3-31 | BRAKE MASTER VAC AND BRAKE BOOSTER
ELF
NPS81 NQR81 E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 051 | I8-98038 347-0 | CLEVIS; HYDRO BRK BOOSTER | 1 | 2204- | NQR81 | |||
| 045 | I8-98031 415-1 | PROTECTOR; HEAT | 1 | 2204- | NQR81 | |||
| 056 | I8-98184 424-0 | GASKET KIT; M/CYL TO SERVO UNIT | 1 | 2204- | NPS81 | W/GREASE | ||
| 048 | I8-98038 346-0 | ACCUMULATOR; HYDRO BOOSTER | 1 | 2204- | NQR81 | |||
| 046 | I0-28050 610-0 | BOLT; HEAT PROTECTOR | 2 | 2204- | ALL | M6X10 FLANGE | ||
| 011 | I8-97205 576-0 | FILTER; M/VAC | 1 | 2204- | NPS81 | |||
| 049 | I8-97191 043-0 | GUARD; HYDRO BRK BOOSTER | 1 | 2204- | NQR81 | |||
| 052 | I1-33739 065-0 | GASKET; HYDRO BRK BOOSTER | 1 | 2204- | NQR81 | |||
| 016 | I1-52139 008-0 | NUT; VLV ROD,M/VAC | 1 | 2204- | NPS81 | M10 | ||
| 015 | I8-94375 083-0 | RETAINER; GUARD,M/VAC | 1 | 2204- | NPS81 | |||
| 001 | I8-97532 751-0 | MASTER VAC ASM; BRK | 1 | 2204- | NQR81 | (B) | ||
| 012 | I8-97205 577-0 | SILENCER; M/VAC | 1 | 2204- | NPS81 | |||
| 024 | I8-98184 421-0 | GUARD; VLV BODY,M/VAC | 1 | 2204- | NPS81 | |||
| 001 | I8-98234 822-0 | MASTER VAC ASM; BRK | 1 | 2204- | NPS81 | (A) | ||
| 050 | I8-98038 349-0 | NUT; HYDRO BRK BOOSTER | 1 | 2204- | NQR81 | |||
| 017 | I8-97224 610-0 | CLEVIS; YOKE,M/VAC | 1 | 2204- | NPS81 |
