| 2 |
8-97359 818-0 |
|
BOLT EYE,SLAVE CYL |
2 |
1602- |
|
ABCDEF |
04.681 M10X22 |
| 5 |
8-98221 241-0 |
|
HOSE FLEX,CLU PIPE |
1 |
1602- |
|
B |
4X4(TFS***) |
| 20 |
0-91180 106-0 |
|
NUT CLU OIL DAMPER |
2 |
1602- |
|
ABCDEF |
01.062 M6 FLANGE |
| 5 |
8-98098 317-1 |
|
HOSE FLEX,CLU PIPE |
1 |
1602- |
|
A CD |
|
| 18 |
8-97946 616-1 |
|
DAMPER ASM CLU OIL |
1 |
1602- |
|
ABCDEF |
(A) |
| 80 |
8-97947 824-0 |
|
CLIP HOSE |
2 |
1602- |
|
ABCDEF |
ID=12 WO/PVC COATING |
| 18 |
8-97946 623-1 |
|
DAMPER ASM CLU OIL |
1 |
1602- |
|
EF |
(B) |
| 57 |
8-98119 218-2 |
|
HOSE CLU M/CYL TO OIL TANK |
1 |
1602- |
|
EF |
(B) |
| 178 |
9-09571 410-0 |
|
GASKET FLEX HOSE TO M/CYL |
4 |
1602- |
|
ABCDEF |
08 . 955 ID=10.2 OD=16.0 |
| 230 |
0-28650 616-0 |
|
BOLT ACTUATOR |
2 |
1602- |
|
EF |
02 .343 M6X16 FLANGE |
| 5 |
8-98098 317-1 |
|
HOSE FLEX,CLU PIPE |
1 |
1602- |
|
B |
4X2(TFB** *) |
| 15 |
8-98097 509-0 |
|
PIPE CLU,FLEX HOSE |
1 |
1602- |
|
EF |
|
| 57 |
8-98097 543-1 |
|
HOSE CLU M/CYL TO OIL TANK |
1 |
1602- |
|
ABCD |
(A) |
| 208 |
8-98100 268-1 |
|
PIPE OIL,M/CYL TO DAMPER CYL |
1 |
1602- |
|
ABCDEF |
|
| 5 |
8-98098 315-1 |
|
HOSE FLEX,CLU PIPE |
1 |
1602- |
|
EF |
|
