| 033 |
I0-91110 510-0 |
|
NUT; KEY BOLT |
2 |
2204- |
|
ALL |
M10 |
| 082 |
I8-94322 468-2 |
|
BAR; STAB,FRT SUSP |
1 |
2204- |
|
NPS81 |
|
| 082 |
I8-98006 957-0 |
|
BAR; STAB,FRT SUSP |
1 |
2204- |
|
NQR81 |
|
| 014 |
I8-94107 672-3 |
|
BUSHING; KING PIN |
4 |
2204- |
|
NQR81 |
DAIDO WO/NOTCH |
| 061 |
I8-97107 348-2 |
|
ROD END; TIE ROD |
1 |
2204- |
|
NQR81 |
|
| 004 |
I6-87832 220-0 |
|
KING PIN KIT |
1 |
2204- |
|
NQR81 |
(IADG) |
| 026 |
I8-94174 354-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.80 |
| 026 |
I8-94162 577-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.65 |
| 182 |
I8-94323 964-1 |
|
ARM; STRG,TIE ROD,FRT AXLE |
1 |
2204- |
|
NPS81 |
|
| 106 |
I0-28651 025-0 |
|
BOLT; CAP FIX |
4 |
2204- |
|
ALL |
M10X25 FLANGE |
| 002 |
I8-98331 374-0 |
|
KNUCKLE; FRT AXLE |
1 |
2204- |
|
NQR81 |
|
| 070 |
I0-91111 520-0 |
|
NUT; TIE ROD END |
2 |
2204- |
|
NPS81 |
(B) M20 |
| 239 |
I0-28851 470-0 |
|
BOLT; LINK ROD |
2 |
2204- |
|
ALL |
M14X70 FLANGE |
| 238 |
I8-97138 300-1 |
|
ROD LINK ASM; STABILIZER,FRT |
2 |
2204- |
|
NPS81 |
|
| 212 |
I8-98049 689-0 |
|
NUT; STRG ROD |
2 |
2204- |
|
ALL |
M16 SLOTTED |
| 070 |
I8-94254 726-0 |
|
NUT; TIE ROD END |
2 |
2204- |
|
NPS81 |
(C) M20 LH THREAD |
| 242 |
I8-94178 430-2 |
|
CAP; LINK ROD |
2 |
2204- |
|
ALL |
|
| 192 |
I0-91116 514-0 |
|
NUT; STRG ARM BRKT |
1 |
2204- |
|
NPS81 |
M14 SLOTTED |
| 008 |
I8-94440 901-0 |
|
BEARING; NEEDLE,KING PIN |
4 |
2204- |
|
NPS81 |
|
| 021 |
I0-90301 406-0 |
|
NIPPLE; GREASE,KING PIN |
4 |
2204- |
|
ALL |
M6 STRAIGHT |
| 049 |
I8-98362 580-0 |
|
CAP; KNUCKLE |
2 |
2204- |
|
NQR81 |
|
| 002 |
I8-94458 330-2 |
|
KNUCKLE; FRT AXLE |
1 |
2204- |
|
NPS81 |
|
| 026 |
I8-94162 576-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.60 |
| 261 |
I0-91110 512-0 |
|
NUT; STOPPER BOLT |
3 |
2204- |
|
NPS81 |
M12 |
| 026 |
I8-94440 842-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NPS81 |
(C) T=0.5 |
| 318 |
I0-91180 110-0 |
|
NUT; CAP FIX |
4 |
2204- |
|
ALL |
M10 FLANGE |
| 036 |
I8-97043 208-0 |
|
ARM; KNUCKLE |
1 |
2204- |
|
NPS81 |
|
| 032 |
I8-97141 945-2 |
|
BOLT; KEY,KING PIN |
2 |
2204- |
|
NQR81 |
|
| 025 |
I8-97141 943-A |
|
BEARING; THRUST,KING PIN |
1 |
2204- |
|
NQR81 |
(IADG) OD=51.6 ID=30.5 T=15.8 |
| 023 |
I8-94440 839-0 |
|
COLLAR; DIST BRG |
4 |
2204- |
|
NPS81 |
|
| 070 |
I8-98043 530-0 |
|
NUT; TIE ROD END |
1 |
2204- |
|
NQR81 |
