5-30 | BATTERY CARRIER
ELF
NQR 71
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 10 | I0-28650 820-0 | BOLT; TIRE HANGER | 3 | 1208- | NQR71 | 01.531 M8X2 0 FLANGE IDN | ||
| 9 | I0-91180 110-0 | NUT; BRKT TO FRAME | 4 | 1208- | NQR71 | 03 . 162 M10 FLANGE | ||
| 149 | I7-05012 010-A | NUT; CARRIER | 2 | 1208- | NQR71 | 05.002 M12 | ||
| 21 | I8-98072 378-2 | BRACKET; SPARE TIRE HANGER | 1 | 1208- | NQR71 | IDN | ||
| 167 | I8-97010 955-1 | HANGER; TIRE | 1 | 1208- | NQR71 | IDN | ||
| 34 | I8-94441 189-0 | BOLT; SPARE TIRE | 2 | 1208- | NQR71 | M12X305 | ||
| 5 | I0-28051 025-0 | BOLT; BRKT TO FRAME | 4 | 1208- | NQR71 | 09.171 M10X2 5 FLANGE | ||
| 168 | I8-94466 483-0 | WASHER; SPARE TIRE | 2 | 1208- | NQR71 | 07.243 ID=12.5 OD=54 |
