| 315 |
8-98203 120-0 |
|
BOLT CASE |
16 |
1602- |
|
F |
(C) |
| 608 |
8-98142 574-0 |
|
GUTTER OIL |
1 |
1602- |
|
E |
(C) |
| 86 |
0-28650 835-0 |
|
BOLT RR COVER |
3 |
1602- |
|
E |
01.060 (D) M8X3 5 FLANGE |
| 421 |
8-97362 423-1 |
|
COVER RR,TRANS |
1 |
1602- |
|
E |
4X4(TFS***) (F) |
| 316 |
8-94249 524-2 |
|
MAGNET TRANS CASE |
1 |
1602- |
|
BCDE |
|
| 43 |
0-28050 816-0 |
|
BOLT PLATE TO PLATE |
2 0 |
1602- |
|
A |
02 . 343 M8X16 FLANGE |
| 24 |
8-94156 700-0 |
|
COVER CHECK HOLE,DUST |
1 |
1602- |
|
A D |
.852777778 |
| 608 |
8-98203 104-0 |
|
GUTTER OIL |
1 |
1602- |
|
F |
(F) |
| 315 |
0-28050 860-0 |
|
BOLT CASE |
14 |
1602- |
|
E |
04 . 686 (A) M8X6 0 FLANGE |
| 417 |
8-98203 118-0 |
|
PLUG OIL FILLER,TRANS |
2 |
1602- |
|
F |
4X2(TFB***) (B) |
| 43 |
8-97365 376-0 |
|
BOLT PLATE TO PLATE |
2 0 |
1602- |
|
BCD |
04.356 M8X22 FLANGE |
| 114 |
5-09589 004-0 |
|
RING SNAP,BALL BRG |
1 |
1602- |
|
A |
04 . 422 (A) ID=49.6 |
| 82 |
8-98203 115-0 |
|
PLUG SCREW,CASE |
1 |
1602- |
|
F |
|
| 41 |
8-97214 402-0 |
|
SPRING DETENT BALL |
1 |
1602- |
|
BCD |
(B) L=2 7.6 |
| 429 |
8-98203 096-0 |
|
PIN STRAIGHT |
4 |
1602- |
|
F |
4X2(TFB***) 04.317 (B) |
| 682 |
8-98042 618-0 |
|
BOLT INHIBITOR |
1 |
1602- |
|
E |
M10X50 |
| 24 |
8-97500 668-0 |
|
COVER CHECK HOLE,DUST |
1 |
1602- |
|
F |
|
| 1 |
8-97978 001-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
B |
4X2(TFB***) IDENTIFICATION LABEL FOR EXC. CONGO EQUIPMENT(CDF) |
| 417 |
8-97365 373-0 |
|
PLUG OIL FILLER,TRANS |
1 |
1602- |
|
B EFG |
4X4(TFS***) (A) |
| 435 |
8-98203 101-0 |
|
CASE TRANS |
1 |
1602- |
|
F |
4X4(TFS***) (H) |
| 90 |
8-97046 705-3 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
BC |
4X2 (TFB***) EXC. IDENTIFICATION LABEL > (B) NOK |
| 86 |
0-28050 845-0 |
|
BOLT RR COVER |
16 |
1602- |
|
B EFG |
4X4(TFS***) 09.173 (G) M8X4 5 FLANGE |
| 49 |
8-98035 675-0 |
|
STUD TRANSFER CASE |
1 |
1602- |
|
E |
4X4(TFS***) M10X30 L=4 5 |
| 1 |
8-98102 382-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
E |
4X4(TFS***) |
| 13 |
8-97072 827-0 |
|
SUPPORT SHIFT FORK |
1 |
1602- |
|
ABCDEF |
L=4 7.5 |
| 113 |
8-97113 190-0 |
|
GASKET FRT COVER TO TRANS CASE |
1 |
1602- |
|
A |
|
| 41 |
8-94435 336-0 |
|
SPRING DETENT BALL |
3 |
1602- |
|
A |
(A) L=2 5.6 |
| 677 |
8-97362 852-0 |
|
SPRING INHIBITOR |
1 |
1602- |
|
E |
|
| 79 |
0-28051 035-0 |
|
BOLT TRANSFER CASE |
6 |
1602- |
|
B EF |
4X4(TFS***) M10X3 5 FLANGE |
| 24 |
8-94156 700-0 |
|
COVER CHECK HOLE,DUST |
1 |
1602- |
|
BC |
EXC. IDENTIFICATION LABEL > 06 . 868 |
| 80 |
0-91180 110-0 |
|
NUT TRANSFER CASE |
1 |
1602- |
|
B EF |
4X4(TFS***) 03.162 M10 FLANGE |
| 113 |
8-97083 589-0 |
|
GASKET FRT COVER TO TRANS CASE |
1 |
1602- |
|
BCD |
|
| 40 |
8-94473 947-0 |
|
