0-60 | ENGINE ELECTRICAL CONTROL PARTS
ELF
NLR85 NMR81 E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 004 | I8-97212 602-0 | BOLT; STARTER | 2 | 2203- | ALL | M10X15,M14X75 L=103 | ||
| 796 | I8-98009 418-0 | SENSOR; MAP | 1 | 2203- | ALL | |||
| 002 | I8-98268 791-2 | GENERATOR ASM | 1 | 2203- | NLR85 | 24V 50A | ||
| 606 | I8-98111 773-4 | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (A) | ||
| 613 | I8-97847 293-0 | CONTROL UNIT; ENG | 1 | 2203- | NMR81 | EXC. INTAKE SHUTTER | ||
| 395 | I0-91180 106-0 | NUT; BRKT FIX | 2 | 2203- | ALL | M6 FLANGE | ||
| 766 | I8-97369 404-0 | GASKET; SENSOR | 1 | 2203- | NLR85 | ID=14.2 OD=18.8 | ||
| 420 | I8-98328 294-1 | BRACKET; HARNESS | 1 | 2203- | NLR85 | (B) | ||
| 748 | I0-28650 825-0 | BOLT; CONT UNIT | 4 | 2203- | ALL | (B) M8X25 FLANGE | ||
| 301 | I8-97357 613-0 | RESISTOR; DROPPING | 1 | 2203- | NLR85 | |||
| 613 | I8-98356 783-0 | CONTROL UNIT; ENG | 1 | 2203- | NLR85 | INTAKE SHUTTER | ||
| 539 | I0-36230 412-0 | SCREW; SENSOR | 2 | 2203- | ALL | M4X12 W/LK&PL WASHER | ||
| 606 | I8-98119 085-0 | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (B) | ||
| 796 | I8-98009 418-0 | SENSOR; MAP | 1 | 2203- | ALL | |||
| 327 | I8-98019 024-0 | SENSOR; CAMSHAFT POSITION | 1 | 2203- | NLR85 | |||
| 023 | I7-05110 010-A | NUT; GEN | 1 | 2203- | ALL | (B) M10 FLANGE | ||
| 016 | I8-97146 998-0 | BOLT; GEN | 1 | 2203- | NMR81 | M10X133 | ||
| 393 | I8-98018 903-0 | BRACKET; HARNESS TO BODY | 1 | 2203- | NLR85 | (B) | ||
| 002 | I8-98268 791-2 | GENERATOR ASM | 1 | 2203- | NLR85 | 24V 50A | ||
| 046 | I8-97173 947-0 | RELAY; GLOW PLUG | 1 | 2203- | NLR85 | 24V 50A | ||
| 026 | I0-28151 070-0 | BOLT; GEN BRKT | 2 | 2203- | NMR81 | (B) M10X70 FLANGE | ||
| 748 | I0-28050 816-0 | BOLT; CONT UNIT | 4 | 2203- | NLR85 | (A) M8X16 FLANGE | ||
| 748 | I0-28650 825-0 | BOLT; CONT UNIT | 4 | 2203- | ALL | (B) M8X25 FLANGE | ||
| 314 | I8-97667 961-A | BRACKET; DROPPING RESISTOR | 1 | 2203- | NLR85 | |||
| 606 | I8-97696 659-A | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (E) | ||
| 129 | I8-98023 717-0 | SENSOR; GLOW PLUG,THERMO | 1 | 2203- | NLR85 | |||
| 129 | I8-98260 257-0 | SENSOR; GLOW PLUG,THERMO | 1 | 2203- | NMR81 | |||
| 314 | I8-97667 961-A | BRACKET; DROPPING RESISTOR | 1 | 2203- | NLR85 | |||
| 460 | I1-09630 086-0 | GASKET; PLUG | 1 | 2203- | NMR81 | ID=16.2 OD=22 | ||
| 008 | I8-97350 947-0 | SPACER; STARTER | 1 | 2203- | NMR81 | |||
| 606 | I8-98146 323-1 | BRACKET; CONT UNIT | 1 | 2203- | ALL | (C) | ||
| 016 | I8-97146 998-0 | BOLT; GEN | 1 | 2203- | NMR81 | M10X133 | ||
