| 345 |
I0-28050 812-0 |
|
BOLT; SENSOR,OIL LEVEL |
14 |
1809-1809 |
|
D |
4X4(TFS***) 02.343 M8X12 FLANGE |
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04 (K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT 02.343 M8X16 FLANGE |
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
1 |
1810- |
|
AB E |
02.343 M8X16 FLANGE |
| 2 |
I8-98228 328-2 |
|
GAUGE; OIL LEVEL |
1 |
1810- |
|
E |
4X4 (TFS***) (C) |
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5) 02.343 M8X16 FLANGE |
| 24 |
I0-91180 208-0 |
|
NUT; OIL PAN |
2 |
1810- |
|
DE |
01.540 M8 FLANGE |
| 43 |
I8-98225 711-0 |
|
PLATE; CRANKCASE |
1 |
1809-1809 |
|
D |
|
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
1 |
1809-1809 |
|
AB |
02.343 M8X16 FLANGE |
| 1 |
I8-98132 001-2 |
|
PAN ASM; OIL |
1 |
1810- |
|
DE |
4X4 (TFS***) |
| 28 |
I0-28050 816-0 |
|
BOLT; CRANKCASE TO C/BL |
6 |
1810- |
|
DE |
02.343 (D) M8X16 FLANGE |
| 2 |
I8-98228 328-2 |
|
GAUGE; OIL LEVEL |
1 |
1809-1809 |
|
D |
4X4 (TFS***) EMISSION SYSTEM R15-04(K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT (C) |
| 29 |
I0-91180 108-0 |
|
NUT; CRANKCASE |
2 |
1809- |
|
C |
01.062 M8 FLANGE |
| 345 |
I0-28050 812-0 |
|
BOLT; SENSOR,OIL LEVEL |
14 |
1810- |
|
DE |
4X4(TFS***) 02.343 M8X12 FLANGE |
| 27 |
I8-98225 710-2 |
|
CRANKCASE |
1 |
1809-1809 |
|
D |
4X4(TFS***) |
| 345 |
I0-28050 812-0 |
|
BOLT; SENSOR,OIL LEVEL |
21 |
1809-1809 |
|
D |
4X2(TFB***) 02.343 M8X12 FLANGE |
| 4 |
I8-97329 621-0 |
|
PLUG; DRAIN,OIL |
1 |
1809-1809 |
|
AB D |
M14X14 |
| 23 |
I0-28050 612-0 |
|
BOLT; OIL PAN |
7 |
1809- |
|
AB |
03.162 M6X12 FLANGE |
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
2 |
1809- |
|
C |
02.343 M8X16 FLANGE |
| 9 |
I8-98034 629-0 |
|
GASKET; GUIDE TUBE,OIL LEVEL GAU |
1 |
1809-1809 |
|
D |
ID=11 OD=15.8 ALSO INCLUDED IN GASKET |
| 28 |
I0-28050 825-0 |
|
BOLT; CRANKCASE TO C/BL |
12 |
1809- |
|
AB |
03.275 (A) M8X25 FLANGE |
| 216 |
I0-28050 812-0 |
|
BOLT; BRKT |
1 |
1809- |
|
C |
02.343 (A) M8X12 FLANGE |
| 8 |
I8-98228 277-2 |
|
TUBE; GUIDE,OIL LEVEL GAUGE |
1 |
1810- |
|
E |
(C) |
| 25 |
I0-41010 612-0 |
|
STUD; OIL PAN |
2 |
1809- |
|
C |
M6X12 L=21 |
| 345 |
I0-28050 812-0 |
|
BOLT; SENSOR,OIL LEVEL |
21 |
1810- |
|
DE |
4X2(TFB***) 02.343 M8X12 FLANGE |
| 24 |
I0-91180 208-0 |
|
NUT; OIL PAN |
2 |
1809-1809 |
|
D |
01.540 M8 FLANGE |
