2-30 | GEAR SHIFTER AND QUADRANT BOX
ELF
NLR NMR
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 535 | I8-98015 113-0 | SPRING, LEVER | 1 | 1512- | MYY5T | (A) | ||
| 174 | I8-98190 419-0 | SPRING, REV | 1 | 1512- | MSB5S | |||
| 36 | I8-97241 329-1 | BLOCK, SHIFT, 4TH & 5TH | 1 | 1512- | MYY5T | (A) | ||
| 346 | I8-97309 855-0 | HOSE, AIR | 1 | 1512- | MYY5T | |||
| 551 | I1-09748 032-0 | PIN, SPRING | 1 | 1512- | MYY5T | (A) L=25 OD=5 | ||
| 167 | I8-98190 276-0 | LEVER, SELECT, EXTERNAL | 1 | 1512- | MSB5S | |||
| 175 | I8-98190 338-0 | RING, STOPPER, SHIFT LEVER | 1 | 1512- | MSB5S | EXHAUST BRAKE | ||
| 49 | I8-97258 716-0 | ARM, SHIFT, 4TH & 5TH | 1 | 1512- | MYY5T | |||
| 130 | I8-97306 647-0 | LEVER, SHIFT, INTERNAL | 1 | 1512- | MYY5T | |||
| 398 | I8-98190 417-0 | SWITCH, REV LAMP | 1 | 1512- | MSB5S | |||
| 104 | I0-92001 416-0 | PLUG , PLATE | 1 | 1512- | MSB5S | OD=16 | ||
| 178 | I9-09567 113-0 | GASKET, PLUG | 1 | 1512- | MYY6S | |||
| 30 | I8-98189 971-0 | PIN, INTER LK | 1 | 1512- | MSB5M | |||
| 142 | I8-97365 376-0 | BOLT, QUAD BOX | 4 | 1512- | MYY5T | (C) M8X22 | ||
| 167 | I8-98039 434-0 | LEVER, SELECT, EXTERNAL | 1 | 1512- | MYY5T | |||
| 163 | I8-98190 302-0 | LEVER, SELECT, INTERNAL | 1 | 1512- | MSB5S | |||
| 164 | I6-97304 068-0 | SEAL, OIL, QUAD BOX | 2 | 1512- | MSB5S | (IADG) OD=27 | ||
| 98 | I8-98188 590-0 | ROD, SHIFT, TOP & 3RD | 1 | 1512- | MSB5S | |||
| 158 | I8-97367 984-1 | CLIP, HARNESS | 1 | 1512- | MSB5M | (A) ID=12 VINYL CHLORIDE | ||
| 192 | I8-97305 661-0 | WASHER, PL | 2 | 1512- | MYY6S | |||
| 551 | I1-09748 032-0 | PIN, SPRING | 1 | 1512- | MYY6S | (A) L=25 OD=5 | ||
| 183 | I8-98190 432-0 | PLUG, SCREW, OIL FILTER | 1 | 1512- | MSB5S | M18 | ||
| 273 | I8-97103 142-0 | PIN, SPR, STOPPER | 1 | 1512- | MYY5T | ID=4.2 L=25 | ||
| 130 | I8-97306 647-0 | LEVER, SHIFT, INTERNAL | 1 | 1512- | MYY6S | |||
| 625 | I8-97362 741-0 | ROD, GEARSHIFT, LOW, REV, 2ND & 3R | 1 | 1512- | MYY6S | |||
| 381 | I0-28650 616-0 | BOLT | 1 | 1512- | MYY6S | M6X16 | ||
| 99 | I8-98190 301-0 | ARM, SHIFT, 4TH & 3RD | 1 | 1512- | MSB5M | |||
| 631 | I8-97305 666-0 | STOPPER, SPRING | 1 | 1512- | MYY5T | |||
| 234 | I0-91800 618-0 | RING, SNAP | 1 | 1512- | MYY6S | ID=16.5 | ||
| 128 | I8-97305 725-0 | LEVER, SHIFT, EXTERNAL | 1 | 1512- | MYY5T | |||
| 180 | I8-98190 423-0 | WASHER, REV STOP SPRING | 1 | 1512- | MSB5M | |||
| 142 | I8-97365 376-0 | BOLT, QUAD BOX | 4 | 1512- | MYY6S | (C) M8X22 | ||
