| 45 |
8-97355 124-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 7 |
| 61 |
8-94468 020-2 |
|
BOLT CLAMP NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 43 |
8-97223 393-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=3.00 |
| 137 |
8-98211 776-0 |
|
PIPE ASM LEAK OFF |
1 |
1602- |
|
BCD |
(A) |
| 290 |
8-98178 706-0 |
|
SENSOR PRESS |
1 |
1602- |
|
D |
|
| 43 |
8-97223 379-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.72 |
| 43 |
8-97223 362-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .38 |
| 45 |
8-97355 122-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 5 |
| 18 |
8-97373 734-0 |
|
PIPE INJ NO.3 |
1 |
1602- |
|
A |
|
| 44 |
1-15343 003-0 |
|
SPRING NOZZLE,NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 175 |
1-15619 508-0 |
|
GASKET EYE BOLT,OUTLET,FUEL FEE |
2 |
1602- |
|
BCD |
ID=10.2 OD=15.2 |
| 45 |
8-97355 126-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 9 |
| 17 |
8-97365 210-0 |
|
PIPE INJ NO.2 |
1 |
1602- |
|
A |
|
| 45 |
8-97355 149-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 2 |
| 45 |
8-97355 116-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.2 9 |
| 122 |
8-97315 286-0 |
|
CLIP LEAK OFF PIPE |
4 |
1602- |
|
BCD |
|
| 45 |
8-97355 114-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.2 7 |
| 29 |
8-97944 126-0 |
|
CLIP HOSE |
10 |
1602- |
|
BCD |
ID=10.5 |
| 43 |
8-97223 360-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .34 |
| 45 |
8-97355 132-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 5 |
| 34 |
8-94320 307-0 |
|
BOLT EYE,NOZZLE HOLDER |
4 |
1602- |
|
A |
3306 |
| 43 |
8-97223 388-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.90 |
| 45 |
8-97355 137-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 0 |
| 199 |
8-97602 218-0 |
|
GASKET EYE BOLT |
2 |
1602- |
|
D |
|
| 45 |
8-97355 130-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 3 |
| 408 |
8-98155 988-3 |
|
PUMP ASM FUEL,SUPPLY |
1 |
1602- |
|
BC |
|
| 43 |
8-97223 375-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 . 64 |
| 211 |
8-98151 214-0 |
|
RAIL ASM COMMON |
1 |
1602- |
|
D |
|
| 31 |
8-98260 109-0 |
|
NOZZLE ASM INJ |
4 |
1602- |
|
D |
|
| 66 |
8-98181 540-0 |
|
GASKET INJ NOZZLE |
4 |
1602- |
|
BCD |
|
| 43 |
8-97223 357-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .28 |
| 140 |
1-15349 044-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0.52 |
| 43 |
8-97223 351-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.16 |
| 45 |
8-97355 125-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 8 |
| 43 |
8-97223 371-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.56 |
| 45 |
8-97355 152-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 5 |
| 45 |
8-97355 148-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.61 |
| 43 |
8-97223 387-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .88 |
| 445 |
8-98209 778-0 |
|
SCREW FILTER,INLET |
1 |
1602- |
|
BCD |
|
| 43 |
8-97223 343-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.00 |
| 45 |
8-97355 173-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 6 |
| 80 |
8-97368 671-0 |
|
BRACKET PUMP |
1 |
1602- |
|
A |
(B) |
| 140 |
8-97116 034-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 40 |
| 283 |
8-98228 566-0 |
|
BOLT COMMON RAIL |
3 |
1602- |
|
BC |
(B) M8X6 6 FLANGE |
| 43 |
8-97223 377-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .68 |
| 9 |
0-41010 630-0 |
|
STUD CLIP |
2 |
1602- |
|
BCD |
00.413 M6X30 L=38 |
| 43 |
8-97223 369-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.52 |
