| 320 |
I0-28060 835-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
2204- |
|
ALL |
M8X35 FLANGE |
| 009 |
I8-97376 758-0 |
|
GASKET; TURBOCHARGER TO EXH DUCT |
1 |
2204- |
|
ALL |
(B) ID=54 |
| 021 |
I0-28050 816-0 |
|
BOLT; PIPE |
2 |
2204- |
|
ALL |
(A) M8X16 FLANGE |
| 131 |
I8-94394 671-0 |
|
GASKET; OIL PIPE,C/BL |
1 |
2204- |
|
ALL |
ID=30 |
| 006 |
I0-28050 816-0 |
|
BOLT; BRKT TO C/BL |
1 |
2204- |
|
ALL |
M8X16 FLANGE |
| 485 |
I8-97648 418-0 |
|
PIPE; WATER EGR |
1 |
2204- |
|
ALL |
(B) |
| 117 |
I8-98251 345-0 |
|
GASKET; WATER PIPE |
2 |
2204- |
|
ALL |
(A) ID=14.2 OD=19.2 |
| 133 |
I8-97559 831-0 |
|
PIPE; OIL DRAIN,TURBOCHARGER |
1 |
2204- |
|
ALL |
|
| 014 |
I0-44011 025-0 |
|
STUD; TURBOCHARGER TO EXH PIPE |
3 |
2204- |
|
ALL |
(B) M10X25 L=40 |
| 143 |
I8-98308 273-0 |
|
CLIP; HOSE,TURBOCHARGER OUTLET |
1 |
2204- |
|
ALL |
(B) ID=65-85 |
| 001 |
I8-97651 327-0 |
|
TURBOCHARGER ASM |
1 |
2204- |
|
ALL |
|
| 137 |
I8-97559 837-A |
|
PIPE; WATER,TURBOCHARGER IN |
1 |
2204- |
|
ALL |
|
| 130 |
I0-50540 620-0 |
|
BOLT; OIL PIPE TO TURBOCHARGER DRAIN |
2 |
2204- |
|
ALL |
M6X20 W/LK WASHER |
| 115 |
I8-97559 839-A |
|
PIPE; WATER,TURBOCHARGER OUT |
1 |
2204- |
|
ALL |
|
| 134 |
I1-09623 462-0 |
|
GASKET; OIL PIPE,TURBOCHARGER DRAIN |
1 |
2204- |
|
ALL |
ID=22.8 OD=27.6 |
| 007 |
I8-94174 537-0 |
|
WASHER; PL,BRKT |
1 |
2204- |
|
ALL |
ID=8 OD=18 T=3 |
| 442 |
I8-97651 753-A |
|
BRACKET; SUPPORT, TURBOCHARGER |
1 |
2204- |
|
ALL |
(A) |
| 173 |
I8-97648 412-0 |
|
PROTECTOR; HEAT,FUEL PIPE |
1 |
2204- |
|
ALL |
|
| 231 |
I6-97209 950-0 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
2204- |
|
ALL |
(IADG) |
| 032 |
I8-97648 411-0 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
2204- |
|
ALL |
|
| 389 |
I8-98332 259-0 |
|
PIPE; INL,TURBOCHARGER TO CAC |
1 |
2204- |
|
ALL |
|
| 162 |
I5-09000 275-0 |
|
BOLT; ADAPTER |
1 |
2204- |
|
ALL |
M8X57 |
| 442 |
I8-97663 611-0 |
|
BRACKET; SUPPORT, TURBOCHARGER |
1 |
2204- |
|
ALL |
(B) |
| 182 |
I0-91180 110-0 |
|
NUT; DUCT |
2 |
2204- |
|
ALL |
M10 FLANGE |
| 117 |
I8-97146 684-A |
|
GASKET; WATER PIPE |
1 |
2204- |
|
ALL |
(C) ID=18.6 |
| 320 |
I0-28060 835-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
2204- |
|
ALL |
M8X35 FLANGE |
| 026 |
I8-98107 962-0 |
|
GASKET; DUCT |
1 |
2204- |
|
ALL |
ID=56 |
| 143 |
I8-97833 075-0 |
|
CLIP; HOSE,TURBOCHARGER OUTLET |
3 |
2204-2207 |
|
ALL |
(A) ID=45-65 |
| 092 |
I0-28650 840-0 |
|
BOLT; INL PIPE |
1 |
2204- |
|
ALL |
M8X40 FLANGE |
| 143 |
I8-98133 396-0 |
|
CLIP; HOSE,TURBOCHARGER OUTLET |
3 |
2208- |
|
ALL |
(A) ID=45-65 |
| 309 |
I0-28650 825-0 |
|
BOLT; TURBOCHARGER |
2 |
2204- |
|
ALL |