| 31 | I8-98190 300-0 | ARM, SHIFT , LOW & 2ND | 1 | 1512- | MSB5M | |||
| 36 | I8-97241 330-0 | BLOCK, SHIFT, 4TH & 5TH | 1 | 1512- | MYY5T | (B) | ||
| 158 | I5-09707 031-1 | CLIP, HARNESS | 1 | 1512- | MSB5M | (B) L= 140 | ||
| 273 | I8-97103 142-0 | PIN, SPR, STOPPER | 1 | 1512- | MYY6S | ID=4.2 L=25 | ||
| 102 | I8-98188 588-0 | BLOCK, SHIFT, 3RD & 4TH | 1 | 1512- | MSB5S | |||
| 635 | I8-97380 892-0 | PLUG, DETENT | 1 | 1512- | MYY5T | |||
| 28 | I9-00097 010-0 | BALL, INTER LK | 7 | 1512- | MSB5M | |||
| 163 | I8-97305 663-0 | LEVER, SELECT, INTERNAL | 1 | 1512- | MYY6S | |||
| 483 | I8-97241 326-2 | BUSHING, SHIFT ARM | 2 | 1512- | MYY6S | |||
| 108 | I8-98188 917-0 | SPRING, LOCK BALL | 3 | 1512- | MSB5S | OD=6.8 L=31.6 | ||
| 100 | I8-98188 592-0 | ROD, SHIFT, REV & 5TH | 1 | 1512- | MSB5M | |||
| 535 | I8-97305 659-0 | SPRING, LEVER | 1 | 1807- | MYY6S | (A) 4HL1-TC | ||
| 234 | I8-94460 357-0 | RING, SNAP | 1 | 1512- | MYY5T | ID=12 | ||
| 104 | I0-92001 416-0 | PLUG , PLATE | 1 | 1512- | MSB5M | OD=16 | ||
| 33 | I8-98188 591-0 | ROD, SHIFT, LOW & 2ND | 1 | 1512- | MSB5M | |||
| 294 | I8-97363 225-0 | SEAL, OIL, SELECT | 1 | 1512- | MYY6S | (A) | ||
| 103 | I8-98188 587-0 | BLOCK, SHIFT, REV TO OD | 1 | 1512- | MSB5S | |||
| 180 | I8-98190 423-0 | WASHER, REV STOP SPRING | 1 | 1512- | MSB5S | |||
| 629 | I8-97237 107-1 | BRIDGE, LEVER | 1 | 1512- | MYY6S | |||
| 164 | I8-97304 068-0 | SEAL, OIL, QUAD BOX | 2 | 1512- | MSB5S | OD=27 | ||
| 294 | I8-97305 662-0 | SEAL, OIL, SELECT | 1 | 1512- | MYY5T | (B) | ||
| 181 | I8-97367 327-0 | WASHER, PL, SELECT LEVER | 1 | 1512- | MYY6S | |||
| 624 | I8-97241 317-3 | PLATE, INTERLOCK | 1 | 1512- | MYY6S | |||
| 142 | I0-28050 830-0 | BOLT, QUAD BOX | 2 | 1512- | MSB5S | (B) M8X30 | ||
| 166 | I1-09748 032-0 | PIN, SPR, SELECT LEVER | 1 | 1512- | MSB5M | L=25 OD=5 | ||
| 171 | I8-98324 878-0 | SWITCH, NEUTRAL | 1 | 1512- | MYY5T | |||
| 391 | I8-97300 273-1 | PLUG, S WHOLE | 1 | 1512- | MYY5T | |||
| 171 | I8-98190 415-0 | SWITCH, NEUTRAL | 1 | 1512- | MSB5M | |||
| 346 | I8-97309 855-0 | HOSE, AIR | 1 | 1512- | MYY6S | |||
| 163 | I8-97305 663-0 | LEVER, SELECT, INTERNAL | 1 | 1512- | MYY5T | |||
| 157 | I8-98190 265-0 | BOX, QUAD, TRANS | 1 | 1512- | MSB5M | |||
| 176 | I1-09748 031-0 | PIN, SPR, STOPPER | 1 | 1512- | MSB5S | EXC. EXHAUST BRAKE L=30 OD=4 | ||
| 535 | I8-97305 659-0 | SPRING, LEVER | 1 | 1512- | MYY5T | (A) | ||
