| 1 |
I8-97948 038-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
DEF |
AISIN TAKAOKA |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1809-1809 |
|
BC |
HIGH RIDE SUSPENSION(7YC) 04.085 (A) M10X30 FLANGE |
| 49 |
I8-98080 420-3 |
|
CASE; RR AXLE |
1 |
1809-1809 |
|
DEF |
M/T MUX 5 SPEED 5S(MZJ),M ED 6N(Y5Z),M/T MVL 6 SPEE EXC. 4 WHEEL ANTI LOCK BR WHL LK CONT LSPV<JR9> (B) |
| 199 |
I8-97216 797-2 |
|
BEARING; RR AXLE |
2 |
1809- |
|
ABCDEF |
|
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1810- |
|
BC |
FINAL GEAR RATIO 41/9(GT3 RATIO 41/11(GT4),FINAL G /12(GU6),FINAL GEAR RATIO FINAL GEAR RATIO 43/10(GY EXC. HIGH RIDE SUSPENSION 04.085 (A) M10X30 FLANGE |
| 163 |
I9-09952 253-0 |
|
RING; SNAP,AXLE SHAFT |
AR |
1809- |
|
ABCDEF |
ID=38.5 T=2.00 |
| 2 |
I0-36410 616-0 |
|
BOLT; BRK DRUM |
2 |
1809- |
|
ABCDEF |
M6X16 CK-HEAD |
| 4 |
I8-98103 450-3 |
|
HOLDER; BRG,AXLE SHAFT |
2 |
1809- |
|
DEF |
|
| 49 |
I8-98080 420-3 |
|
CASE; RR AXLE |
1 |
1810- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) EXC. 4 WHEEL ANTI LOCK BR WHL LK CONT LSPV<JR9> (B) |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1809-1809 |
|
BC |
FINAL GEAR RATIO 43/12(GM R RATIO 41/9(GT3),FINAL G /11(GT4),FINAL GEAR RATIO FINAL GEAR RATIO 43/11(GW R RATIO 43/10(GY2) EXC. HIGH RIDE SUSPENSION (B) M10X90 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1810- |
|
A DEF |
M10X31 L=4 3 |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1810- |
|
BC |
FINAL GEAR RATIO 41/9(GT3 RATIO 41/11(GT4),FINAL G /12 (GU6) ,FINAL GEAR RATIO FINAL GEAR RATIO 43/10(GY EXC. HIGH RIDE SUSPENSION (B) M10X90 |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1809-1809 |
|
ABC |
4 WHEEL ANTI LOCK BRAKE<J LIMITED SLIP DIFF<G80> HIGH RIDE SUSPENSION(7YC) (B) |
| 60 |
I8-98006 960-0 |
|
BREATHER; RR AXLE CASE |
1 |
1809- |
|
ABCDEF |
EXC. AUSTRALIA EQUIPMENT( (C) L=2 9 |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1810- |
|
BC |
FINAL GEAR RATIO 41/9(GT3 RATIO 41/11(GT4),FINAL G /12(GU6),FINAL GEAR RATIO FINAL GEAR RATIO 43/10(GY EXC. HIGH RIDE SUSPENSION 04.085 M10 FLANGE |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1809-1809 |
|
BC |
HIGH RIDE SUSPENSION(7YC) 04.085 M10 FLANGE |
| 49 |
I8-98080 420-3 |
|
CASE; RR AXLE |
1 |
1809-1809 |
|
ABC |
HIGH RIDE SUSPENSION(7YC) EXC. 4 WHEEL ANTI LOCK BR WHL LK CONT LSPV<JR9> (B) |
| 49 |
I8-98080 420-3 |
|
CASE; RR AXLE |
1 |
1810- |
|
DEF |
M/T MUA 5 SPEED 5H(MWQ),M ED 5S(MZJ),M/T MVL 6 SPEE T MVL 6 SPEED 6Y(Y6P) EXC. 4 WHEEL ANTI LOCK BR WHL LK CONT LSPV<JR9> (B) |
| 25 |
I8-98080 678-2 |
|
SHAFT; AXLE,RR |
2 |
1809- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) |
| 18 |
I8-97239 868-0 |
|
RETAINER; RR AXLE |
2 |
1809- |
|
ABCDEF |
EXC. 4 WHEEL ANTI LOCK BR |
| 1 |
I8-98061 813-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) SOMBOON |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1809-1809 |
|
