| 8 |
9-41519 160-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 32 |
| 8 |
9-41519 154-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 2 0 |
| 35 |
5-41562 005-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
T= 1.00 |
| 1 |
8-98104 900-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 43/12(GM0 43/12 |
| 7 |
8-94472 100-1 |
|
BEARING PINION,OUTER |
1 |
1602- |
|
DEF |
05.484 JTEKT |
| 37 |
8-97079 518-0 |
|
GEAR PINION DIFF |
2 |
1602- |
|
DEF |
Z=10 |
| 1 |
8-98104 901-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/11(GT4 41/11 |
| 110 |
8-97038 065-0 |
|
BOLT DIFF BOX |
10 |
1602- |
|
DEF |
05.531 M10X17 |
| 8 |
9-41519 164-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 4 0 |
| 8 |
9-41519 153-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2.18 |
| 12 |
8-97130 387-0 |
|
SHIM FINAL PINION CAGE |
AR |
1602- |
|
DEF |
T= 0.50 |
| 12 |
8-97130 386-0 |
|
SHIM FINAL PINION CAGE |
AR |
1602- |
|
DEF |
T= 0.10 |
| 8 |
9-41519 167-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 4 6 |
| 6 |
8-94318 520-2 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
DEF |
|
| 8 |
9-41519 155-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 22 |
| 12 |
9-41519 109-0 |
|
SHIM FINAL PINION CAGE |
AR |
1602- |
|
DEF |
T= 0.24 |
| 9 |
8-94472 118-0 |
|
COLLAR DIST,PINION |
1 |
1602- |
|
DEF |
|
| 5 |
8-94318 409-1 |
|
COVER DUST,PINION,FINAL DRIVE |
1 |
1602- |
|
DEF |
|
| 8 |
9-41519 170-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2.52 |
| 19 |
9-00093 621-1 |
|
BEARING PINION,INNER |
1 |
1602- |
|
DEF |
NSK |
| 7 |
8-94472 099-0 |
|
BEARING PINION,OUTER |
1 |
1602- |
|
DEF |
05.484 NSK |
| 11 |
8-97038 515-1 |
|
CAGE FINAL PINION |
1 |
1602- |
|
DEF |
|
| 36 |
8-97079 519-2 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
DEF |
Z=17 |
| 8 |
9-41519 157-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 2 6 |
| 21 |
8-98104 915-1 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 43/12(GM0 43/12 |
| 4 |
8-94318 527-6 |
|
COUPLING FINAL DRIVE PINION |
1 |
1602- |
|
DEF |
|
| 8 |
9-41519 162-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 3 6 |
| 34 |
9-41521 044-1 |
|
PIN CROSS,DIFF PINION |
1 |
1602- |
|
DEF |
.567361111 |
| 8 |
9-41519 163-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 3 8 |
| 2 |
8-94376 262-0 |
|
NUT FINAL DRIVE PINION |
1 |
1602- |
|
DEF |
M18 LOCK NUT |
| 35 |
5-41562 006-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
T=1.05 |
| 8 |
9-41519 158-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 2 8 |
| 1 |
8-98157 170-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1602- |
|
EF |
FINAL GEAR RATIO 43/14(G44 43/14 |
| 1 |
8-98104 903-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/10(GT5 41/10 |
| 8 |
9-41519 159-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 3 0 |
| 8 |
9-41519 169-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2.50 |
| 8 |
9-41519 156-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 24 |
| 8 |
9-41519 166-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 44 |
| 21 |
8-98104 945-1 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/10(GT5 41/10 |
| 8 |
9-41519 165-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 42 |
| 8 |
9-41519 161-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 34 |
| 35 |
5-41562 007-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
T= 1.10 |
| 8 |
9-41519 172-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2.56 |
| 8 |
9-41519 168-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2 . 4 8 |
| 12 |
9-41519 111-0 |
|
SHIM FINAL PINION CAGE |
AR |
1602- |
|
DEF |
T= 0.15 |
| 8 |
9-41519 171-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
DEF |
T=2.54 |
| 39 |
9-09878 096-0 |
|
PIN LK,CROSS PIN |
1 |
1602- |
|
DEF |
OD=5 L=35 |
| 21 |
8-98157 175-1 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1602- |
|
EF |
FINAL GEAR RATIO 43/14(G44 43/14 |
| 21 |
8-98104 929-1 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/11(GT4 41/11 |
| 1 |
8-98104 902-0 |
|
DRIVE ASM FINAL,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 43/11(GW1 43/11 |
| 14 |
8-98104 910-2 |
|
CARRIER ASM FINAL DRIVE,FRT AXL |
1 |
1602- |
|
DEF |
|
| 21 |
8-98104 933-1 |
|
GEAR SET FINAL DRIVE,FRT |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 43/11(GW1 43/11 |
| 69 |
9-00093 074-1 |
|
BEARING DIFF SIDE |
2 |
1602- |
|
DEF |
05.536 NSK |
| 30 |
8-94376 322-0 |
|
BOLT DIFF CAGE SETTING |
4 |
1602- |
|
DEF |
05.387 M12X62 |