| 45 |
8-97355 161-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.74 |
| 45 |
8-97355 178-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.91 |
| 43 |
8-97223 359-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .32 |
| 1 |
8-97350 393-4 |
|
PUMP ASM INJ |
1 |
1602- |
|
A |
AIR CONDITIONER MANUAL CO EMISSION SYSTEM R15-04<K7 |
| 140 |
1-15349 048-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0 .60 |
| 140 |
8-97116 029-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 10 |
| 43 |
8-97223 349-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.12 |
| 43 |
8-97223 391-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.96 |
| 43 |
8-97223 381-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.76 |
| 140 |
8-97116 043-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0.58 |
| 140 |
1-15349 004-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=1 . 20 |
| 47 |
8-97223 340-0 |
|
SPACER NOZZLE SPRING,NOZZLE HOL |
4 |
1602- |
|
A |
|
| 45 |
8-97355 162-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 5 |
| 93 |
8-97375 236-0 |
|
GASKET LEAK OFF PIPE |
4 |
1602- |
|
A |
|
| 43 |
8-97223 374-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 . 62 |
| 140 |
8-97116 041-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0.56 |
| 45 |
8-97355 134-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 7 |
| 18 |
8-98223 196-0 |
|
PIPE INJ NO.3 |
1 |
1602- |
|
BC |
|
| 45 |
8-97355 182-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.94 |
| 45 |
8-97355 147-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 0 |
| 43 |
8-97223 346-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.06 |
| 45 |
8-97355 127-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 0 |
| 45 |
8-97355 163-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 6 |
| 72 |
0-50551 020-0 |
|
BOLT BRKT TO INJ PUMP |
2 |
1602- |
|
A |
M10X20 W/LK WASHER |
| 140 |
8-97116 035-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 50 |
| 76 |
0-50540 825-0 |
|
BOLT BRKT TO BRKT |
2 |
1602- |
|
A |
09.008 M8X2 5 W/LK WASHER |
| 43 |
8-97223 352-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.18 |
| 45 |
8-97355 170-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 3 |
| 68 |
8-97330 118-3 |
|
CLIP INJ PIPE |
2 |
1602- |
|
D |
(C) ID= 7 & 7 L=2 2 |
| 424 |
8-98145 455-1 |
|
OVERHAUL KIT SUPPLY PUMP |
1 |
1602- |
|
BCD |
|
| 45 |
8-97355 142-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 5 |
| 78 |
0-28650 820-0 |
|
BOLT BRKT TO C/BL |
2 |
1602- |
|
A |
01. 531 M8X2 0 FLANGE |
| 45 |
8-97355 151-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 4 |
| 43 |
8-97223 368-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.50 |
| 272 |
8-97362 572-0 |
|
NOZZLE KIT INJ |
4 |
1602- |
|
A |
|
| 45 |
8-97355 146-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 9 |
| 43 |
8-97223 350-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.14 |
| 43 |
8-97223 383-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .80 |
| 45 |
8-97355 160-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.73 |
| 45 |
8-97355 135-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 8 |
| 283 |
8-98174 080-0 |
|
BOLT COMMON RAIL |
3 |
1602- |
|
D |
(C) M8X2 5 FLANGE |
| 43 |
8-97223 385-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 . 84 |
| 31 |
8-98246 130-0 |
|
NOZZLE ASM INJ |
4 |
1602- |
|
B |
|
| 45 |
8-97355 133-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 6 |
| 313 |
8-98228 637-0 |
|
BOLT BRKT,INJ NOZZLE |
4 |
1602- |
|
BC |
M8X8 5 W/WASHER |
