| 79 |
I0-91180 208-0 |
|
NUT; UPR LINK END TO KNUCKLE |
8 |
2110- |
|
ABCDE F |
(B) M8 FLANGE |
| 88 |
I8-97245 631-0 |
|
NUT; LWR LINK |
4 |
2110- |
|
ABCDE F |
M16FLANGE |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
B |
4JJ3 ENG(LNG) REAR SPRING HEAVY DUTY(G50) EUROS SPECIFICATI0N(NT5),EUR06D SPECIFICATION(8SJ) HIGH RIDE SUSPENSION(7YC) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
D |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) EXC. REAR SPRING HEAVY DUTY(G50) |
| 17 |
I8-97236 303-0 |
|
BUSHING; RUBBER,S/ABS |
2 |
2110- |
|
ABCDE F |
(B) |
| 65 |
I8-98005 971-0 |
|
WASHER; S/ABS |
2 |
2110- |
|
ABCDE F |
(A) |
| 16 |
I8-97947 100-0 |
|
COVER; DUST,FRT S/ABS |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 240 |
I8-97946 180-0 |
|
BUMPER; LWR CONT ARM |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
B |
4JJ3 ENG(LNG) GENERAL EXPORT EQUIPMENT(TAA) HIGH RIDE SUSPENSION(7YC) EXC. REAR SPRING HEAVY DUTY(G50) |
| 84 |
I8-98389 433-1 |
|
ARM; LWR CONT |
1 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
C |
4JJ3 ENG(LNG) AUSTRALIA EQUIPMENT(B13) HIGH RIDE SUSPENSION(7YC) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 3 |
I0-29261 490-0 |
|
BOLT; UPR LINK TO FRAME |
4 |
2110- |
|
A D E F |
M14X90 |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
D |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) EXC. REAR SPRING HEAVY DUTY(G50) |
| 48 |
I6-98005 875-0 |
|
JOINT ASM; BALL,LWR CONT ARM |
2 |
2110- |
|
BC |
(IADG) HIGH RIDE SUSPENSION(7YC) |
| 77 |
I0-81123 028-0 |
|
PIN; SPLIT.LINK END TO KNUCKLE |
2 |
2110- |
|
A BC D E F |
OD=2.8 L=28 |
| 103 |
I8-97245 635-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
2110- |
|
A BC D E F |
(A) M14FLANGE |
| 149 |
I0-28651 025-0 |
|
BOLT; ARM TO LWR CONT ARM |
4 |
2110- |
|
BC |
EXC. HIGH RIDE SUSPENSION(7YC) |
| 3 |
I8-97947 455-0 |
|
BOLT; UPR LINK TO FRAME |
4 |
2110- |
|
BC |
EXC. HIGH RIDE SUSPENSION(7YC) M14X74 |
| 84 |
I8-98389 434-1 |
|
ARM; LWR CONT |
1 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 25 |
I8-98389 431-1 |
|
ARM; UPRCONT |
1 |
2110- |
|
A D E F |
|
| 16 |
I8-97947 100-0 |
|
COVER; DUST,FRT S/ABS |
2 |
2110- |
|
A D E F |
|
| 48 |
I8-98005 875-0 |
|
JOINT ASM; BALL,LWR CONT ARM |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 65 |
I8-97944 892-0 |
|
WASHER; S/ABS |
2 |
2110- |
|
A BC D E F |
(C) |
| 17 |
I8-97264 184-0 |
|
BUSHING; RUBBER,S/ABS |
2 |
2110- |
|
A BC D E F |
(A) |
| 45 |
I8-98389 666-1 |
|
BUSHING; UPR LINK.FRT |
4 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 58 |
I8-98389 670-0 |
|
BUSHING; LWR LINK |
4 |
2110- |
|
A D E F |
|
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
D |
4JJ3 ENG(LNG) GENERAL EXPORT EQUIPMENT(TAA) EXC. REAR SPRING HEAVY DUTY(G50) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
E |
RZ4E-TC ENG(RDZ) INDONESIA EQUIPMENT(BOO),MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) EXC. REAR SPRING HEAVY DUTY(G50) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
E |
RZ4E-TC ENG(RDZ) REAR SPRING HEAVY DUTY(G50) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) |
| 25 |
I8-98389 431-1 |
|
ARM; UPRCONT |
1 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) INDONESIA EQUIPMENT(BOO),MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 48 |
I8-98005 875-0 |
|
JOINT ASM; BALL,LWR CONT ARM |
2 |
2110- |
|
A D E F |
|
| 79 |
I0-91110 514-0 |
|
NUT; UPR LINK END TO KNUCKLE |
2 |
2110- |
|
ABCDE F |
(A) M14 |
| 103 |
I8-97245 637-0 |
|
NUT; S/ABS TO LWR LINK |
6 |
2110- |
|
A BC D E F |
(B) M10FLANGE |
| 58 |
I8-98389 670-0 |
|
BUSHING; LWR LINK |
4 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 53 |
I0-91110 518-0 |
|
NUT; LWR LINK |
2 |
2110- |
|
ABCDE F |
(B) M18 |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
B |
4JJ3 ENG(LNG) GENERAL EXPORT EQUIPMENT(TAA) EUROS SPECIFICATI0N(NT5),EUR06D SPECIFICATION(8SJ) HIGH RIDE SUSPENSION(7YC) EXC. REAR SPRING HEAVY DUTY(G50) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
