| 006 |
I8-98020 796-0 |
|
COUPLING ASM; DRIVER,PROP SHAFT |
1 |
2204- |
|
NQR81 |
|
| 017 |
I0-90301 406-0 |
|
NIPPLE; GREASE,PROP SHAFT |
1 |
2204- |
|
ALL |
(B) M6 STRAIGHT |
| 106 |
I0-90301 406-0 |
|
NIPPLE; GREASE,YOKE,PROP SHAFT |
1 |
2204- |
|
ALL |
M6 STRAIGHT |
| 128 |
I8-97145 746-0 |
|
SEAL; SLEEVE |
1 |
2204- |
|
ALL |
|
| 089 |
I8-98056 949-0 |
|
NUT; YOKE TO RR AXLE |
8 |
2204- |
|
NPS81 |
(B) M10 |
| 096 |
I8-97365 451-1 |
|
BOLT; PROP SHAFT |
4 |
2204- |
|
ALL |
(B) M12X35 |
| 220 |
I8-97167 316-0 |
|
YOKE; SPLINED |
1 |
2204- |
|
NPS81 |
|
| 008 |
I8-97178 365-0 |
|
YOKE; FLANGE,PROP SHAFT |
1 |
2204- |
|
NPS81 |
(B) D=65 |
| 301 |
I8-98090 720-0 |
|
SHAFT ASM; PROP,FRT |
1 |
2204- |
|
NPS81 |
L=774 |
| 120 |
I8-98056 948-0 |
|
BOLT; YOKE TO RR AXLE |
4 |
2204- |
|
NPS81 |
(B) M10X29 |
| 300 |
I8-98040 793-A |
|
SHAFT ASM; PROP,RR |
1 |
2204- |
|
NQR81 |
(A) L=1127 |
| 020 |
I8-98020 880-0 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
2204- |
|
NQR81 |
|
| 009 |
I8-98020 789-0 |
|
JOURNAL ASM; PROP SHAFT |
2 |
2204- |
|
ALL |
(A) |
| 126 |
I8-94366 900-0 |
|
PLUG; SPLINED YOKE |
1 |
2204- |
|
ALL |
(B) |
| 090 |
I0-91510 610-0 |
|
WASHER; LK,YOKE TO RR AXLE |
8 |
2204- |
|
NPS81 |
(B) ID=10.2 |
| 017 |
I0-90301 610-0 |
|
NIPPLE; GREASE,PROP SHAFT |
3 |
2204- |
|
ALL |
(A) PT1/8 ELBOW |
| 126 |
I1-09600 023-0 |
|
PLUG; SPLINED YOKE |
1 |
2204- |
|
ALL |
(A) |
| 120 |
I8-97365 451-1 |
|
BOLT; YOKE TO RR AXLE |
4 |
2204- |
|
ALL |
(A) M12X35 |
| 119 |
I8-97365 450-1 |
|
NUT; PROP SHAFT |
4 |
2204- |
|
ALL |
(A) M12 |
| 121 |
I8-97035 623-1 |
|
RETAINER; CUSHION RUBBER |
1 |
2204- |
|
NQR81 |
|
| 008 |
I1-37211 037-4 |
|
YOKE; FLANGE,PROP SHAFT |
3 |
2204- |
|
ALL |
(A) D=80 |
| 111 |
I8-97020 597-1 |
|
RING; SLEEVE |
1 |
2204- |
|
NPS81 |
|
| 125 |
I8-98044 229-0 |
|
YOKE ASM; SPLINED,PROP SHAFT |
1 |
2204- |
|
ALL |
L=224 |
| 089 |
I8-97365 450-1 |
|
NUT; YOKE TO RR AXLE |
8 |
2204- |
|
ALL |
(A) M12 |
| 059 |
I8-97160 857-0 |
|
NUT; RET TO SUPPORT |
1 |
2204- |
|
NQR81 |
M30 |
| 090 |
I0-91510 812-0 |
|
WASHER; LK,YOKE TO RR AXLE |
8 |
2204- |
|
ALL |
(A) ID=12.2 |
| 119 |
I8-97371 572-0 |
|
NUT; PROP SHAFT |
2 |
2204- |
|
NQR81 |
(B) |
| 127 |
I0-90301 406-0 |
|
NIPPLE; GREASE,SPLINED YOKE |
1 |
2204- |
|
ALL |
M6 STRAIGHT |
| 009 |
I8-97167 317-0 |
|
JOURNAL ASM; PROP SHAFT |
1 |
2204- |
|
NPS81 |
(B) |
| 020 |
I6-98020 880-1 |
|
BEARING ASM; CTR,PROP SHAFT |
1 |
2204- |
|
NQR81 |
(IADG) |
| 346 |
I0-91510 812-0 |
|
WASHER; PROP SHAFT |
4 |
2204- |
|
ALL |
ID=12.2 |
| 096 |
I0-50641 025-0 |
|
BOLT; PROP SHAFT |
4 |
2204- |
|
NQR81 |
(A) M10X25 W/LK&PL WASHER |
| 009 |
I8-98020 789-0 |
|
JOURNAL ASM; PROP SHAFT |
3 |
2204- |
|
ALL |
(A) |
| 300 |
I8-98049 839-1 |
|
SHAFT ASM; PROP,RR |
1 |
2204- |
|
NPS81 |
(C) L=1506 |
| 300 |
I8-98063 805-1 |
|
SHAFT ASM; PROP,RR |
1 |
2204- |
|
NQR81 |
(B) L=1252 |