GASKET DETENT SPR PLATE |
1 |
1602- |
|
A |
|
| 675 |
9-11229 058-1 |
|
DOWEL |
4 |
1602- |
|
E |
OD=11 L= 8 |
| 299 |
8-98203 096-0 |
|
PLUG SHIFTER ROD |
2 |
1602- |
|
F |
(A) |
| 608 |
8-97362 564-1 |
|
GUTTER OIL |
1 |
1602- |
|
E |
(B) |
| 680 |
8-98024 431-0 |
|
BEARING |
1 |
1602- |
|
E |
(B) |
| 421 |
8-98108 319-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
E |
4X4 (TFS***) (E) |
| 45 |
8-97164 900-0 |
|
GASKET FILLER PLUG |
1 |
1602- |
|
F |
4X4(TFS***) |
| 33 |
8-97947 838-0 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
A |
NOK |
| 1 |
8-97978 030-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
B |
4X2(TFB***) CONGO EQUIPMENT(CDF) IDENTIFICATION LABEL FOR |
| 417 |
8-98203 118-0 |
|
PLUG OIL FILLER,TRANS |
1 |
1602- |
|
F |
4X4(TFS***) (B) |
| 603 |
8-98039 270-0 |
|
RING SNAP |
1 |
1602- |
|
E |
|
| 33 |
8-97046 699-3 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
BC |
EXC. IDENTIFICATION LABEL > |
| 50 |
8-97115 712-0 |
|
GASKET DRAIN PLUG |
1 |
1602- |
|
B EFG |
4X4(TFS***) ID=17 |
| 435 |
8-98047 230-0 |
|
CASE TRANS |
1 |
1602- |
|
BCD |
(B) |
| 33 |
8-98203 098-0 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
F |
|
| 102 |
8-97138 673-0 |
|
RETAINER BRG UPR,MAINSHAFT |
1 |
1602- |
|
BCD |
|
| 29 |
0-28650 820-0 |
|
BOLT FRT COVER |
3 |
1602- |
|
E |
01.531 M8X20 FLANGE |
| 680 |
8-97362 853-0 |
|
BEARING |
1 |
1602- |
|
E |
(C) |
| 446 |
8-98203 100-0 |
|
PLUG CASE,TRANS |
1 |
1602- |
|
F |
4X2(TFB***) |
| 421 |
8-97978 059-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
BC |
4X2(TFB***) IDENTIFICATION LABEL FOR (A) |
| 86 |
8-97305 468-0 |
|
BOLT RR COVER |
1 |
1602- |
|
BCD |
(A) M10X18 M10X55 L=86.8 |
| 86 |
8-98035 672-0 |
|
BOLT RR COVER |
3 |
1602- |
|
A |
(B) M10X55 FLANGE |
| 28 |
8-97381 406-0 |
|
COVER FRT,TRANS CASE |
1 |
1602- |
|
D |
|
| 28 |
8-97116 796-0 |
|
COVER FRT,TRANS CASE |
1 |
1602- |
|
A |
|
| 313 |
8-98203 113-0 |
|
SEAL OIL |
1 |
1602- |
|
F |
|
| 90 |
8-98004 531-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
E |
4X4(TFS***) (A) JTEKT |
| 24 |
8-94156 700-0 |
|
COVER CHECK HOLE,DUST |
1 |
1602- |
|
BC |
IDENTIFICATION LABEL FOR 06 . 868 |
| 417 |
8-97365 373-0 |
|
PLUG OIL FILLER,TRANS |
1 |
1602- |
|
ABCDE |
(A) |
| 670 |
8-98203 106-0 |
|
BAFFLE |
1 |
1602- |
|
F |
|
| 678 |
9-08160 436-0 |
|
PIN |
1 |
1602- |
|
E |
|
| 429 |
8-98203 096-0 |
|
PIN STRAIGHT |
2 |
1602- |
|
F |
4X4(TFS***) 04.317 (B) |
| 434 |
8-98108 316-0 |
|
HOUSING CLU |
1 |
1602- |
|
E |
|
| 86 |
0-28050 850-0 |
|
BOLT RR COVER |
2 |
1602- |
|
E |
00.386 (C) M8X50 FLANGE |
| 421 |
8-98191 921-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
BC |
4X2(TFB***) EXC. IDENTIFICATION LABEL > (A) |
| 200 |
8-89048 304-0 |
|
BUSHING SHIFT FORK SHAFT |
