| 34 |
I8-97328 859-0 |
|
VALVE; OIL RELIEF |
1 |
1208- |
|
NQR71 |
.1479166666667 |
| 132 |
I8-97329 618-0 |
|
VALVE; CHECK,OIL |
4 |
1208- |
|
NQR71 |
M10X18.5 |
| 1 |
I8-98204 534-0 |
|
BLOCK ASM; CYL |
1 |
1208- |
|
NQR71 |
|
| 335 |
I8-97329 617-0 |
|
PLUG; C/BL,SIDE |
1 |
1208- |
|
NQR71 |
M14X16.5 |
| 212 |
I8-97135 423-0 |
|
PIN; CRANKCASE |
2 |
1208- |
|
NQR71 |
04.510 OD=10 L=20 |
| 56 |
I8-98370 781-0 |
|
JET; OIL,PISTON COOLING |
4 |
1208- |
|
NQR71 |
|
| 89 |
I9-11129 128-0 |
|
CUP; SEALING,OIL GALLERY |
3 |
1208- |
|
NQR71 |
00.253 OD=2 0 |
| 35 |
I8-94173 412-0 |
|
GASKET; RELIEF VLV |
1 |
1208- |
|
NQR71 |
ID=23.3 |
| 97 |
I8-97209 609-0 |
|
CUP; SEALING |
3 |
1208- |
|
NQR71 |
00.253 (B) OD=2 2 |
| 136 |
I8-98091 566-0 |
|
BUSHING; DRIVE SHAFT,OIL PUMP |
2 |
1208- |
|
NQR71 |
|
| 4 |
I8-98014 048-0 |
|
LINER; C/BL |
4 |
1208- |
|
NQR71 |
OD GRADE=1X,ID GRADE=NON |
| 2 |
I5-87816 317-0 |
|
LINER SET; ENG CYL |
4 |
1208- |
|
NQR71 |
OD GRADE=1X,ID GRADE=NON |
| 70 |
I8-97096 824-0 |
|
CUP; SEALING,FRT & RR |
4 |
1208- |
|
NQR71 |
OD=4 0 |
| 406 |
I5-09605 005-0 |
|
PLUG; CRANK CASE |
2 |
1208- |
|
NQR71 |
01.073 PT3/8 |
| 23 |
I1-09600 016-0 |
|
CUP; SEALING,C/BL FRT & RR |
1 |
1208- |
|
NQR71 |
00.293 (B) OD=2 5 |
| 2 |
I5-87816 318-0 |
|
LINER SET; ENG CYL |
4 |
1208- |
|
NQR71 |
OD GRADE=3X,ID GRADE=NON |
| 17 |
I8-97176 230-0 |
|
SWITCH; OIL PRESSURE |
1 |
1208- |
|
NQR71 |
|
| 211 |
I8-97077 638-0 |
|
BOLT; CRANKCASE |
10 |
1208- |
|
NQR71 |
00.293 (B) M14X115 W/FLANGE |
| 4 |
I6-98014 048-0 |
|
LINER ; C/BL |
4 |
1208- |
|
NQR71 |
(IADG) OD GRADE=1X,ID GRADE=NON |
| 13 |
I8-94399 688-1 |
|
DOWEL; C/BL TO HD |
2 |
1208- |
|
NQR71 |
OD=18.15 |
| 61 |
I8-94483 674-0 |
|
PIN; STRAIGHT |
4 |
1208- |
|
NQR71 |
L=22 |
| 23 |
I8-97036 550-1 |
|
CUP; SEALING,C/BL FRT & RR |
3 |
1208- |
|
NQR71 |
(A) OD=45 |
| 211 |
I8-94399 553-2 |
|
BOLT; CRANKCASE |
17 |
1208- |
|
NQR71 |
(A) M10X82 |
| 4 |
I8-98014 049-1 |
|
LINER; C/BL |
4 |
1208- |
|
NQR71 |
OD GRADE=3X,ID GRADE=NON |
| 351 |
I1-09630 083-0 |
|
GASKET; COCK,WATER DRAIN |
1 |
1208- |
|
NQR71 |
ID=10.2 OD=15.2 |
| 97 |
I5-11129 006-0 |
|
CUP; SEALING |
1 |
1208- |
|
NQR71 |
00.253 (A) OD=16 |
| 7 |
I8-97352 537-0 |
|
PLUG; WATER DRAIN |
1 |
1208- |
|
NQR71 |
M10X10 |
