| 035 |
I9-41562 602-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1907- |
|
NPS81 |
T=1.00 |
| 008 |
I9-41219 614-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.24 |
| 006 |
I8-97328 648-0 |
|
SEAL OIL,FINAL PINION |
1 |
1907- |
|
NPS81 |
|
| 008 |
I9-41219 612-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.20 |
| 007 |
I9-00093 078-A |
|
BEARING PINION,OUTER |
1 |
1907- |
|
NPS81 |
(IADG) |
| 012 |
I9-41519 010-0 |
|
SHIM FINAL PINION CAGE |
AR |
1907- |
|
NPS81 |
T=0.25 |
| 006 |
I6-97328 648-0 |
|
SEAL OIL,FINAL PINION |
1 |
1907- |
|
NPS81 |
(IADG) |
| 037 |
I8-98186 829-0 |
|
GEAR PINION DIFF |
4 |
1907- |
|
NPS81 |
Z=10 |
| 008 |
I9-41219 628-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.52 |
| 008 |
I9-41219 624-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.44 |
| 036 |
I8-98190 383-1 |
|
GEAR SIDE,DIFF |
2 |
1907- |
|
NPS81 |
Z=18 |
| 008 |
I9-41219 620-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.36 |
| 011 |
I9-41510 610-0 |
|
CAGE FINAL PINION |
1 |
1907- |
|
NPS81 |
|
| 028 |
I8-97314 497-0 |
|
BOLT DIFF CAGE SETTING |
8 |
1907- |
|
NPS81 |
M12X58 |
| 009 |
I9-41219 634-1 |
|
COLLAR DIST,PINION |
1 |
1907- |
|
NPS81 |
L=53.35 |
| 008 |
I9-41219 618-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.32 |
| 030 |
I8-94365 377-3 |
|
BOLT DIFF CAGE SETTING |
4 |
1907- |
|
NPS81 |
M14X80 |
| 008 |
I9-41219 608-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.12 |
| 034 |
I9-41521 611-0 |
|
PIN CROSS,DIFF PINION |
1 |
1907- |
|
NPS81 |
|
| 012 |
I9-41519 602-0 |
|
SHIM FINAL PINION CAGE |
AR |
1907- |
|
NPS81 |
T=0.35 |
| 033 |
I0-91510 612-0 |
|
WASHER LK,DIFF CAGE |
8 |
1907- |
|
NPS81 |
ID=12.2 |
| 019 |
I9-00093 079-1 |
|
BEARING PINION,INNER |
1 |
1907- |
|
NPS81 |
|
| 001 |
I8-97377 818-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1907- |
|
NPS81 |
41/8 |
| 007 |
I9-00093 078-0 |
|
BEARING PINION,OUTER |
1 |
1907- |
|
NPS81 |
|
| 008 |
I9-41219 626-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.48 |
| 019 |
I9-00093 079-A |
|
BEARING PINION,INNER |
1 |
1907- |
|
NPS81 |
(IADG) |
| 008 |
I9-41219 610-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.16 |
| 026 |
I9-00032 211-A |
|
BEARING DIFF CAGE |
2 |
1907- |
|
NPS81 |
|
| 014 |
I8-97078 083-2 |
|
CARRIER ASM FINAL DRIVE,FRT AXLE |
1 |
1907- |
|
NPS81 |
|
| 005 |
I8-94317 615-0 |
|
COVER DUST,PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
|
| 012 |
I9-41519 009-0 |
|
SHIM FINAL PINION CAGE |
AR |
1907- |
|
NPS81 |
T=0.50 |
| 002 |
I8-94376 261-1 |
|
NUT FINAL DRIVE PINION |
1 |
1907- |
|
NPS81 |
M24 FLANGE |
| 004 |
I8-97303 538-0 |
|
COUPLING FINAL DRIVE PINION |
1 |
1907- |
|
NPS81 |
|
| 024 |
I9-09606 505-2 |
|
BOLT FINAL DRIVE GEAR |
12 |
1907- |
|
NPS81 |
M12X25 |
| 021 |
I8-97211 238-0 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1907- |
|
NPS81 |
41/8 |
| 012 |
I9-41519 601-0 |
|
SHIM FINAL PINION CAGE |
AR |
1907- |
|
NPS81 |
T=0.30 |
| 008 |
I9-41219 630-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.56 |
| 008 |
I9-41219 616-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.28 |
| 008 |
I9-41219 622-0 |
|
SHIM PINION,FINAL DRIVE |
1 |
1907- |
|
NPS81 |
OD=89.5 T=2.40 |