| 45 |
8-97355 138-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.51 |
| 282 |
8-98158 715-2 |
|
BRACKET COMMON RAIL |
1 |
1602- |
|
D |
|
| 43 |
8-97223 367-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .48 |
| 140 |
8-97116 040-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 55 |
| 45 |
8-97355 139-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.52 |
| 43 |
8-97223 378-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.70 |
| 282 |
8-98205 942-0 |
|
BRACKET COMMON RAIL |
1 |
1602- |
|
BC |
|
| 43 |
8-97223 358-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .30 |
| 17 |
8-98158 730-0 |
|
PIPE INJ NO.2 |
1 |
1602- |
|
D |
|
| 290 |
8-98181 616-0 |
|
SENSOR PRESS |
1 |
1602- |
|
BC |
|
| 45 |
8-97355 150-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 3 |
| 45 |
8-97355 115-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.2 8 |
| 45 |
8-97355 179-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.92 |
| 30 |
8-98053 693-0 |
|
HOSE RUBBER,FUEL LEAK |
3 |
1602- |
|
BCD |
(A) L=96 |
| 140 |
8-97116 039-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0.54 |
| 45 |
8-97355 117-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 0 |
| 45 |
8-97355 157-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 0 |
| 45 |
8-97355 153-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 6 |
| 16 |
8-98223 194-0 |
|
PIPE INJ NO.1 |
1 |
1602- |
|
BC |
|
| 313 |
8-98095 575-0 |
|
BOLT BRKT,INJ NOZZLE |
4 |
1602- |
|
D |
M8X50 W/WASHER |
| 45 |
8-97355 166-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 9 |
| 45 |
8-97355 167-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 0 |
| 43 |
8-97223 373-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .60 |
| 137 |
8-98158 737-1 |
|
PIPE ASM LEAK OFF |
1 |
1602- |
|
BCD |
(C) |
| 43 |
8-97223 389-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.92 |
| 140 |
8-97116 044-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 59 |
| 43 |
8-97223 363-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .40 |
| 45 |
8-97355 112-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.2 5 |
| 68 |
1-09701 240-0 |
|
CLIP INJ PIPE |
4 |
1602- |
|
A |
03.634 (D) ID= 5.5 & 5.5 L=13 |
| 45 |
8-97355 118-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.31 |
| 45 |
8-97355 131-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 4 |
| 45 |
8-97355 154-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 7 |
| 43 |
8-97223 384-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 . 82 |
| 43 |
8-97223 365-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .44 |
| 31 |
8-97382 946-0 |
|
NOZZLE ASM INJ |
4 |
1602- |
|
A |
|
| 30 |
8-98135 263-1 |
|
HOSE RUBBER,FUEL LEAK |
1 |
1602- |
|
A |
(B) L=3 2 0 |
| 43 |
8-97223 370-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.54 |
| 45 |
8-97355 129-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 2 |
| 45 |
8-97355 140-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.53 |
| 45 |
8-97355 158-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.71 |
| 110 |
0-91180 106-0 |
|
NUT CLIP |
2 |
1602- |
|
ABCD |
01. 062 M6 FLANGE |
| 1 |
8-97350 394-3 |
|
PUMP ASM INJ |
1 |
1602- |
|
A |
HEATER & DEFROSTER(C42) EMISSION SYSTEM R15-04<K7 |
| 16 |
8-98158 729-0 |
|
PIPE INJ NO.1 |
1 |
1602- |
|
D |
|
| 140 |
8-97116 033-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 30 |
| 211 |
8-98228 475-0 |
|
RAIL ASM COMMON |
1 |
1602- |
|
BC |
|
| 140 |
1-15349 049-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0 . 70 |
| 17 |