| 766 | I8-97369 404-0 | GASKET; SENSOR | 1 | 2203- | NLR85 | ID=14.2 OD=18.8 | ||
| 129 | I8-98260 257-0 | SENSOR; GLOW PLUG,THERMO | 1 | 2203- | NMR81 | |||
| 897 | I8-98082 814-8 | DRM | 1 | 2203- | ALL | |||
| 327 | I8-98019 024-0 | SENSOR; CAMSHAFT POSITION | 1 | 2203- | NLR85 | |||
| 021 | I8-97075 884-2 | BRACKET; GEN | 1 | 2203- | NMR81 | |||
| 748 | I0-28650 620-0 | BOLT; CONT UNIT | 2 | 2203- | NLR85 | (C) M6X20 FLANGE | ||
| 016 | I0-28056 012-0 | BOLT; GEN | 1 | 2203- | NLR85 | M10X120 FLANGE | ||
| 748 | I0-28050 612-0 | BOLT; CONT UNIT | 4 | 2203- | ALL | (A) M6X12 FLANGE | ||
| 026 | I0-28151 070-0 | BOLT; GEN BRKT | 2 | 2203- | NMR81 | (B) M10X70 FLANGE | ||
| 737 | I0-91610 606-0 | WASHER; PL | 2 | 2203- | NMR81 | ID=6.4 | ||
| 460 | I1-09630 086-0 | GASKET; PLUG | 1 | 2203- | NMR81 | ID=16.2 OD=22 | ||
| 008 | I8-97350 947-0 | SPACER; STARTER | 1 | 2203- | NMR81 | |||
| 606 | I8-98111 773-4 | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (A) | ||
| 539 | I0-36230 412-0 | SCREW; SENSOR | 2 | 2203- | ALL | M4X12 W/LK&PL WASHER | ||
| 587 | I8-98029 921-0 | NUT; RESISTOR & RELAY | 3 | 2203- | NLR85 | M6 W/DISHED WASHER | ||
| 737 | I0-91610 606-0 | WASHER; PL | 2 | 2203- | NMR81 | ID=6.4 | ||
| 862 | I8-97333 832-0 | CONNECTOR; GEN | 1 | 2203- | NMR81 | |||
| 016 | I0-28056 012-0 | BOLT; GEN | 1 | 2203- | NLR85 | M10X120 FLANGE | ||
| 420 | I8-98328 294-1 | BRACKET; HARNESS | 1 | 2203- | NLR85 | (B) | ||
| 023 | I7-05108 010-A | NUT; GEN | 1 | 2203- | ALL | (A) M8 FLANGE | ||
| 748 | I0-28050 612-0 | BOLT; CONT UNIT | 4 | 2203- | ALL | (A) M6X12 FLANGE | ||
| 046 | I8-97173 947-0 | RELAY; GLOW PLUG | 1 | 2203- | NLR85 | 24V 50A | ||
| 002 | I7-55244 736-1 | GENERATOR ASM | 1 | 2203- | NMR81 | 24V 60A | ||
| 393 | I8-98018 903-0 | BRACKET; HARNESS TO BODY | 1 | 2203- | NLR85 | (B) | ||
| 782 | I0-28050 616-0 | BOLT; SENSOR | 1 | 2203- | NLR85 | M6X16 FLANGE | ||
| 606 | I8-98119 085-0 | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (B) | ||
| 606 | I8-98369 699-A | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (B) | ||
| 601 | I7-05108 010-A | NUT; UNIT | 9 | 2203- | ALL | M8 FLANGE | ||
| 001 | I8-98222 018-3 | STARTER ASM | 1 | 2203- | ALL | 24V 4.0KW | ||
| 862 | I8-97333 832-0 | CONNECTOR; GEN | 1 | 2203- | NMR81 | |||
| 002 | I7-55244 736-1 | GENERATOR ASM | 1 | 2203- | NMR81 | 24V 60A | ||
| 129 | I8-98023 717-0 | SENSOR; GLOW PLUG,THERMO | 1 | 2203- | NLR85 | |||
| 001 | I8-98222 018-2 | STARTER ASM | 1 | 2203- | ALL | 24V 4.0KW | ||
