| 155 |
I0-58330 610-0 |
|
BOLT; BAFFLE PLATE |
8 |
1809-1809 |
|
D |
M6X10 HEX SOCKET |
| 2 |
I8-98261 319-0 |
|
GASKET; CYL HD |
1 |
1809-1809 |
|
D |
GRADE=B T=1.19 2-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) GRADE=B T=1.19 2-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) |
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
1 |
1810- |
|
E |
(B) OD=18 |
| 2 |
I8-98261 318-0 |
|
GASKET; CYL HD |
1 |
1809-1809 |
|
D |
GRADE=A T=1.14 1-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) |
| 91 |
I8-98228 414-0 |
|
PIPE; HTR |
1 |
1810- |
|
D |
HEATER & DEFROSTER(C42),AIR COND R MANUAL CONT(C60),AIR CONDITION OMATIC CONT(C61) |
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
6 |
1809-1809 |
|
D |
(B) OD=18 |
| 263 |
I0-28050 860-0 |
|
BOLT; CYL HD |
1 |
1809-1809 |
|
D |
04.686 (A) M8X60 FLANGE |
| 13 |
I0-28151 020-0 |
|
BOLT; HANGER |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5) 03.417 (C) M10X20 FLANGE |
| 91 |
I8-98228 414-0 |
|
PIPE; HTR |
1 |
1809-1809 |
|
D |
HEATER & DEFROSTER(C42),AIR COND R MANUAL CONT(C60),AIR CONDITION OMATIC CONT(C61) |
| 123 |
I0-28050 820-0 |
|
BOLT; COVER |
3 |
1809-1809 |
|
D |
04 .338 M8X20 FLANGE |
| 13 |
I0-58330 830-0 |
|
BOLT; HANGER |
1 |
1810- |
|
DE |
00.206 (B) M8X30 HEX SOCKET |
| 3 |
I0-28650 835-0 |
|
BOLT; CYL HD TO BLOCK |
4 |
1809- |
|
AB |
01.060 (B) M8X35 FLANGE |
| 224 |
I0-91180 208-0 |
|
NUT; COVER |
4 |
1810- |
|
DE |
01.540 M8 FLANGE |
| 230 |
I8-97943 955-0 |
|
GASKET; SLEEVE,INJECTOR |
4 |
1810- |
|
DE |
|
| 10 |
I8-98117 567-1 |
|
PLUG; GLOW |
4 |
1810- |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) NGK |
| 5 |
I8-97311 379-0 |
|
SEAT; VLV INSERT |
8 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) (F) EXHAUST ID=2 6 OD=32 |
| 1 |
I8-98270 378-2 |
|
HEAD ASM; CYL |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) |
| 221 |
I1-09044 074-0 |
|
BOLT; BRKT |
21 |
1809-1809 |
|
D |
01.531 (B) M8X85 |
| 172 |
I8-98250 484-0 |
|
PLATE; BAFFLE,CYL HD |
1 |
1810- |
|
DE |
|
| 10 |
I8-98117 567-1 |
|
PLUG; GLOW |
4 |
1810- |
|
E |
NGK |
| 7 |
I8-97333 120-0 |
|
CUP; SEALING,CYL HEAD |
5 |
1810- |
|
DE |
(G) OD=2 4 |
| 230 |
I8-97943 955-0 |
|
GASKET; SLEEVE,INJECTOR |
4 |
1809-1809 |
|
D |
|
| 123 |
I0-28050 820-0 |
|
BOLT; COVER |
3 |
1810- |
|
DE |
04 .338 M8X20 FLANGE |
| 91 |
I8-98228 414-0 |
|
PIPE; HTR |
1 |
1810- |
|
E |
|
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
6 |
1810- |
|
DE |
(B) OD=18 |
| 5 |
I8-97311 378-0 |
|
SEAT; VLV INSERT |
8 |
1810- |
