5-01 | FRAME AND OTHER PARTS
ELF
NLR85 NMR81 E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 188 | I8-97696 775-A | BRACKET; SUPPORT,CTR BRG | 1 | 2203- | NMR81 | (B) NMR81-TSDL | ||
| 345 | I8-97696 748-A | MEMBER; CROSS,5TH | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 101 | I8-98034 042-0 | BRACKET; RR SPR,FRT | 2 | 2203- | NLR85 | (C) NLR85-TL; NLR85-BL | ||
| 063 | I7-53192 063-A | BRACKET; RAD MTG | 1 | 2203- | NLR85 | |||
| 105 | I8-98031 058-0 | BRACKET; RR SPR,RR | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 534 | I8-97695 551-A | BRACKET; BACK BAR | 1 | 2203- | ALL | |||
| 034 | I7-21130 211-A | MEMBER; CROSS,3RD | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 288 | I0-91180 212-0 | NUT; SPARE TIRE BRKT | 4 | 2203- | NMR81 | M12 FLANGE | ||
| 139 | I8-97696 748-A | MEMBER; CROSS,6TH | 1 | 2203- | NMR81 | (B) | ||
| 376 | I9-06751 036-0 | RIVET; FRAME | AR | 2203- | ALL | (K) D10X36 TAPER END | ||
| 376 | I9-06750 830-0 | RIVET; FRAME | AR | 2203- | ALL | (E) D8X30 TAPER END | ||
| 376 | I9-06751 030-0 | RIVET; FRAME | AR | 2203- | ALL | (I) D10X30 TAPER END | ||
| 142 | I8-97695 654-A | BRACKET; FLEX HOSE,BRAKE | 1 | 2203- | NMR81 | (A) | ||
| 105 | I8-98031 059-0 | BRACKET; RR SPR,RR | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 001 | I7-20010 227-A | FRAME ASM | 1 | 2407- | NMR81 | (C) NMR81-THD; TSHD; OAL=4300MM | ||
| 376 | I9-06751 024-0 | RIVET; FRAME | AR | 2203- | ALL | (F) D10X24 TAPER END | ||
| 198 | I7-53134 011-A | GUSSET; 6TH C/MBR | 4 | 2203- | ALL | (C) | ||
| 376 | I9-06751 026-0 | RIVET; FRAME | AR | 2203- | ALL | (G) D10X26 TAPER END | ||
| 074 | I7-21100 201-A | GUSSET; 4TH C/MBR | 2 | 2203- | NLR85 | (A) RH LOWER,LH UPPER; NLR85-TL; NLR85-BL | ||
| 376 | I9-06750 824-0 | RIVET; FRAME | AR | 2203- | ALL | (C) D8X24 TAPER END | ||
| 039 | I8-97695 646-A | BRACKET; FRT SPR,RR | 2 | 2203- | NMR81 | (B) | ||
| 286 | I0-28051 230-0 | BOLT; SPARE TIRE BRKT | 4 | 2203- | NLR85 | M12X30 FLANGE; NLR85-TL; NLR85-BL | ||
| 376 | I9-06751 230-0 | RIVET; FRAME | AR | 2203- | ALL | (L) D12X30 TAPER END | ||
| 039 | I8-94258 091-A | BRACKET; FRT SPR,RR | 2 | 2203- | NLR85 | (A) NLR85-T; NLR85-B | ||
| 001 | I7-20010 224-A | FRAME ASM | 1 | 2407- | NMR81 | (C) NMR81-TSDL; OAL=5700MM | ||
| 063 | I7-53192 022-A | BRACKET; RAD MTG | 1 | 2203- | NLR85 | |||
| 198 | I8-97695 396-A | GUSSET; 6TH C/MBR | 1 | 2203- | NLR85 | (A) UPPER; NLR85-TL; NLR85-BL | ||
| 060 | I0-28051 030-0 | BOLT; MBR | 6 | 2203- | ALL | M10X30 FLANGE | ||
| 123 | I0-91180 212-0 | NUT | 30 | 2203- | NMR81 | (B) M12 FLANGE | ||
| 139 | I8-97696 748-A | MEMBER; CROSS,6TH | 1 | 2203- | NLR85 | (B) NLR85-TL; NLR85-BL | ||
| 001 | I7-20010 223-A | FRAME ASM | 1 | 2203- | NLR85 | (A) NLR85-B | ||
| 074 | I7-21100 200-A | GUSSET; 4TH C/MBR | 2 | 2203- | NLR85 | (A) RH UPPER,LH LOWER; NLR85-TL; NLR85-BL | ||
| 051 | I8-94258 963-0 | BRACKET; ENG SUPPORT,OUTER | 2 | 2203- | ALL | |||
| 188 | I8-97078 869-1 | BRACKET; SUPPORT,CTR BRG | 1 | 2203- | NMR81 | (A) | ||
| 123 | I0-91180 212-0 | NUT | 30 | 2203- | NLR85 | (B) M12 FLANGE; NLR85-TL; NLR85-BL | ||
