| 064 |
I0-91180 106-0 |
|
NUT; RET |
2 |
2204- |
|
ALL |
M6 FLANGE |
| 049 |
I8-97048 418-0 |
|
SHIM; FINAL PINION CAGE |
AR |
2204- |
|
ALL |
ID=142 T=0.25 |
| 020 |
I1-41562 073-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=2.80 |
| 060 |
I8-98092 137-0 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
2204- |
|
NPS81 |
41/8 |
| 056 |
I1-09070 027-0 |
|
BOLT; BRG CAP |
4 |
2204- |
|
ALL |
M14X95 FLANGE |
| 060 |
I8-98092 140-0 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
2204- |
|
NQR81 |
41/9; EXC. DRIVE GEAR NOISE CONTROL |
| 020 |
I1-41562 077-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=3.20 |
| 088 |
I9-41124 015-0 |
|
PLATE; LK,ADJ NUT |
AR |
2204- |
|
ALL |
(A) T=2.3 |
| 100 |
I6-09625 484-0 |
|
SEAL; OIL,FINAL PINION |
1 |
2204- |
|
ALL |
(IADG) OD=103 |
| 020 |
I6-41562 073-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=2.80 |
| 088 |
I8-97087 821-0 |
|
PLATE; LK,ADJ NUT |
AR |
2204- |
|
ALL |
(B) T=2.3 |
| 070 |
I9-00093 130-0 |
|
BEARING; DIFF CAGE |
2 |
2204- |
|
ALL |
ID=66.7 OD=113 T=30 |
| 045 |
I8-98220 227-0 |
|
BOLT; FINAL PINION CAGE |
6 |
2204- |
|
ALL |
M12X40 W/LK WASHER |
| 043 |
I8-97047 098-0 |
|
CAGE; FINAL PINION |
1 |
2204- |
|
ALL |
|
| 020 |
I6-41562 077-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=3.20 |
| 049 |
I8-97047 299-0 |
|
SHIM; FINAL PINION CAGE |
AR |
2204- |
|
ALL |
ID=142 T=0.15 |
| 021 |
I8-98359 567-0 |
|
GEAR; SIDE,DIFF |
2 |
2204- |
|
ALL |
Z=16 |
| 086 |
I8-97047 294-0 |
|
WASHER; PL,DIFF CAGE SETTING |
12 |
2204- |
|
ALL |
ID=12.5 OD=22 T=2 |
| 063 |
I8-97047 296-0 |
|
BEARING; PINION PILOT |
1 |
2204- |
|
ALL |
|
| 024 |
I8-98359 568-0 |
|
GEAR; PINION,DIFF |
4 |
2204- |
|
ALL |
Z=10 |
| 071 |
I8-97047 099-4 |
|
CAGE ASM; DIFF,FINAL DRIVE |
1 |
2204- |
|
NQR81 |
41/9; 43/9 |
| 020 |
I6-41562 074-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=2.90 |
| 020 |
I1-41562 075-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=3.00 |
| 020 |
I6-41562 076-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=3.10 |
| 049 |
I8-97047 300-0 |
|
SHIM; FINAL PINION CAGE |
AR |
2204- |
|
ALL |
ID=142 T=0.20 |
| 100 |
I1-09625 484-0 |
|
SEAL; OIL,FINAL PINION |
1 |
2204- |
|
ALL |
NOK OD=103 |
| 001 |
I8-98171 662-0 |
|
DRIVE ASM; FINAL,RR |
1 |
2204- |
|
NQR81 |
41/8 |
| 061 |
I8-97047 150-0 |
|
RETAINER; PILOT BRG,PINION |
1 |
2204- |
|
ALL |
(B) |
| 071 |
I8-97047 100-4 |
|
CAGE ASM; DIFF,FINAL DRIVE |
1 |
2204- |
|
ALL |
41/8 |
| 007 |
I8-97047 095-2 |
|
FLANGE; FINAL |
1 |
2204- |
|
ALL |
|
| 050 |
I1-09812 042-1 |
|
BEARING; FINAL PINION |
1 |
2204- |
|
ALL |
|
| 050 |
I1-09812 042-A |
|
BEARING; FINAL PINION |
1 |
2204- |
|
ALL |
(IADG) |
| 044 |
I8-97048 053-0 |
|
GASKET; PINION CAGE |
1 |
2204- |
|
ALL |
|
| 084 |
I8-97047 147-0 |
|
BOLT; FINAL DRIVE GEAR |
12 |
2204- |
|
ALL |
