| 004 |
I7-55189 835-0 |
|
LINER; C/BL |
4 |
2312- |
|
NMR81 |
OD GRADE=1X,ID GRADE=NON |
| 002 |
I5-87818 145-1 |
|
LINER SET; ENG CYL |
4 |
2203- |
|
NMR81 |
GRADE=3X |
| 013 |
I8-94399 688-1 |
|
DOWEL; C/BL TO HD |
2 |
2203- |
|
NMR81 |
OD=18.15 |
| 051 |
I8-94336 292-0 |
|
GASKET; OIL PRESS WARNING SW, C/BL |
1 |
2203- |
|
NLR85 |
ID=8.2 OD=18.0 |
| 136 |
I8-98091 566-0 |
|
BUSHING; DRIVE SHAFT,OIL PUMP |
2 |
2203- |
|
NMR81 |
|
| 001 |
I8-98290 980-1 |
|
BLOCK ASM; CYL |
1 |
2203- |
|
NLR85 |
|
| 035 |
I8-94173 412-0 |
|
GASKET; RELIEF VLV |
1 |
2203- |
|
NMR81 |
ID=23.3 |
| 061 |
I8-94483 674-0 |
|
PIN; STRAIGHT |
4 |
2203- |
|
NMR81 |
L=22 |
| 004 |
I8-98014 043-0 |
|
LINER; C/BL |
4 |
2203- |
|
NMR81 |
OD GRADE=3X,ID GRADE=NON |
| 015 |
I8-98322 217-0 |
|
PLUG; OIL GALLERY |
4 |
2203- |
|
NLR85 |
PT1/8 |
| 070 |
I8-97096 824-0 |
|
CUP; SEALING,FRT & RR |
4 |
2203- |
|
NMR81 |
OD=40 |
| 045 |
I8-97176 230-0 |
|
SWITCH; OIL PRESSURE |
1 |
2203- |
|
NLR85 |
|
| 351 |
I1-09630 083-0 |
|
GASKET; COCK,WATER DRAIN |
1 |
2203- |
|
NMR81 |
ID=10.2 OD=15.2 |
| 061 |
I9-09878 597-0 |
|
PIN; STRAIGHT |
2 |
2203- |
|
NLR85 |
L=31 |
| 023 |
I1-09600 016-0 |
|
CUP; SEALING,C/BL FRT & RR |
1 |
2203- |
|
NMR81 |
(B) OD=25 |
| 008 |
I8-97941 068-0 |
|
BOLT; BRG CAP |
10 |
2203- |
|
NLR85 |
M14X89 FLANGE |
| 303 |
I8-98251 345-0 |
|
GASKET; PLUG |
1 |
2203- |
|
NMR81 |
ID=14.2 OD=19.2 |
| 017 |
I8-97176 230-0 |
|
SWITCH; OIL PRESSURE |
1 |
2203- |
|
ALL |
|
| 400 |
I8-97369 404-0 |
|
GASKET; CRANKSHAFT POSITION SENSOR |
1 |
2203- |
|
NLR85 |
ID=14.2 OD=18.8 |
| 021 |
I5-09600 013-0 |
|
CUP; SEALING,RR |
1 |
2203- |
|
NLR85 |
(C) OD=12.3 |
| 401 |
I0-28050 616-0 |
|
BOLT; SENSOR |
1 |
2203- |
|
NLR85 |
M6X16 FLANGE |
| 132 |
I8-97329 618-0 |
|
VALVE; CHECK,OIL |
4 |
2203- |
|
NMR81 |
M10X18.5 |
| 213 |
I9-09571 410-0 |
|
GASKET; NIPPLE,OIL FEED |
1 |
2203- |
|
NLR85 |
ID=10.2 OD=16.0 |
| 211 |
I0-28050 880-0 |
|
BOLT; CRANKCASE |
5 |
2203- |
|
NLR85 |
(B) M8X80 FLANGE |
| 097 |
I5-11129 006-0 |
|
CUP; SEALING |
1 |
2203- |
|
ALL |
(A) OD=16 |
| 007 |
I8-97352 537-0 |
|
PLUG; WATER DRAIN |
1 |
2203- |
|
NMR81 |
M10X10 |
| 097 |
I8-97209 609-0 |
|
CUP; SEALING |
3 |
2203- |
|
NMR81 |
(B) OD=22 |
| 056 |
I8-97179 086-2 |
|
JET; OIL,PISTON COOLING |
4 |
2203- |
|
NMR81 |
|
| 399 |
I8-97312 108-1 |
|
SENSOR; CRANKSHAFT POSITION |
