| 2 |
I1-09675 086-0 |
|
BOLT; EYE,OIL PIPE |
1 |
1810- |
|
DE |
03.162 (E) M14X27 EYE-BOLT |
| 581 |
I0-36230 510-0 |
|
BOLT; VSV |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 03.680 M5X10 W/LK+PL WASHER |
| 499 |
I8-98228 436-0 |
|
PIPE; VACUUM |
1 |
1810- |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI URO5 SPECIFICATION(NT5) (B) |
| 580 |
I8-97352 145-0 |
|
VALVE; VAC SW |
1 |
1810- |
|
E |
EURO2 SPECIFICATION(NT2 03.670 (B) |
| 29 |
I8-97380 673-1 |
|
BOLT; OIL PIPE,OIL JET |
4 |
1809-1809 |
|
D |
(B) M6X20 FLANGE |
| 89 |
I0-95235 536-0 |
|
CLIP; VAC HOSE |
1 |
1810- |
|
DE |
ID=16 L=20 |
| 500 |
I8-98228 438-0 |
|
HOSE; VACUUM |
1 |
1809-1809 |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI URO5 SPECIFICATION(NT5) (D) |
| 147 |
I8-98132 017-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (A) |
| 89 |
I0-95235 536-0 |
|
CLIP; VAC HOSE |
1 |
1809-1809 |
|
D |
ID=16 L=20 |
| 63 |
I8-98132 014-1 |
|
PIPE; OIL,TURBOCHARGER FEED |
1 |
1810- |
|
E |
|
| 149 |
I8-98156 381-0 |
|
PIPE; OIL RETURN,TURBOCHARGER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 313 |
I0-28050 812-0 |
|
BOLT; PIPE BRKT |
1 |
1809- |
|
C |
02.343 M8X12 FLANGE |
| 500 |
I0-08508 090-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
DE |
(A) |
| 40 |
I0-28050 616-0 |
|
BOLT; OIL PIPE |
2 |
1809- |
|
C |
09. 242 M6X16 FLANGE |
| 311 |
I0-28050 816-0 |
|
BOLT; PIPE FIX |
3 |
1810- |
|
DE |
02.343 M8X16 FLANGE |
| 534 |
I0-91180 208-0 |
|
NUT; OIL PIPE |
2 |
1810- |
|
DE |
01.540 M8 FLANGE |
| 2 |
I8-98151 063-1 |
|
BOLT; EYE,OIL PIPE |
1 |
1809-1809 |
|
D |
(B) M10X25 EYE-BOLT |
| 3 |
I8-98136 142-0 |
|
GASKET; EYE BOLT,OIL PIPE |
1 |
1810- |
|
E |
ID=10.2 OD=16 |
| 3 |
I9-09571 414-0 |
|
GASKET; EYE BOLT,OIL PIPE |
2 |
1809- |
|
C |
08.955 ID=14.2 OD=2 0 |
| 58 |
I8-97379 464-0 |
|
VALVE; RELIEF,OIL JET,PISTON COO |
1 |
1809-1809 |
|
D |
|
| 149 |
I8-98156 381-0 |
|
PIPE; OIL RETURN,TURBOCHARGER |
1 |
1810- |
|
E |
(B) |
| 28 |
I8-98113 762-0 |
|
GASKET; OIL PIPE |
1 |
1810- |
|
DE |
(B) ID=14.2 OD=2 0 ALSO INCLUDED IN GASKET |
| 3 |
I8-98136 142-0 |
|
GASKET; EYE BOLT,OIL PIPE |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N ID=10.2 OD=16 |
| 563 |
I0-41010 820-0 |
|
STUD; OIL PIPE |
2 |
1809-1809 |
|
D |
02.510 M8X20 L=32 |
| 57 |
I8-97312 132-3 |
|
PIPE; OIL,OIL JET |
1 |
1810- |
|
DE |
|
| 414 |
I0-58330 616-0 |
|
BOLT; OIL PIPE |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 00.724 (C) M6X16 HEX SOCKET |
| 500 |
I8-98228 430-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
E |
EURO2 SPECIFICATION(NT2 (B) |
| 57 |
I8-97312 132-3 |
|
PIPE; OIL,OIL JET |
1 |
1809-1809 |
|
D |
|
| 586 |
I8-98251 165-0 |
|
PIPE; OIL,TENSIONER |
1 |
1810- |
|
DE |
(A) |
