| 399 |
I8-98480 566-0 |
|
SENSOR, CRANKSHAFT POSITION |
1 |
2311- |
|
C |
|
| 90 |
I8-98247 320-0 |
|
PIPE, OIL,JET |
4 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATIONS),EUR02 SPECIFICATION(NT2) |
| 476 |
I0-44011 070-0 |
|
STUD, NOZZLE HOLDER |
2 |
2311- |
|
AB |
(D-MAX 2024) M10X70 L=85 |
| 385 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
4 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) M8X20 FLANGE |
| 400 |
I8-97388 684-0 |
|
GASKET, CRANKSHAFT POSITION SENSOR |
1 |
2311- |
|
C |
|
| 8 |
I8-98257 516-0 |
|
BOLT, BRG CAP |
10 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) M11X88 FLANGE |
| 203 |
I0-49140 818-0 |
|
STUD, FAN CLU |
1 |
2311- |
|
A |
(D-MAX 2024) (B) M8X18 L=36 |
| 323 |
I9-09571 412-0 |
|
GASKET |
2 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5)D=12.2 OD=18 |
| 23 |
I5-11219 018-0 |
|
CUP, SEALING,RR |
10 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (A) 0D=36 |
| 385 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
4 |
2311- |
|
A |
(D-MAX 2024) M8X20 FLANGE |
| 15 |
I8-98336 980-0 |
|
PLUG, OIL GALLERY |
2 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) M12X11 |
| 1 |
I8-97790 302-1 |
|
BLOCK ASM, CYL |
1 |
2311- |
|
C |
|
| 117 |
I8-97495 759-0 |
|
COVER ASM, C/BL |
1 |
2311- |
|
C |
|
| 211 |
I0-28050 880-0 |
|
BOLT, WATER PUMP |
8 |
2311- |
|
C |
(A) M8X80 FLANGE |
| 61 |
I5-11129 006-0 |
|
CUP, SEALING,CYL HEAD |
6 |
2311- |
|
C |
(D-MAX 2024) od=16 |
| 21 |
I5-09600 013-0 |
|
CUP, SEALING,CYL HEAD |
1 |
2311- |
|
C |
(D-MAX 2024) (C) OD=12.3 |
| 441 |
I8-94453 344-0 |
|
PIN, INJ PUMP BRKT |
2 |
2311- |
|
A |
(D-MAX 2024) (B) OD=14 |
| 103 |
I8-98240 170-1 |
|
NIPPLE, OIL FEED |
1 |
2311- |
|
C |
|
| 203 |
I0-41010 820-0 |
|
STUD |
2 |
2311- |
|
AB |
(D-MAX 2024) (A) M 8X20 L=32 |
| 82 |
I8-97515 875-0 |
|
STUD, FLYWHEEL HSG |
1 |
2311- |
|
A B |
(D-MAX 2024) (B) M10X65 L=80 |
| 21 |
I5-11219 018-0 |
|
CUP, SEALING,RR |
1 |
2311- |
|
C |
(D-MAX 2024) (B) OD=36 |
| 434 |
I8-97495 760-0 |
|
COVER, CRANKCASE |
1 |
2311- |
|
C |
4X2(TFB***) (A) |
| 5 |
I5-09600 013-0 |
|
CUP, SEALING,CYL HEAD |
4 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (A) OD=12.3 |
| 23 |
I8-97333 120-0 |
|
CUP, SEALING,CYL HEAD |
3 |
2311- |
|
A |
(D-MAX 2024) (E) OD=24 |
| 323 |
I9-09571 412-0 |
|
GASKET |
2 |
2311- |
|
A |
(D-MAX 2024) ID=12.2 OD=18 |
| 83 |
I8-94483 674-0 |
|
PIN, CRANKCASE |
2 |
2311- |
|
AB |
(D-MAX 2024) L=22 |
| 5 |
