3-50 | BRAKE PIPING; OIL,MASTER CYLINDER
ELF
NPS81 NQR81 E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 254 | I8-98319 373-1 | PIPE; BRAKE,2WAY | 1 | 2204- | NQR81 | |||
| 186 | I8-97359 141-0 | CLIP; HOSE | 1 | 2204- | ALL | (C) ID=22 | ||
| 192 | I8-98193 137-0 | PIPE; PRESSURE | 1 | 2204- | NQR81 | (B) | ||
| 010 | I0-28650 640-0 | BOLT; JOINT | 1 | 2204- | ALL | M6X40 FLANGE | ||
| 193 | I8-97538 419-0 | PIPE; RETURN | 1 | 2204- | NQR81 | |||
| 008 | I8-97076 471-0 | CLIP; FLEX HOSE,CABLE SIDE | 1 | 2204- | ALL | (B) | ||
| 117 | I8-97856 616-0 | SEAL; UNION,BRK PIPE JOINT | 2 | 2204- | ALL | |||
| 262 | I8-97139 186-0 | COLLAR; LSPV | 1 | 2204- | NPS81 | |||
| 263 | I8-97093 662-0 | CAP; BLEEDER | 1 | 2204- | NPS81 | |||
| 035 | I8-98159 735-0 | PIPE; BRK,VLV TO RR AXLE | 1 | 2204- | NPS81 | L=674 | ||
| 205 | I8-97672 350-A | HOSE; TANK TO PIPE | 1 | 2204- | NQR81 | |||
| 056 | I8-98154 266-1 | BRACKET; UNION,BRK | 1 | 2204- | NQR81 | (B) | ||
| 253 | I8-97120 033-2 | JOINT | 1 | 2204- | NPS81 | |||
| 164 | I8-97093 663-0 | SCREW; BLEEDER | 1 | 2204- | NPS81 | |||
| 187 | I0-19809 300-0 | HOSE; RUBBER,OIL TANK | 1 | 2204- | NQR81 | L=220 | ||
| 007 | I8-98029 865-0 | HOSE; FLEX,PIPE TO 5 WAY JOINT | 2 | 2204- | ALL | |||
| 019 | I8-98115 279-A | PIPE; BRK,M/CYL TO UNION | 1 | 2204- | NPS81 | (B) L=1274 | ||
| 129 | I0-28050 612-0 | BOLT; BRKT | 1 | 2204- | ALL | (B) M6X12 FLANGE | ||
| 008 | I8-97365 304-0 | CLIP; FLEX HOSE,CABLE SIDE | 2 | 2204- | ALL | (A) | ||
| 261 | I8-97145 631-0 | BUSHING; LSPV | 2 | 2204- | NPS81 | |||
| 056 | I8-98098 679-0 | BRACKET; UNION,BRK | 1 | 2204- | NQR81 | (A) | ||
| 253 | I5-47456 009-1 | JOINT | 1 | 2204- | NQR81 | |||
| 186 | I8-98008 098-0 | CLIP; HOSE | 2 | 2204- | ALL | (A) ID=16 | ||
| 184 | I0-28050 816-0 | BOLT; CLIP | 2 | 2204- | ALL | M8X16 FLANGE | ||
| 185 | I8-97330 513-0 | HOSE; RUBBER,SUCTION | 1 | 2204- | NQR81 | (A) | ||
| 186 | I8-98150 355-0 | CLIP; HOSE | 1 | 2204- | ALL | (D) ID=21 | ||
| 145 | I8-98115 269-A | PIPE; BRK,METERING VLV TO UNION | 1 | 2204- | NPS81 | (B) L=1371 | ||
| 129 | I8-98081 030-0 | BOLT; BRKT | 2 | 2204- | ALL | (A) M6X20 W/LK&PL WASHER | ||
| 026 | I8-98057 012-0 | BRACKET; PROPORTIONING VLV | 1 | 2204- | NPS81 | |||
| 186 | I8-98150 355-0 | CLIP; HOSE | 2 | 2204- | NQR81 | (B) ID=21 | ||
| 019 | I8-97389 366-1 | PIPE; BRK,M/CYL TO UNION | 2 | 2204- | NPS81 | (A) L=580 | ||
| 019 | I8-98098 682-1 | PIPE; BRK,M/CYL TO UNION | 1 | 2204- | NQR81 | (D) L=1067 | ||
| 056 | I8-98154 264-1 | BRACKET; UNION,BRK | 1 | 2204- | NPS81 | (C) | ||
| 100 | I8-97358 958-0 | NUT; HYDRAULIC UNIT | 1 | 2204- | NQR81 | (A) | ||
| 019 | I8-98043 501-2 | PIPE; BRK,M/CYL TO UNION | 2 | 2204- | NQR81 | (C) L=317 | ||
| 260 | I8-97173 366-0 | SHACKLE; LSPV | 1 | 2204- | NPS81 | |||
| 100 | I7-05108 010-A | NUT; HYDRAULIC UNIT | 5 | 2204- | ALL | (B) M8 FLANGE | ||
| 022 | I8-98293 938-0 | CLIP | 3 | 2204- | NQR81 | (B) ID=16 L=20 | ||
| 146 | I8-94279 050-0 | NUT; BRKT | 1 | 2204- | ALL | M8 W/LK WASHER | ||
| 104 | I0-28050 816-0 | BOLT; BRKT TO BODY | 2 | 2204- | ALL | M8X16 FLANGE | ||
| 185 | I8-98085 720-0 | HOSE; RUBBER,SUCTION | 1 | 2204- | NQR81 | (B) | ||
| 145 | I8-98098 680-1 | PIPE; BRK,METERING VLV TO UNION | 1 | 2204- | NQR81 | (A) L=1168 | ||
| 011 | I8-94427 224-2 | VALVE; BRK CONT | 1 | 2204- | NPS81 | |||
| 022 | I0-95235 025-0 | CLIP | 2 | 2204- | NQR81 | (A) ID=11 L=16 | ||
| 192 | I8-98127 262-0 | PIPE; PRESSURE | 1 | 2204- | NQR81 | (A) | ||
| 013 | I0-28050 816-0 | BOLT; VLV TO BRKT | 4 | 2204- | ALL | M8X16 FLANGE |