| 581 |
I0-28050 816-0 |
|
BOLT; VSV |
1 |
1810- |
|
E |
EURO2 SPECIFICATION(NT2 02.343 M8X16 FLANGE |
| 147 |
I9-09571 410-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
2 |
1810- |
|
C E |
08.955 (B) ID=10.2 OD=16.0 |
| 586 |
I8-98251 165-0 |
|
PIPE; OIL,TENSIONER |
1 |
1809-1809 |
|
D |
(A) |
| 499 |
I8-98228 436-0 |
|
PIPE; VACUUM |
1 |
1810- |
|
E |
(B) |
| 3 |
I8-98136 142-0 |
|
GASKET; EYE BOLT,OIL PIPE |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N ID=10.2 OD=16 |
| 47 |
I9-09571 410-0 |
|
GASKET; OIL PIPE |
2 |
1809- |
|
C |
08.955 (B) ID=10.2 OD=16.0 |
| 110 |
I8-98251 964-0 |
|
NUT; CAP OIL PIPE |
1 |
1809-1809 |
|
D |
M8 CAP NUT FLANGE |
| 332 |
I8-98233 768-0 |
|
PIPE; OIL,C/BL TO VAC PUMP |
1 |
1810- |
|
DE |
|
| 47 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
1 |
1809- |
|
C |
05.398 (A) ID= 8.2 OD=14.0 T=1.0 |
| 500 |
I0-08508 090-0 |
|
HOSE; VACUUM |
1 |
1809-1809 |
|
D |
(A) |
| 534 |
I0-91180 208-0 |
|
NUT; OIL PIPE |
2 |
1809-1809 |
|
D |
01.540 M8 FLANGE |
| 2 |
I8-98151 063-1 |
|
BOLT; EYE,OIL PIPE |
1 |
1810- |
|
DE |
(B) M10X25 EYE-BOLT |
| 2 |
I8-98108 689-0 |
|
BOLT; EYE,OIL PIPE |
1 |
1809-1809 |
|
D |
(D) M8X23 EYE-BOLT |
| 63 |
I8-98132 014-1 |
|
PIPE; OIL,TURBOCHARGER FEED |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 311 |
I0-28050 816-0 |
|
BOLT; PIPE FIX |
3 |
1809-1809 |
|
D |
02.343 M8X16 FLANGE |
| 311 |
I0-28050 812-0 |
|
BOLT; PIPE FIX |
2 |
1809- |
|
C |
02.343 M8X12 FLANGE |
| 500 |
I8-98228 438-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI URO5 SPECIFICATION(NT5) (D) |
| 499 |
I8-98132 058-2 |
|
PIPE; VACUUM |
1 |
1810- |
|
DE |
(D) |
| 586 |
I8-98228 274-0 |
|
PIPE; OIL,TENSIONER |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 500 |
I8-98228 437-0 |
|
HOSE; VACUUM |
1 |
1809-1809 |
|
D |
(C) |
| 499 |
I8-98011 527-1 |
|
PIPE; VACUUM |
1 |
1810- |
|
DE |
(A) |
| 580 |
I8-97352 145-0 |
|
VALVE; VAC SW |
1 |
1809-1809 |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI 03.670 (B) |
| 150 |
I8-98132 018-1 |
|
GASKET; OIL PIPE TO C/BL |
1 |
1809-1809 |
|
D |
|
| 581 |
I0-28050 816-0 |
|
BOLT; VSV |
1 |
1809-1809 |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI 02.343 M8X16 FLANGE |
| 27 |
I0-28050 816-0 |
|
BOLT; OIL PIPE FIX |
1 |
1809- |
|
AB |
02.343 (A) M8X16 FLANGE |
| 338 |
I8-97910 296-1 |
|
BOLT; JOINT,OIL PIPE |
2 |
1810- |
|
DE |
M8X20 EYE-BOLT |
| 28 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
1 |
1810- |
|
DE |
05.398 (D) ID= 8.2 OD=14.0 T=1.0 ALSO INCLUDED IN GASKET |
| 150 |
I8-98132 018-1 |
|
GASKET; OIL PIPE TO C/BL |
1 |
1810- |
|
DE |
|
| 147 |
I9-09571 410-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
2 |
1809-1809 |
|
C |
08.955 (B) ID=10.2 OD=16.0 |