| 105 | I7-66200 217-A | BRACKET; RR SPR,RR | 1 | 2203- | NLR85 | (A) NLR85-T; NLR85-B | ||
| 173 | I8-97695 657-A | STIFFENER; RR SPRING | 1 | 2203- | NMR81 | (A) | ||
| 534 | I8-97695 550-A | BRACKET; BACK BAR | 1 | 2203- | ALL | |||
| 139 | I8-97695 395-0 | MEMBER; CROSS,6TH | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 376 | I9-06751 028-0 | RIVET; FRAME | AR | 2203- | ALL | (H) D10X28 TAPER END | ||
| 042 | I8-97696 674-A | MEMBER; CROSS,ENG MTG | 1 | 2203- | NLR85 | (A) | ||
| 376 | I9-06750 820-0 | RIVET; FRAME | AR | 2203- | ALL | (A) D8X20 TAPER END | ||
| 034 | I7-21130 211-A | MEMBER; CROSS,3RD | 1 | 2203- | NMR81 | (A) | ||
| 113 | I0-28061 240-0 | BOLT; SPR STOPPER | 24 | 2203- | NMR81 | M12X40 FLANGE | ||
| 376 | I9-06751 234-0 | RIVET; FRAME | AR | 2203- | ALL | (M) D12X34 TAPER END | ||
| 001 | I7-20010 228-A | FRAME ASM | 1 | 2407- | NLR85 | (B) NLR85-TL; OAL=4700MM | ||
| 123 | I7-05110 010-A | NUT | 2 | 2203- | ALL | (A) M10 FLANGE | ||
| 075 | I7-53134 011-A | GUSSET; 5TH C/MBR | 4 | 2203- | ALL | (A) | ||
| 414 | I0-28661 030-0 | BOLT | 2 | 2203- | ALL | (A) M10X30 FLANGE | ||
| 173 | I8-97695 673-A | STIFFENER; RR SPRING | 1 | 2203- | NMR81 | (B) NMR81-TSD; TSDL | ||
| 123 | I0-91180 212-0 | NUT | 6 | 2203- | NMR81 | (B) M12 FLANGE | ||
| 286 | I0-28051 230-0 | BOLT; SPARE TIRE BRKT | 4 | 2203- | NMR81 | M12X30 FLANGE | ||
| 024 | I8-97695 543-A | BRACKET; FRT SPR,FRT | 1 | 2203- | NLR85 | |||
| 130 | I7-21170 209-A | MEMBER; CROSS,END | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 024 | I8-97695 542-A | BRACKET; FRT SPR,FRT | 1 | 2203- | NLR85 | |||
| 130 | I8-97695 645-A | MEMBER; CROSS,END | 1 | 2203- | NMR81 | (B) | ||
| 001 | I8-97696 675-A | FRAME ASM | 1 | 2203- | NMR81 | (C) NMR81-THD; TSHD; OAL=4165MM | ||
| 001 | I8-97696 770-A | FRAME ASM | 1 | 2203- | NMR81 | (C) NMR81-TSDL; OAL=5170MM | ||
| 001 | I7-20010 226-A | FRAME ASM | 1 | 2407- | NMR81 | (C) NMR81-TSD; OAL=4600MM | ||
| 201 | I8-97695 534-A | GUSSET; C/MBR | 4 | 2203- | ALL | |||
| 140 | I8-97695 655-A | BRACKET; S/ABS,RR | 2 | 2203- | NMR81 | (A) | ||
| 376 | I9-06750 828-0 | RIVET; FRAME | AR | 2203- | ALL | (D) D8X28 TAPER END | ||
| 142 | I8-97047 775-1 | BRACKET; FLEX HOSE,BRAKE | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 345 | I8-97045 542-2 | MEMBER; CROSS,5TH | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 198 | I8-97695 397-A | GUSSET; 6TH C/MBR | 1 | 2203- | NLR85 | (A) UPPER; NLR85-TL; NLR85-BL | ||
| 075 | I8-94258 081-1 | GUSSET; 5TH C/MBR | 2 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 376 | I9-06750 822-0 | RIVET; FRAME | AR | 2203- | ALL | (B) D8X22 TAPER END | ||
| 002 | I8-97696 678-A | MEMBER; CROSS,1ST | 1 | 2203- | ALL | |||
| 103 | I7-66202 213-A | STOPPER; SUB SPR | 4 | 2203- | NMR81 | |||
| 105 | I7-66200 216-A | BRACKET; RR SPR,RR | 1 | 2203- | NLR85 | (A) NLR85-T; NLR85-B | ||
| 198 | I8-97695 412-A | GUSSET; 6TH C/MBR | 2 | 2203- | NLR85 | (B) LOWER; NLR85-TL; NLR85-BL | ||
| 344 | I8-97696 747-A | MEMBER; CROSS,4TH | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 042 | I8-97696 040-A | MEMBER; CROSS,ENG MTG | 1 | 2203- | NMR81 | (B) | ||
