| 51 |
8-94435 356-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=1.94 |
| 50 |
8-94452 448-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
A DEF |
JTEKT |
| 73 |
8-94435 348-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0.12 |
| 21 |
8-98186 828-1 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> Z = 18 |
| 50 |
8-94452 448-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) JTEKT |
| 20 |
5-41562 006-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) T=1.05 |
| 51 |
9-41519 154-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.20 |
| 20 |
9-41562 602-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=1 . 00 |
| 51 |
8-94435 373-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .28 |
| 51 |
8-94435 376-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.34 |
| 51 |
8-94435 372-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.26 |
| 51 |
8-94435 375-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.32 |
| 51 |
9-41519 170-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.52 |
| 39 |
9-00093 078-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) NSK |
| 72 |
8-97038 515-1 |
|
CAGE DIFF |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.453 |
| 20 |
8-94435 347-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=1 . 30 |
| 51 |
9-41519 169-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.50 |
| 51 |
9-41519 159-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.30 |
| 51 |
8-94435 366-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.14 |
| 51 |
8-94435 374-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.30 |
| 51 |
8-94435 360-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.02 |
| 21 |
8-97200 286-0 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 51 |
8-94435 361-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.04 |
| 1 |
8-98190 116-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/11(GW1) EXC. LIMITED SLIP DIFF<G80> 43/11 |
| 24 |
8-97079 518-0 |
|
GEAR PINION,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) 05.527 Z = 10 |
| 51 |
8-94435 364-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.10 |
| 20 |
8-94435 347-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=1 . 30 |
| 51 |
8-94435 359-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.00 |
| 73 |
8-94435 352-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0 . 30 |
| 70 |
8-94452 449-1 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
A DEF |
JTEKT |
| 51 |
9-41519 157-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.26 |
| 84 |
8-97038 064-0 |
|
BOLT FINAL DRIVE GEAR |
12 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M10X18.5 |
| 73 |
8-94435 351-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0.25 |
| 51 |
9-41519 166-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.44 |
| 51 |
8-94435 367-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.16 |
| 20 |
8-94365 187-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1.60 |
| 51 |
8-94435 364-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.10 |
| 1 |
8-98167 623-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/12(GM0) LIMITED SLIP DIFF<G80> 43/12 |
| 20 |
8-94435 344-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14 (G44) EXC. LIMITED SLIP DIFF<G80> T=0.90 |
| 76 |
8-97096 209-0 |
|
DISC BEVEL |
4 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 22 |
8-94435 308-1 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> |
| 126 |
8-98166 552-1 |
|
COUPLING DRIVING PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 73 |
8-94435 348-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0.12 |
| 1 |
8-98190 119-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/9(GT3) 41/9 |
| 60 |
8-97374 174-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/12(GM0) 43/12 |
| 37 |
8-94376 262-0 |
|
NUT DRIVING PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) M18 LOCK NUT |
| 20 |
8-94435 344-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=0.90 |
| 24 |
8-97200 285-1 |
|
GEAR PINION,DIFF |
4 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 51 |
8-94435 358-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=1.98 |
| 126 |
8-97321 411-1 |
|
COUPLING DRIVING PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) |
| 51 |
8-94435 366-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.14 |
| 74 |
9-09878 096-0 |
|
PIN LK,CROSS PIN |
1 |
1602- |
|
A |
OD= 5 L=3 5 |
| 1 |
8-98190 115-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
ABCDEF |
FINAL GEAR RATIO 41/11(GT4) EXC. LIMITED SLIP DIFF<G80> 41/11 |
| 51 |
9-41519 160-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.32 |
| 20 |
8-94435 345-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=1.10 |
| 70 |
8-94435 355-0 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) NSK |
| 100 |
8-97207 784-0 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) TKK |
| 50 |
8-94435 342-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) NSK |
| 37 |
8-94376 261-1 |
|
NUT DRIVING PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) M24 FLANGE |
| 60 |
8-98030 515-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
ABCDEF |
FINAL GEAR RATIO 41/11(GT4) 41/11 |
| 70 |
8-94435 355-0 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) NSK |
| 51 |
8-94435 356-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=1.94 |
| 51 |
