2-10 | REPAIR KIT TRANSMISSION OVERHAUL
DMAX
D-MAX 2016
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 1 | 5-87832 204-2 | GASKET SET TRANS OVERHAUL | 1 | 1602- | A | |||
| 1 | 5-87832 371-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | B | 4X4 (TFS***) EXC. IDENTIFICATION LABEL FOR KD > | ||
| 1 | 5-87832 289-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | BC | 4X2(TFB***) EXC. IDENTIFICATION LABEL FOR KD > | ||
| 1 | 5-87832 278-2 | GASKET SET TRANS OVERHAUL | 1 | 1602- | B | 4X2(TFB***) CONGO EQUIPMENT(CDF) | ||
| 1 | 5-87832 374-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | C | IDENTIFICATION LABEL FOR KD<6UT> | ||
| 1 | 5-87832 373-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | B | 4X4(TFS***) IDENTIFICATION LABEL FOR KD<6UT> | ||
| 1 | 5-87832 278-2 | GASKET SET TRANS OVERHAUL | 1 | 1602- | D | |||
| 1 | 5-87832 374-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | B | 4X2 (TFB***) IDENTIFICATION LABEL FOR KD<6UT> EXC. CONGO EQUIPMENT(CDF) | ||
| 1 | 5-87832 263-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | E | 4X4(TFS***) | ||
| 1 | 5-87832 262-0 | GASKET SET TRANS OVERHAUL | 1 | 1602- | E | 4X2(TFB***) |