I5-09600 013-0 |
|
CUP, SEALING,CYL HEAD |
4 |
2311- |
|
A |
(D-MAX 2024) (A) OD=12.3 |
| 383 |
I8-97799 849-0 |
|
SENSOR, THERMO,OIL TEMP |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) |
| 7 |
I9-09664 001-0 |
|
DRAIN PIPE |
1 |
2311- |
|
C |
(D-MAX 2024) PT1/4 |
| 61 |
I9-08150 616-0 |
|
PIN, FLYWHEEL |
2 |
2311- |
|
AB |
(D-MAX 2024) (C) L=16 |
| 15 |
I8-98322 217-0 |
|
PLUG, OIL FILTER |
4 |
2311- |
|
C |
PT1/8 |
| 434 |
I8-97495 763-0 |
|
COVER, CRANKCASE |
1 |
2311- |
|
C |
4X4(TFS***) (D) |
| 441 |
I8-94453 344-0 |
|
PIN, INJ PUMP BRKT |
2 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (B) OD=14 |
| 5 |
I5-11129 006-0 |
|
CUP, SEALING,CYL HEAD |
2 |
2311- |
|
A |
(D-MAX 2024) (B) OD=16 |
| 23 |
I5-11219 018-0 |
|
CUP, SEALING,RR |
2 |
2311- |
|
C |
(D-MAX 2024) (A) OD=36 |
| 23 |
I5-11219 008-0 |
|
CUP, SEALING,C/BL FRT & RR |
2 |
2311- |
|
C |
(D-MAX 2024) (B) OD=18 |
| 52 |
I8-94167 750-2 |
|
NIPPLE, OIL PRESS WARNING SW,C/BL |
1 |
2311- |
|
C |
|
| 23 |
I8-97333 120-0 |
|
CUP, SEALING,CYL HEAD |
3 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (E) OD=24 |
| 203 |
I0-49140 818-0 |
|
STUD, FAN CLU |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (B) M8X18 L=36 |
| 441 |
I8-94200 819-0 |
|
DOWEL, FLYWHEEL HSG |
2 |
2311- |
|
A B |
(D-MAX 2024) (A) OD=15.25 |
| 23 |
I8-98258 386-0 |
|
CUP, SEALING,C/BL FRT & RR |
3 |
2311- |
|
C |
(D) OD=45 |
| 23 |
I5-11219 015-0 |
|
CUP, SEALING,C/BL FRT & RR |
4 |
2311- |
|
C |
(C) OD=32 |
| 13 |
I8-94453 344-0 |
|
PIN, INJ PUMP BRKT |
2 |
2311- |
|
C |
(D-MAX 2024) OD=14 |
| 82 |
I0-44011 050-0 |
|
STUD, INL PIPE |
1 |
2401- |
|
B |
(D-MAX 2024) (A) M10X50 L=65 |
| 21 |
I5-11219 017-0 |
|
CUP, SEALING,RR |
1 |
2311- |
|
C |
(a) OD=38 |
| 542 |
I0-41010 816-0 |
|
STUD, INL COVER |
2 |
2311- |
|
AB |
(D-MAX 2024) M8X16 L=28 |
| 8 |
I8-98257 516-0 |
|
BOLT, BRG CAP |
10 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) M11X88 FLANGE |
| 8 |
I8-97941 068-0 |
|
BOLT, BRG CAP |
10 |
2311- |
|
C |
M14X89 FLANGE |
| 1 |
I8-98348 629-4 |
|
BLOCK ASM, CYL |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 5 |
I5-11129 006-0 |
|
CUP, SEALING,CYL HEAD |
2 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (B) OD=16 |
| 213 |
I9-09571 410-0 |
|
GASKET, LEVEL PLUG |
1 |
2311- |
|
C |
(D-MAX 2024) ID=10.2 OD=16.0 |
| 23 |
I5-11219 018-0 |
|
CUP, SEALING,RR |
10 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (a) OD=36 |
| 61 |
I8-94483 674-0 |
|