(A) M20 RH THREAD |
| 004 |
I5-87832 400-0 |
|
KING PIN KIT |
1 |
2204- |
|
NQR81 |
|
| 002 |
I8-98331 376-0 |
|
KNUCKLE; FRT AXLE |
1 |
2204- |
|
NQR81 |
|
| 002 |
I8-94458 331-2 |
|
KNUCKLE; FRT AXLE |
1 |
2204- |
|
NPS81 |
|
| 091 |
I8-94440 793-0 |
|
BUSHING; RUBBER,STAB BAR |
2 |
2204- |
|
ALL |
(C) |
| 087 |
I8-94321 458-A |
|
BRACKET; STABILIZER |
1 |
2204- |
|
NPS81 |
|
| 025 |
I8-97141 943-1 |
|
BEARING; THRUST,KING PIN |
1 |
2204- |
|
NQR81 |
OD=51.6 ID=30.5 T=15.8 |
| 232 |
I8-97239 911-0 |
|
BUSHING; LINK ROD |
2 |
2204- |
|
ALL |
|
| 026 |
I8-94168 490-0 |
|
SHIM; KING PIN,BRG |
1 |
2204- |
|
NQR81 |
(B) T=1.95 |
| 101 |
I8-97360 124-0 |
|
NUT; STAB BAR |
2 |
2204- |
|
ALL |
M14 FLANGE |
| 091 |
I8-97239 911-0 |
|
BUSHING; RUBBER,STAB BAR |
2 |
2204- |
|
ALL |
(B) |
| 044 |
I8-94440 230-0 |
|
COVER; KING PIN |
2 |
2204- |
|
NPS81 |
|
| 036 |
I8-98332 434-0 |
|
ARM; KNUCKLE |
1 |
2204- |
|
NQR81 |
|
| 031 |
I8-97145 460-0 |
|
PIN; S/ABS,LWR |
2 |
2204- |
|
NQR81 |
|
| 091 |
I8-94342 187-0 |
|
BUSHING; RUBBER,STAB BAR |
2 |
2204- |
|
NQR81 |
(A) |
| 025 |
I8-94248 883-3 |
|
BEARING; THRUST,KING PIN |
1 |
2204- |
|
NQR81 |
OD=54 ID=30.2 T=13.8 |
| 041 |
I9-08161 028-0 |
|
PIN; KNOCK,KNUCKLE ARM |
4 |
2204- |
|
NPS81 |
|
| 018 |
I0-91111 512-0 |
|
NUT; STOPPER BOLT,KNUCKLE |
3 |
2204- |
|
NQR81 |
M12 |
| 027 |
I8-98333 711-0 |
|
PIN; STRAIGHT,KING PIN |
4 |
2204- |
|
NPS81 |
OD=4 L=8 |
| 070 |
I8-94254 726-0 |
|
NUT; TIE ROD END |
1 |
2204- |
|
NQR81 |
(A) M20 LH THREAD |
| 001 |
I8-98358 862-0 |
|
AXLE; FRT |
1 |
2204- |
|
NQR81 |
|
| 101 |
I0-91370 012-0 |
|
NUT; STAB BAR |
2 |
2204- |
|
NQR81 |
M12 LOCK NUT |
| 046 |
I0-91510 814-0 |
|
WASHER; LK,COVER |
16 |
2204- |
|
ALL |
ID=14.2 |
| 260 |
I8-98049 680-0 |
|
BOLT; STOPPER,TIE ROD ARM |
3 |
2204- |
|
NPS81 |
|
| 034 |
I0-91510 510-0 |
|
WASHER; LK,KEY BOLT |
2 |
2204- |
|
NQR81 |
ID=10.2 |
| 010 |
I8-97360 117-0 |
|
PLUG; PLATE,KNUCKLE |
1 |
2204- |
|
NQR81 |
|
| 025 |
I8-94248 883-A |
|
BEARING; THRUST,KING PIN |
1 |
2204- |
|
NQR81 |
(IADG) OD=54 ID=30.2 T=13.8 |
| 048 |
I0-28051 012-0 |
|
BOLT; COVER |
2 |
2204- |
|
ALL |
M10X12 FLANGE |
| 048 |
I9-92361 445-0 |
|
BOLT; COVER |
16 |
2204- |
|
NPS81 |
M14X45 |
| 238 |
I8-97239 907-0 |
|
ROD LINK ASM; STABILIZER,FRT |
2 |
2204- |
|
NQR81 |
|
| 026 |
I8-94162 574-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.50 |
| 126 |
I8-97089 556-0 |