| 183 | I8-98190 432-0 | PLUG, SCREW, OIL FILTER | 1 | 1512- | MSB5M | M18 | ||
| 49 | I8-97362 732-1 | ARM, SHIFT, 4TH & 5TH | 1 | 1512- | MYY6S | |||
| 633 | I8-97362 743-0 | ROD, GEARSHIFT, 4TH, 5TH | 1 | 1512- | MYY5T | |||
| 25 | I8-98255 926-1 | ARM, SHIFT , 2ND & 3RD | 1 | 1512- | MYY5T | |||
| 398 | I8-98242 173-1 | SWITCH, REV LAMP | 1 | 1512- | MYY5T | |||
| 167 | I8-98190 276-0 | LEVER, SELECT, EXTERNAL | 1 | 1512- | MSB5M | |||
| 554 | I8-97365 378-0 | STUD, CONT BOX | 2 | 1512- | MYY6S | M8X15,M8X25 L=49 | ||
| 627 | I8-98119 293-0 | ROD, GEARSHIFT, 6TH SUB | 1 | 1512- | MYY6S | |||
| 166 | I1-09748 032-0 | PIN, SPR, SELECT LEVER | 1 | 1512- | MSB5S | L=25 OD=5 | ||
| 294 | I8-97305 662-0 | SEAL, OIL, SELECT | 1 | 1512- | MYY6S | (B) | ||
| 175 | I8-98190 338-0 | RING, STOPPER, SHIFT LEVER | 1 | 1512- | MSB5M | EXHAUST BRAKE | ||
| 99 | I8-98190 301-0 | ARM, SHIFT, 4TH & 3RD | 1 | 1512- | MSB5S | |||
| 184 | I8-98189 969-0 | GASKET, FILLER PLUG | 1 | 1512- | MSB5S | ID=15.5 | ||
| 551 | I8-97241 340-0 | PIN, SPRING | 1 | 1512- | MYY6S | (C) L=20 | ||
| 535 | I8-97323 772-0 | SPRING, LEVER | 1 | 1512- | MYY5T | (B) | ||
| 645 | I8-98019 536-0 | DETENT ASM | 1 | 1512- | MYY6S | |||
| 163 | I8-98190 302-0 | LEVER, SELECT, INTERNAL | 1 | 1512- | MSB5M | |||
| 133 | I8-97305 667-0 | SEAT, SPR | 1 | 1512- | MYY5T | |||
| 559 | I8-97358 318-0 | PIPE, BREATHER | 1 | 1512- | MYY5T | |||
| 6 | I8-97241 344-0 | LEVER, RELAY | 1 | 1512- | MYY5T | |||
| 398 | I8-98256 418-0 | SWITCH, REV LAMP | 1 | 1807- | MYY6S | 4HL1-TC | ||
| 559 | I8-97358 318-0 | PIPE, BREATHER | 1 | 1512- | MYY6S | |||
| 634 | I8-97241 327-1 | BLOCK, SHIFT, LOW, REV | 1 | 1512- | MYY5T | |||
| 102 | I8-98188 588-0 | BLOCK, SHIFT, 3RD & 4TH | 1 | 1512- | MSB5M | |||
| 101 | I8-98190 303-0 | ARM, SHIFT, REV & 5TH | 1 | 1512- | MSB5M | |||
| 192 | I8-97305 661-0 | WASHER, PL | 1 | 1512- | MYY5T | |||
| 171 | I8-98324 878-0 | SWITCH, NEUTRAL | 1 | 1512- | MYY6S | |||
| 50 | I8-97241 325-1 | ARM, SHIFT, 6TH | 1 | 1512- | MYY6S | |||
| 262 | I8-98240 999-2 | BOX ASM, SHIFT CONT | 1 | 1512- | MYY5T | |||
| 130 | I8-98190 340-0 | LEVER, SHIFT, INTERNAL | 1 | 1512- | MSB5M | |||
| 630 | I8-98019 536-0 | DETENT ASM | 3 | 1512- | MYY5T | |||
| 51 | I8-98188 589-0 | BLOCK, SHIFT, 1ST & 2ND | 1 | 1512- | MSB5M | |||
| 181 | I8-97367 327-0 | WASHER, PL, SELECT LEVER | 1 | 1512- | MYY5T | |||
| 535 | I8-97305 660-0 | SPRING, LEVER | 1 | 1512- | MYY6S | (B) | ||
