| 338 |
8-97910 296-1 |
|
BOLT JOINT,OIL PIPE |
2 |
1602- |
|
BCD |
M8X20 EYE-BOLT |
| 248 |
8-94315 336-1 |
|
CONNECTOR TURBOCHARGER OIL FEED |
1 |
1602- |
|
A |
M14X25 |
| 499 |
8-98258 938-0 |
|
PIPE VACUUM |
1 |
1602- |
|
BC |
EMISSION SYSTEM R15-04<K7 (C) |
| 2 |
1-09675 086-0 |
|
BOLT EYE,OIL PIPE |
1 |
1602- |
|
BCD |
03.162 (E) M14X2 7 FLANGE |
| 31 |
8-98186 104-0 |
|
NIPPLE OIL PIPE |
1 |
1602- |
|
BCD |
(B) |
| 110 |
8-98251 964-0 |
|
NUT CAP OIL PIPE |
1 |
1602- |
|
BCD |
M8 CAP NUT FLANGE |
| 458 |
8-94217 809-0 |
|
CAP RUBBER |
1 |
1602- |
|
A |
HEATER & DEFROSTER(C42) EMISSION SYSTEM R15-04<K7 01.780 ID=4 |
| 586 |
8-98186 103-2 |
|
PIPE OIL,TENSIONER |
1 |
1602- |
|
D |
(B) |
| 26 |
8-97923 928-0 |
|
PIPE OIL,PUMP TO C/BL |
1 |
1602- |
|
A |
|
| 58 |
8-98285 334-0 |
|
VALVE RELIEF,OIL JET,PISTON COO |
1 |
1602- |
|
A |
|
| 149 |
8-98151 189-0 |
|
PIPE OIL RETURN,TURBOCHARGER |
1 |
1602- |
|
D |
(D) |
| 500 |
0-08508 230-0 |
|
HOSE VACUUM |
1 |
1602- |
|
D |
(B) |
| 46 |
8-98137 710-0 |
|
BOLT JOINT,OIL FEED PIPE,VAC PU |
1 |
1602- |
|
A |
M8X2 0 FLANGE |
| 29 |
0-28050 810-0 |
|
BOLT OIL PIPE,OIL JET |
1 |
1602- |
|
ABCD |
03.407 (A) M8X10 FLANGE |
| 147 |
8-98029 475-0 |
|
GASKET OIL PIPE TO TURBOCHARGER |
2 |
1602- |
|
D |
(D) ID=16 |
| 3 |
9-09571 414-0 |
|
GASKET EYE BOLT,OIL PIPE |
2 |
1602- |
|
A |
08.955 ID=14.2 OD=2 0.0 |
| 311 |
0-28050 812-0 |
|
BOLT PIPE FIX |
2 |
1602- |
|
A |
02 . 343 (A) M8X12 FLANGE |
| 149 |
8-97333 749-1 |
|
PIPE OIL RETURN,TURBOCHARGER |
1 |
1602- |
|
A |
(A) |
| 407 |
8-98251 964-0 |
|
NUT CAP,TURBOCHARGE R OIL FEED P |
1 |
1602- |
|
D |
M8 CAP NUT FLANGE |
| 47 |
9-09571 408-0 |
|
GASKET OIL PIPE |
1 |
1602- |
|
A |
05.398 (A) ID= 8.2 OD=14.0 T=1.0 |
| 147 |
8-94362 672-1 |
|
GASKET OIL PIPE TO TURBOCHARGER |
1 |
1602- |
|
A |
03.358 (E) |
| 2 |
8-94443 535-0 |
|
BOLT EYE,OIL PIPE |
1 |
1602- |
|
A |
(A) M10X2 7 FLANGE |
| 219 |
0-28650 635-0 |
|
BOLT CLIP FIX,OIL PIPE |
1 |
1602- |
|
A |
03.162 M6X3 5 FLANGE |
| 57 |
8-97312 132-3 |
|
PIPE OIL,OIL JET |
1 |
1602- |
|
BCD |
|
| 586 |
8-98228 274-0 |
|