BC |
HIGH RIDE SUSPENSION(7YC) (B) M10X90 |
| 163 |
I9-09180 042-0 |
|
RING; SNAP,AXLE SHAFT |
AR |
1809- |
|
ABCDEF |
ID=38.5 T=1.75 |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1810- |
|
A DEF |
04.085 (A) M10X30 FLANGE |
| 1 |
I8-98061 813-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
DEF |
SOMBOON |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1809-1809 |
|
ABC |
4 WHEEL ANTI LOCK BRAKE<J HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G8 C TRACTION CONTROL<NW9> (B) |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1810- |
|
BC |
HIGH RIDE SUSPENSION(7YC) 04.085 M10 FLANGE |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1810- |
|
DEF |
M/T MUA 5 SPEED 5H(MWQ),M ED 5S(MZJ),M/T MVL 6 SPEE T MVL 6 SPEED 6Y(Y6P) 4 WHEEL ANTI LOCK BRAKE<J EXC. ELECTRONIC TRACTION (B) |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1810- |
|
ABC |
4 WHEEL ANTI LOCK BRAKE<J HIGH RIDE SUSPENSION(7YC) EXC. LIMITED SLIP DIFF<G8 C TRACTION CONTROL<NW9> (B) |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1810- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M10X31 L=4 3 |
| 1 |
I8-98061 813-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
ABC |
ELECTRONIC TRACTION CONTRO EXC. HIGH RIDE SUSPENSION SOMBOON |
| 12 |
I8-98107 914-2 |
|
BOLT; BRG HOLDER TO CASE |
8 |
1809- |
|
DEF |
M12X59 FLANGE |
| 49 |
I8-98173 631-1 |
|
CASE; RR AXLE |
1 |
1809- |
|
DEF |
A/T 5 SPEED-AISIN(MA1),A/ SIN(Y6A) 4 WHEEL ANTI LOCK BRAKE<J EXC. ELECTRONIC TRACTION (B) |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1810- |
|
A DEF |
04.085 M10 FLANGE |
| 270 |
I9-41519 109-0 |
|
SHIM; RETAINER |
AR |
1809- |
|
ABCDEF |
05. 537 T=0 . 24 |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1809-1809 |
|
A DEF |
04.085 M10 FLANGE |
| 70 |
I0-91180 210-0 |
|
NUT; CARRIER |
2 |
1809-1809 |
|
BC |
FINAL GEAR RATIO 43/12(GM R RATIO 41/9(GT3),FINAL G /11(GT4),FINAL GEAR RATIO FINAL GEAR RATIO 43/11(GW R RATIO 43/10(GY2) EXC. HIGH RIDE SUSPENSION 04.085 M10 FLANGE |
| 12 |
I8-98107 914-2 |
|
BOLT; BRG HOLDER TO CASE |
8 |
1809- |
|
ABC |
ELECTRONIC TRACTION CONTRO EXC. HIGH RIDE SUSPENSION M12X59 FLANGE |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1809-1809 |
|
BC |
FINAL GEAR RATIO 43/12(GM R RATIO 41/9(GT3),FINAL G /11 (GT4) ,FINAL GEAR RATIO FINAL GEAR RATIO 43/11(GW R RATIO 43/10(GY2) EXC. HIGH RIDE SUSPENSION M10X31 L=4 3 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
1809- |
|
ABCDEF |
01.252 ID=16.2 OD=2 4 |
| 9 |
I8-97944 831-1 |
|
PIN; WHEEL,RR AXLE |
12 |
1809- |
|
ABCDEF |
M12X42.5 RH THREAD |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1809-1809 |
|
DEF |
M/T MUX 5 SPEED 5S(MZJ),M ED 6N(Y5Z),M/T MVL 6 SPEE 4 WHEEL ANTI LOCK BRAKE<J EXC. ELECTRONIC TRACTION (B) |
| 1 |
I8-97948 038-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) AISIN TAKAOKA |
| 63 |
I8-97307 059-1 |
|
PLUG; OIL FILLER,AXLE CASE |
1 |
1809- |
