8-01 | LAMP; FRONT AND FRONT SIDE
ELF
NLR85 NMR81 E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 331 | I8-98155 459-A | LAMP; TURN SIGNAL | 1 | 2203- | L | ALL | ||
| 005 | I1-82194 063-0 | BULB; HEADLAMP | 2 | 2203- | ALL | (A) 24V 75/70W | ||
| 001 | I8-98241 325-A | LAMP ASM; HEAD | 1 | 2203- | R | ALL | ||
| 427 | I0-91180 106-0 | NUT; TURN SIGNAL LAMP | 2 | 2203- | ALL | M6 FLANGE | ||
| 004 | I8-98226 182-0 | HEADLAMP UNIT | 1 | 2203- | R | ALL | ||
| 355 | I8-98051 428-0 | SCREW; TURN SIGNAL | 4 | 2203- | ALL | |||
| 327 | I8-97410 180-A | LAMP ASM; SIDE TURN SIGNAL | 1 | 2203- | R | ALL | ||
| 437 | I8-98051 390-0 | SOCKET; SIDE,TURN | 2 | 2203- | ALL | |||
| 327 | I8-97410 180-A | LAMP ASM; SIDE TURN SIGNAL | 1 | 2203- | R | ALL | ||
| 007 | I0-91180 106-0 | NUT; FRT COMB LAMP | 2 | 2203- | ALL | M6 FLANGE | ||
| 331 | I8-98155 459-A | LAMP; TURN SIGNAL | 1 | 2203- | L | ALL | ||
| 427 | I0-91180 106-0 | NUT; TURN SIGNAL LAMP | 2 | 2203- | ALL | M6 FLANGE | ||
| 437 | I8-98051 390-0 | SOCKET; SIDE,TURN | 2 | 2203- | ALL | |||
| 032 | I8-97695 760-A | LAMP ASM; FOG | 1 | 2203- | L | ALL | ||
| 004 | I8-98226 183-0 | HEADLAMP UNIT | 1 | 2203- | L | ALL | ||
| 428 | I8-94430 184-1 | GROMMET; SIDE COMB LAMP | 2 | 2203- | ALL | |||
| 023 | I8-97232 491-0 | COVER; BULB,HEADLAMP | 2 | 2203- | ALL | |||
| 408 | I8-97378 874-0 | CAP; BREATHER,HEADLAMP | 2 | 2203- | ALL | |||
| 331 | I8-98155 458-A | LAMP; TURN SIGNAL | 1 | 2203- | R | ALL | ||
| 020 | I8-97378 871-0 | SCREW; HEADLAMP | 6 | 2203- | ALL | |||
| 457 | I8-98241 354-0 | GRIP; HEADLAMP | 2 | 2203- | ALL | |||
| 432 | I8-98051 431-0 | FASTENER; TURN SIGNAL,LAMP | 4 | 2203- | ALL | |||
| 020 | I8-97378 871-0 | SCREW; HEADLAMP | 6 | 2203- | ALL | |||
| 382 | I8-98225 685-0 | PLUG; SOCKET,HEADLAMP | 2 | 2203- | ALL | |||
| 004 | I8-98226 183-0 | HEADLAMP UNIT | 1 | 2203- | L | ALL | ||
| 399 | I8-98051 387-0 | SOCKET; TURN SIGNAL | 2 | 2203- | ALL | |||
| 139 | I8-98034 056-A | COVER; HEADLAMP | 2 | 2203- | NLR85 | |||
| 005 | I1-82194 063-0 | BULB; HEADLAMP | 2 | 2203- | ALL | (A) 24V 75/70W | ||
| 431 | I8-97378 874-0 | CAP; TURN SIGNAL,LAMP | 2 | 2203- | ALL | |||
| 399 | I8-98051 387-0 | SOCKET; TURN SIGNAL | 2 | 2203- | ALL | |||
| 357 | I8-97323 806-A | BULB; TURN SIGNAL | 2 | 2203- | ALL | 24V 21W AMBER | ||
| 139 | I8-98084 160-0 | COVER; HEADLAMP | 2 | 2203- | NMR81 | |||
