| 180 |
I8-97545 787-0 |
|
COLLAR; BRKT |
1 |
2110- |
|
BC D E F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) |
| 123 |
I8-97545 811-0 |
|
GASKET; RECEIVER PIPE |
2 |
2110- |
|
BCDE F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) EUR05 SPECIFICATI0N(NT5),EUR06D SPECIFICATION(8SJ) |
| 67 |
I8-97512 041-0 |
|
GASKET; FLE |
2 |
2110- |
|
A |
4JJ3 ENG(LNG),RZ4E-TC ENG(RDZ) (E) |
| 123 |
I8-97545 811-0 |
|
GASKET; RECEIVER PIPE |
2 |
2110- |
|
A |
|
| 49 |
I8-97547 127-0 |
|
CLAMP; FLEX HOSE |
1 |
2110- |
|
BC D E F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) (B) |
| 53 |
I8-97491 403-4 |
|
PIPE; RECEIVER TANK TO EVAP |
1 |
2110- |
|
ACE |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) |
| 226 |
I8-97491 408-0 |
|
TUBE; A/C |
1 |
2110- |
|
BCDE F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),COOLER WO/HEATER(C65) EUROO SPECIFICATIONS),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR06D SPECIFICATION(8SJ) (E) |
| 23 |
I8-97383 407-0 |
|
BOLT; BRKT |
1 |
2110- |
|
A |
4JJ3 ENG(LNG),RZ4E-TC ENG(RDZ) M6X30W/PL WASHER |
| 226 |
I8-97491 409-0 |
|
TUBE; A/C |
1 |
2110- |
|
CD F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER AUTOMATIC CONT(C61) EU ROO SPECIFICATIONS),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR06D SPECIFICATIONS) (G) |
| 147 |
I8-97512 045-0 |
|
CAP; FLEX HOSE |
1 |
2110- |
|
BCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) |
| 67 |
I8-97512 039-0 |
|
GASKET; FLE |
2 |
2110- |
|
A |
RZ4E-TC ENG(RDZ) (D) |
| 49 |
I8-97547 127-0 |
|
CLAMP; FLEX HOSE |
1 |
2110- |
|
BCDE F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (b) |
| 67 |
I8-97512 040-0 |
|
GASKET; FLE |
1 |
2110- |
|
A |
4JJ3 ENG(LNG),RZ4E-TC ENG(RDZ) (F) |
| 216 |
I0-28650 620-0 |
|
BOLT; HOSE FIX |
1 |
2110- |
|
A |
4JJ3 ENG(LNG),RZ4E-TC ENG(RDZ) (A) M6X20 FLANGE |
| 122 |
I8-97512 043-0 |
|
GASKET |
Ol |
2110- |
|
BC D E F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) |
| 158 |
I0-52000 616-0 |
|
BOLT; PIPE FIX |
2 |
2110- |
|
BC D E F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) M6X16 |
| 226 |
I8-97491 404-1 |
|
TUBE; A/C |
1 |
2110- |
|
BCDE F |
|
| 147 |
I8-97512 044-0 |
|
CAP; FLEX HOSE |
Ol |
2110- |
|
A |
(B) |
| 162 |
I0-28650 825-0 |
|
BOLT; FLEX HOSE |
1 |
2110- |
|
A BC D E F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) M8X25 FLANGE |
| 67 |
I8-97512 041-0 |
|
GASKET; FLE |
1 |
2110- |
|
A |
RZ4E-TC ENG(RDZ) îcï |
| 214 |
I8-97545 786-0 |
|
RUBBER; CUSHION |
1 |
2110- |
|
BCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) |
| 66 |
I8-97491 399-2 |
|
HOSE; FLEX,A/C |
1 |
2110- |
|
B C D E F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) EU ROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION (NT4),EUR06D SPECIFICATION(8SJ) (E) |
| 66 |
I8-97550 700-1 |
|
HOSE; FLEX,A/C |
1 |
2110- |
|
CD F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER AUTOMATIC CONT(C61) EU ROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION (NT4),EUR06D SPECIFICATION(8SJ) (F) |
| 123 |
I8-97545 811-0 |
|
GASKET; RECEIVER PIPE |
2 |
2110- |
|
BC D E F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) |
| 67 |
I8-97512 040-0 |
|
GASKET; FLE |
1 |
2110- |
|
BCDE F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) (F) |
| 67 |
I8-97512 039-0 |
|
GASKET; FLE |
2 |
2110- |
|
B C D E F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C6S) (D) |