| 165 | I8-98190 282-0 | LEVER, SHIFT | 1 | 1512- | MSB5M | |||
| 628 | I8-97241 327-1 | BLOCK, SHIFT, LOW, REV & 6TH | 2 | 1512- | MYY6S | |||
| 195 | I8-97365 375-0 | BOLT | 2 | 1512- | MYY5T | M10X28 REAMER | ||
| 142 | I0-28050 825-0 | BOLT, QUAD BOX | 8 | 1512- | MSB5S | (A) M8X25 | ||
| 551 | I8-97241 340-0 | PIN, SPRING | 1 | 1512- | MYY5T | (C) L=20 | ||
| 372 | I8-97241 343-0 | LEVER, RELAY, 6TH | 1 | 1512- | MYY6S | |||
| 398 | I8-98242 173-1 | SWITCH, REV LAMP | 1 | 1512- | MYY6S | 4HG1-T | ||
| 100 | I8-98188 592-0 | ROD, SHIFT, REV & 5TH | 1 | 1512- | MSB5S | |||
| 174 | I8-98190 419-0 | SPRING, REV | 1 | 1512- | MSB5M | |||
| 164 | I8-97304 068-0 | SEAL, OIL, QUAD BOX | 2 | 1512- | MSB5M | OD=27 | ||
| 142 | I0-28050 825-0 | BOLT, QUAD BOX | 8 | 1512- | MSB5M | (A) M8X25 | ||
| 626 | I8-97366 024-1 | ROD, GEARSHIFT, 4TH, 5TH & 6TH | 1 | 1512- | MYY6S | |||
| 167 | I8-98039 434-0 | LEVER, SELECT, EXTERNAL | 1 | 1512- | MYY6S | |||
| 51 | I8-98188 589-0 | BLOCK, SHIFT, 1ST & 2ND | 1 | 1512- | MSB5S | |||
| 148 | I8-98189 273-0 | GASKET, QUAD BOX | 1 | 1512- | MSB5S | |||
| 157 | I8-98190 265-0 | BOX, QUAD, TRANS | 1 | 1512- | MSB5S | EXHAUST BRAKE | ||
| 33 | I8-98188 591-0 | ROD, SHIFT, LOW & 2ND | 1 | 1512- | MSB5S | |||
| 31 | I8-98190 300-0 | ARM, SHIFT , LOW & 2ND | 1 | 1512- | MSB5S | |||
| 158 | I5-09707 031-1 | CLIP, HARNESS | 1 | 1512- | MSB5S | (B) L= 140 | ||
| 630 | I8-98019 536-0 | DETENT ASM | 4 | 1512- | MYY6S | |||
| 548 | I8-97031 674-0 | CLIP, HOSE | 1 | 1512- | MYY6S | |||
| 195 | I8-97365 375-0 | BOLT | 2 | 1512- | MYY6S | M10X28 REAMER | ||
| 130 | I8-98190 340-0 | LEVER, SHIFT, INTERNAL | 1 | 1512- | MSB5S | |||
| 178 | I9-09567 113-0 | GASKET, PLUG | 1 | 1512- | MYY5T | |||
| 551 | I8-97011 596-2 | PIN, SPRING | 4 | 1512- | MYY6S | (B) L=32 | ||
| 128 | I8-97363 226-0 | LEVER, SHIFT, EXTERNAL | 1 | 1512- | MYY6S | |||
| 30 | I8-98189 971-0 | PIN, INTER LK | 1 | 1512- | MSB5S | |||
| 108 | I8-98188 917-0 | SPRING, LOCK BALL | 3 | 1512- | MSB5M | OD=6.8 L=31.6 | ||
| 294 | I8-97363 225-0 | SEAL, OIL, SELECT | 1 | 1512- | MYY5T | (A) | ||
| 129 | I1-09748 031-0 | PIN, SPR, SHIFT | 1 | 1512- | MYY6S | L=30 OD=4 | ||
| 103 | I8-98188 587-0 | BLOCK, SHIFT, REV TO OD | 1 | 1512- | MSB5M | |||
| 391 | I8-97300 273-1 | PLUG, S WHOLE | 1 | 1512- | MYY6S | |||
| 398 | I8-98190 417-0 | SWITCH, REV LAMP | 1 | 1512- | MSB5M | |||