|
E |
(E) INLET ID=2 9 OD=35 |
| 7 |
I5-11219 011-0 |
|
CUP; SEALING,CYL HEAD |
2 |
1810- |
|
DE |
00.034 (E) OD=14 |
| 13 |
I0-58330 830-0 |
|
BOLT; HANGER |
1 |
1809-1809 |
|
D |
00.206 (B) M8X30 HEX SOCKET |
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
3 |
1809- |
|
AB |
(B) OD=18 |
| 14 |
I8-97379 383-0 |
|
STUD; EXH MANIF |
1 |
1809- |
|
AB |
03.604 (B) M10X33 L=4 8 |
| 221 |
I0-28050 630-0 |
|
BOLT; BRKT |
8 |
1809-1809 |
|
D |
01.531 (C) M6X3 0 FLANGE |
| 1 |
I8-98270 378-2 |
|
HEAD ASM; CYL |
1 |
1810- |
|
E |
|
| 155 |
I0-58330 610-0 |
|
BOLT; BAFFLE PLATE |
8 |
1810- |
|
DE |
M6X10 HEX SOCKET |
| 4 |
I8-94239 423-0 |
|
GUIDE; VLV |
16 |
1809-1809 |
|
D |
L=42 |
| 2 |
I8-98261 320-0 |
|
GASKET; CYL HD |
1 |
1810- |
|
DE |
GRADE=C T=1.24 3-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) |
| 12 |
I8-98239 364-0 |
|
HANGER; ENG,RR |
1 |
1810- |
|
DE |
|
| 12 |
I8-98239 364-0 |
|
HANGER; ENG,RR |
1 |
1809-1809 |
|
D |
|
| 2 |
I8-98261 318-0 |
|
GASKET; CYL HD |
1 |
1810- |
|
DE |
GRADE=A T=1.14 1-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) |
| 5 |
I8-97311 379-0 |
|
SEAT; VLV INSERT |
8 |
1810- |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) (F) EXHAUST ID=2 6 OD=32 |
| 7 |
I5-09600 013-0 |
|
CUP; SEALING,CYL HEAD |
5 |
1809- |
|
C |
(A) OD=12.3 |
| 39 |
I8-97329 129-1 |
|
DOWEL; CAP,CM/SHF |
26 |
1810- |
|
DE |
|
| 7 |
I8-97333 120-0 |
|
CUP; SEALING,CYL HEAD |
5 |
1809-1809 |
|
D |
(G) OD=2 4 |
| 263 |
I0-28050 860-0 |
|
BOLT; CYL HD |
1 |
1810- |
|
DE |
04.686 (A) M8X60 FLANGE |
| 7 |
I8-97233 429-0 |
|
CUP; SEALING,CYL HEAD |
1 |
1809-1809 |
|
D |
(F) OD=8 |
| 1 |
I8-98270 378-2 |
|
HEAD ASM; CYL |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) |
| 172 |
I8-98250 484-0 |
|
PLATE; BAFFLE,CYL HD |
1 |
1809-1809 |
|
D |
|
| 263 |
I0-28650 835-0 |
|
BOLT; CYL HD |
3 |
1810- |
|
DE |
01.060 (B) M8X35 FLANGE |
| 9 |
I0-41010 830-0 |
|
STUD; INL MANIF |
2 |
1809- |
|
AB |
02.042 M8X30 L=41 |
| 244 |
I9-08150 510-0 |
|
PIN; HEAD GASKET |
1 |
1810- |
|
DE |
08.939 OD=5 L=10 |
| 7 |
I5-11219 011-0 |
|
CUP; SEALING,CYL HEAD |
2 |
1809-1809 |
|
D |
00.034 (E) OD=14 |
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
1 |
1810- |
|
D |
HEATER & DEFROSTER(C42),AIR COND R MANUAL CONT(C60),AIR CONDITION OMATIC CONT(C61) (B) OD=18 |
| 91 |
I8-98228 414-0 |
|
PIPE; HTR |
2 |
1809- |
|
D |
AUTO COOLER SYSTEM(CJ2),COOLER W AIR(C65),COOLER WO/FRESH AIR(8N |
| 11 |
I8-98209 370-0 |
|
CONNECTOR; GLOW PLUG |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) |