1 |
1602- |
|
F |
|
| 49 |
8-98035 677-0 |
|
STUD TRANSFER CASE |
1 |
1602- |
|
B |
4X4(TFS***) EXC. IDENTIFICATION LABEL > M10X27 L=4 3.5 |
| 679 |
0-28050 612-0 |
|
BOLT GUTTER |
4 |
1602- |
|
E |
03.162 M6X12 FLANGE |
| 1 |
8-98147 062-3 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
F |
4X4(TFS***) |
| 39 |
8-98035 571-0 |
|
PLATE DETENT SPR |
1 |
1602- |
|
ABCD |
|
| 676 |
8-98037 604-1 |
|
INHIBITOR |
1 |
1602- |
|
E |
|
| 114 |
5-09589 005-0 |
|
RING SNAP,BALL BRG |
1 |
1602- |
|
A |
04.412 (B) ID=71.7 |
| 435 |
8-98203 177-0 |
|
CASE TRANS |
1 |
1602- |
|
F |
4X2(TFB***) (F) |
| 674 |
8-98042 863-0 |
|
PLATE INTERMEDIATE |
1 |
1602- |
|
E |
|
| 435 |
8-98203 088-0 |
|
CASE TRANS |
1 |
1602- |
|
F |
(D) |
| 33 |
8-97947 839-0 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
BC |
IDENTIFICATION LABEL FOR NOK |
| 421 |
8-98108 411-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
E |
4X2(TFB***) 4 WHEEL ANTI LOCK BRAKE<J (D) |
| 114 |
8-98024 221-0 |
|
RING SNAP,BALL BRG |
1 |
1602- |
|
E |
(C) OD=77 |
| 608 |
8-97362 391-0 |
|
GUTTER OIL |
1 |
1602- |
|
E |
(A) |
| 315 |
8-98046 876-0 |
|
BOLT CASE |
11 |
1602- |
|
E |
16.069 (B) M8X3 5 FLANGE |
| 1 |
8-97978 003-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
B |
4X4(TFS***) IDENTIFICATION LABEL FOR |
| 446 |
8-98203 100-0 |
|
PLUG CASE,TRANS |
2 |
1602- |
|
F |
4X4(TFS***) |
| 421 |
8-97978 061-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
B |
4X4(TFS***) IDENTIFICATION LABEL FOR (B) |
| 419 |
8-98047 054-0 |
|
PLUG RR COVER |
1 |
1602- |
|
E |
M12X9 |
| 76 |
8-97238 999-0 |
|
SEAL OIL,TRANSFER CASE |
1 |
1602- |
|
B EFG |
4X4(TFS***) NOK |
| 608 |
8-98004 505-0 |
|
GUTTER OIL |
1 |
1602- |
|
E |
(D) |
| 86 |
8-98203 180-0 |
|
BOLT RR COVER |
8 |
1602- |
|
F |
4X2(TFB***) (E) |
| 47 |
8-97115 712-0 |
|
GASKET FILLER PLUG,TRANSFER CAS |
1 |
1602- |
|
B EFG |
4X4(TFS***) 04.105 ID=17 |
| 414 |
8-98203 251-0 |
|
COVER DUST,RR COVER |
1 |
1602- |
|
F |
4X2(TFB***) |
| 429 |
5-09740 018-1 |
|
PIN STRAIGHT |
2 |
1602- |
|
ABCD |
(A) OD=10 L=40 |
| 1 |
8-98172 465-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
B |
4X4(TFS***) EXC. IDENTIFICATION LABEL > |
| 529 |
8-98203 179-0 |
|
BRACKET MISSION CASE |
1 |
1602- |
|
F |
4X2(TFB***) |
| 90 |
8-97046 700-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
B |
4X4(TFS***) EXC. IDENTIFICATION LABEL > 04.510 (A) TKK |
| 86 |
8-97305 468-0 |
|
BOLT RR COVER |
5 |
1602- |
|
A |
(A) M10X18 M10X55 L=86.8 |
| 86 |
8-98035 672-0 |
|
BOLT RR COVER |
7 |
1602- |
|
BCD |
(B) M10X55 FLANGE |
| 296 |
8-98203 099-0 |
|
PIN QUAD BOX TO CASE |
2 |
1602- |
|
F |
|
| 34 |
8-98097 470-0 |
|
COVER DUST,SHIFT FORK |
1 |
1602- |
|
E |
.596527778 |
| 455 |
8-98035 654-0 |
|
SCREW BRG RET |