8-94435 361-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.04 |
| 20 |
8-94435 343-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=0.80 |
| 20 |
8-94435 347-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=1 . 30 |
| 1 |
8-98073 915-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) 41/10 |
| 24 |
8-98186 829-0 |
|
GEAR PINION,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> Z=10 |
| 20 |
9-41562 602-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=1 . 00 |
| 51 |
8-94435 372-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .26 |
| 51 |
9-41519 168-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.48 |
| 73 |
8-94435 351-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0.25 |
| 39 |
9-00093 078-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) NSK |
| 72 |
8-94325 448-0 |
|
CAGE DIFF |
1 |
1602- |
|
A |
|
| 37 |
8-94376 261-1 |
|
NUT DRIVING PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M24 FLANGE |
| 20 |
8-94435 345-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=1 . 10 |
| 51 |
8-94435 365-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.12 |
| 22 |
8-94435 308-1 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> |
| 20 |
5-41562 005-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) T=1 . 00 |
| 51 |
9-41519 158-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.28 |
| 51 |
8-94435 365-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.12 |
| 73 |
9-41519 109-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) T=0.24 |
| 1 |
8-98190 113-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
ABC |
FINAL GEAR RATIO 41/12(GU6) 41/12 |
| 21 |
8-98186 828-1 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
A |
Z = 18 |
| 39 |
8-94472 100-1 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) JTEKT |
| 51 |
8-94435 377-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .36 |
| 51 |
8-94435 376-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .34 |
| 51 |
8-94435 357-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=1.96 |
| 20 |
8-94435 346-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9 (GT3) ,FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14 (G44) EXC. LIMITED SLIP DIFF<G80> T=1.20 |
| 51 |
8-94435 374-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.30 T=2 .32 |
| 51 |
8-94435 367-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.16 |
| 51 |
8-94435 372-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .26 |
| 126 |
8-98166 552-1 |
|
COUPLING DRIVING PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) |
| 20 |
8-94435 346-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
A |
T=1 . 20 |
| 51 |
8-94435 374-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.30 |
| 51 |
8-94435 363-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.08 |
| 51 |
8-94435 371-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .24 |
| 20 |
5-41562 007-1 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) T=1.10 |
| 20 |
8-94435 343-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> T=0.80 |
| 60 |
8-98014 984-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/10(GT5) 41/10 |
| 55 |
8-97240 889-2 |
|
CARRIER DIFF |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) |
| 73 |
8-97130 386-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) T=0.10 |
| 55 |
8-97240 889-2 |
|
CARRIER DIFF |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 70 |
8-94452 449-1 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) JTEKT |
| 73 |
8-94435 353-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0 . 50 |
| 51 |
8-94435 377-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.36 |
| 21 |
8-98186 828-1 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> Z=18 |
| 51 |
8-94435 369-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.20 |
| 56 |
8-94376 322-0 |
|
BOLT BRG CAP |
4 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.387 M12X62 |
| 73 |
9-41519 111-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) T=0.15 |
| 73 |
8-94435 348-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0.12 |
| 60 |
8-98014 990-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/9(GT3) 41/9 |
| 51 |
9-41519 167-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.46 |
| 51 |
9-41519 155-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.22 |
| 51 |
8-94435 365-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.12 |
| 73 |
8-94435 349-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0.15 |
| 51 |
8-94435 368-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.18 |
| 51 |
8-94435 363-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.08 |
| 51 |
8-94435 370-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .22 |
| 20 |
8-94453 935-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1 . 50 |
| 82 |
8-94453 932-0 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 51 |
8-94435 360-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.02 |
| 20 |
8-94435 346-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=1 . 20 |
| 51 |
8-94435 357-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=1.96 |
| 1 |
8-98167 624-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 41/11(GT4) LIMITED SLIP DIFF<G80> 41/11 |
| 56 |
8-98176 233-0 |
|
BOLT BRG CAP |
4 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M12X75 FLANGE |
| 51 |
8-94435 375-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .32 |