8-98223 195-1 |
|
PIPE INJ NO.2 |
1 |
1602- |
|
BC |
|
| 347 |
8-98165 035-0 |
|
PIN |
4 |
1602- |
|
BCD |
|
| 137 |
8-98211 775-0 |
|
PIPE ASM LEAK OFF |
3 |
1602- |
|
BCD |
(B) |
| 382 |
8-98161 995-0 |
|
KEY DRIVE SHAFT |
1 |
1602- |
|
BCD |
|
| 31 |
8-98106 693-2 |
|
NOZZLE ASM INJ |
4 |
1602- |
|
C |
|
| 43 |
8-97223 380-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.74 |
| 216 |
8-98043 033-0 |
|
BOLT EYE |
1 |
1602- |
|
D |
(B) M10X23 EYE-BOLT |
| 19 |
8-98158 732-0 |
|
PIPE INJ NO.4 |
1 |
1602- |
|
D |
|
| 166 |
9-09566 111-0 |
|
GASKET FUEL INJECTOR |
4 |
1602- |
|
BCD |
03 . 332 ID=11 OD=14.8 |
| 140 |
8-97116 038-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0.53 |
| 43 |
8-97223 366-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .46 |
| 140 |
1-15349 047-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0.58 |
| 45 |
8-97355 120-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 3 |
| 45 |
8-97355 169-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 2 |
| 289 |
8-98138 695-0 |
|
LIMITER FUEL PRESS |
1 |
1602- |
|
D |
|
| 16 |
8-97373 733-0 |
|
PIPE INJ NO.1 |
1 |
1602- |
|
A |
|
| 216 |
8-98209 777-0 |
|
BOLT EYE |
1 |
1602- |
|
BCD |
(A) |
| 66 |
8-97171 331-0 |
|
GASKET INJ NOZZLE |
4 |
1602- |
|
A |
ID= 7.2 OD=15.0 T=6.6 |
| 43 |
8-97223 354-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .22 |
| 32 |
8-97217 835-0 |
|
HOLDER ASM NOZZLE |
4 |
1602- |
|
A |
|
| 45 |
8-97355 171-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 4 |
| 43 |
8-97223 376-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .66 |
| 43 |
8-97223 372-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.58 |
| 341 |
8-97365 211-1 |
|
BRACKET CLIP,INJ PIPE |
1 |
1602- |
|
A |
(A) |
| 45 |
8-97355 136-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.4 9 |
| 35 |
1-15349 041-0 |
|
NUT NOZZLE RET,NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 45 |
8-97355 168-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.81 |
| 45 |
8-97355 123-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 6 |
| 45 |
8-97355 145-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 8 |
| 45 |
8-97355 155-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 8 |
| 205 |
8-98023 581-0 |
|
SENSOR FUEL TEMP |
1 |
1602- |
|
BCD |
|
| 219 |
1-09623 541-0 |
|
GASKET |
1 |
1602- |
|
BCD |
ID=49.7 |
| 80 |
8-97368 670-0 |
|
BRACKET PUMP |
1 |
1602- |
|
A |
(A) |
| 45 |
8-97355 144-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 7 |
| 1 |
8-97350 398-3 |
|
PUMP ASM INJ |
1 |
1602- |
|
A |
HEATER & DEFROSTER(C42) EURO1 SPECIFICATION<NT1> |
| 140 |
8-97116 036-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 51 |
| 43 |
8-97223 392-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.98 |
| 68 |
8-98227 926-0 |
|
CLIP INJ PIPE |
1 |
1602- |
|
A |
(E) |
| 1 |
8-97350 396-4 |
|
PUMP ASM INJ |
1 |
1602- |
|
A |
AIR CONDITIONER MANUAL CO EURO1 SPECIFICATION<NT1> |
| 408 |
8-98151 213-2 |
|
PUMP ASM FUEL,SUPPLY |
1 |
1602- |
|
D |
|
| 68 |
8-97330 119-3 |
|
CLIP INJ PIPE |
2 |
1602- |
|
D |
(B) ID=7 & 7 L=22 |
| 210 |
8-98158 733-0 |
|
PIPE INJ,C/R |
1 |
1602- |
|
D |
|
| 45 |
8-97355 165-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 8 |
| 45 |
8-97355 174-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 7 |
| 19 |
8-98223 197-0 |
|
PIPE INJ NO.4 |
1 |
1602- |
|
BC |
|
| 43 |
8-97223 386-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .86 |
| 63 |
8-94467 727-3 |
|
PIPE FUEL,NOZZLE LEAK OFF |
1 |
1602- |
|
A |
|
| 43 |