M16X30 |
| 024 |
I6-98359 568-0 |
|
GEAR; PINION,DIFF |
4 |
2204- |
|
ALL |
(IADG) Z=10 |
| 020 |
I1-41562 076-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=3.10 |
| 083 |
I8-98219 705-0 |
|
CAGE ASM; DIFF |
1 |
2204- |
|
NQR81 |
41/9; 43/9 |
| 089 |
I0-28050 816-0 |
|
BOLT; LK PLATE |
4 |
2204- |
|
ALL |
M8X16 FLANGE |
| 066 |
I8-97047 297-0 |
|
RING; SNAP,PILOT BRG |
1 |
2204- |
|
ALL |
|
| 017 |
I8-98219 448-0 |
|
BOLT; DIFF CAGE SETTING |
12 |
2204- |
|
ALL |
M12X90 |
| 037 |
I8-97047 146-0 |
|
NUT; DRIVING PINION |
1 |
2204- |
|
ALL |
M30 FLANGE |
| 061 |
I8-97047 149-0 |
|
RETAINER; PILOT BRG,PINION |
1 |
2204- |
|
ALL |
(A) W/STUD |
| 042 |
I8-97047 097-0 |
|
COLLAR; DIST,COLLAPSIBLE |
1 |
2204- |
|
ALL |
L=22.2 |
| 060 |
I8-98092 137-0 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
2204- |
|
NQR81 |
41/8; EXC. DRIVE GEAR NOISE CONTROL |
| 055 |
I8-97094 637-0 |
|
CARRIER; DIFF |
1 |
2204- |
|
ALL |
|
| 083 |
I8-98219 707-0 |
|
CAGE ASM; DIFF |
1 |
2204- |
|
ALL |
|
| 020 |
I1-41562 074-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=2.90 |
| 020 |
I1-41562 078-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=3.30 |
| 039 |
I5-09812 063-A |
|
BEARING; FINAL PINION |
1 |
2204- |
|
ALL |
|
| 001 |
I8-97388 702-0 |
|
DRIVE ASM; FINAL,RR |
1 |
2204- |
|
NQR81 |
41/9 |
| 025 |
I6-41552 020-0 |
|
WASHER; THRUST,PINION |
4 |
2204- |
|
ALL |
(IADG) |
| 039 |
I5-09812 063-A |
|
BEARING; FINAL PINION |
1 |
2204- |
|
ALL |
|
| 063 |
I8-97047 296-A |
|
BEARING; PINION PILOT |
1 |
2204- |
|
ALL |
(IADG) |
| 070 |
I9-00093 130-A |
|
BEARING; DIFF CAGE |
2 |
2204- |
|
ALL |
(IADG) ID=66.7 OD=113 T=30 |
| 025 |
I1-41552 020-0 |
|
WASHER; THRUST,PINION |
4 |
2204- |
|
ALL |
|
| 049 |
I8-97047 298-0 |
|
SHIM; FINAL PINION CAGE |
AR |
2204- |
|
ALL |
ID=142 T=0.12 |
| 020 |
I6-41562 079-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=3.40 |
| 020 |
I1-41562 079-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
T=3.40 |
| 085 |
I8-97065 214-0 |
|
NUT; DIFF CAGE SETTING |
12 |
2204- |
|
ALL |
M12 |
| 082 |
I6-41521 035-0 |
|
SPIDER; DIFF PINION |
1 |
2204- |
|
ALL |
(IADG) |
| 020 |
I6-41562 075-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=3.00 |
| 082 |
I1-41521 035-2 |
|
SPIDER; DIFF PINION |
1 |
2204- |
|
ALL |
|
| 021 |
I6-98165 935-0 |
|
GEAR; SIDE,DIFF |
2 |
2204- |
|
ALL |
(IADG) Z=16 |
| 060 |
I8-98171 586-0 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
2204- |
|
NQR81 |
41/8; DRIVE GEAR NOISE CONTROL |
| 020 |
I6-41562 078-0 |
|
WASHER; THRUST,SIDE GEAR |
AR |
2204- |
|
ALL |
(IADG) T=3.30 |
| 049 |
I8-97048 419-0 |
|
SHIM; FINAL PINION CAGE |
AR |
2204- |
|
ALL |
ID=142 T=0.50 |
| 069 |
I1-41121 039-0 |
|
NUT; ADJ,DIFF CAGE |
2 |
2204- |
|
ALL |
M115 H=20 |
| 001 |
I8-97388 704-0 |
|
DRIVE ASM; FINAL,RR |
1 |
2204- |
|
NPS81 |
41/8 |