|
RUBBER; MTG,STAB BAR |
4 |
2204- |
|
NQR81 |
L=20 |
| 058 |
I8-94440 366-0 |
|
ARM; TIE ROD |
1 |
2204- |
|
NPS81 |
|
| 117 |
I8-97360 124-0 |
|
NUT; STAB BAR BUSHING |
2 |
2204- |
|
ALL |
M14 FLANGE |
| 044 |
I8-97360 023-0 |
|
COVER; KING PIN |
2 |
2204- |
|
NQR81 |
OD=36 |
| 066 |
I8-98049 689-0 |
|
NUT; TIE ROD END |
2 |
2204- |
|
ALL |
M16 SLOTTED |
| 012 |
I8-98084 500-0 |
|
GASKET; KNUCKLE |
2 |
2204- |
|
NQR81 |
|
| 234 |
I8-97360 055-0 |
|
WASHER; STAB |
4 |
2204- |
|
NQR81 |
(B) ID=12.5 |
| 171 |
I0-81123 025-0 |
|
PIN; SPLIT,STRG ARM |
1 |
2204- |
|
NPS81 |
OD=2.8 L=25 |
| 213 |
I0-81124 025-0 |
|
PIN; COTTER,STRG ROD |
4 |
2204- |
|
NPS81 |
OD=3.7 L=25 |
| 061 |
I8-94419 609-3 |
|
ROD END; TIE ROD |
2 |
2204- |
|
NPS81 |
LH THREAD |
| 026 |
I8-94174 356-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.90 |
| 061 |
I8-97107 349-2 |
|
ROD END; TIE ROD |
1 |
2204- |
|
NQR81 |
|
| 233 |
I8-97360 120-0 |
|
STUD; STABILIZER |
2 |
2204- |
|
NQR81 |
|
| 017 |
I8-97360 059-0 |
|
BOLT; STOPPER KNUCKLE |
3 |
2204- |
|
NQR81 |
M12X24 |
| 022 |
I8-94440 228-0 |
|
PIN; KING,FRT AXLE |
4 |
2204- |
|
NPS81 |
|
| 234 |
I0-91510 514-0 |
|
WASHER; STAB |
2 |
2204- |
|
NQR81 |
(A) ID=14.2 |
| 081 |
I8-97061 869-0 |
|
ROD; TIE |
1 |
2204- |
|
NQR81 |
|
| 026 |
I8-94162 575-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.55 |
| 026 |
I8-94174 352-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NQR81 |
(A) T=0.70 |
| 106 |
I0-28651 025-0 |
|
BOLT; CAP FIX |
4 |
2204- |
|
ALL |
M10X25 FLANGE |
| 024 |
I8-94458 454-0 |
|
RECEIVER; KING PIN |
2 |
2204- |
|
NPS81 |
|
| 193 |
I0-91614 614-0 |
|
WASHER; PL,STRG ARM BRKT |
1 |
2204- |
|
NPS81 |
ID=15 OD=30 |
| 026 |
I8-94440 840-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NPS81 |
(C) T=0.1 |
| 190 |
I8-94447 552-1 |
|
BOLT; STRG ARM TO BRKT,FRT AXLE |
1 |
2204- |
|
NPS81 |
|
| 026 |
I8-94440 841-0 |
|
SHIM; KING PIN,BRG |
AR |
2204- |
|
NPS81 |
(C) T=0.2 |
| 081 |
I8-94440 365-0 |
|
ROD; TIE |
2 |
2204- |
|
NPS81 |
|
| 122 |
I0-28851 470-0 |
|
BOLT; BRKT |
2 |
2204- |
|
ALL |
M14X70 FLANGE |
| 069 |
I0-81124 020-0 |
|
PIN; SPLIT,TIE ROD END |
2 |
2204- |
|
ALL |
OD=3.7 L=20 |
| 211 |
I8-94458 045-0 |
|
ROD ASM; STEERING TIE ROD |
1 |
2204- |
|
NPS81 |
|
| 058 |
I8-98331 396-0 |
|
ARM; TIE ROD |
1 |
2204- |
|
NQR81 |
|
| 059 |
I8-97360 123-0 |
|
NUT; TIE ROD ARM |
2 |
2204- |
|
NQR81 |
|