| 748 | I0-28650 620-0 | BOLT; CONT UNIT | 2 | 2203- | NLR85 | (C) M6X20 FLANGE | ||
| 010 | I8-97264 947-0 | RELAY; STARTER | 1 | 2203- | ALL | 24V 50A | ||
| 606 | I8-97505 645-0 | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (D) | ||
| 601 | I7-05108 010-A | NUT; UNIT | 7 | 2203- | ALL | M8 FLANGE | ||
| 606 | I8-98369 699-A | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (B) | ||
| 897 | I8-98082 814-7 | DRM | 1 | 2203- | ALL | |||
| 748 | I0-28650 825-0 | BOLT; CONT UNIT | 5 | 2203- | ALL | (B) M8X25 FLANGE | ||
| 587 | I8-98029 921-0 | NUT; RESISTOR & RELAY | 3 | 2203- | NLR85 | M6 W/DISHED WASHER | ||
| 782 | I0-28050 616-0 | BOLT; SENSOR | 1 | 2203- | NLR85 | M6X16 FLANGE | ||
| 023 | I7-05108 010-A | NUT; GEN | 1 | 2203- | ALL | (A) M8 FLANGE | ||
| 613 | I8-97847 293-0 | CONTROL UNIT; ENG | 1 | 2203- | NMR81 | EXC. INTAKE SHUTTER | ||
| 613 | I8-97681 437-0 | CONTROL UNIT; ENG | 1 | 2203- | NMR81 | INTAKE SHUTTER | ||
| 023 | I7-05110 010-A | NUT; GEN | 1 | 2203- | ALL | (B) M10 FLANGE | ||
| 026 | I0-28151 050-0 | BOLT; GEN BRKT | 1 | 2203- | ALL | (A) M10X50 FLANGE | ||
| 010 | I8-97264 947-0 | RELAY; STARTER | 1 | 2203- | ALL | 24V 50A | ||
| 301 | I8-97357 613-0 | RESISTOR; DROPPING | 1 | 2203- | NLR85 | |||
| 395 | I0-91180 106-0 | NUT; BRKT FIX | 2 | 2203- | ALL | M6 FLANGE | ||
| 601 | I7-05108 010-A | NUT; UNIT | 9 | 2203- | ALL | M8 FLANGE | ||
| 393 | I8-97357 140-0 | BRACKET; HARNESS TO BODY | 1 | 2203- | ALL | (A) | ||
| 026 | I0-28151 050-0 | BOLT; GEN BRKT | 1 | 2203- | ALL | (A) M10X50 FLANGE | ||
| 748 | I0-28050 816-0 | BOLT; CONT UNIT | 4 | 2203- | NLR85 | (A) M8X16 FLANGE | ||
| 606 | I8-97505 646-0 | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (A) | ||
| 606 | I8-97505 646-0 | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (A) | ||
| 606 | I8-98146 323-1 | BRACKET; CONT UNIT | 1 | 2203- | ALL | (C) | ||
| 613 | I8-98356 783-0 | CONTROL UNIT; ENG | 1 | 2203- | NLR85 | INTAKE SHUTTER | ||
| 021 | I8-97075 884-2 | BRACKET; GEN | 1 | 2203- | NMR81 | |||
| 420 | I8-98009 094-0 | BRACKET; HARNESS | 1 | 2203- | NLR85 | (A) | ||
| 606 | I8-97505 645-0 | BRACKET; CONT UNIT | 1 | 2203- | NMR81 | (D) | ||
| 393 | I8-97357 140-0 | BRACKET; HARNESS TO BODY | 1 | 2203- | ALL | (A) | ||
| 420 | I8-98009 094-0 | BRACKET; HARNESS | 1 | 2203- | NLR85 | (A) | ||
| 004 | I8-97212 602-0 | BOLT; STARTER | 2 | 2203- | ALL | M10X15,M14X75 L=103 | ||
| 606 | I8-97696 659-A | BRACKET; CONT UNIT | 1 | 2203- | NLR85 | (E) | ||
| 601 | I7-05108 010-A | NUT; UNIT | 7 | 2203- | ALL | M8 FLANGE |