B |
4JJ3 ENG(LNG) AUSTRALIA EQUIPMENT(B13),HONG KONG EQUIPMENT(B14) HIGH RIDE SUSPENSION(7YC) EXC. REAR SPRING HEAVY DUTY(G50) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
C |
4JJ3 ENG(LNG) MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUR05 SPECIFICATION(NTS) HIGH RIDE SUSPENSION(7YC) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 21 |
I8-98480 997-0 |
|
JOINT ASM; BALLfUPR CONT ARM |
2 |
2110- |
|
A D E F |
|
| 84 |
I8-98389 433-1 |
|
ARM; LWR CONT |
1 |
2110- |
|
A D E F |
|
| 3 |
I0-29261 490-0 |
|
BOLT; UPR LINK TO FRAME |
4 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M14X90 |
| 84 |
I8-98389 434-1 |
|
ARM; LWR CONT |
1 |
2110- |
|
A D E F |
|
| 25 |
I8-98389 432-1 |
|
ARM; UPRCONT |
1 |
2110- |
|
A D E F |
|
| 48 |
I6-98005 875-0 |
|
JOINT ASM; BALL,LWR CONT ARM |
2 |
2110- |
|
A D E F |
(IADG) |
| 92 |
I7-05110 010-A |
|
NUT; FRT SUSP |
4 |
2110- |
|
ABCDE F |
M10FLANGE |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) INDONESIA EQUIPMENT(BOO),MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 65 |
I8-98005 972-0 |
|
WASHER; S/ABS |
2 |
2110- |
|
ABCDE F |
(B) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
F |
4JJ3 ENG(LNG) INDONESIA EQUIPMENT(BOO),MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 81 |
I0-81123 028-0 |
|
PIN; SPLIT, LWR LINK TO KNUCKLE |
2 |
2110- |
|
ABCDE F |
OD=2.8 L=28 |
| 14 |
I8-97236 304-0 |
|
NUT; S/ABS.UPR |
2 |
2110- |
|
ABCDE F |
M12 FLANGE |
| 19 |
I0-28061 080-0 |
|
BOLT; FRT SUSP TO C/MBR |
4 |
2110- |
|
BC |
EXC. HIGH RIDE SUSPENSION(7YC) M10X80 FLANGE |
| 75 |
I8-98177 899-1 |
|
BRACKET; FRT S/ABS |
2 |
2110- |
|
ABCDE F |
|
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
C |
4JJ3 ENG(LNG) MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) HIGH RIDE SUSPENSION(7YC) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
A |
4JJ3 ENG(LNG) |
| 21 |
I8-98480 997-0 |
|
JOINT ASM; BALLfUPR CONT ARM |
2 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 20 |
I0-28060 825-0 |
|
BOLT; UPR LINK END TO UPR LINK |
8 |
2110- |
|
ABCDE F |
M8X25 FLANGE |
| 45 |
I8-98389 666-1 |
|
BUSHING; UPR LINK.FRT |
4 |
2110- |
|
A D E F |
|
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
D F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) REAR SPRING HEAVY DUTY(G50) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
C |
RZ4E-TC ENG(RDZ) MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) HIGH RIDE SUSPENSION(7YC) EXC. SOFT RIDE SUSPENSION SYSTEM<FE1>,REAR SPRING HEAVY DUTY(G50) |
| 96 |
I8-98186 404-0 |
|
BOLT; LWR LINK |
4 |
2110- |
|
A BC D E F |
(B) M16X102W/P LATE |
| 5 |
I8-97245 635-0 |
|
NUT; UPR LINK TO FRAME |
4 |
2110- |
|
ABCDE F |
M14 FLANGE |
| 25 |
I8-98389 432-1 |
|
ARM; UPRCONT |
1 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) |
| 53 |
I0-91180 212-0 |
|
NUT; LWR LINK |
8 |
2110- |
|
ABCDE F |
(A) M12FLANGE |
| 19 |
I0-28061 000-0 |
|
BOLT; FRT SUSP TO C/MBR |
4 |
2110- |
|
A D E F |
M10X100 |
| 96 |
I8-97245 639-0 |
|
BOLT; LWR LINK |
8 |
2110- |
|
ABCDE F |
(A) M12X37 FLANGE |
| 19 |
I0-28061 000-0 |
|
BOLT; FRT SUSP TO C/MBR |
4 |
2110- |
|
BC |
HIGH RIDE SUSPENSION(7YC) M10X100 |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
E |
4JJ3 ENG(LNG),RZ4E-TC ENG(RDZ) INDONESIA EQUIPMENT(BOO),MALAYSIA EQUIPMENT(B10),GENERAL EXPORT EQUIPMENT(TAA) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) EXC. REAR SPRING HEAVY DUTY(G50) |
| 240 |
I8-97946 180-0 |
|
BUMPER; LWR CONT ARM |
2 |
2110- |
|
A D E F |
|
| 47 |
I8-98394 074-2 |
|
SPRING; COIL.FRT SUSP |
2 |
2110- |
|
C |
4JJ3 ENG(LNG) REAR SPRING HEAVY DUTY(G50) EUROS SPECIFICATION(NT5) HIGH RIDE SUSPENSION(7YC) |
| 62 |
I8-98481 334-1 |
|
ABSORBER ASM; SHOCK,FRT |
2 |
2110- |
|
B |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) GENERAL EXPORT EQUIPMENT(TAA) HIGH RIDE SUSPENSION(7YC) EXC. REAR SPRING HEAVY DUTY(G50) |
| 60 |
I8-97947 455-0 |
|
BOLT; S/ABS TO LWR LINK |
2 |
2110- |
|
ABCDE F |
M14X74 |
