| 080 |
I0-28151 020-0 |
|
BOLT; FAN GUIDE |
2 |
2204- |
|
ALL |
(C) M10X20 FLANGE |
| 075 |
I8-94249 446-0 |
|
BOLT; CUSHION RUBBER,RAD MTG |
1 |
2204- |
|
NPS81 |
M8X63 |
| 025 |
I0-28651 030-0 |
|
BOLT; BRKT |
2 |
2204- |
|
ALL |
(B) M10X30 FLANGE |
| 089 |
I1-21469 153-0 |
|
BOLT |
2 |
2204- |
|
ALL |
(B) M8X25 W/PL WASHER |
| 089 |
I0-28050 812-A |
|
BOLT |
2 |
2204- |
|
ALL |
(A) M8X12 FLANGE |
| 023 |
I0-91180 110-0 |
|
NUT; RAD MTG |
2 |
2204- |
|
ALL |
(B) M10 FLANGE |
| 062 |
I0-28050 812-A |
|
BOLT; STAY |
2 |
2204- |
|
ALL |
M8X12 FLANGE |
| 057 |
I0-91610 510-0 |
|
WASHER; PL,STAY |
2 |
2204- |
|
ALL |
ID=10.5 |
| 092 |
I8-97676 008-0 |
|
BRACKET; FAN GUIDE |
1 |
2204- |
|
ALL |
(A) |
| 267 |
I1-21467 023-0 |
|
RUBBER; CUSHION |
2 |
2204- |
|
ALL |
|
| 065 |
I8-94249 346-A |
|
INSULATOR; RAD |
2 |
2204- |
|
ALL |
(A) |
| 022 |
I8-98347 885-0 |
|
BRACKET; RAD MTG |
2 |
2204- |
|
NQR81 |
(A) |
| 080 |
I8-98039 672-0 |
|
BOLT; FAN GUIDE |
4 |
2204- |
|
NPS81 |
(B) M6X12 |
| 421 |
I0-28050 816-0 |
|
BOLT; BRKT FAN GUIDE |
2 |
2204- |
|
ALL |
M8X16 FLANGE |
| 080 |
I1-21559 481-0 |
|
BOLT; FAN GUIDE |
4 |
2204- |
|
NQR81 |
(A) M6X16 |
| 080 |
I0-28650 830-0 |
|
BOLT; FAN GUIDE |
3 |
2204- |
|
ALL |
(D) M8X30 FLANGE |
| 065 |
I8-94249 347-A |
|
INSULATOR; RAD |
2 |
2204- |
|
ALL |
(B) |
| 536 |
I8-97350 995-0 |
|
SHROUD; FAN |
1 |
2204- |
|
NPS81 |
|
| 023 |
I7-05108 010-A |
|
NUT; RAD MTG |
2 |
2204- |
|
ALL |
(A) M8 FLANGE |
| 100 |
I1-09337 027-0 |
|
RUBBER; MTG |
6 |
2204- |
|
NPS81 |
OD=32 |
| 514 |
I7-05108 010-A |
|
NUT; RAD |
2 |
2204- |
|
ALL |
M8 FLANGE |
| 051 |
I8-97171 437-A |
|
PLUG; DRAIN |
1 |
2204- |
|
ALL |
W/GASKET |
| 056 |
I8-98347 580-0 |
|
STAY; RAD |
1 |
2204- |
|
NQR81 |
(A) |
| 232 |
I8-98141 232-0 |
|
COLLAR; DIST,CUSHION RUBBER |
2 |
2204- |
|
NPS81 |
(B) |
| 232 |
I8-98141 232-0 |
|
COLLAR; DIST,CUSHION RUBBER |
2 |
2204- |
|
NQR81 |
(A) |
| 016 |
I8-97239 187-0 |
|
CAP; RAD |
1 |
2204- |
|
NPS81 |
(B) |
| 056 |
I8-98101 270-0 |
|
STAY; RAD |
1 |
2204- |
|
NPS81 |
(B) |
| 001 |
I8-98245 665-1 |
|
RADIATOR ASM |
1 |
2204- |
|
NPS81 |
(B) |
| 079 |
I8-98172 924-0 |
|
GUIDE; FAN,RAD |
1 |
2204- |
|
NQR81 |
(A) |
| 074 |
I8-97359 049-1 |
|
WASHER; PL,CUSHION RUBBER |
2 |
2204- |
|
ALL |
(B) ID=8.5 OD=36 |
| 016 |
I8-98096 226-0 |
|
CAP; RAD |
1 |
2204- |
|
NQR81 |
(A) |
| 082 |
I8-98006 478-0 |
|
COVER; FAN,RAD |
1 |
2204- |
|
NPS81 |
|
| 079 |
I8-98245 715-0 |
|
GUIDE; FAN,RAD |
1 |
2204- |
|
NPS81 |
(B) |
| 092 |
I8-97386 233-0 |
|
BRACKET; FAN GUIDE |
1 |
2204- |
|
NPS81 |
(B) |
| 022 |
I8-97074 093-0 |
|
BRACKET; RAD MTG |
1 |
2204- |
|
NPS81 |
(B) |
| 025 |
I0-28050 612-0 |
|
BOLT; BRKT |
4 |
2204- |
|
ALL |
(A) M6X12 FLANGE |
| 070 |
I8-98018 941-0 |
|
STAY; RAD |
1 |
2204- |
|
NQR81 |
(A) |
| 070 |
I8-98034 644-0 |
|
STAY; RAD |
1 |
2204- |
|
NPS81 |
(B) |
| 059 |
I8-97359 052-0 |
|
PIN; SNAP,STAY |
2 |
2204- |
|
ALL |
L=32.6 |
| 092 |
I8-97350 997-0 |
|
BRACKET; FAN GUIDE |
1 |
2204- |
|
NPS81 |
(C) |
| 001 |
I8-98174 420-0 |
|
RADIATOR ASM |
1 |
2204- |
|
NQR81 |
(A) |
| 074 |
I0-91610 710-0 |
|
WASHER; PL,CUSHION RUBBER |
1 |
2204- |
|
NPS81 |
(A) ID=10.5 |
