PORTAL SPAREPART

8-03 | 8-03 - LAMP; REAR AND REAR SIDE

Partial Engine Partial Engine Partial Engine Partial Engine Partial Engine

DMAX

D-MAX 2022

Key PART NO ITC DESCRIPTION QTY APP DATE LR MODEL REMARKS
8 I8-97492 806-0 HARNESS; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
5 I8-97179 967-0 BULB; RR COMB LAMP 1 2110- ABCDE F REAR BODY DBL WALL CTR PULL(E63) (A) TURN SIGNAL 12V21WAMBER
51 I8-97310 952-0 BULB; LICENSE PLATE LAMP 2 2110- A B C D E 12V 5W
5 I8-94125 959-0 BULB; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (C) TAIL & STOP 12V21/5W
49 I8-98224 482-0 LAMP; LICENSE PLATE 2 2110- A B C D E
1 I8-98328 799-3 LAMP ASM; RR COMB 1 2110- R A REAR BODY DBL WALL CTR PULL(E63) (B)
8 I8-97495 751-0 HARNESS; RR COMB LAMP 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
318 I8-97553 900-0 LAMP SUB ASM 1 2110- A CD F
5 I8-97179 967-0 BULB; RR COMB LAMP 1 2110- ABCDE F REAR BODY DBL WALL CTR PULL(E63) (A) TURN SIGNAL 12V21WAMBER
287 I8-97488 284-0 LAMP UNIT; RR COMB 1 2110- L AB E REAR BODY DBL WALL CTR PULL(E63) (B)
287 I8-97488 279-0 LAMP UNIT; RR COMB 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> EXC. RR FOG LAMP<T79> (A)
201 I8-94124 074-0 BULB; RR FOG LAMP 1 2110- BC D E F RR FOG LAM P<T79> REAR BODY DELETE(8HH) 12V 21W
298 I8-97289 148-0 CAP; BREATH ER, RR COMB LAMP 2 2110- CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
318 I8-97553 900-0 LAMP SUB ASM 1 2110- B E HIGH MOUNT STOP LAMP<TS6>
5 I8-94124 074-0 BULB; RR COMB LAMP 4 2110- A C D E F REAR BODY DELETE(8HH) (B) BACK-UP 12V 21W
5 I8-94125 959-0 BULB; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (C) TAIL & STOP 12V21/5W
8 I8-97495 751-0 HARNESS; RR COMB LAMP 1 2110- L AB E REAR BODY DBL WALL CTR PULL(E63) (B)
1 I8-98328 806-3 LAMP ASM; RR COMB 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
1 I8-98328 806-3 LAMP ASM; RR COMB 1 2110- L AB E REAR BODY DBL WALL CTR PULL(E63) (B)
298 I8-97289 148-0 CAP; BREATH ER, RR COMB LAMP 2 2110- CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
5 I8-94125 959-0 BULB; RR COMB LAMP 2 2110- B REAR BODY FLAT BED(E39),REAR BODY DELETE(8HH) (C) TAIL & STOP 12V21/5W
201 I8-94124 074-0 BULB; RR FOG LAMP 1 2110- B REAR BODY FLAT BED(E39) RR FOG LAM P<T79> EXC. RR UNDERRUN PROTECTOR<6DY> 12V 21W
298 I8-97289 148-0 CAP; BREATH ER, RR COMB LAMP 2 2110- AB E REAR BODY DBL WALL CTR PULL(E63) (B)
1 I8-98326 843-4 LAMP ASM; RR COMB 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> EXC. RR FOG LAMP<T79> (A)
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R A REAR BODY DBL WALL CTR PULL(E63) (B)
298 I8-97289 148-0 CAP; BREATH ER, RR COMB LAMP 2 2110- AB E REAR BODY DBL WALL CTR PULL(E63) (B)
51 I8-97310 952-0 BULB; LICENSE PLATE LAMP 2 2110- A B C D E 12V 5W
8 I8-97495 751-0 HARNESS; RR COMB LAMP 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
1 I8-98326 844-4 LAMP ASM; RR COMB 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