| 158 | I8-97367 984-1 | CLIP, HARNESS | 1 | 1512- | MSB5S | (A) ID=12 VINYL CHLORIDE | ||
| 91 | I1-09748 032-0 | PIN, SPR, SHIFT ARM | 6 | 1512- | MSB5S | L=25 OD=5 | ||
| 483 | I8-97241 326-2 | BUSHING, SHIFT ARM | 2 | 1512- | MYY5T | |||
| 1 | I8-97241 320-2 | ARM, SHIFT, 1ST & REV | 1 | 1512- | MYY5T | |||
| 551 | I8-97011 596-2 | PIN, SPRING | 4 | 1512- | MYY5T | (B) L=32 | ||
| 631 | I8-97305 666-0 | STOPPER, SPRING | 1 | 1512- | MYY6S | |||
| 157 | I8-98190 266-0 | BOX, QUAD, TRANS | 1 | 1512- | MSB5S | EXC. EXHAUST BRAKE | ||
| 629 | I8-97241 345-1 | BRIDGE, LEVER | 1 | 1512- | MYY6S | |||
| 91 | I1-09748 032-0 | PIN, SPR, SHIFT ARM | 6 | 1512- | MSB5M | L=25 OD=5 | ||
| 1 | I8-97241 320-2 | ARM, SHIFT, 1ST & REV | 1 | 1512- | MYY6S | |||
| 171 | I8-98190 415-0 | SWITCH, NEUTRAL | 1 | 1512- | MSB5S | |||
| 554 | I8-97365 378-0 | STUD, CONT BOX | 2 | 1512- | MYY5T | M8X15,M8X25 L=49 | ||
| 142 | I0-28050 830-0 | BOLT, QUAD BOX | 2 | 1512- | MSB5M | (B) M8X30 | ||
| 535 | I8-98015 113-0 | SPRING, LEVER | 1 | 1512- | MYY6S | (A) 4HG1-T | ||
| 176 | I1-09748 031-0 | PIN, SPR, STOPPER | 1 | 1512- | MSB5M | EXC. EXHAUST BRAKE L=30 OD=4 | ||
| 98 | I8-98188 590-0 | ROD, SHIFT, TOP & 3RD | 1 | 1512- | MSB5M | |||
| 629 | I8-97237 107-1 | BRIDGE, LEVER | 1 | 1512- | MYY5T | |||
| 184 | I8-98189 969-0 | GASKET, FILLER PLUG | 1 | 1512- | MSB5M | ID=15.5 | ||
| 262 | I8-98240 992-2 | BOX ASM, SHIFT CONT | 1 | 1512- | MYY6S | |||
| 129 | I1-09748 031-0 | PIN, SPR, SHIFT | 1 | 1512- | MYY5T | L=30 OD=4 | ||
| 645 | I8-98019 536-0 | DETENT ASM | 1 | 1512- | MYY5T | |||
| 101 | I8-98190 303-0 | ARM, SHIFT, REV & 5TH | 1 | 1512- | MSB5S | |||
| 624 | I8-97241 317-3 | PLATE, INTERLOCK | 1 | 1512- | MYY5T | |||
| 25 | I8-98255 926-1 | ARM, SHIFT , 2ND & 3RD | 1 | 1512- | MYY6S | |||
| 381 | I0-28650 616-0 | BOLT | 1 | 1512- | MYY5T | M6X16 | ||
| 168 | I8-98190 433-0 | WASHER, LK, SELECT LEVER | 1 | 1512- | MSB5M | |||
| 625 | I8-97362 741-0 | ROD, GEARSHIFT, LOW, REV, 2ND & 3R | 1 | 1512- | MYY5T | |||
| 165 | I8-98190 282-0 | LEVER, SHIFT | 1 | 1512- | MSB5S | |||
| 148 | I8-98189 273-0 | GASKET, QUAD BOX | 1 | 1512- | MSB5M | |||
| 28 | I9-00097 010-0 | BALL, INTER LK | 7 | 1512- | MSB5S | |||
| 164 | I6-97304 068-0 | SEAL, OIL, QUAD BOX | 2 | 1512- | MSB5M | (IADG) OD=27 | ||
| 168 | I8-98190 433-0 | WASHER, LK, SELECT LEVER | 1 | 1512- | MSB5S | |||
| 165 | I8-98190 273-0 | LEVER, SHIFT | 1 | 1512- | MSB5S | EXC. EXHAUST BRAKE |