|
ABCDEF |
M20X17 |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1809-1809 |
|
A DEF |
(B) M10X90 |
| 4 |
I8-98103 450-3 |
|
HOLDER; BRG,AXLE SHAFT |
2 |
1809- |
|
ABC |
ELECTRONIC TRACTION CONTR EXC. HIGH RIDE SUSPENSION |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1809-1809 |
|
BC |
HIGH RIDE SUSPENSION(7YC) M10X31 L=4 3 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
1809- |
|
ABCDEF |
M16X12.5 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1810- |
|
BC |
FINAL GEAR RATIO 41/9(GT3 RATIO 41/11(GT4),FINAL G /12(GU6),FINAL GEAR RATIO FINAL GEAR RATIO 43/10(GY EXC. HIGH RIDE SUSPENSION M10X31 L=4 3 |
| 12 |
I8-98107 914-2 |
|
BOLT; BRG HOLDER TO CASE |
8 |
1809- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) M12X59 FLANGE |
| 4 |
I8-98103 450-3 |
|
HOLDER; BRG,AXLE SHAFT |
2 |
1809- |
|
ABC |
HIGH RIDE SUSPENSION(7YC) |
| 18 |
I8-98009 341-0 |
|
RETAINER; RR AXLE |
2 |
1809- |
|
ABCDEF |
4 WHEEL ANTI LOCK BRAKE<J |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1809-1809 |
|
A DEF |
04.085 (A) M10X30 FLANGE |
| 18 |
I6-97239 868-0 |
|
RETAINER; RR AXLE |
2 |
1809- |
|
ABCDEF |
(IADG) EXC. 4 WHEEL ANTI LOCK BR |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER,AXLE CASE |
1 |
1809- |
|
ABCDEF |
ID=20 OD=3 0 |
| 49 |
I8-98080 421-3 |
|
CASE; RR AXLE |
1 |
1810- |
|
ABC |
4 WHEEL ANTI LOCK BRAKE<J LIMITED SLIP DIFF<G80> HIGH RIDE SUSPENSION(7YC) (B) |
| 14 |
I0-91180 212-0 |
|
NUT; BRG HOLDER TO CASE |
8 |
1809- |
|
ABCDEF |
M12 FLANGE |
| 1 |
I8-97948 038-1 |
|
DRUM; BRK,RR |
2 |
1809- |
|
ABC |
ELECTRONIC TRACTION CONTRO EXC. HIGH RIDE SUSPENSION AISIN TAKAOKA |
| 16 |
I8-98134 394-0 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
1809- |
|
ABCDEF |
|
| 25 |
I8-98080 678-2 |
|
SHAFT; AXLE,RR |
2 |
1809- |
|
DEF |
|
| 278 |
I8-98103 447-2 |
|
CATCHER; OIL |
2 |
1809- |
|
ABCDEF |
|
| 40 |
I8-97323 297-0 |
|
SEAL; OIL,REAR AXLE |
2 |
1809- |
|
ABCDEF |
|
| 16 |
I6-98134 394-0 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
1809- |
|
ABCDEF |
(IADG) |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1810- |
|
A DEF |
(B) M10X90 |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1810- |
|
BC |
HIGH RIDE SUSPENSION(7YC) 04.085 (A) M10X30 FLANGE |
| 199 |
I8-97216 797-A |
|
BEARING; RR AXLE |
2 |
1809- |
|
ABCDEF |
(IADG) |
| 71 |
I0-91510 808-0 |
|
WASHER; LK,FINAL DRIVE SETTING |
2 |
1809- |
|
BC |
FINAL GEAR RATIO 41/10(GT EXC. HIGH RIDE SUSPENSION 02.559 ID= 8.2 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
1809-1809 |
|
A DEF |
M10X31 L=4 3 |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
1809-1809 |
|
BC |
FINAL GEAR RATIO 43/12(GM R RATIO 41/9(GT3),FINAL G /11(GT4),FINAL GEAR RATIO FINAL GEAR RATIO 43/11(GW R RATIO 43/10(GY2) EXC. HIGH RIDE SUSPENSION 04.085 (A) M10X30 FLANGE |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
1810- |
|
BC |
HIGH RIDE SUSPENSION(7YC) (B) M10X90 |