PIN, CRANKCASE |
2 |
2311- |
|
AB |
(D-MAX 2024) (B) L=22 |
| 7 |
I9-09664 001-0 |
|
DRAIN PIPE |
1 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) PT1/4 |
| 23 |
I8-97333 120-0 |
|
CUP, SEALING,CYL HEAD |
3 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (E) OD=24 |
| 401 |
I0-28050 616-0 |
|
BOLT |
1 |
2311- |
|
C |
(D-MAX 2024) M6X16 FLANGE |
| 61 |
I8-97920 964-1 |
|
PIN, STRAIGHT |
2 |
2311- |
|
C |
(a) L=31 |
| 434 |
I8-97495 761-0 |
|
COVER, CRANKCASE |
1 |
2311- |
|
C |
4X4(TFS***) (C) |
| 211 |
I0-28650 825-0 |
|
BOLT, BATTERY CABLE |
12 |
2311- |
|
C |
(D-MAX 2024) (B) M8X25 FLANGE |
| 441 |
I8-94453 344-0 |
|
PIN, INJ PUMP BRKT |
2 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (B) OD=14 |
| 90 |
I8-98247 320-0 |
|
PIPE, OIL,JET |
4 |
2311- |
|
A |
(D-MAX 2024) |
| 5 |
I5-09600 013-0 |
|
CUP, SEALING,CYL HEAD |
4 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (A) OD=12.3 |
| 51 |
I8-97912 498-0 |
|
GASKET, OIL PRESS WARNING SW,C/BL |
1 |
2311- |
|
C |
ID=8.2 OD=18 |
| 5 |
I5-11129 006-0 |
|
CUP, SEALING,CYL HEAD |
2 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (B) OD=16 |
| 323 |
I9-09571 412-0 |
|
GASKET |
2 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2)D=12.2 OD=18 |
| 82 |
I0-44011 050-0 |
|
STUD, INL PIPE |
1 |
2311-2312 |
|
B |
(D-MAX 2024) EUROO SPECIFICATIONS),EUR02 SPECIFICATION(NT2) (A) M10X50 L=65 |
| 23 |
I5-11219 018-0 |
|
CUP, SEALING,RR |
10 |
2311- |
|
A |
(D-MAX 2024) (a) OD=36 |
| 38 |
I9-08151 020-0 |
|
PIN, STRAIGHT,RR PLATE |
2 |
2311- |
|
C |
OD=10 L=20 |
| 203 |
I0-49140 818-0 |
|
STUD, FAN CLU |
2 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (B) M 8X18 L=36 |
| 8 |
I8-98257 516-0 |
|
BOLT, BRG CAP |
10 |
2311- |
|
A |
(D-MAX 2024) M11X88 FLANGE |
| 352 |
I9-09566 109-0 |
|
GASKET, RET |
1 |
2311- |
|
C |
ID=8.8 |
| 15 |
I8-98336 980-0 |
|
PLUG, OIL GALLERY |
2 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) M12X11 |
| 7 |
I9-09664 001-0 |
|
DRAIN PIPE |
1 |
2311- |
|
A |
(D-MAX 2024) PT1/4 |
| 7 |
I9-09664 001-0 |
|
DRAIN PIPE |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) PT1/4 |
| 45 |
I8-97176 230-0 |
|
SWITCH, OIL PRESSURE |
1 |
2311- |
|
ABC |
(D-MAX 2024) |
| 434 |
I8-97495 762-0 |
|
COVER, CRANKCASE |
1 |
2311- |
|
C |
4X2(TFB***) (B) |
| 416 |
I0-49140 828-0 |
|
STUD, INL MANIF |
2 |
2311- |
|
A B |
(D-MAX 2024) M 8X28 L=46 |
| 15 |
I8-98336 980-0 |
|
PLUG, OIL GALLERY |
2 |
2311- |
|
A |
(D-MAX 2024) M12X11 |