| 414 |
I0-28050 616-0 |
|
BOLT; OIL PIPE |
2 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 09.242 (B) M6X16 FLANGE |
| 500 |
I8-98228 430-0 |
|
HOSE; VACUUM |
1 |
1809-1809 |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI (B) |
| 27 |
I0-28050 810-0 |
|
BOLT; OIL PIPE FIX |
1 |
1809- |
|
C |
03.407 (C) M8X10 FLANGE |
| 500 |
I8-98228 430-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI (B) |
| 248 |
I8-97944 505-1 |
|
CONNECTOR; TURBOCHARGER OIL FEED |
1 |
1809-1809 |
|
D |
01.531 M10X24 |
| 499 |
I8-98011 527-1 |
|
PIPE; VACUUM |
1 |
1809-1809 |
|
D |
(A) |
| 28 |
I8-98136 142-0 |
|
GASKET; OIL PIPE |
1 |
1809- |
|
AB |
(E) ID=10.2 OD=16 |
| 586 |
I8-98228 274-0 |
|
PIPE; OIL,TENSIONER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 138 |
I0-28050 816-0 |
|
BOLT; CLIP FIX |
1 |
1809-1809 |
|
D |
02.343 M8X16 FLANGE |
| 580 |
I8-97352 145-0 |
|
VALVE; VAC SW |
1 |
1810- |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI 03.670 (B) |
| 325 |
I8-97944 127-0 |
|
CLIP; RUBBER HOSE,OIL RETURN |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 08.846 ID=20 . 8 |
| 2 |
I1-09675 086-0 |
|
BOLT; EYE,OIL PIPE |
1 |
1809-1809 |
|
D |
03.162 (E) M14X27 EYE-BOLT |
| 500 |
I8-98228 437-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
DE |
(C) |
| 338 |
I8-97910 296-1 |
|
BOLT; JOINT,OIL PIPE |
2 |
1809-1809 |
|
D |
M8X20 EYE-BOLT |
| 248 |
I8-97944 505-1 |
|
CONNECTOR; TURBOCHARGER OIL FEED |
1 |
1810- |
|
DE |
01.531 M10X24 |
| 27 |
I0-28050 820-0 |
|
BOLT; OIL PIPE FIX |
2 |
1809- |
|
AB |
04.338 (B) M8X2 0 FLANGE |
| 147 |
I9-09571 410-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
2 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 08.955 (B) ID=10.2 OD=16.0 |
| 53 |
I8-97379 384-0 |
|
NUT; OIL PIPE |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 03.342 M8 FLANGE |
| 29 |
I0-28050 810-0 |
|
BOLT; OIL PIPE,OIL JET |
1 |
1809-1809 |
|
CD |
03.407 (A) M8X10 FLANGE |
| 339 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
4 |
1809-1809 |
|
D |
05.398 ID= 8.2 OD=14.0 T=1.0 |
| 28 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
1 |
1809-1809 |
|
D |
05.398 (D) ID= 8.2 OD=14.0 T=1.0 ALSO INCLUDED IN GASKET |
| 149 |
I8-98156 381-0 |
|
PIPE; OIL RETURN,TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (B) |
| 28 |
I8-98065 992-0 |
|
GASKET; OIL PIPE |
2 |
1809-1809 |
|
D |
03.332 (A) ID= 8.3 OD=15.0 ALSO INCLUDED IN GASKET |
| 110 |
I8-98251 964-0 |
|
NUT; CAP OIL PIPE |
1 |
1810- |
|
DE |
M8 CAP NUT FLANGE |
| 58 |
I8-97379 464-0 |
|
VALVE; RELIEF,OIL JET,PISTON COO |
1 |
1810- |
|
DE |
|
| 563 |
I0-41010 820-0 |
|
STUD; OIL PIPE |
2 |
1810- |
|
DE |
02.510 M8X20 L=32 |
| 339 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
