8-03 | LAMP; REAR AND REAR SIDE
ELF
NQR 71
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 55 | I8-94153 039-0 | NUT; LICENSE PLATE LAMP | 2 | 1208- | NQR71 | 03.444 M5 FLANGE | ||
| 26 | I0-71240 412-0 | SCREW; BACK HORN | 2 | 1208- | R | NQR71 | BACK BUZZER<YM9> 02.688 M4X12 TAPPING IDN | |
| 50 | I5-82125 004-1 | LENS; LICENSE PLATE LAMP | 1 | 1208- | NQR71 | |||
| 58 | I7-41411 211-A | COVER; LICENSE PLATE LAMP | 1 | 1208- | NQR71 | IDN | ||
| 59 | I9-93490 520-0 | SCREW; TAP,LICENSE LAMP BODY | 2 | 1208- | NQR71 | 14.550 M5X2 0 | ||
| 37 | I8-97520 138-A | COVER; RR COMB LAMP | 1 | 1208- | L | NQR71 | IDN | |
| 22 | I8-94257 512-A | LENS; BACKUP,RR COMB LAMP | 2 | 1208- | NQR71 | IDN | ||
| 7 | I8-94402 623-0 | SCREW; RR COMB LAMP | 4 | 1208- | NQR71 | BOLT M6X2 0 | ||
| 51 | I1-82194 037-0 | BULB; LICENSE PLATE LAMP | 1 | 1208- | NQR71 | 24V 10W IDN | ||
| 14 | I8-94178 624-A | LENS; TAIL & STOP,RR COMB LAMP | 1 | 1208- | R | NQR71 | IDN | |
| 15 | I0-71190 420-0 | SCREW; RR COMB LAMP | 16 | 1208- | NQR71 | 08.977 M4X2 0 TAPPING STAINLESS IDN | ||
| 24 | I8-94257 506-0 | GASKET; BACK,LAMP | 2 | 1208- | NQR71 | IDN | ||
| 1 | I7-41210 322-A | LAMP ASM; RR COMB | 1 | 1208- | R | NQR71 | EXC. BACK BUZZER<YM9> IDN | |
| 25 | I8-94257 518-A | HORN ASM; BACK | 1 | 1208- | R | NQR71 | BACK BUZZER<YM9> IDN | |
| 9 | I8-98049 362-0 | NUT; LAMP,RR COMB | 4 | 1208- | NQR71 | 07. 829 M6 FLANGE IDN | ||
| 26 | I9-07076 414-0 | SCREW; BACK HORN | 1 | 1208- | L | NQR71 | 09.655 M4X14 TAPPING IDN | |
| 1 | I7-41210 323-A | LAMP ASM; RR COMB | 1 | 1208- | L | NQR71 | IDN | |
| 28 | I8-94257 507-0 | GASKET; T URN,LAMP | 2 | 1208- | NQR71 | IDN | ||
| 37 | I8-97520 137-A | COVER; RR COMB LAMP | 1 | 1208- | R | NQR71 | IDN | |
| 49 | I8-98029 477-0 | LAMP; LICENSE PLATE | 1 | 1208- | NQR71 | 24V 10W IDN | ||
| 13 | I8-94174 639-A | LENS; TURN SIGNAL | 1 | 1208- | L | NQR71 | IDN | |
| 5 | I1-82194 109-0 | BULB; RR COMB LAMP | 2 | 1208- | NQR71 | (B) 24V 21/5W IDN | ||
| 1 | I6-41210 323-0 | LAMP ASM; RR COMB | 1 | 1208- | L | NQR71 | (IADG) IDN | |
| 14 | I8-94178 625-A | LENS; TAIL & STOP,RR COMB LAMP | 1 | 1208- | L | NQR71 | IDN | |
| 26 | I0-71240 412-0 | SCREW; BACK HORN | 1 | 1208- | R | NQR71 | EXC. BACK BUZZER<YM9> 02.688 M4X12 TAPPING IDN | |
| 13 | I8-94174 638-A | LENS; TURN SIGNAL | 1 | 1208- | R | NQR71 | IDN | |
| 3 | I8-94257 505-0 | GASKET; RR COMB LAMP | 2 | 1208- | NQR71 | IDN | ||
| 54 | I8-94419 312-0 | SCREW; LICENSE PLATE LAMP | 1 | 1208- | NQR71 | 02.709 M4X8 IDN | ||
| 5 | I1-82194 108-0 | BULB; RR COMB LAMP | 4 | 1208- | NQR71 | (A) 24V 21W IDN | ||
| 1 | I7-41210 322-A | LAMP ASM; RR COMB | 1 | 1208- | R | NQR71 | BACK BUZZER<YM9> IDN | |
| 1 | I6-41210 322-0 | LAMP ASM; RR COMB | 1 | 1208- | R | NQR71 | (IADG) EXC. BACK BUZZER<YM9> IDN |