| 24 |
I0-91180 106-0 |
|
NUT; OIL PAN |
2 |
1809- |
|
AB |
01.062 M6 FLANGE |
| 21 |
I0-28050 612-0 |
|
BOLT; BAFFLE P LATE,CRANKCASE |
8 |
1809- |
|
AB |
03.162 M6X12 FLANGE |
| 25 |
I0-41010 616-0 |
|
STUD; OIL PAN |
2 |
1809- |
|
AB |
00.206 M6X16 L=25 |
| 28 |
I0-28050 816-0 |
|
BOLT; CRANKCASE TO C/BL |
6 |
1809-1809 |
|
D |
02.343 (D) M8X16 FLANGE |
| 10 |
I0-28050 816-0 |
|
BOLT; GUIDE TUBE |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04 (K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT 02.343 M8X16 FLANGE |
| 113 |
I9-08161 032-0 |
|
PIN; STRAIGHT |
2 |
1810- |
|
D |
08.939 OD=10 L=32 |
| 1 |
I8-98132 001-2 |
|
PAN ASM; OIL |
1 |
1809-1809 |
|
D |
4X4(TFS***) |
| 113 |
I9-08161 032-0 |
|
PIN; STRAIGHT |
2 |
1810- |
|
E |
A/T 5 SPEED-AISIN(MA1) 08.939 OD=10 L=32 |
| 27 |
I8-98225 708-2 |
|
CRANKCASE |
1 |
1810- |
|
E |
4X4(TFS***) M/T MUA 5 SPEED 5H(MWQ) |
| 113 |
I9-08161 032-0 |
|
PIN; STRAIGHT |
2 |
1809-1809 |
|
D |
08.939 OD=10 L=32 |
| 25 |
I0-41010 816-0 |
|
STUD; OIL PAN |
2 |
1809-1809 |
|
D |
M8X16 L=28 |
| 25 |
I0-41010 816-0 |
|
STUD; OIL PAN |
2 |
1810- |
|
DE |
M8X16 L=28 |
| 69 |
I0-28050 612-0 |
|
BOLT; PLATE |
6 |
1809- |
|
AB |
03.162 M6X12 FLANGE |
| 4 |
I8-97329 621-0 |
|
PLUG; DRAIN,OIL |
1 |
1810- |
|
AB DE |
M14X14 |
| 27 |
I8-98225 710-2 |
|
CRANKCASE |
1 |
1810- |
|
D |
4X4 (TFS***) |
| 3 |
I8-94158 328-0 |
|
GASKET; DRAIN PLUG |
1 |
1809-1809 |
|
CD |
ID=14.2 OD=2 4 ALSO INCLUDED IN GASKET |
| 9 |
I8-98034 629-0 |
|
GASKET; GUIDE TUBE,OIL LEVEL GAU |
1 |
1810- |
|
DE |
ID=11 OD=15.8 ALSO INCLUDED IN GASKET |
| 27 |
I8-98225 710-2 |
|
CRANKCASE |
1 |
1810- |
|
E |
4X4(TFS***) A/T 5 SPEED-AISIN(MA1) |
| 3 |
I8-94158 328-0 |
|
GASKET; DRAIN PLUG |
1 |
1810- |
|
CDE |
ID=14.2 OD=2 4 ALSO INCLUDED IN GASKET |
| 43 |
I8-98225 711-0 |
|
PLATE; CRANKCASE |
1 |
1810- |
|
DE |
|
| 8 |
I8-98228 277-2 |
|
TUBE; GUIDE,OIL LEVEL GAUGE |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04(K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT (C) |
| 2 |
I8-98228 328-2 |
|
GAUGE; OIL LEVEL |
1 |
1810- |
|
D |
4X4(TFS***) EMISSION SYSTEM R15-04(K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT (C) |
| 8 |
I8-98228 277-2 |
|
TUBE; GUIDE,OIL LEVEL GAUGE |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04(K IFICATION(NT2),EURO3 SPE ),EURO4 SPECIFICATION(NT (C) |