| 21 |
8-97079 519-2 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) Z = 17 |
| 84 |
8-97038 065-0 |
|
BOLT FINAL DRIVE GEAR |
10 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) M10X17 |
| 51 |
8-94435 371-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.24 |
| 73 |
8-94435 350-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0.18 |
| 22 |
8-94435 308-1 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> |
| 73 |
8-94435 351-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0 . 25 |
| 21 |
8-98186 828-1 |
|
GEAR SIDE,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> Z=18 |
| 51 |
8-94435 366-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.14 |
| 42 |
8-94472 118-0 |
|
COLLAR DIST,COLLAPSIBLE |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) |
| 72 |
8-94325 448-0 |
|
CAGE DIFF |
1 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> |
| 39 |
8-94472 099-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) NSK |
| 56 |
8-98176 233-0 |
|
BOLT BRG CAP |
4 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) M12X75 FLANGE |
| 51 |
8-94435 358-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=1.98 |
| 51 |
8-94435 377-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .36 |
| 20 |
8-94435 344-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=0.90 |
| 51 |
8-94435 373-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .28 |
| 51 |
9-41519 156-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.24 |
| 20 |
9-41562 602-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14 (G44) EXC. LIMITED SLIP DIFF<G80> T=1.00 |
| 73 |
8-94435 350-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0.18 |
| 79 |
8-94453 936-0 |
|
PLATE FRICTION |
4 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1.75 |
| 50 |
8-94452 448-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) JTEKT |
| 72 |
8-94325 448-0 |
|
CAGE DIFF |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> |
| 51 |
8-94435 360-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.02 |
| 100 |
8-97328 648-0 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) NOK |
| 51 |
8-94435 368-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.18 |
| 20 |
9-41562 602-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=1.00 |
| 1 |
8-98167 625-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/11(GW1) LIMITED SLIP DIFF<G80> 43/11 |
| 37 |
8-94376 261-1 |
|
NUT DRIVING PINION |
1 |
1602- |
|
A DEF |
M24 FLANGE |
| 20 |
8-94435 343-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=0.80 |
| 50 |
8-94435 342-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
A DEF |
NSK |
| 100 |
8-97146 826-0 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) NOK |
| 73 |
8-97130 387-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) T=0.50 |
| 73 |
8-94435 349-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0 . 15 |
| 51 |
8-94435 363-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.08 |
| 51 |
8-94435 371-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .24 |
| 84 |
8-97038 064-0 |
|
BOLT FINAL DRIVE GEAR |
12 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) M10X18.5 |
| 73 |
8-94435 352-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0 . 30 |
| 1 |
8-98190 117-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
DEF |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80> 41/10 |
| 39 |
9-00093 078-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
A DEF |
NSK |
| 51 |
8-94435 361-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.04 |
| 51 |
8-94435 376-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2 .34 |
| 51 |
8-94435 362-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.06 |
| 51 |
8-94435 358-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=1.98 |
| 51 |
9-41519 165-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.42 |
| 51 |
9-41519 153-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.18 |
| 51 |
9-41519 163-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.38 |
| 20 |
8-94435 345-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=1.10 |
| 60 |
8-98014 987-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 43/10(GY2) 43/10 |
| 55 |
5-41110 014-3 |
|
CARRIER DIFF |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) |
| 22 |
9-41521 044-1 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) 05.517 |
| 51 |
8-94435 368-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.18 |
| 71 |
8-98167 619-0 |
|
CAGE ASM DIFF,FINAL DRIVE |
1 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 51 |
9-41519 164-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.40 |
| 51 |
9-41519 172-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G8 0>,HIG SUSPENSION(7YC) 05.460 T=2.56 |
| 51 |
8-94435 373-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.28 |
| 42 |
8-97035 399-0 |
|
COLLAR DIST,COLLAPSIBLE |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) |
| 60 |
8-97374 177-2 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
ABC |
FINAL GEAR RATIO 41/12(GU6) 41/12 |
| 73 |
8-94435 353-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0 . 50 |
| 51 |
8-94435 362-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.06 |
| 60 |
8-98014 980-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/11(GW1) 43/11 |
| 51 |
8-94435 357-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=1.96 |
| 70 |