4 |
1810- |
|
DE |
05.398 ID= 8.2 OD=14.0 T=1 . 0 |
| 414 |
I0-28050 616-0 |
|
BOLT; OIL PIPE |
2 |
1810- |
|
E |
09.242 (B) M6X16 FLANGE |
| 332 |
I8-98233 768-0 |
|
PIPE; OIL,C/BL TO VAC PUMP |
1 |
1809-1809 |
|
D |
|
| 499 |
I8-98132 058-2 |
|
PIPE; VACUUM |
1 |
1809-1809 |
|
D |
(D) |
| 44 |
I0-28650 820-0 |
|
BOLT; CLIP,OIL PIPE |
1 |
1809- |
|
C |
M8X2 0 FLANGE |
| 29 |
I0-28050 810-0 |
|
BOLT; OIL PIPE,OIL JET |
1 |
1810- |
|
CDE |
03.407 (A) M8X10 FLANGE |
| 147 |
I8-98132 017-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
1 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N (A) |
| 414 |
I0-28050 616-0 |
|
BOLT; OIL PIPE |
2 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 09.242 (B) M6X16 FLANGE |
| 147 |
I9-09571 410-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
2 |
1810- |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N 08.955 (B) ID=10.2 OD=16.0 |
| 3 |
I8-98136 142-0 |
|
GASKET; EYE BOLT,OIL PIPE |
2 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 ID=10.2 OD=16 |
| 79 |
I8-97581 233-0 |
|
NUT; OIL DRAIN PIPE |
2 |
1809- |
|
C |
04.634 M8 FLANGE |
| 499 |
I8-98228 436-0 |
|
PIPE; VACUUM |
1 |
1809-1809 |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI URO5 SPECIFICATION(NT5) (B) |
| 63 |
I8-98132 014-1 |
|
PIPE; OIL,TURBOCHARGER FEED |
1 |
1809-1809 |
|
D |
EMISSION SYSTEM R15-04( IFICATION(NT2),EURO3 SP ),EURO4 SPECIFICATION(N |
| 414 |
I0-28050 820-0 |
|
BOLT; OIL PIPE |
1 |
1809- |
|
D |
EURO5 SPECIFICATION(NT5 04.338 (D) M8X2 0 FLANGE |
| 31 |
I8-98186 104-0 |
|
NIPPLE; OIL PIPE |
1 |
1809-1809 |
|
D |
|
| 28 |
I8-98113 762-0 |
|
GASKET; OIL PIPE |
1 |
1809-1809 |
|
D |
(B) ID=14.2 OD=2 0 ALSO INCLUDED IN GASKET |
| 100 |
I0-28050 812-0 |
|
BOLT; CLIP |
1 |
1809-1809 |
|
D |
02 . 343 M8X12 FLANGE |
| 586 |
I8-98228 274-0 |
|
PIPE; OIL,TENSIONER |
1 |
1810- |
|
E |
(B) |
| 2 |
I8-98108 689-0 |
|
BOLT; EYE,OIL PIPE |
1 |
1810- |
|
DE |
(D) M8X23 EYE-BOLT |
| 147 |
I8-98132 017-0 |
|
GASKET; OIL PIPE TO TURBOCHARGER |
1 |
1810- |
|
E |
(A) |
| 47 |
I9-09571 408-0 |
|
GASKET; OIL PIPE |
2 |
1809- |
|
C |
|
| 29 |
I8-97380 673-1 |
|
BOLT; OIL PIPE,OIL JET |
4 |
1810- |
|
DE |
(B) M6X20 FLANGE |
| 100 |
I0-28050 812-0 |
|
BOLT; CLIP |
1 |
1810- |
|
DE |
02.343 M8X12 FLANGE |
| 500 |
I8-98228 438-0 |
|
HOSE; VACUUM |
1 |
1810- |
|
E |
(D) |
| 31 |
I8-98186 104-0 |
|
NIPPLE; OIL PIPE |
1 |
1810- |
|
DE |
|
| 581 |
I0-28050 816-0 |
|
BOLT; VSV |
1 |
1810- |
|
D |
EURO2 SPECIFICATION(NT2 CATION(NT3),EURO4 SPECI 02.343 M8X16 FLANGE |
| 138 |
I0-28050 816-0 |
|
BOLT; CLIP FIX |
1 |
1810- |
|
DE |
02.343 M8X16 FLANGE |
| 28 |
I8-98065 992-0 |
|
GASKET; OIL PIPE |
2 |
1810- |
|
DE |
03.332 (A) ID= 8.3 OD=15.0 ALSO INCLUDED IN GASKET |