5 I8-94124 074-0 BULB; RR COMB LAMP 1 2110- ABCDE F REAR BODY DBL WALL CTR PULL(E63) (B) BACK-UP 12V 21W
8 I8-97492 806-0 HARNESS; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> EXC. RR FOG LAMP<T79> (A)
287 I8-97488 283-0 LAMP UNIT; RR COMB 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAM P<T79>, LAM PS TAIL AND STOP DELUXE<T81 > (B)
234 I1-82119 148-0 SOCKET ASM; 2 2110- A BC D E F
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R A REAR BODY DBL WALL CTR PULL(E63) (B)
49 I8-98224 482-0 LAMP; LICENSE PLATE 2 2110- A B C D E
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAM P<T79>, LAM PS TAIL AND STOP DELUXE<T81 > (B)
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R B E REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAMP<T79> (B)
1 I8-98328 799-3 LAMP ASM; RR COMB 1 2110- R B E REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAMP<T79> (B)
298 I8-97492 810-0 CAP; BREATH ER, RR COMB LAMP 2 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
5 I8-94125 959-0 BULB; RR COMB LAMP 2 2110- A C D E F REAR BODY DELETE(8HH) (C) TAIL &. STOP 12V21/5W
5 I8-94125 959-0 BULB; RR COMB LAMP 1 2110- AB E REAR BODY DBL WALL CTR PULL(E63) (C) TAIL & STOP 12V21/5W
287 I8-97488 283-0 LAMP UNIT; RR COMB 1 2110- R B E REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAMP<T79> (B)
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAM P<T79>, LAM PS TAIL AND STOP DELUXE<T81 > (B)
5 I8-94125 959-0 BULB; RR COMB LAMP 1 2110- AB E REAR BODY DBL WALL CTR PULL(E63) (C) TAIL & STOP 12V21/5W
8 I8-97492 806-0 HARNESS; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
287 I8-97488 283-0 LAMP UNIT; RR COMB 1 2110- R A REAR BODY DBL WALL CTR PULL(E63) (B)
300 I8-97372 854-0 HOLDER; LAMP 4 2110- A B C D E REAR BODY DBL WALL CTR PULL(E63)
298 I8-97492 810-0 CAP; BREATH ER, RR COMB LAMP 2 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
8 I8-97492 808-0 HARNESS; RR COMB LAMP 1 2110- R B E REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAMP<T79> (B)
1 I8-98328 799-3 LAMP ASM; RR COMB 1 2110- R CD F REAR BODY DBL WALL CTR PULL(E63) EXC. RR FOG LAM P<T79>, LAM PS TAIL AND STOP DELUXE<T81 > (B)
5 I8-94124 074-0 BULB; RR COMB LAMP 1 2110- ABCDE F REAR BODY DBL WALL CTR PULL(E63) (B) BACK-UP 12V 21W
287 I8-97488 284-0 LAMP UNIT; RR COMB 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) EXC. LAMPS TAIL AND STOP DELUXE<T81> (B)
5 I8-94124 074-0 BULB; RR COMB LAMP 4 2110- B REAR BODY FLAT BED(E39),REAR BODY DELETE(8HH) (B) BACK-UP 12V 21W
7 I0-74160 514-0 SCREW; RR COMB LAMP 4 2110- A BC D E F REAR BODY DBL WALL CTR PULL(E63) M5X14 TAPPING W/PL WASHER
8 I8-97492 806-0 HARNESS; RR COMB LAMP 1 2110- CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> EXC. RR FOG LAMP<T79> (A)
287 I8-97488 280-0 LAMP UNIT; RR COMB 1 2110- L CD F REAR BODY DBL WALL CTR PULL(E63) LAMPS TAIL AND STOP DELUXE<T81> (A)
8 I8-97495 751-0 HARNESS; RR COMB LAMP 1 2110- L AB E REAR BODY DBL WALL CTR PULL(E63) (B)