8-97361 697-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(A) |
| 140 |
8-97116 032-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 20 |
| 45 |
8-97355 113-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.2 6 |
| 45 |
8-97355 159-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.72 |
| 43 |
8-97223 347-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.08 |
| 138 |
8-94174 141-0 |
|
SPRING NOZZLE LWR,NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 43 |
8-97223 353-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .20 |
| 68 |
8-98148 996-2 |
|
CLIP INJ PIPE |
4 |
1602- |
|
BC |
(A) ID=11 & 11 L=19 |
| 45 |
8-97355 176-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 9 |
| 45 |
8-97355 143-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.5 6 |
| 341 |
8-97333 806-1 |
|
BRACKET CLIP,INJ PIPE |
1 |
1602- |
|
A |
(B) |
| 140 |
1-15349 046-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0.56 |
| 210 |
8-98233 237-0 |
|
PIPE INJ,C/R |
1 |
1602- |
|
BC |
|
| 45 |
8-97355 128-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.41 |
| 283 |
8-98174 180-0 |
|
BOLT COMMON RAIL |
4 |
1602- |
|
D |
(A) M8X40 FLANGE |
| 43 |
8-97223 344-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.02 |
| 43 |
8-97223 382-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.78 |
| 45 |
8-97355 175-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 8 |
| 43 |
8-97223 355-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .24 |
| 43 |
8-97223 356-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .26 |
| 59 |
8-97259 884-0 |
|
CLAMP NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 59 |
8-98092 539-0 |
|
CLAMP NOZZLE HOLDER |
4 |
1602- |
|
BCD |
|
| 29 |
8-97173 219-0 |
|
CLIP HOSE |
2 |
1602- |
|
A |
03.163 ID=11 |
| 45 |
8-97355 164-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.7 7 |
| 45 |
8-97355 121-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 4 |
| 140 |
8-97116 037-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0.52 |
| 289 |
8-98032 549-0 |
|
LIMITER FUEL PRESS |
1 |
1602- |
|
BC |
|
| 45 |
8-97355 177-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.9 0 |
| 30 |
8-98189 998-0 |
|
HOSE RUBBER,FUEL LEAK |
1 |
1602- |
|
BCD |
(D) |
| 45 |
8-97355 172-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.8 5 |
| 50 |
8-97287 402-2 |
|
GASKET NOZZLE HOLDER |
4 |
1602- |
|
A |
|
| 30 |
8-98179 014-0 |
|
HOSE RUBBER,FUEL LEAK |
1 |
1602- |
|
BCD |
(C) |
| 140 |
1-15349 045-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(A) T=0.54 |
| 18 |
8-98158 731-0 |
|
PIPE INJ NO.3 |
1 |
1602- |
|
D |
|
| 45 |
8-97355 141-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.54 |
| 43 |
8-97223 345-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.04 |
| 43 |
8-97223 390-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.94 |
| 45 |
8-97355 119-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.3 2 |
| 81 |
0-91614 708-0 |
|
WASHER PL,BRKT TO PUMP |
2 |
1602- |
|
A |
02.277 ID= 8.4 OD=22 |
| 43 |
8-97223 361-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .36 |
| 45 |
8-97355 156-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.6 9 |
| 43 |
8-97223 364-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2 .42 |
| 43 |
8-97223 348-0 |
|
SEAT NOZZLE SPRING,NOZZLE HOLDE |
4 |
1602- |
|
A |
(B) T=2.10 |
| 45 |
8-97355 180-0 |
|
ROD PUSH,NOZZLE HOLDER |
4 |
1602- |
|
A |
L=3 8.93 |
| 140 |
8-97116 042-0 |
|
SHIM NOZZLE SPRING,NOZZLE HOLDE |
AR |
1602- |
|
A |
(B) T=0 . 57 |
| 19 |
8-97373 735-0 |
|
PIPE INJ NO.4 |
1 |
1602- |
|
A |
|