PIPE OIL,TENSIONER |
1 |
1602- |
|
BC |
(D) |
| 27 |
0-28050 810-0 |
|
BOLT OIL PIPE FIX |
1 |
1602- |
|
A |
03.407 M8X10 FLANGE |
| 331 |
8-97108 102-0 |
|
CLAMP VAC HOSE,PUMP RETURN |
1 |
1602- |
|
A |
|
| 308 |
8-97362 329-3 |
|
HOSE OIL COOLER FEED |
1 |
1602- |
|
A |
|
| 581 |
0-28050 816-0 |
|
BOLT VSV |
1 |
1602- |
|
BC |
EURO1 SPECIFICATION<NT1>, ATION<NT2 >,EURO4 SPECIFIC 02 . 343 M8X16 FLANGE |
| 252 |
8-98177 334-2 |
|
HOSE RUBBER,TURBOCHARGER RETURN |
1 |
1602- |
|
D |
|
| 28 |
8-98065 992-0 |
|
GASKET OIL PIPE |
2 |
1602- |
|
BCD |
03 . 332 (A) ID= 8.3 OD=15.0 |
| 57 |
8-94469 992-2 |
|
PIPE OIL,OIL JET |
1 |
1602- |
|
A |
|
| 414 |
0-58330 616-0 |
|
BOLT OIL PIPE |
4 |
1602- |
|
D |
00.724 M6X16 HEX SOCKET |
| 248 |
8-97944 505-1 |
|
CONNECTOR TURBOCHARGER OIL FEED |
1 |
1602- |
|
BC |
01.531 M10X24 |
| 149 |
8-98156 381-0 |
|
PIPE OIL RETURN,TURBOCHARGER |
1 |
1602- |
|
BC |
(B) |
| 58 |
8-97379 464-0 |
|
VALVE RELIEF,OIL JET,PISTON COO |
1 |
1602- |
|
BCD |
|
| 147 |
9-09571 410-0 |
|
GASKET OIL PIPE TO TURBOCHARGER |
2 |
1602- |
|
ABC |
08.955 (B) ID=10.2 OD=16.0 |
| 580 |
8-97352 145-0 |
|
VALVE VAC SW |
1 |
1602- |
|
BC |
EURO1 SPECIFICATION<NT1>, ATION<NT2 >,EURO4 SPECIFIC 03.670 |
| 40 |
0-28050 616-0 |
|
BOLT OIL PIPE |
2 |
1602- |
|
A |
09. 242 M6X16 FLANGE |
| 87 |
9-09571 408-0 |
|
GASKET JOINT BOLT |
1 |
1602- |
|
D |
05.398 ID= 8.2 OD=14.0 T=1 . 0 |
| 499 |
8-98132 058-2 |
|
PIPE VACUUM |
1 |
1602- |
|
BCD |
(D) |
| 150 |
8-97045 326-1 |
|
GASKET OIL PIPE TO C/BL |
1 |
1602- |
|
A |
|
| 2 |
8-98186 729-0 |
|
BOLT EYE,OIL PIPE |
1 |
1602- |
|
D |
(C) M10X27 |
| 563 |
0-41010 820-0 |
|
STUD OIL PIPE |
2 |
1602- |
|
BCD |
02.510 M8X20 L=32 |
| 248 |
8-98178 353-1 |
|
CONNECTOR TURBOCHARGER OIL FEED |
1 |
1602- |
|
D |
M10X24 |
| 567 |
8-94107 762-0 |
|
CLIP PIPE |
1 |
1602- |
|
A |
HEATER & DEFROSTER(C42) EMISSION SYSTEM R15-04<K7 03.145 ID=8 |
| 586 |
8-98251 165-0 |
|
PIPE OIL,TENSIONER |
1 |
1602- |
|
BC |
(C) |
| 63 |
8-98132 014-1 |
|
PIPE OIL,TURBOCHARGER FEED |
1 |
1602- |
|
BC |
(B) |
| 31 |
8-98178 328-2 |
|
NIPPLE OIL PIPE |