M8X25 FLANGE |
| 485 |
I8-97559 833-1 |
|
PIPE; WATER EGR |
1 |
2204- |
|
ALL |
(C) |
| 116 |
I8-98037 827-0 |
|
BOLT; WATER PIPE |
1 |
2204- |
|
ALL |
(B) M14X30 EYE-BOLT |
| 116 |
I0-28050 816-0 |
|
BOLT; WATER PIPE |
2 |
2204- |
|
ALL |
(C) M8X16 FLANGE |
| 231 |
I8-97209 950-A |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
2204- |
|
ALL |
|
| 009 |
I8-98046 241-0 |
|
GASKET; TURBOCHARGER TO EXH DUCT |
1 |
2204- |
|
ALL |
(A) ID=49 |
| 019 |
I8-94170 486-0 |
|
NUT; EXH PIPE,TURBOCHARGER |
3 |
2204- |
|
ALL |
M8 FLANGE |
| 118 |
I8-97359 141-0 |
|
CLIP; WATER HOSE |
4 |
2204- |
|
ALL |
(A) ID=22 |
| 136 |
I9-09571 412-0 |
|
GASKET; WATER PIPE |
2 |
2204- |
|
ALL |
ID=12.2 OD=18 |
| 011 |
I8-97381 617-0 |
|
NUT; TURBOCHARGER |
4 |
2204- |
|
ALL |
M10 FLANGE |
| 118 |
I8-98025 921-0 |
|
CLIP; WATER HOSE |
2 |
2204- |
|
ALL |
(B) ID=24 |
| 178 |
I0-44011 028-0 |
|
STUD; DUCT |
2 |
2204- |
|
ALL |
M10X28 L=43 |
| 071 |
I8-97648 520-A |
|
HOSE; INLET PIPE TO TURBOCHARGER |
1 |
2204- |
|
NQR81 |
(A) |
| 014 |
I8-97019 478-0 |
|
STUD; TURBOCHARGER TO EXH PIPE |
3 |
2204- |
|
ALL |
(A) M8X49 L=63 |
| 320 |
I8-94368 563-1 |
|
BOLT; BRKT,TURBOCHARGER |
4 |
2204- |
|
ALL |
M8X18 FLANGE |
| 118 |
I8-94221 519-0 |
|
CLIP; WATER HOSE |
2 |
2204- |
|
ALL |
(C) ID=15.5 |
| 332 |
I8-97648 413-A |
|
DUCT; AIR,TURBOCHARGER |
1 |
2204- |
|
ALL |
|
| 033 |
I8-97108 669-0 |
|
BOLT; HEAT PROTECTOR |
6 |
2204- |
|
ALL |
M6X12 FLANGE |
| 288 |
I0-28050 816-0 |
|
BOLT; WATER PIPE CLIP |
3 |
2204- |
|
ALL |
(B) M8X16 FLANGE |
| 204 |
I8-97846 239-0 |
|
COLLAR; PIPE ADAPTER |
1 |
2204- |
|
ALL |
|
| 016 |
I8-97648 409-A |
|
ADAPTER; EXH PIPE |
1 |
2204- |
|
ALL |
|
| 395 |
I8-94395 766-0 |
|
RUBBER; MTG |
1 |
2204- |
|
ALL |
(B) OD=32 |
| 527 |
I8-98060 887-2 |
|
BRACKET; TURBOCHARGER |
1 |
2204- |
|
ALL |
|
| 288 |
I0-28050 812-A |
|
BOLT; WATER PIPE CLIP |
1 |
2204- |
|
ALL |
(A) M8X12 FLANGE |
| 395 |
I8-97105 689-A |
|
RUBBER; MTG |
1 |
2204- |
|
ALL |
(A) OD=23 |
| 012 |
I8-97307 075-2 |
|
STUD; TURBOCHARGER |
2 |
2204- |
|
ALL |
M10X33 L=48 |
| 117 |
I9-09571 412-0 |
|
GASKET; WATER PIPE |
2 |
2204- |
|
ALL |
(B) ID=12.2 OD=18 |
| 485 |
I8-97559 832-0 |
|
PIPE; WATER EGR |
1 |
2204- |
|
ALL |
(A) |
| 116 |
I1-09675 081-0 |
|
BOLT; WATER PIPE |
2 |
2204- |
|
ALL |
(A) M12X24 EYE-BOLT |
| 071 |
I8-97648 434-A |
|
HOSE; INLET PIPE TO TURBOCHARGER |
1 |
2204- |
|
ALL |
(B) |
| 135 |
I0-28050 820-0 |
|
BOLT; OIL PIPE TO C/BL |
2 |
2204- |
|
ALL |
M8X20 FLANGE |
| 021 |
I7-04508 025-A |
|
BOLT; PIPE |
2 |
2204- |
|
ALL |
(B) M8X20 FLANGE |
| 071 |
I8-97648 521-A |
|
HOSE; INLET PIPE TO TURBOCHARGER |
1 |
2204- |
|
NPS81 |
(A) |