1 |
2203- |
|
NLR85 |
|
| 083 |
I9-08161 032-0 |
|
PIN; FLYWHEEL HSG |
1 |
2203- |
|
NLR85 |
OD=10 L=32 |
| 103 |
I8-94469 596-0 |
|
NIPPLE; OIL FEED |
1 |
2203-2302 |
|
NLR85 |
|
| 052 |
I8-97657 692-0 |
|
NIPPLE; OIL PRESS WARNING SW, C/BL |
1 |
2203- |
|
NLR85 |
|
| 021 |
I5-11219 018-0 |
|
CUP; SEALING,RR |
1 |
2203- |
|
NLR85 |
(B) OD=36 |
| 352 |
I9-09566 109-0 |
|
GASKET; C/BL TO CRANKCASE |
1 |
2203- |
|
NLR85 |
ID=8.8 |
| 335 |
I8-97658 185-0 |
|
PLUG; C/BL,SIDE |
1 |
2203- |
|
NMR81 |
(A) M14X16.5 |
| 103 |
I8-97268 398-0 |
|
NIPPLE; OIL FEED |
1 |
2303- |
|
NLR85 |
|
| 034 |
I8-97328 859-0 |
|
VALVE; OIL RELIEF |
1 |
2203- |
|
NMR81 |
|
| 211 |
I0-28650 825-0 |
|
BOLT; CRANKCASE |
9 |
2203- |
|
NLR85 |
(A) M8X25 FLANGE |
| 212 |
I8-97135 423-0 |
|
PIN; CRANKCASE |
2 |
2203- |
|
ALL |
OD=10 L=20 |
| 004 |
I7-55189 836-0 |
|
LINER; C/BL |
4 |
2312- |
|
NMR81 |
OD GRADE=3X,ID GRADE=NON |
| 406 |
I5-09605 005-0 |
|
PLUG; CRANK CASE |
2 |
2203- |
|
NMR81 |
PT3/8 T=12 |
| 023 |
I5-11219 018-0 |
|
CUP; SEALING,C/BL FRT & RR |
2 |
2203- |
|
NLR85 |
(D) OD=36 |
| 023 |
I5-11219 008-0 |
|
CUP; SEALING,C/BL FRT & RR |
2 |
2203- |
|
NLR85 |
(B) OD=18 |
| 089 |
I9-11129 128-0 |
|
CUP; SEALING,OIL GALLERY |
3 |
2203- |
|
NMR81 |
OD=20 |
| 002 |
I5-87818 144-1 |
|
LINER SET; ENG CYL |
4 |
2203- |
|
NMR81 |
GRADE=1X |
| 023 |
I1-09600 012-2 |
|
CUP; SEALING,C/BL FRT & RR |
4 |
2203- |
|
NLR85 |
(C) OD=32 |
| 004 |
I8-98014 042-0 |
|
LINER; C/BL |
4 |
2203-2311 |
|
NMR81 |
OD GRADE=1X,ID GRADE=NON |
| 001 |
I8-98204 537-1 |
|
BLOCK ASM; CYL |
1 |
2203- |
|
NMR81 |
|
| 007 |
I9-09664 001-0 |
|
PLUG; WATER DRAIN |
1 |
2203- |
|
NLR85 |
PT1/4 |
| 021 |
I5-11219 017-0 |
|
CUP; SEALING,RR |
1 |
2203- |
|
NLR85 |
(A) OD=38 |
| 070 |
I5-11129 006-0 |
|
CUP; SEALING,FRT & RR |
6 |
2203- |
|
NLR85 |
OD=16 |
| 335 |
I8-98038 403-0 |
|
PLUG; C/BL,SIDE |
1 |
2203- |
|
NMR81 |
(B) M14X18 |
| 038 |
I8-97135 423-0 |
|
PIN; TIMING GEAR CASE |
2 |
2203- |
|
NLR85 |
OD=10 L=20 |
| 023 |
I8-97036 550-1 |
|
CUP; SEALING,C/BL FRT & RR |
3 |
2203- |
|
ALL |
(A) OD=45 |
| 013 |
I8-94453 344-0 |
|
DOWEL; C/BL TO HD |
2 |
2203- |
|
NLR85 |
OD=14 |
| 211 |
I8-94399 553-2 |
|
BOLT; CRANKCASE |
17 |
2203- |
|
NMR81 |
(A) M10X82 FLANGE |
| 211 |
I8-97077 638-0 |
|
BOLT; CRANKCASE |
10 |
2203- |
|
NMR81 |
(B) M14X115 FLANGE |