4 |
1602- |
|
BCD |
M8X22 |
| 90 |
8-97947 840-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
A D |
(A) NOK |
| 14 |
0-91510 512-0 |
|
WASHER LK,SUPPORT |
1 |
1602- |
|
BCD |
03.634 ID=12.2 |
| 33 |
8-97046 698-0 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
BC |
EXC. IDENTIFICATION LABEL > |
| 1 |
8-97978 005-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
C |
IDENTIFICATION LABEL FOR |
| 421 |
8-98108 318-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
E |
4X2(TFB***) (C) |
| 435 |
8-97330 878-0 |
|
CASE TRANS |
1 |
1602- |
|
A |
(A) |
| 90 |
8-98203 102-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
F |
(A) |
| 90 |
8-97947 841-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
B |
4X4(TFS***) IDENTIFICATION LABEL FOR (A) NOK |
| 435 |
8-98203 111-0 |
|
CASE TRANS |
1 |
1602- |
|
F |
4X2(TFB***) (E) |
| 561 |
8-98203 114-0 |
|
PLUG |
1 |
1602- |
|
F |
|
| 424 |
8-98203 099-0 |
|
RING INSERT |
2 |
1602- |
|
F |
4510 |
| 272 |
8-89048 559-0 |
|
BOLT |
2 |
1602- |
|
F |
(A) |
| 680 |
8-97362 720-1 |
|
BEARING |
1 |
1602- |
|
E |
(A) |
| 28 |
8-98094 800-0 |
|
COVER FRT,TRANS CASE |
1 |
1602- |
|
E |
|
| 50 |
8-97115 712-0 |
|
GASKET DRAIN PLUG |
1 |
1602- |
|
ABCDE |
ID=17 |
| 419 |
8-97164 926-0 |
|
PLUG RR COVER |
1 |
1602- |
|
F |
4105 |
| 79 |
0-28051 045-0 |
|
BOLT TRANSFER CASE |
7 |
1602- |
|
G |
4X4(TFS***) 00. 685 M10X4 5 FLANGE |
| 90 |
8-97046 705-3 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
B EFG |
4X4(TFS***) (B) NOK |
| 29 |
8-97365 376-0 |
|
BOLT FRT COVER |
6 |
1602- |
|
ABCD |
M8X22 FLANGE |
| 608 |
8-98203 105-0 |
|
GUTTER OIL |
1 |
1602- |
|
F |
(G) |
| 41 |
8-94320 193-0 |
|
SPRING DETENT BALL |
2 |
1602- |
|
BCD |
(D) L=2 6.8 |
| 1 |
8-97978 028-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
D |
|
| 481 |
8-98203 169-0 |
|
SPRING SHIFTER ROD,OIL PUMP |
1 |
1602- |
|
F |
|
| 608 |
8-98203 103-0 |
|
GUTTER OIL |
1 |
1602- |
|
F |
(E) |
| 90 |
8-97947 840-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
BC |
4X2(TFB***) IDENTIFICATION LABEL FOR (A) NOK |
| 414 |
8-98027 802-0 |
|
COVER DUST,RR COVER |
1 |
1602- |
|
A CD |
|
| 510 |
8-97362 853-0 |
|
BEARING |
1 |
1602- |
|
E |
|
| 421 |
8-97382 905-2 |
|
COVER RR,TRANS |
1 |
1602- |
|
E |
4X2 (TFB***) EXC. 4 WHEEL ANTI LOCK BR (D) |
| 314 |
8-98203 119-0 |
|
GASKET CASE |
1 |
1602- |
|
F |
|
| 328 |
8-97164 900-0 |
|
GASKET PLUG |
1 |
1602- |
|
F |
|
| 414 |
8-98027 802-0 |
|
COVER DUST,RR COVER |
1 |
1602- |
|
B E |
4X2(TFB***) |
| 28 |
8-97381 406-0 |
|
COVER FRT,TRANS CASE |
1 |
1602- |
|
BC |
IDENTIFICATION LABEL FOR |
| 42 |
8-94435 335-0 |
|
BALL DETENT,GEAR SHIFT |
3 |
1602- |
|
ABCD |
|
| 678 |
8-98203 165-0 |
|
PIN |
1 |
1602- |
|
F |
|
| 434 |
8-98203 097-0 |
|
