1512- |
|
MSB5M |
Z=55 |
| 325 |
I8-97252 668-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.41 |
| 480 |
I8-97253 123-1 |
|
WASHER, THRUST, 6TH |
1 |
1512- |
|
MYY6S |
|
| 531 |
I8-97368 343-0 |
|
RING, BLOCK, REV |
1 |
1512- |
|
MYY6S |
Z=45 |
| 504 |
I8-97241 312-1 |
|
RING, INSIDE, LOW & REV |
1 |
1512- |
|
MYY5T |
|
| 325 |
I8-97252 666-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.29 |
| 313 |
I8-98189 748-0 |
|
BEARING, NEEDLE, LOW GEAR |
1 |
1512- |
|
MSB5M |
|
| 185 |
I9-09180 045-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
ID=41.5 |
| 396 |
I8-97253 110-0 |
|
BEARING, NEEDLE, MAINSHAFT |
4 |
1512- |
|
MYY6S |
(B) |
| 525 |
I8-97309 532-0 |
|
RING, BLOCK, TOP & 4TH, OD |
2 |
1512- |
|
MYY5T |
|
| 36 |
I8-98180 093-1 |
|
GEAR, 3RD, MAINSHAFT |
1 |
1512- |
|
MSB5M |
Z=31 |
| 396 |
I8-98189 970-0 |
|
BEARING, NEEDLE, MAINSHAFT |
1 |
1512- |
|
MSB5S |
(A) |
| 132 |
I8-98189 378-0 |
|
SHAFT, REV |
1 |
1512- |
|
MSB5M |
|
| 423 |
I8-97367 022-0 |
|
SLEEVE & HUB ASM, 6TH |
1 |
1512- |
|
MYY5T |
|
| 517 |
I8-97252 935-0 |
|
BALL, SYNCHRO, INDEX |
6 |
1512- |
|
MYY5T |
|
| 325 |
I8-97252 670-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.53 |
| 84 |
I5-09800 062-A |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5M |
|
| 82 |
I8-97368 837-0 |
|
SHAFT, MAIN, TRANS |
1 |
1512- |
|
MSB5M |
Z=27-40-37-27 |
| 132 |
I8-97252 655-0 |
|
SHAFT, REV |
1 |
1512- |
|
MYY5T |
|
| 405 |
I8-98189 965-0 |
|
INSERT, SYN, LOW & 2ND |
3 |
1512- |
|
MSB5S |
|
| 314 |
I8-98189 749-0 |
|
BEARING, NEEDLE, REV GEAR |
1 |
1512- |
|
MSB5M |
|
| 84 |
I6-09800 062-0 |
|
BEARING, COUNTER SHAFT, FRT |
1 |
1512- |
|
MSB5S |
(IADG) |
| 325 |
I8-97252 673-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY6S |
ID=62.7 T=2.71 |
| 82 |
I8-97253 117-3 |
|
SHAFT, MAIN, TRANS |
1 |
1512- |
|
MYY5T |
Z=28-42-42-21 |
| 172 |
I8-94402 407-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.85 |
| 1 |
I8-98387 238-0 |
|
SHAFT, TOP GEAR,TRANS |
1 |
1801- |
|
MYY6S |
Z=26 |
| 62 |
I8-98189 962-0 |
|
SPRING, INSERT, REV & 5TH |
2 |
1512- |
|
MSB5M |
|
| 325 |
I8-97252 667-0 |
|
SHIM, COUNTER SHAFT BRG |
1 |
1512- |
|
MYY5T |
ID=62.7 T=2.35 |
| 180 |
I1-09588 177-0 |
|
RING, SNAP, CLUSTER GEAR |
1 |
1512- |
|
MSB5S |
(A) ID=32.2 |
| 268 |
I8-97252 684-1 |
|
PLATE, ANTI LASH, COUNTER |
1 |
1512- |
|
MYY6S |
|
| 172 |
I8-94402 406-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5S |
T=1.80 |
| 505 |
I8-97253 119-2 |
|
COLLAR, 3RD & REV |
2 |
1512- |
|
MYY6S |
|
| 288 |
I8-97252 942-0 |
|
SPACER, BRG, MAINSHAFT |
1 |
1512- |
|
MYY6S |
|
| 323 |
I8-94448 202-2 |
|
INSERT |
3 |
1512- |
|
MYY6S |
|
| 287 |
I8-98190 445-0 |
|
PIN, COUNTER GEAR |
3 |
1512- |
|
MSB5M |
|
| 511 |
I8-97254 767-0 |
|
RING, SNAP, ANTI LASH PLATE |
1 |
1512- |
|
MYY5T |
|
| 300 |
I8-97254 728-0 |
|
RING, SNAP, COUNTER SHAFT, RR END |
1 |
1512- |
|
MYY6S |
ID=30.7 T=1.8 |
| 287 |
I8-98190 445-0 |
|
PIN, COUNTER GEAR |
3 |
1512- |
|
MSB5S |
|
| 510 |
I9-08160 825-0 |
|
PIN, STRAIGHT, ANTI LASH |
3 |
1512- |
|
MYY6S |
|
| 526 |
I8-97253 112-0 |
|
BEARING, NEEDLE, 4TH & 5TH |
1 |
1512- |
|
MYY6S |
Z=45 |
| 508 |
I6-97309 532-0 |
|
RING, BLOCK, 6TH |
1 |
1512- |
|
MYY6S |
(IADG) Z=45 |
| 184 |
I8-98189 350-0 |
|
SPRING, CLUSTER GEAR |
1 |
1512- |
|
MSB5M |
|
| 172 |
I8-94402 406-0 |
|
RING, SNAP, CLU HUB |
1 |
1512- |
|
MSB5M |
T=1.80 |
| 260 |
I8-97360 410-0 |
|
NUT, MAINSHAFT END |
1 |
1512- |
|
MYY6S |
M27 H=25 |