9-00093 074-1 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) NSK |
| 20 |
8-97066 412-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1.80 |
| 1 |
8-98167 626-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 41/10(GT5) LIMITED SLIP DIFF<G80> 41/10 |
| 51 |
9-41519 161-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.34 |
| 20 |
8-94435 346-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> T=1.20 |
| 20 |
8-94435 347-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> T=1 . 30 |
| 42 |
8-97035 399-0 |
|
COLLAR DIST,COLLAPSIBLE |
1 |
1602- |
|
A DEF |
|
| 50 |
8-94435 342-0 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) NSK |
| 60 |
8-98197 452-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BC EF |
FINAL GEAR RATIO 43/14(G44) 43/14 |
| 56 |
8-98176 233-0 |
|
BOLT BRG CAP |
4 |
1602- |
|
A DEF |
M12X75 FLANGE |
| 126 |
8-98166 552-1 |
|
COUPLING DRIVING PINION |
1 |
1602- |
|
A DEF |
|
| 51 |
8-94435 375-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.32 |
| 50 |
9-00093 621-1 |
|
BEARING FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.484 NSK |
| 1 |
8-98197 453-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BC EF |
FINAL GEAR RATIO 43/14(G44) 43/14 |
| 22 |
8-94435 308-1 |
|
SPIDER DIFF PINION |
1 |
1602- |
|
A |
|
| 73 |
8-94435 352-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0 . 30 |
| 1 |
8-98190 118-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 43/10(GY2) 43/10 |
| 1 |
8-98190 114-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BCDEF |
FINAL GEAR RATIO 43/12(GM0) EXC. LIMITED SLIP DIFF<G80> 43/12 |
| 51 |
8-94435 369-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.20 |
| 51 |
8-94435 359-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.00 |
| 20 |
8-94365 188-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1.70 |
| 74 |
9-09878 096-0 |
|
PIN LK,CROSS PIN |
1 |
1602- |
|
BCDEF |
EXC. LIMITED SLIP DIFF<G80> OD= 5 L=3 5 |
| 100 |
8-97328 648-0 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
A DEF |
NOK |
| 24 |
8-98186 829-0 |
|
GEAR PINION,DIFF |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> Z = 10 |
| 20 |
8-94435 344-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=0 . 90 |
| 1 |
8-98190 117-0 |
|
DRIVE ASM FINAL,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> 41/10 |
| 51 |
8-94435 362-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.06 |
| 51 |
8-94435 364-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.10 |
| 55 |
8-97240 889-2 |
|
CARRIER DIFF |
1 |
1602- |
|
A DEF |
|
| 80 |
8-94453 931-0 |
|
RING PRESSURE |
2 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 100 |
8-97328 648-0 |
|
SEAL OIL,FINAL PINION |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) NOK |
| 51 |
8-94435 369-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .20 |
| 51 |
9-41519 171-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.54 |
| 73 |
8-94435 350-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=0.18 |
| 73 |
8-94435 349-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
A DEF |
T=0 . 15 |
| 51 |
9-41519 162-1 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 05.460 T=2.36 |
| 78 |
8-94453 937-0 |
|
DISC FRICTION |
4 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> |
| 20 |
8-94435 345-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9 (GT3) ,FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14 (G44) EXC. LIMITED SLIP DIFF<G80> T=1.10 |
| 73 |
8-94435 353-0 |
|
SHIM DIFF SIDE BRG |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=0 . 50 |
| 84 |
8-97038 064-0 |
|
BOLT FINAL DRIVE GEAR |
12 |
1602- |
|
A DEF |
M10X18.5 |
| 70 |
8-94452 449-1 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) JTEKT |
| 72 |
8-94325 448-0 |
|
CAGE DIFF |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 4 3/12(GM0),FIN R RATIO 41/9(GT3),FINAL GEAR RA /11(GT4),FINAL GEAR RATIO 41/12 FINAL GEAR RATIO 43/11(GW1),FIN R RATIO 43/10(GY2),FINAL GEAR R 3/14(G44) EXC. LIMITED SLIP DIFF<G80> |
| 51 |
8-94435 367-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=2.16 |
| 51 |
8-94435 359-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2.00 |
| 51 |
8-94435 356-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) T=1.94 |
| 24 |
8-98186 829-0 |
|
GEAR PINION,DIFF |
2 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G80> Z=10 |
| 79 |
8-94365 189-0 |
|
PLATE FRICTION |
4 |
1602- |
|
BCDEF |
LIMITED SLIP DIFF<G80> T=1.85 |
| 60 |
8-98013 580-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) EXC. LIMITED SLIP DIFF<G80>,HIG SUSPENSION(7YC) 41/10 |
| 51 |
8-94435 370-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
A DEF |
T=2 .22 |
| 70 |
8-94435 355-0 |
|
BEARING DIFF CAGE |
2 |
1602- |
|
A DEF |
NSK |
| 51 |
8-94435 370-0 |
|
SHIM PINION,FINAL DRIVE |
AR |
1602- |
|
BC |
FINAL GEAR RATIO 41/11(GT4),FIN R RATIO 41/12(GU6),FINAL GEAR R 3/11(GW1),FINAL GEAR RATIO 43/1 ,FINAL GEAR RATIO 43/14(G44) EXC. HIGH RIDE SUSPENSION(7YC) T=2.22 |
| 42 |
8-97035 399-0 |
|
COLLAR DIST,COLLAPSIBLE |
1 |
1602- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 60 |
8-98014 984-1 |
|
GEAR SET FINAL DRIVE,RR |
1 |
1602- |
|
BC |
FINAL GEAR RATIO 41/10(GT5) HIGH RIDE SUSPENSION(7YC) 41/10 |
| 20 |
8-94435 343-0 |
|
WASHER THRUST,SIDE GEAR |
2 |
1602- |
|
DEF |
EXC. LIMITED SLIP DIFF<G80> T=0.80 |
| 24 |
8-98186 829-0 |
|
GEAR PINION,DIFF |
2 |
1602- |
|
A |
Z = 10 |