1 |
1602- |
|
D |
(A) |
| 310 |
8-97010 605-0 |
|
CLIP WATER HOSE FIX |
2 |
1602- |
|
A |
01.150 (B) ID=24 |
| 2 |
8-98151 063-1 |
|
BOLT EYE,OIL PIPE |
1 |
1602- |
|
BC |
(B) M10X2 5 FLANGE |
| 311 |
0-28050 816-0 |
|
BOLT PIPE FIX |
3 |
1602- |
|
BC |
02 . 343 (B) M8X16 FLANGE |
| 2 |
8-98108 689-0 |
|
BOLT EYE,OIL PIPE |
1 |
1602- |
|
BCD |
(D) M8X23 FLANGE |
| 63 |
8-97350 308-0 |
|
PIPE OIL,TURBOCHARGER FEED |
1 |
1602- |
|
A |
(A) |
| 331 |
8-97108 102-0 |
|
CLAMP VAC HOSE,PUMP RETURN |
1 |
1602- |
|
A |
|
| 149 |
8-98151 190-2 |
|
PIPE OIL RETURN,TURBOCHARGER |
1 |
1602- |
|
D |
(C) |
| 332 |
8-97942 810-0 |
|
PIPE OIL,C/BL TO VAC PUMP |
1 |
1602- |
|
A |
|
| 310 |
8-94125 862-1 |
|
CLIP WATER HOSE FIX |
6 |
1602- |
|
A |
01.166 (A) ID=20.8 |
| 309 |
8-97256 047-1 |
|
HOSE OIL COOLER RETURN |
1 |
1602- |
|
A |
(A) |
| 28 |
8-98113 762-0 |
|
GASKET OIL PIPE |
1 |
1602- |
|
BCD |
(B) ID=14.2 OD=2 0.0 |
| 534 |
0-91180 208-0 |
|
NUT OIL PIPE |
2 |
1602- |
|
BCD |
01.540 M8 FLANGE |
| 313 |
0-28050 812-0 |
|
BOLT PIPE BRKT |
1 |
1602- |
|
A |
02 . 343 M8X12 FLANGE |
| 586 |
8-98186 102-2 |
|
PIPE OIL,TENSIONER |
1 |
1602- |
|
D |
(A) |
| 500 |
0-08508 090-0 |
|
HOSE VACUUM |
1 |
1602- |
|
BCD |
(A) |
| 28 |
5-09623 002-0 |
|
GASKET OIL PIPE |
2 |
1602- |
|
A |
01.516 (C) ID=11 |
| 47 |
9-09571 410-0 |
|
GASKET OIL PIPE |
2 |
1602- |
|
A |
08.955 (B) ID=10.2 OD=16.0 |
| 500 |
8-98228 438-0 |
|
HOSE VACUUM |
1 |
1602- |
|
BC |
EURO1 SPECIFICATION<NT1>, ATION<NT2 >,EURO4 SPECIFIC (D) |
| 332 |
8-98233 768-0 |
|
PIPE OIL,C/BL TO VAC PUMP |
1 |
1602- |
|
BC |
|
| 100 |
0-28050 812-0 |
|
BOLT CLIP |
1 |
1602- |
|
BCD |
02 . 343 M8X12 FLANGE |
| 118 |
8-97350 307-2 |
|
BRACKET CLIP,OIL PIPE |
1 |
1602- |
|
A |
|
| 267 |
8-94478 875-0 |
|
CLIP HOSE |
2 |
1602- |
|
D |
01.540 ID=18.9 |
| 414 |
0-28050 616-0 |
|
BOLT OIL PIPE |
2 |
1602- |
|
BC |
09.242 M6X16 FLANGE |
| 89 |
0-95235 536-0 |
|
CLIP VAC HOSE |
1 |
1602- |
|
BCD |
ID=16 L=20 |
| 311 |
0-28050 616-0 |
|
BOLT PIPE FIX |
2 |
1602- |
|
D |
09. 242 (C) M6X16 FLANGE |
| 29 |
0-50640 625-0 |
|
