| 25 |
I8-98080 678-2 |
|
SHAFT; AXLE,RR |
2 |
2110- |
|
D E F |
EXC. REAR AXLE DIFF LOCK<8CL> |
| 217 |
I0-28650 616-0 |
|
BOLT; RR BRK |
1 |
2110- |
|
A D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) M6X16 FLANGE |
| 16 |
I6-98134 394-0 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
2110- |
|
ABCDE F |
(IADG) |
| 16 |
I8-98134 394-0 |
|
SEAL; OIL,RR HUB,OUTER |
2 |
2110- |
|
ABCDE F |
|
| 2 |
I0-36410 616-0 |
|
BOLT; BRK DRUM |
2 |
2110- |
|
ABCDE F |
M6X16 CK-HEAD |
| 61 |
I8-97015 784-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
A |
(A) |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
2110- |
|
ABCDE F |
M16X12.5 |
| 1 |
I8-98061 813-1 |
A |
DRUM; BRK,RR |
2 |
2110- |
|
A D E F |
SOMBOON |
| 79 |
I0-28061 090-0 |
|
BOLT; COVER TO CASE |
1 |
2110- |
|
ABCDE F |
(B) M10X90 |
| 199 |
I8-97216 797-2 |
|
BEARING; RR AXLE |
2 |
2110- |
|
A BC D E F |
|
| 49 |
I8-98481 858-0 |
|
CASE; RR AXLE |
1 |
2110- |
|
D E F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. REAR AXLE DIFF LOCK<8CL> |
| 278 |
I8-98103 447-2 |
|
CATCHER; OIL |
2 |
2110- |
|
ABCDE F |
|
| 25 |
I8-98080 678-2 |
|
SHAFT; AXLE,RR |
2 |
2110- |
|
ABC |
|
| 1 |
I8-98061 813-1 |
A |
DRUM; BRK,RR |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) SOMBOON |
| 217 |
I0-28650 616-0 |
|
BOLT; RR BRK |
1 |
2110- |
|
BC |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) HIGH RIDE SUSPENSION(7YC) M6X16 FLANGE |
| 61 |
I8-94368 493-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) REAR AXLE DIFF LOCK<8CL> (B) L=129.5 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
2110- |
|
A BC D E F |
M10X31 L=43 |
| 79 |
I0-28061 030-0 |
|
BOLT; COVER TO CASE |
7 |
2110- |
|
ABCDE F |
(A) M10X30 FLANGE |
| 18 |
I8-98009 341-0 |
|
RETAINER; RR AXLE |
2 |
2110- |
|
A |
|
| 49 |
I8-98481 858-0 |
|
CASE; RR AXLE |
1 |
2110- |
|
ABC |
4 WHEEL ANTI LOCK BRAKE<JE5> HIGH RIDE SUSPENSION(7YC) |
| 61 |
I8-94368 493-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
BC |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) HIGH RIDE SUSPENSION(7YC) (B) L=129.5 |
| 60 |
I8-98396 031-0 |
|
BREATHER; RR AXLE CASE |
1 |
2110- |
|
BC |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) HIGH RIDE SUSPENSION(7YC) (A) L=38.5 |
| 40 |
I8-97323 297-0 |
|
SEAL; OIL.REAR AXLE |
2 |
2110- |
|
ABCDE F |
|
| 25 |
I8-98393 150-0 |
|
SHAFT; AXLE,RR |
1 |
2110- |
L |
D E F |
REAR AXLE DIFF LOCK<8CL> |
| 62 |
I8-98395 037-1 |
|
HOSE; RUBBER,BREATHER,RR AXLE |
1 |
2110- |
|
BC |
REAR BODY DBL WALL CTR PULL(E63) HIGH RIDE SUSPENSION(7YC) (B) |
| 25 |
I8-98393 149-0 |
|
SHAFT; AXLE,RR |
1 |
2110- |
R |
D E F |
REAR AXLE DIFF LOCK<8CL> |
| 163 |
I9-09952 253-0 |
|
RING; SNAP,AXLE SHAFT |
AR |
2110- |
|
ABCDE F |
ID=38.5 T=2.00 |
| 9 |
I8-97944 831-1 |
|
PIN; WH EEL, RR AXLE |
12 |
2110- |
|
ABCDE F |
M12X42.5 RH THREAD |
| 270 |
I9-41519 109-0 |
|
SHIM; RETAINER |
AR |
2110- |
|
ABCDE F |
T=0.24 |
| 61 |
I8-97015 784-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
1 |
2110- |
|
BC |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) HIGH RIDE SUSPENSION(7YC) (A) ID=11 |
| 4 |
I8-98103 450-3 |
|
HOLDER; BRG,AXLE SHAFT |
2 |
2110- |
|
ABCDE F |
|
| 14 |
I0-91180 212-0 |
|
NUT; BRG HOLDER TO CASE |
8 |
2110- |
|
A BC D E F |
M12 FLANGE |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER,AXLE CASE |
1 |
2110- |
|
ABCDE F |
ID=20 OD=30 |
| 60 |
I8-98396 031-0 |
|
BREATHER; RR AXLE CASE |
1 |
2110- |
|
A D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) (A) L=38.5 |
| 61 |
I8-97015 784-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) (A) ID=11 |
| 61 |
I8-97015 784-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
1 |
2110- |
|
A D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) (A) ID=11 |
| 61 |
I8-97015 784-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) (A) ID=11 |
| 62 |
I8-98395 037-1 |
|
HOSE; RUBBER,BREATHER,RR AXLE |
1 |
2110- |
|
A D E F |
REAR BODY DBL WALL CTR PULL(E63) (B) |
| 40 |
I6-97323 297-0 |
|
SEAL; OIL.REAR AXLE |
2 |
2110- |
|
ABCDE F |
(IADG) |
| 12 |
I8-98107 914-2 |
|
BOLT; BRG HOLDER TO CASE |
8 |
2110- |
|
ABCDE F |
M12X59 FLANGE |
| 199 |
I8-97216 797-A |
|
BEARING; RR AXLE |
2 |
2110- |
|
A BC D E F |
(IADG) |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
2110- |
|
ABCDE F |
ID=16.2 OD=24 |
| 49 |
I8-98481 860-0 |
|
CASE; RR AXLE |
1 |
2110- |
|
D E F |
A/T 6 SPEED-AISIN(Y6A) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. REAR AXLE DIFF LOCK<8CL> |
| 49 |
I8-98481 862-0 |
|
CASE; RR AXLE |
1 |
2110- |
|
D E F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) 4 WHEEL ANTI LOCK BRAKE<JE5> REAR AXLE DIFF LOCK<8CL> |
| 163 |
I9-09180 042-0 |
|
RING; SNAP,AXLE SHAFT |
AR |
2110- |
|
ABCDE F |
ID=38.5 T=1.75 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
2110- |
|
A BC D E F |
M10FLANGE |
| 61 |
I8-94368 493-0 |
|
CLIP; BREATHER HOSE.RR AXLE |
2 |
2110- |
|
A D E F |
REAR BODY DBL WALL CTR PULL(E63),REAR BODY DELETE(8HH) (B) L=129.5 |
| 18 |
I8-98009 341-0 |
|
RETAINER; RR AXLE |
2 |
2110- |
|
BCDE F |
4 WHEEL ANTI LOCK BRAKE<JE5> |
| 63 |
I8-97307 059-1 |
|
PLUG; OIL FILLER,AXLE CASE |
1 |
2110- |
|
ABCDE F |
M20X17 |