| 024 | I8-97695 546-A | BRACKET; FRT SPR,FRT | 1 | 2203- | NMR81 | |||
| 376 | I9-06751 032-0 | RIVET; FRAME | AR | 2203- | ALL | (J) D10X32 TAPER END | ||
| 414 | I0-28051 230-0 | BOLT | 6 | 2203- | NLR85 | (B) M12X30 FLANGE; NLR85-TL; NLR85-BL | ||
| 001 | I7-20010 220-A | FRAME ASM | 1 | 2203- | NLR85 | (B) NLR85-TL; OAL=4230MM | ||
| 140 | I8-94258 104-1 | BRACKET; S/ABS,RR | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 414 | I0-28061 240-0 | BOLT | 24 | 2203- | NMR81 | (C) M12X40 FLANGE | ||
| 173 | I8-97695 677-A | STIFFENER; RR SPRING | 1 | 2203- | NMR81 | (B) NMR81-TSD; TSDL | ||
| 137 | I7-20210 211-A | BRACKET; SPARE TIRE | 2 | 2203- | NMR81 | (B) | ||
| 173 | I8-97213 460-A | STIFFENER; RR SPRING | 2 | 2203- | NLR85 | (B) NLR85-TL; NLR85-BL | ||
| 188 | I8-97078 869-1 | BRACKET; SUPPORT,CTR BRG | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 165 | I8-97695 548-A | BRACKET; RAD STAY | 1 | 2203- | NLR85 | NLR85-T; NLR85-B | ||
| 344 | I8-97695 634-A | MEMBER; CROSS,4TH | 1 | 2203- | NMR81 | (C) | ||
| 024 | I8-97695 545-A | BRACKET; FRT SPR,FRT | 1 | 2203- | NMR81 | |||
| 173 | I8-97695 675-A | STIFFENER; RR SPRING | 1 | 2203- | NMR81 | (A) | ||
| 101 | I7-66225 211-A | BRACKET; RR SPR,FRT | 2 | 2203- | NMR81 | (A) | ||
| 140 | I8-97163 956-0 | BRACKET; S/ABS,RR | 1 | 2203- | NLR85 | (C) NLR85-TL; NLR85-BL | ||
| 123 | I0-91180 212-0 | NUT | 6 | 2203- | NLR85 | (B) M12 FLANGE; NLR85-TL; NLR85-BL | ||
| 105 | I7-66226 211-A | BRACKET; RR SPR,RR | 2 | 2203- | NMR81 | (B) | ||
| 001 | I7-20010 222-A | FRAME ASM | 1 | 2203- | NLR85 | (A) NLR85-T | ||
| 140 | I8-97163 957-0 | BRACKET; S/ABS,RR | 1 | 2203- | NLR85 | (C) NLR85-TL; NLR85-BL | ||
| 344 | I8-97696 740-A | MEMBER; CROSS,4TH | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 288 | I0-91180 212-0 | NUT; SPARE TIRE BRKT | 4 | 2203- | NLR85 | M12 FLANGE; NLR85-TL; NLR85-BL | ||
| 414 | I0-28051 230-0 | BOLT | 6 | 2203- | NMR81 | (B) M12X30 FLANGE | ||
| 034 | I7-21130 211-A | MEMBER; CROSS,3RD | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 062 | I0-91180 110-0 | NUT; MBR | 6 | 2203- | ALL | M10 FLANGE | ||
| 001 | I7-20010 221-A | FRAME ASM | 1 | 2203- | NLR85 | (B) NLR85-BL | ||
| 039 | I8-97695 646-A | BRACKET; FRT SPR,RR | 2 | 2203- | NLR85 | (B) NLR85-TL; NLR85-BL | ||
| 020 | I8-97696 679-A | MEMBER; CROSS,2ND | 1 | 2203- | ALL | |||
| 001 | I8-97696 767-A | FRAME ASM | 1 | 2203- | NMR81 | (C) NMR81-TSD; OAL=4165MM | ||
| 140 | I8-94258 103-1 | BRACKET; S/ABS,RR | 1 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 101 | I8-94258 093-1 | BRACKET; RR SPR,FRT | 2 | 2203- | NLR85 | (B) NLR85-T; NLR85-B | ||
| 137 | I7-89900 200-A | BRACKET; SPARE TIRE | 1 | 2203- | NLR85 | (A) NLR85-TL; NLR85-BL | ||
| 176 | I0-28051 030-0 | BOLT; C/MBR,ENG MTG | 8 | 2203- | ALL | M10X30 FLANGE | ||
| 142 | I8-97695 669-A | BRACKET; FLEX HOSE,BRAKE | 1 | 2203- | NLR85 | (C) NLR85-TL; NLR85-BL | ||
| 074 | I7-53134 011-A | GUSSET; 4TH C/MBR | 4 | 2203- | ALL | (B) | ||
| 345 | I8-97696 748-A | MEMBER; CROSS,5TH | 1 | 2203- | NMR81 | (A) |
