| 089 |
I9-11129 128-0 |
|
CUP SEALING,OIL GALLERY |
3 |
1907- |
|
4HL1‑TCS |
OD=20 |
| 212 |
I8-97135 423-0 |
|
PIN CRANKCASE |
2 |
1907- |
|
4HL1‑TCS |
OD=10 L=20 |
| 136 |
I8-98091 566-0 |
|
BUSHING DRIVE SHAFT,OIL PUMP |
2 |
1907- |
|
4HL1‑TCS |
|
| 097 |
I8-97209 609-0 |
|
CUP SEALING |
3 |
1907- |
|
4HL1‑TCS |
(B) OD=22 |
| 001 |
I8-98204 537-1 |
|
BLOCK ASM CYL |
1 |
1907- |
|
4HL1‑TCS |
|
| 406 |
I5-09605 005-0 |
|
PLUG CRANK CASE |
2 |
1907- |
|
4HL1‑TCS |
PT3/8 T=12 |
| 002 |
I5-87818 145-0 |
|
LINER SET ENG CYL |
4 |
1907- |
|
4HL1‑TCS |
GRADE=3X |
| 034 |
I8-97328 859-0 |
|
VALVE OIL RELIEF |
1 |
1907- |
|
4HL1‑TCS |
|
| 017 |
I8-97176 230-0 |
|
SWITCH OIL PRESSURE |
1 |
1907- |
|
4HL1‑TCS |
|
| 023 |
I1-09600 016-0 |
|
CUP SEALING,C/BL FRT & RR |
1 |
1907- |
|
4HL1‑TCS |
(B) OD=25 |
| 002 |
I5-87818 144-0 |
|
LINER SET ENG CYL |
4 |
1907- |
|
4HL1‑TCS |
GRADE=1X |
| 211 |
I8-97077 638-0 |
|
BOLT CRANKCASE |
10 |
1907- |
|
4HL1‑TCS |
(B) M14X115 FLANGE |
| 004 |
I8-98014 043-0 |
|
LINER C/BL |
4 |
1907- |
|
4HL1‑TCS |
OD GRADE=3X,ID GRADE=NON |
| 132 |
I8-97329 618-0 |
|
VALVE CHECK,OIL |
4 |
1907- |
|
4HL1‑TCS |
M10X18.5 |
| 013 |
I8-94399 688-1 |
|
DOWEL C/BL TO HD |
2 |
1907- |
|
4HL1‑TCS |
OD=18.15 |
| 035 |
I8-94173 412-0 |
|
GASKET RELIEF VLV |
1 |
1907- |
|
4HL1‑TCS |
ID=23.3 |
| 070 |
I8-97096 824-0 |
|
CUP SEALING,FRT & RR |
4 |
1907- |
|
4HL1‑TCS |
OD=40 |
| 007 |
I8-97352 537-0 |
|
PLUG WATER DRAIN |
1 |
1907- |
|
4HL1‑TCS |
M10X10 |
| 211 |
I8-94399 553-2 |
|
BOLT CRANKCASE |
17 |
1907- |
|
4HL1‑TCS |
(A) M10X82 FLANGE |
| 056 |
I8-97179 086-1 |
|
JET OIL,PISTON COOLING |
4 |
1907- |
|
4HL1‑TCS |
|
| 004 |
I8-98014 042-0 |
|
LINER C/BL |
4 |
1907- |
|
4HL1‑TCS |
OD GRADE=1X,ID GRADE=NON |
| 023 |
I8-97036 550-1 |
|
CUP SEALING,C/BL FRT & RR |
3 |
1907- |
|
4HL1‑TCS |
(A) OD=45 |
| 061 |
I8-94483 674-0 |
|
PIN STRAIGHT |
4 |
1907- |
|
4HL1‑TCS |
L=22 |
| 335 |
I8-97329 617-0 |
|
PLUG C/BL,SIDE |
1 |
1907- |
|
4HL1‑TCS |
M14X16.5 |
| 351 |
I1-09630 083-0 |
|
GASKET COCK,WATER DRAIN |
1 |
1907- |
|
4HL1‑TCS |
ID=10.2 OD=15.2 |
| 097 |
I5-11129 006-0 |
|
CUP SEALING |
1 |
1907- |
|
4HL1‑TCS |
(A) OD=16 |
