3-60 | BRAKE PIPING; VACUUM
ELF
NQR 71
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 235 | I8-97214 235-0 | RUBBER; SUPPORT,PIPE | 1 | 1208- | NQR71 | 03.162 OD=16.5 L=50 | ||
| 136 | I8-98008 098-0 | CLIP; VAC HOSE | 6 | 1208- | NQR71 | 03 .162 ID=16 | ||
| 236 | I0-28650 825-0 | BOLT; PIPE | 1 | 1208- | NQR71 | 06.216 M8X2 5 FLANGE IDN | ||
| 169 | I8-98101 041-1 | PIPE; VAC,BOOSTER SIDE | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) (A) | ||
| 235 | I8-97214 235-0 | RUBBER; SUPPORT,PIPE | 1 | 1208- | NQR71 | 03.162 OD=16.5 L=50 | ||
| 108 | I8-94128 319-A | GROMMET; PIPE | 1 | 1208- | NQR71 | 02.343 (B) ID=1 7 IDN | ||
| 39 | I8-98173 762-1 | CLIP; HOSE,VAC | 8 | 1208- | NQR71 | (C) ID=11-17 | ||
| 165 | I0-28650 616-0 | BOLT; BRKT | 1 | 1208- | NQR71 | 02.343 (B) M6X16 FLANGE | ||
| 184 | I8-98156 526-0 | BRACKET; UNION FIX | 1 | 1208- | NQR71 | KD PREPARATORY PACK VAR.4<7TV> (B) | ||
| 66 | I8-98008 098-0 | CLIP; VAC HOSE,M/VAC | 4 | 1208- | NQR71 | 03 .162 ID=16 | ||
| 39 | I8-98008 098-0 | CLIP; HOSE,VAC | 2 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 04.930 (B) ID=16 IDN | ||
| 116 | I0-08158 300-0 | HOSE; VAC,M/VAC | 1 | 1208- | NQR71 | (D) L=140 SERVICED BY L=3000 | ||
| 12 | I8-98008 097-0 | CLIP; HOSE | 2 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 04 . 930 ID=15.5 | ||
| 184 | I8-98193 144-0 | BRACKET; UNION FIX | 1 | 1208- | NQR71 | EXC. KD PREPARATORY PACK VAR.4<7TV> (C) | ||
| 98 | I0-28050 612-0 | BOLT; VAC PIPE FIX | 1 | 1208- | NQR71 | 03.162 M6X12 FLANGE | ||
| 39 | I1-09987 182-0 | CLIP; HOSE,VAC | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 02.559 (A) L=170.3 | ||
| 169 | I8-98041 053-4 | PIPE; VAC,BOOSTER SIDE | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) (C) | ||
| 184 | I8-98193 145-0 | BRACKET; UNION FIX | 1 | 1208- | NQR71 | KD PREPARATORY PACK VAR.4<7TV> (A) | ||
| 169 | I8-98100 234-2 | PIPE; VAC,BOOSTER SIDE | 1 | 1208- | NQR71 | (B) | ||
| 20 | I0-91180 106-0 | NUT; BRKT | 1 | 1208- | NQR71 | 01.062 M6 FLANGE | ||
| 78 | I8-98169 859-0 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | (D) | ||
| 13 | I8-98035 106-0 | JOINT; HOSE,VAC | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) | ||
| 169 | I8-98132 683-1 | PIPE; VAC,BOOSTER SIDE | 1 | 1208- | NQR71 | EXC. POWER ASSIST CLUTCH(S2T) (D) | ||
| 116 | I8-98081 002-2 | HOSE; VAC,M/VAC | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) (B) | ||
| 78 | I8-98136 613-0 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | (F) | ||
| 78 | I8-98171 287-0 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | (B) | ||