HOUSING CLU |
1 |
1602- |
|
F |
|
| 16 |
8-97358 601-0 |
|
PLUG SHIFT ROD |
2 |
1602- |
|
ABCD |
OD=14 |
| 326 |
8-98023 517-0 |
|
NOZZLE OIL,OUTLET |
1 |
1602- |
|
E |
|
| 430 |
8-97365 374-0 |
|
PLUG OIL DRAIN |
1 |
1602- |
|
B EFG |
4X4(TFS***) (A) |
| 435 |
8-98108 317-1 |
|
CASE TRANS |
1 |
1602- |
|
E |
(C) |
| 429 |
8-97135 423-0 |
|
PIN STRAIGHT |
2 |
1602- |
|
B EFG |
4X4(TFS***) 04.510 (C) OD=10 L=20 |
| 25 |
8-98004 774-0 |
|
GASKET COVER |
1 |
1602- |
|
E |
4X2(TFB***) |
| 430 |
8-97164 953-0 |
|
PLUG OIL DRAIN |
1 |
1602- |
|
F |
(B) |
| 421 |
8-98277 853-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
B |
4X4(TFS***) EXC. IDENTIFICATION LABEL > (B) |
| 40 |
8-97083 600-1 |
|
GASKET DETENT SPR PLATE |
1 |
1602- |
|
BCD |
|
| 49 |
8-98035 675-0 |
|
STUD TRANSFER CASE |
1 |
1602- |
|
B |
4X4(TFS***) IDENTIFICATION LABEL FOR M10X30 L=4 5 |
| 421 |
8-98193 595-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
A |
(A) |
| 45 |
8-97115 712-0 |
|
GASKET FILLER PLUG |
1 |
1602- |
|
ABCDE |
ID=17 |
| 45 |
8-97164 900-0 |
|
GASKET FILLER PLUG |
2 |
1602- |
|
F |
4X2(TFB***) |
| 90 |
8-97947 840-0 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
E |
4X2(TFB***) (A) NOK |
| 299 |
8-94173 641-0 |
|
PLUG SHIFTER ROD |
2 |
1602- |
|
B EFG |
4X4(TFS***) 00. 034 (B) OD=15.6 |
| 1 |
8-98087 608-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
E |
4X2(TFB***) 4 WHEEL ANTI LOCK BRAKE<J |
| 86 |
8-98203 112-0 |
|
BOLT RR COVER |
4 |
1602- |
|
F |
4X4(TFS***) (F) |
| 28 |
8-97104 676-0 |
|
COVER FRT,TRANS CASE |
1 |
1602- |
|
BC |
EXC. IDENTIFICATION LABEL > |
| 1 |
8-98161 475-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
C |
EXC. IDENTIFICATION LABEL > |
| 272 |
8-98203 117-0 |
|
BOLT |
1 |
1602- |
|
F |
(B) |
| 421 |
8-97978 059-0 |
|
COVER RR,TRANS |
1 |
1602- |
|
D |
(A) |
| 1 |
8-98145 931-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
A |
|
| 1 |
8-98147 061-2 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
F |
4X2(TFB***) |
| 114 |
9-09180 156-0 |
|
RING SNAP,BALL BRG |
1 |
1602- |
|
E |
(D) OD= 6 0.2 |
| 33 |
8-97947 839-0 |
|
SEAL OIL,FRT COVER,T/M |
1 |
1602- |
|
DE |
NOK |
| 1 |
8-98172 464-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
B |
4X2(TFB***) EXC. CONGO EQUIPMENT(CDF) TION LABEL FOR KD< 6UT> |
| 435 |
8-98203 108-0 |
|
CASE TRANS |
1 |
1602- |
|
F |
4X4(TFS***) (G) |
| 1 |
8-98102 485-0 |
|
GASKET SET TRANS OVERHAUL |
1 |
1602- |
|
E |
4X2(TFB***) EXC. 4 WHEEL ANTI LOCK BR |
| 41 |
8-97214 403-0 |
|
SPRING DETENT BALL |
1 |
1602- |
|
BCD |
(C) L=2 6.6 |
| 430 |
8-97365 374-0 |
|
PLUG OIL DRAIN |
1 |
1602- |
|
ABCDE |
(A) |
| 90 |
8-97046 701-2 |
|
SEAL OIL,RR COVER |
1 |
1602- |
|
B |
4X4(TFS***) EXC. IDENTIFICATION LABEL > 04.510 (A) NOK |