| 023 | I8-97232 491-0 | COVER; BULB,HEADLAMP | 2 | 2203- | ALL | |||
| 139 | I8-98084 160-0 | COVER; HEADLAMP | 2 | 2203- | NMR81 | |||
| 355 | I8-98051 428-0 | SCREW; TURN SIGNAL | 4 | 2203- | ALL | |||
| 432 | I8-98051 431-0 | FASTENER; TURN SIGNAL,LAMP | 4 | 2203- | ALL | |||
| 091 | I8-98051 495-0 | BULB; SIDE TURN SIGNAL | 2 | 2203- | ALL | 24V 21W AMBER | ||
| 420 | I8-98218 601-0 | SPRING; BULB,HEADLAMP | 2 | 2203- | ALL | |||
| 420 | I8-98218 601-0 | SPRING; BULB,HEADLAMP | 2 | 2203- | ALL | |||
| 431 | I8-97378 874-0 | CAP; TURN SIGNAL,LAMP | 2 | 2203- | ALL | |||
| 005 | I6-82194 063-1 | BULB; HEADLAMP | 2 | 2203- | ALL | (IADG) (A) 24V 75/70W | ||
| 005 | I1-82194 042-0 | BULB; HEADLAMP | 2 | 2203- | ALL | (B) 24V 5W | ||
| 139 | I8-98034 056-A | COVER; HEADLAMP | 2 | 2203- | NLR85 | |||
| 032 | I8-97695 760-A | LAMP ASM; FOG | 1 | 2203- | L | ALL | ||
| 028 | I8-98164 723-0 | BOLT; HEADLAMP | 8 | 2203- | ALL | M6X23.5 W/LK&PL WASHER | ||
| 028 | I8-98164 723-0 | BOLT; HEADLAMP | 8 | 2203- | ALL | M6X23.5 W/LK&PL WASHER | ||
| 005 | I6-82194 063-1 | BULB; HEADLAMP | 2 | 2203- | ALL | (IADG) (A) 24V 75/70W | ||
| 001 | I8-98241 325-A | LAMP ASM; HEAD | 1 | 2203- | R | ALL | ||
| 004 | I8-98226 182-0 | HEADLAMP UNIT | 1 | 2203- | R | ALL | ||
| 001 | I8-98241 326-A | LAMP ASM; HEAD | 1 | 2203- | L | ALL | ||
| 327 | I8-97410 181-A | LAMP ASM; SIDE TURN SIGNAL | 1 | 2203- | L | ALL | ||
| 032 | I8-97695 759-A | LAMP ASM; FOG | 1 | 2203- | R | ALL | ||
| 331 | I8-98155 458-A | LAMP; TURN SIGNAL | 1 | 2203- | R | ALL | ||
| 357 | I8-97323 806-A | BULB; TURN SIGNAL | 2 | 2203- | ALL | 24V 21W AMBER | ||
| 428 | I8-94430 184-1 | GROMMET; SIDE COMB LAMP | 2 | 2203- | ALL | |||
| 007 | I0-91180 106-0 | NUT; FRT COMB LAMP | 2 | 2203- | ALL | M6 FLANGE | ||
| 091 | I8-98051 495-0 | BULB; SIDE TURN SIGNAL | 2 | 2203- | ALL | 24V 21W AMBER | ||
| 457 | I8-98241 354-0 | GRIP; HEADLAMP | 2 | 2203- | ALL | |||
| 001 | I8-98241 326-A | LAMP ASM; HEAD | 1 | 2203- | L | ALL | ||
| 327 | I8-97410 181-A | LAMP ASM; SIDE TURN SIGNAL | 1 | 2203- | L | ALL | ||
| 005 | I1-82194 042-0 | BULB; HEADLAMP | 2 | 2203- | ALL | (B) 24V 5W | ||
| 032 | I8-97695 759-A | LAMP ASM; FOG | 1 | 2203- | R | ALL | ||
| 382 | I8-98225 685-0 | PLUG; SOCKET,HEADLAMP | 2 | 2203- | ALL | |||
| 408 | I8-97378 874-0 | CAP; BREATHER,HEADLAMP | 2 | 2203- | ALL |