| 67 |
I8-97512 041-0 |
|
GASKET; FLE |
2 |
2110- |
|
BC D E F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (E) |
| 67 |
I8-97512 039-0 |
|
GASKET; FLE |
1 |
2110- |
|
A |
4JJ3 ENG(LNG) (D) |
| 67 |
I8-97512 039-0 |
|
GASKET; FLE |
1 |
2110- |
|
BCDE F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (D) |
| 162 |
I0-28650 835-0 |
|
BOLT; FLEX HOSE |
2 |
2110- |
|
BCDE F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (B) M8X35 FLANGE |
| 216 |
I0-28650 825-0 |
|
BOLT; HOSE FIX |
2 |
2110- |
|
A |
RZ4E-TC ENG(RDZ) (B) M8X25 FLANGE |
| 216 |
I0-28650 825-0 |
|
BOLT; HOSE FIX |
2 |
2110- |
|
BC D E F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (B) M8X25 FLANGE |
| 67 |
I8-97512 041-0 |
|
GASKET; FLE |
2 |
2110- |
|
BCDE F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (E) |
| 23 |
I8-97383 407-0 |
|
BOLT; BRKT |
1 |
2110- |
|
BC D E F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) M6X30W/PL WASHER |
| 226 |
I8-97491 405-1 |
|
TUBE; A/C |
1 |
2110- |
|
CD F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER AUTOMATIC CONT(C61) EU ROO SPECIFICATIONS),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATI0N(NT4),EUR06D SPECIFICATION^) (H) |
| 162 |
I0-28650 825-0 |
|
BOLT; FLEX HOSE |
1 |
2110- |
|
A BC D E F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) M8X25 FLANGE |
| 67 |
I8-97512 040-0 |
|
GASKET; FLE |
1 |
2110- |
|
BC D E F |
4JJ3 ENG(LNG) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (F) |
| 67 |
I8-97512 041-0 |
|
GASKET; FLE |
1 |
2110- |
|
BCDE F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) (E) |
| 66 |
I8-97491 395-2 |
|
HOSE; FLEX,A/C |
1 |
2110- |
|
BC D E F |
RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),COOLER WO/HEATER(C65) EU ROO SPECIFICATIONS),EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION (NT4),EUR06D SPECIFICATION(8SJ) (D) |
| 202 |
I8-97512 048-0 |
|
SWITCH; PRESSURE |
1 |
2110- |
|
BC D E F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) |
| 214 |
I8-97545 786-0 |
|
RUBBER; CUSHION |
1 |
2110- |
|
A |
|
| 53 |
I8-97491 403-4 |
|
PIPE; RECEIVER TANK TO EVAP |
1 |
2110- |
|
B D F |
RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) (A) |
| 122 |
I8-97512 043-0 |
|
GASKET |
Ol |
2110- |
|
A |
|
| 180 |
I8-97545 787-0 |
|
COLLAR; BRKT |
1 |
2110- |
|
A |
|
| 146 |
I8-97512 047-0 |
|
CLIP; RECEIVER PIPE |
Ol |
2110- |
|
BCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (B) |
| 158 |
I0-52000 616-0 |
|
BOLT; PIPE FIX |
2 |
2110- |
|
A |
RZ4E-TC ENG(RDZ) M6X16 |
| 202 |
I8-97512 048-0 |
|
SWITCH; PRESSURE |
1 |
2110- |
|
A |
|
| 146 |
I8-97512 046-0 |
|
CLIP; RECEIVER PIPE |
2 |
2110- |
|
A |
(A) |
| 146 |
I8-97512 047-0 |
|
CLIP; RECEIVER PIPE |
Ol |
2110- |
|
A |
|
| 216 |
I0-28650 620-0 |
|
BOLT; HOSE FIX |
1 |
2110- |
|
BCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) M6X20 FLANGE |
| 162 |
I0-28650 825-0 |
|
BOLT; FLEX HOSE |
1 |
2110- |
|
ABCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/H EATER(C65) (A) M8X25 FLANGE |
| 162 |
I0-28650 835-0 |
|
BOLT; FLEX HOSE |
2 |
2110- |
|
A |
RZ4E-TC ENG(RDZ) (B) M8X35 FLANGE |
| 146 |
I8-97512 046-0 |
|
CLIP; RECEIVER PIPE |
2 |
2110- |
|
BCDE F |
AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61),COOLER WO/HEATER(C65) (A) (B) |
| 49 |
I8-97547 127-0 |
|
CLAMP; FLEX HOSE |
1 |
2110- |
|
A |
4JJ3 ENG(LNG) (B) |