BOLT OIL PIPE,OIL JET |
4 |
1602- |
|
A |
(C) M6X2 5 W/LK&PL WASHER |
| 339 |
9-09571 408-0 |
|
GASKET OIL PIPE |
4 |
1602- |
|
BCD |
05.398 ID= 8.2 OD=14.0 T=1.0 |
| 150 |
8-98132 018-1 |
|
GASKET OIL PIPE TO C/BL |
1 |
1602- |
|
BCD |
|
| 309 |
8-97213 919-2 |
|
HOSE OIL COOLER RETURN |
1 |
1602- |
|
A |
(B) |
| 500 |
8-98228 437-0 |
|
HOSE VACUUM |
1 |
1602- |
|
BC |
(C) |
| 499 |
8-98228 436-0 |
|
PIPE VACUUM |
1 |
1602- |
|
BC |
EURO1 SPECIFICATION<NT1>,E ATION<NT2 >,EURO4 SPECIFIC (B) |
| 311 |
0-28050 816-0 |
|
BOLT PIPE FIX |
2 |
1602- |
|
D |
02 . 343 (B) M8X16 FLANGE |
| 147 |
8-98132 017-0 |
|
GASKET OIL PIPE TO TURBOCHARGER |
1 |
1602- |
|
BC |
(A) |
| 63 |
8-98178 927-1 |
|
PIPE OIL,TURBOCHARGER FEED |
1 |
1602- |
|
D |
(D) |
| 28 |
9-09571 408-0 |
|
GASKET OIL PIPE |
1 |
1602- |
|
BC |
05.398 (D) ID= 8.2 OD=14.0 T=1.0 |
| 44 |
0-28650 820-0 |
|
BOLT CLIP,OIL PIPE |
1 |
1602- |
|
A |
M8X2 0 FLANGE |
| 63 |
8-98178 928-0 |
|
PIPE OIL,TURBOCHARGER FEED |
1 |
1602- |
|
D |
(C) |
| 29 |
8-97380 673-1 |
|
BOLT OIL PIPE,OIL JET |
4 |
1602- |
|
BCD |
(B) M6X2 0 FLANGE |
| 500 |
8-98228 430-0 |
|
HOSE VACUUM |
1 |
1602- |
|
BC |
EURO1 SPECIFICATION<NT1>, ATION<NT2 >,EURO4 SPECIFIC (E) |
| 147 |
8-98065 992-0 |
|
GASKET OIL PIPE TO TURBOCHARGER |
2 |
1602- |
|
D |
03 . 332 (C) ID= 8.3 OD=15.0 |
| 3 |
8-98136 142-0 |
|
GASKET EYE BOLT,OIL PIPE |
1 |
1602- |
|
BC |
ID=10.2 |
| 47 |
9-09571 408-0 |
|
GASKET OIL PIPE |
2 |
1602- |
|
A |
05.398 (A) ID= 8.2 OD=14.0 T=1.0 |
| 3 |
8-98136 142-0 |
|
GASKET EYE BOLT,OIL PIPE |
2 |
1602- |
|
D |
ID=10.2 |
| 332 |
8-98038 929-0 |
|
PIPE OIL,C/BL TO VAC PUMP |
1 |
1602- |
|
D |
|
| 48 |
1-09701 228-3 |
|
CLIP OIL PIPE |
1 |
1602- |
|
A |
ID= 7 & 9 L=2 5 |
| 499 |
8-98172 379-0 |
|
PIPE VACUUM |
1 |
1602- |
|
D |
(E) |
| 79 |
8-97581 233-0 |
|
NUT OIL DRAIN PIPE |
2 |
1602- |
|
A |
04.634 M8 FLANGE |
| 138 |
0-28050 816-0 |
|
BOLT CLIP FIX |
1 |
1602- |
|
BCD |
02 . 343 M8X16 FLANGE |
| 330 |
8-98189 794-0 |
|
HOSE VAC PUMP,RETURN |
1 |
1602- |
|
A |
|
| 499 |
8-98011 527-1 |
|
PIPE VACUUM |
1 |
1602- |
|
BCD |
(A) |