| 2 |
I8-98261 319-0 |
|
GASKET; CYL HD |
1 |
1810- |
|
DE |
|
| 5 |
I8-97311 378-0 |
|
SEAT; VLV INSERT |
8 |
1810- |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) (E) INLET ID=2 9 OD=35 |
| 262 |
I8-98243 226-0 |
|
COVER; CYL HEAD |
1 |
1810- |
|
DE |
|
| 262 |
I8-98243 226-0 |
|
COVER; CYL HEAD |
1 |
1809-1809 |
|
D |
|
| 5 |
I8-97311 379-0 |
|
SEAT; VLV INSERT |
8 |
1810- |
|
E |
(F) EXHAUST ID=2 6 OD=32 |
| 11 |
I8-98209 370-0 |
|
CONNECTOR; GLOW PLUG |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) |
| 225 |
I8-97945 022-0 |
|
STUD; COVER |
2 |
1809-1809 |
|
D |
M8X20 L=31 |
| 13 |
I0-58330 820-0 |
|
BOLT; HANGER |
1 |
1809-1809 |
|
D |
01.758 (A) M8X20 HEX SOCKET |
| 7 |
I5-11129 006-0 |
|
CUP; SEALING,CYL HEAD |
3 |
1809- |
|
C |
(D) OD=1 6 |
| 10 |
I8-98117 567-1 |
|
PLUG; GLOW |
4 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) |
| 13 |
I0-58330 820-0 |
|
BOLT; HANGER |
1 |
1810- |
|
DE |
01.758 (A) M8X20 HEX SOCKET |
| 225 |
I8-97945 022-0 |
|
STUD; COVER |
2 |
1810- |
|
DE |
M8X20 L=31 |
| 3 |
I8-98201 019-0 |
|
BOLT; CYL HD TO BLOCK |
18 |
1809-1809 |
|
D |
(D) M11X114 W/WASHER |
| 5 |
I8-97311 378-0 |
|
SEAT; VLV INSERT |
8 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-0 4(K75),EURO IFICATION(NT2),EURO3 SPECIFICATI ),EURO4 SPECIFICATION(NT4) (E) INLET ID=2 9 OD=35 |
| 7 |
I5-09600 013-0 |
|
CUP; SEALING,CYL HEAD |
7 |
1809- |
|
AB |
(A) OD=12.3 |
| 221 |
I0-28050 630-0 |
|
BOLT; BRKT |
8 |
1810- |
|
DE |
01.531 (C) M6X3 0 FLANGE |
| 224 |
I0-91180 208-0 |
|
NUT; COVER |
4 |
1809-1809 |
|
D |
01.540 M8 FLANGE |
| 7 |
I8-97233 429-0 |
|
CUP; SEALING,CYL HEAD |
1 |
1810- |
|
DE |
(F) OD=8 |
| 263 |
I0-28650 835-0 |
|
BOLT; CYL HD |
3 |
1809-1809 |
|
D |
01.060 (B) M8X35 FLANGE |
| 7 |
I5-11219 008-0 |
|
CUP; SEALING,CYL HEAD |
1 |
1809-1809 |
|
D |
HEATER & DEFROSTER(C42),AIR COND R MANUAL CONT(C60),AIR CONDITION OMATIC CONT(C61) (B) OD=18 |
| 11 |
I8-98209 370-0 |
|
CONNECTOR; GLOW PLUG |
1 |
1810- |
|
E |
|
| 39 |
I8-97329 129-1 |
|
DOWEL; CAP,CM/SHF |
26 |
1809-1809 |
|
D |
|
| 3 |
I8-98201 019-0 |
|
BOLT; CYL HD TO BLOCK |
18 |
1810- |
|
DE |
(D) M11X114 W/WASHER |
| 221 |
I1-09044 074-0 |
|
BOLT; BRKT |
21 |
1810- |
|
DE |
01.531 (B) M8X85 |
| 244 |
I9-08150 510-0 |
|
PIN; HEAD GASKET |
1 |
1809-1809 |
|
D |
08.939 OD=5 L=10 |
| 4 |
I8-94239 423-0 |
|
GUIDE; VLV |
16 |
1810- |
|
DE |
L=42 |
| 2 |
I8-98261 320-0 |
|
GASKET; CYL HD |
1 |
1809-1809 |
|
D |
GRADE=C T=1.24 3-HOLE ALSO INCLUDED IN GASKET SET(ENG. D) |
