8-15 | FIXING PARTS; WIRING HARNESS
ELF
NQR 71
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 552 | I0-91180 110-0 | NUT; BRKT,HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98051 457-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98084 590-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | EXC. FORGED AIR VENTILATION(C39),HEATER & | ||
| 16 | I8-94472 578-0 | CLIP; HARNESS | 1 | 1208- | NQR71 | 02.343 (D) ID=16 IDN | ||
| 480 | I0-28650 825-0 | BOLT; BRKT | 1 | 1208- | NQR71 | |||
| 24 | I8-98297 112-0 | NUT; HARNESS | 1 | 1410- | NQR71 | |||
| 515 | I0-91180 108-0 | NUT; BRKT | 2 | 1208- | NQR71 | |||
| 16 | I8-94225 185-0 | CLIP; HARNESS | 2 | 1208- | NQR71 | AIR CONDITIONER MANUAL CONT(C60) (E) ID=12 B=13 ID=6.5 | ||
| 22 | I1-09987 182-0 | CLIP; ENG HARNESS | 1 | 1208- | NQR71 | L=170.3 | ||
| 577 | I8-97068 819-0 | NUT; FUSE BOX | 4 | 1208- | NQR71 | |||
| 577 | I0-91180 106-0 | NUT; FUSE BOX | 2 | 1208- | NQR71 | |||
| 530 | I8-98031 126-0 | SEAL; HARNESS | 1 | 1208- | NQR71 | |||
| 377 | I8-98141 255-0 | BOLT; CAB EARTH | 3 | 1208- | NQR71 | |||
| 16 | I8-97173 307-0 | CLIP; HARNESS | 14 | 1208- | NQR71 | (A) L=155 IDN | ||
| 386 | I8-98141 256-1 | BOLT; GRAND HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98077 504-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98130 669-1 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98173 558-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 294 | I8-94424 179-0 | NUT | 1 | 1208- | NQR71 | |||
| 459 | I8-98123 282-0 | BRACKET; S UPPORT,HARNE S S | 1 | 1208- | NQR71 | |||
| 24 | I0-91180 106-0 | NUT; HARNESS | 1 | 1208- | NQR71 | 01.062 M6 FLANGE | ||
| 515 | I0-91180 110-0 | NUT; BRKT | 1 | 1208- | NQR71 | |||
| 48 | I5-09700 319-0 | CLIP; FRAME HARNESS | 4 | 1208- | NQR71 | 01.240 (A) ID=14 L=4 7 | ||
| 139 | I0-28050 812-A | BOLT; BRKT | 1 | 1208- | NQR71 | |||
| 16 | I8-98052 679-0 | CLIP; HARNESS | 2 | 1208- | NQR71 | (F) | ||
| 459 | I8-98123 286-1 | BRACKET; S UPPORT,HARNE S S | 1 | 1208- | NQR71 | |||
| 313 | I0-28450 616-0 | BOLT; BRKT | 1 | 1208- | NQR71 | |||
| 515 | I0-91180 106-0 | NUT; BRKT | 1 | 1208- | NQR71 | |||
| 483 | I5-09707 031-1 | CLIP; ENG HARNESS | 1 | 1208- | NQR71 | |||
| 16 | I5-09707 030-1 | CLIP; HARNESS | 1 | 1208- | NQR71 | (G) L=250 IDN | ||
| 53 | I8-98126 454-2 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 16 | I8-97069 515-0 | CLIP; HARNESS | 2 | 1208- | NQR71 | 02 .694 (B) ID=6 & 10-13 | ||
| 53 | I8-98077 503-1 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98132 377-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 139 | I8-98177 744-0 | BOLT; BRKT | 1 | 1208- | NQR71 | EXC. FORGED AIR VENTILATION(C39),HEATER & | ||
| 386 | I8-98141 255-0 | BOLT; GRAND HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98173 558-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | (B) | ||
| 515 | I8-98040 024-0 | NUT; BRKT | 1 | 1208- | NQR71 | |||
| 575 | I8-98173 144-2 | BRACKET; FUSE BOX | 1 | 1208- | NQR71 | |||
| 38 | I0-28250 612-0 | BOLT; CLIP,HARNESS | 2 | 1208- | NQR71 | AIR CONDITIONER MANUAL CONT(C60) 09.216 M6X12 FLANGE | ||
| 53 | I8-98052 458-0 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 377 | I8-98164 836-0 | BOLT; CAB EARTH | 1 | 1208- | NQR71 | |||
| 515 | I0-91180 108-0 | NUT; BRKT | 2 | 1208- | NQR71 | |||
| 515 | I0-91180 110-0 | NUT; BRKT | 1 | 1208- | NQR71 | |||
| 53 | I8-98018 900-2 | BRACKET; HARNESS | 1 | 1208- | NQR71 | |||
| 513 | I8-97304 373-0 | TAPE; SOFT,HARNESS | 1 | 1208- | NQR71 | EXC. FORGED AIR VENTILATION(C39),HEATER & | ||
| 529 | I0-28650 825-0 | BOLT; RELAY BOX | 3 | 1208- | NQR71 | |||
| 16 | I8-97229 357-0 | CLIP; HARNESS | 2 | 1208- | NQR71 | (C) L=40.6 | ||
| 515 | I0-91180 110-0 | NUT; BRKT | 1 | 1208- | NQR71 | |||
| 480 | I0-28651 030-0 | BOLT; BRKT | 1 | 1208- | NQR71 | |||
| 48 | I5-09700 319-0 | CLIP; FRAME HARNESS | 3 | 1208- | NQR71 | 01.240 (A) ID=14 L=4 7 | ||
| 552 | I0-91180 108-0 | NUT; BRKT,HARNESS | 2 | 1208- | NQR71 | |||
| 48 | I1-09707 142-1 | CLIP; FRAME HARNESS | 1 | 1208- | NQR71 | 03.483 (B) L=450 | ||
| 516 | I8-98063 767-0 | BOLT; HARNESS | 1 | 1208- | NQR71 | |||
| 53 | I8-98114 461-2 | BRACKET; HARNESS | 1 | 1208- | NQR71 |