| 202 | I8-97856 616-0 | SEAL | 2 | 1208- | NQR71 | 08 .845 IDN | ||
| 169 | I8-98122 740-1 | PIPE; VAC,BOOSTER SIDE | 1 | 1208- | NQR71 | EXC. POWER ASSIST CLUTCH(S2T) (C) | ||
| 98 | I0-28650 825-0 | BOLT; VAC PIPE FIX | 1 | 1208- | NQR71 | 06.216 M8X2 5 FLANGE IDN | ||
| 158 | I8-97061 603-0 | CLIP; HOSE | 1 | 1208- | NQR71 | 02.559 ID=14-20 | ||
| 80 | I8-98097 788-0 | PIPE; VAC,ENG SIDE | 1 | 1208- | NQR71 | (B) | ||
| 184 | I8-98017 628-1 | BRACKET; UNION FIX | 1 | 1208- | NQR71 | (D) IDN | ||
| 44 | I8-98070 194-0 | PIPE; VAC,MAG VLV | 1 | 1208- | NQR71 | (A) | ||
| 116 | I8-98067 702-0 | HOSE; VAC,M/VAC | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) (A) | ||
| 234 | I8-98008 098-0 | CLAMP; PIPE | 3 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 04 . 930 ID=16 IDN | ||
| 116 | I8-98189 220-0 | HOSE; VAC,M/VAC | 1 | 1208- | NQR71 | (C) | ||
| 116 | I0-08158 300-0 | HOSE; VAC,M/VAC | 1 | 1208- | NQR71 | (D) L=140 SERVICED BY L=3000 | ||
| 33 | I8-94462 219-0 | CLIP; VAC PIPE | 2 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) ID=10 H=40 IDN | ||
| 98 | I0-28050 612-0 | BOLT; VAC PIPE FIX | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 03.162 M6X12 FLANGE | ||
| 66 | I8-98008 098-0 | CLIP; VAC HOSE,M/VAC | 2 | 1208- | NQR71 | 03.162 ID=16 | ||
| 75 | I0-91180 108-0 | NUT; CLIP,VAC HOSE | 1 | 1208- | NQR71 | 01.062 M8 FLANGE | ||
| 78 | I8-98057 462-0 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | (C) | ||
| 136 | I8-98008 098-0 | CLIP; VAC HOSE | 2 | 1208- | NQR71 | 03.162 ID=16 | ||
| 39 | I8-98030 682-0 | CLIP; HOSE,VAC | 2 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) 01.097 (D) ID=16 | ||
| 44 | I8-98057 425-1 | PIPE; VAC,MAG VLV | 1 | 1208- | NQR71 | (B) | ||
| 165 | I8-98031 842-0 | BOLT; BRKT | 2 | 1208- | NQR71 | 02.762 (A) M6X2 0 W/LK&PL WASHER | ||
| 80 | I8-97386 605-0 | PIPE; VAC,ENG SIDE | 1 | 1208- | NQR71 | 04.685 (A) | ||
| 98 | I0-28650 825-0 | BOLT; VAC PIPE FIX | 1 | 1208- | NQR71 | 06.216 M8X2 5 FLANGE IDN | ||
| 108 | I9-09956 353-A | GROMMET; PIPE | 1 | 1208- | NQR71 | EXC. POWER ASSIST CLUTCH(S2T) (A) | ||
| 96 | I8-98220 579-0 | PIPE; VAC,M/VAC TO VAC PUMP | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) | ||
| 78 | I8-98080 833-1 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | POWER ASSIST CLUTCH(S2T) (A) | ||
| 78 | I8-97386 589-0 | HOSE; VAC,PIPE TO PIPE | 1 | 1208- | NQR71 | 04.686 (E) | ||
| 108 | I8-94128 319-A | GROMMET; PIPE | 1 | 1208- | NQR71 | 02.343 (B) ID=1 7 IDN | ||
| 122 | I8-98189 104-0 | HOSE; AIR,MAG VLV TO AIR PIPE | 1 | 1208- | NQR71 |
