| 2 |
I8-98132 073-0 |
|
GASKET; TURBOCHARGER TO EXH MANI |
1 |
1810- |
|
E |
ALSO INCLUDED IN GASKET D) |
| 12 |
I8-97378 062-0 |
|
STUD; TURBOCHARGER |
2 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03.601 (C) M8X25 L=3 6 |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
4 |
1809- |
|
D |
EURO3 SPECIFICATION(NT3 (A) ID=15.1 |
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
6 |
1809- |
|
B |
08.846 (B) ID=20.8 |
| 12 |
I8-97378 062-0 |
|
STUD; TURBOCHARGER |
2 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03.601 (C) M8X25 L=3 6 |
| 320 |
I0-28050 880-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 01.252 (G) M8X8 0 FLANGE |
| 526 |
I8-97352 985-0 |
|
GASKET; PLATE |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.519 |
| 528 |
I0-91180 106-0 |
|
NUT; VLV |
2 |
1809- |
|
A |
01.062 M6 FLANGE |
| 101 |
I0-28050 812-0 |
|
BOLT; HEAT PROTECTOR |
2 |
1809-1809 |
|
B D |
02.343 M8X12 FLANGE |
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
4 |
1809- |
|
D |
EURO4 SPECIFICATION(NT4 CATION(NT5) 08.846 (B) ID=20.8 |
| 320 |
I0-28650 820-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.531 (C) M8X2 0 FLANGE |
| 11 |
I8-97379 384-0 |
|
NUT; TURBOCHARGER |
4 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N M8 FLANGE |
| 458 |
I8-98184 505-0 |
|
PIPE; WATER,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 21 |
I0-28050 816-0 |
|
BOLT; PIPE |
2 |
1809- |
|
AB |
02.343 (A) M8X16 FLANGE |
| 320 |
I8-97378 076-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03. 670 (D) M8X18 FLANGE |
| 12 |
I8-97378 064-0 |
|
STUD; TURBOCHARGER |
2 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03.604 (D) M8X30 L=41 |
| 14 |
I8-97378 062-0 |
|
STUD; TURBOCHARGER TO EXH PIPE |
4 |
1809- |
|
C |
03.601 M8X25 L=3 6 |
| 527 |
I8-98156 388-0 |
|
BRACKET; TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 191 |
I0-91180 108-0 |
|
NUT; HEAT PROTECTOR |
1 |
1809- |
|
AB |
01.062 M8 FLANGE |
| 101 |
I0-28050 812-0 |
|
BOLT; HEAT PROTECTOR |
6 |
1809- |
|
C |
02.343 M8X12 FLANGE |
| 458 |
I8-98184 505-0 |
|
PIPE; WATER,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 16 |
I8-98250 275-0 |
|
ADAPTER; EXH PIPE |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2) |
| 217 |
I0-28050 830-0 |
|
BOLT; BRKT |
2 |
1809- |
|
AB |
00.206 (A) M8X30 FLANGE |
| 526 |
I8-97352 985-0 |
|
GASKET; PLATE |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.519 |
| 460 |
I0-91180 108-0 |
|
NUT; PIPE |
2 |
1809- |
|
AB |
01.062 M8 FLANGE |
| 527 |
I8-98156 388-0 |
|
BRACKET; TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 119 |
I8-98179 580-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
1810- |
|
E |
(C) L=170 |
| 320 |
I0-28650 820-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1810- |
|
E |
01.531 (C) M8X2 0 FLANGE |
| 458 |
I8-98184 505-0 |
|
PIPE; WATER,TURBOCHARGER |
1 |
1810- |
|
E |
|
| 119 |
I8-98179 580-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (C) L=170 |
| 16 |
I8-98250 275-0 |
|
ADAPTER; EXH PIPE |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2) |
| 231 |
I8-98228 462-0 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 21 |
I0-28050 816-0 |
|
BOLT; PIPE |
2 |
1809- |
|
D |
EURO4 SPECIFICATION(NT4 02.343 (A) M8X16 FLANGE |
| 320 |
I8-97378 076-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1810- |
|
E |
03.670 (D) M8X18 FLANGE |
| 320 |
I0-28151 020-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
1809- |
|
B |
03.417 (A) M10X2 0 FLANGE |
| 21 |
I0-28050 816-0 |
|
BOLT; PIPE |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 02.343 (A) M8X16 FLANGE |
| 1 |
I8-98235 628-1 |
|
TURBOCHARGER ASM |
1 |
