| Key |
PART NO |
ITC |
DESCRIPTION |
QTY |
APP DATE |
LR |
MODEL |
REMARKS |
|
|
|
|
|
|
|
|
|
| 141 |
I8-98244 644-0 |
|
COVER, RAD GRILLE |
1 |
1512- |
|
ALL |
|
| 1 |
I8-97429 372-B |
|
GRILLE, RAD |
1 |
1512- |
|
ALL |
BLACK |
| 11 |
I8-97581 651-2 |
|
CLIP, RAD GRILLE |
2 |
1512- |
|
ALL |
(A) |
| 179 |
I8-94291 927-0 |
|
RETAINER, GRILLE, RAD |
1 |
1512- |
|
ALL |
D=7X7 L=7.5 |
| 1 |
I6-97429 372-0 |
|
GRILLE, RAD |
1 |
1512- |
|
ALL |
(IADG) |
| 9 |
I0-74165 516-0 |
|
SCREW, RAD GRILLE |
1 |
1512- |
|
ALL |
M5X16 TAPPING |
| 11 |
I8-98025 698-0 |
|
CLIP, RAD GRILLE |
5 |
1512- |
|
ALL |
(B) |
| 141 |
I8-98244 643-0 |
|
COVER, RAD GRILLE |
1 |
1512- |
|
ALL |
|
| 133 |
I0-72180 512-0 |
|
SCREW, COVER |
10 |
1512- |
|
ALL |
M5X12 |