1810- |
|
E |
(C) |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
6 |
1809-1809 |
|
D |
(A) ID=15.1 |
| 2 |
I8-98132 073-0 |
|
GASKET; TURBOCHARGER TO EXH MANI |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N ALSO INCLUDED IN GASKET D) |
| 21 |
I0-28050 645-0 |
|
BOLT; PIPE |
2 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.652 (B) M6X45 FLANGE |
| 527 |
I8-98156 388-0 |
|
BRACKET; TURBOCHARGER |
1 |
1810- |
|
E |
(B) |
| 217 |
I0-28661 230-0 |
|
BOLT; BRKT |
3 |
1809- |
|
D |
EURO3 SPECIFICATION(NT3 CATION(NT4),EURO5 SPECI 06.509 (C) M12X30 FLANGE |
| 119 |
I8-98179 580-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (C) L=170 |
| 375 |
I0-28050 820-0 |
|
BOLT; FLANGE |
6 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 04.338 M8X2 0 FLANGE |
| 13 |
I0-44011 025-0 |
|
STUD; EXH PIPE |
2 |
1809- |
|
AB |
03.342 M10X25 L=40 |
| 528 |
I0-91180 108-0 |
|
NUT; VLV |
2 |
1809- |
|
B |
01.062 M8 FLANGE |
| 11 |
I8-97379 384-0 |
|
NUT; TURBOCHARGER |
4 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N M8 FLANGE |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
6 |
1810- |
|
DE |
(A) ID=15.1 |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
4 |
1809- |
|
AB |
(A) ID=15.1 |
| 11 |
I8-97379 384-0 |
|
NUT; TURBOCHARGER |
4 |
1810- |
|
E |
M8 FLANGE |
| 16 |
I8-98250 275-0 |
|
ADAPTER; EXH PIPE |
1 |
1810- |
|
E |
|
| 119 |
I8-98239 061-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
1810- |
|
DE |
(B) L=163.5 |
| 12 |
I8-97378 062-0 |
|
STUD; TURBOCHARGER |
2 |
1810- |
|
E |
03.601 (C) M8X25 L=3 6 |
| 66 |
I0-44011 025-0 |
|
STUD; EXH PIPE |
2 |
1809-1809 |
|
D |
M10X25 L=40 |
| 32 |
I8-98156 389-0 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
1810- |
|
E |
(B) |
| 2 |
I8-98132 073-0 |
|
GASKET; TURBOCHARGER TO EXH MANI |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N ALSO INCLUDED IN GASKET D) |
| 320 |
I8-97378 076-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03.670 (D) M8X18 FLANGE |
| 21 |
I0-28050 645-0 |
|
BOLT; PIPE |
2 |
1810- |
|
E |
01.652 (B) M6X45 FLANGE |
| 526 |
I8-97352 985-0 |
|
GASKET; PLATE |
1 |
1810- |
|
E |
1519 |
| 101 |
I0-28050 820-0 |
|
BOLT; HEAT PROTECTOR |
1 |
1809- |
|
A |
04.338 M8X20 FLANGE |
| 231 |
I8-98228 462-0 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
1810- |
|
E |
|
| 32 |
I8-98156 389-0 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 21 |
I0-28050 830-0 |
|
BOLT; PIPE |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 00.206 (D) M8X30 FLANGE |
| 12 |
I8-97378 064-0 |
|
STUD; TURBOCHARGER |
2 |
1810- |
|
E |
03.604 (D) M8X30 L=41 |
| 12 |
I8-97378 064-0 |
|
STUD; TURBOCHARGER |
2 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 03.604 (D) M8X30 L=41 |
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
4 |
1809- |
|
A |
08.846 (B) ID=20.8 |
| 119 |
I8-98239 061-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
1809-1809 |
|
D |
(B) L=163.5 |
| 320 |
I0-28650 820-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.531 (C) M8X2 0 FLANGE |
| 32 |
I8-98156 389-0 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 101 |
I0-28050 812-0 |
|
BOLT; HEAT PROTECTOR |
2 |
1810- |
|
B DE |
02.343 M8X12 FLANGE |
| 21 |
I0-28050 645-0 |
|
BOLT; PIPE |
2 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 01.652 (B) M6X45 FLANGE |
| 231 |
I8-98228 462-0 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 66 |
I0-44011 025-0 |
|
STUD; EXH PIPE |
2 |
1810- |
|
DE |
M10X25 L=40 |
| 460 |
I0-91180 208-0 |
|
NUT; PIPE |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 01.540 M8 FLANGE |
| 217 |
I0-28151 020-0 |
|
BOLT; BRKT |
2 |
1809- |
|
B |
(B) M10X2 0 FLANGE |
