| 107 |
I8-98245 905-0 |
|
SHAFT, IDLE GEAR |
1 |
2311- |
|
C |
(B) |
| 4 |
I8-97490 215-1 |
|
VALVE, INL |
8 |
2311- |
|
AB |
(D-MAX 2024) |
| 101 |
I0-28161 060-0 |
|
BOLT, IDLE PULLEY |
2 |
2311- |
|
AB |
(D-MAX 2024) M10X60 FLANGE |
| 3 |
I8-98228 493-2 |
|
CAMSHAFT, EXH |
1 |
2311- |
|
C |
|
| 87 |
I8-98224 626-0 |
|
BOLT |
14 |
2311- |
|
C |
M6X25 HEX SOCKET |
| 198 |
I8-98351 830-1 |
|
GUIDE, TIMING CHAIN |
1 |
2311- |
|
B |
(D-MAX 2024) |
| 112 |
I8-98231 907-0 |
|
GEAR, IDLE |
1 |
2311- |
|
C |
(A) Z=35 |
| 348 |
I8-98486 075-0 |
|
NUT, SPROCKET |
1 |
2311- 1 |
|
C |
|
| 68 |
I8-97311 669-0 |
|
SPRING, VLV |
16 |
2311- |
|
C |
H=49 NATURAL |
| 44 |
I8-97178 704-0 |
|
BOLT, FUEL FILLER LID |
1 |
2311- |
|
A B |
(D-MAX 2024) M5X15 HEX SOCKET |
| 252 |
I8-97556 736-0 |
|
FLANGE, IDLE SHAFT |
1 |
2311- |
|
C |
(B) |
| 81 |
I8-98029 893-0 |
|
SCREW, ADJ,ROCKER ARM |
16 |
2311- |
|
C |
M8 L=22 |
| 78 |
I8-98247 698-0 |
|
ARM, ROCKER |
16 |
2311- |
|
AB |
(D-MAX 2024) |
| 200 |
I8-98351 647-0 |
|
BOLT, CHAIN GUIDE,LWR |
1 |
2311- |
|
AB |
(D-MAX 2024) (C) |
| 300 |
I8-98351 831-1 |
|
LEVER, TENSION,TIMING CHAIN |
1 |
2311- |
|
B |
(D-MAX 2024) |
| 172 |
I8-98119 279-1 |
|
CHAIN, TIMING,CM/SHF |
1 |
2311- |
|
c |
|
| 119 |
I8-97141 154-0 |
|
NUT, LWR LINK TO FRT C/MBR |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) M18 |
| 200 |
I8-98351 646-0 |
|
BOLT, CHAIN GUIDE,LWR |
1 |
2311- |
|
AB |
(D-MAX 2024) (B) |
| 185 |
I8-98258 885-0 |
|
TENSIONER, CHAIN |
1 |
2311- |
|
c |
|
| 329 |
I8-98351 804-0 |
|
GEAR, INJ PUMP |
1 |
2311- |
|
B |
EU ROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) Z=57 |
| 28 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
3 |
2311- |
|
A B |
(D-MAX 2024) M8X20 FLANGE |
| 114 |
I0-28161 260-0 |
|
BOLT, ADJ PLATE |
1 |
2311- |
|
C |
EUR02 SPECIFICATIONS),EUR04 SPECIFICATION(NT4) (a) M12X60 FLANGE |
| 322 |
I8-98377 692-2 |
|
PULLEY, IDLE |
1 |
2311- 1 |
|
A B |
(D-MAX 2024) |
| 66 |
I8-98299 554-0 |
|
CAP, VLV STEM END |
16 |
2311- |
|
A B |
(D-MAX 2024) |
| 2 |
I8-98228 490-2 |
|
CAMSHAFT, INL |
1 |
2311- |
|
C |
|
| 66 |
I8-98147 945-0 |
|
CAP, VLV STEM END |
16 |
2311- |
|
C |
|
| 315 |
I8-98378 675-1 |
|
TENSIONER, AUTO |
1 |
2311- 1 |
|
A B |
(D-MAX 2024) |
| 112 |
I8-97490 745-1 |
|
GEAR, IDLE |
1 |
2311- |
|
C |
(B) Z=80 |
| 114 |
I0-28161 225-0 |
|
BOLT, ENG HANGER |
1 |
2311- |
|
C |
EUR05 SPECIFICATION(NT5) (a) M12X25 FLANGE |
| 200 |
I1-09070 120-1 |
|
BOLT, COUPLING TO WATER PUMP |
2 |
2311- |
|
C |
(A) M8X20 FLANGE |
| 4 |
I8-97309 675-1 |
|
VALVE, INL |
8 |
2311- |
|
C |
|
| 172 |
I8-98247 668-0 |
|
CHAIN, TIMING,CM/SHF |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 309 |
I0-28050 840-0 |
|
BOLT, CLIP |
1 |
2311- 1 |
|
A B |
(D-MAX 2024) M8X40 FLANGE |
| 3 |
I8-98398 234-1 |
|
CAMSHAFT, EXH |
1 |
2311- |
|
AB |
(D-MAX 2024) |
| 349 |
I8-98351 646-0 |
|
BOLT, CHAIN GUIDE,LWR |
1 |
2311- |
|
AB |
(D-MAX 2024) |
| 71 |
I8-97311 668-0 |
|
SEAT, SPR |
16 |
2311- |
|
C |
(A) UPPER OD=29.5 |
| 198 |
I8-97533 958-2 |
|
GUIDE, TIMING CHAIN |
1 |
2311- |
|
A |
|
| 107 |
I8-97312 315-2 |
|
SHAFT, IDLE GEAR |
1 |
2311- |
|
C |
(A) |
| 199 |
I8-97356 061-1 |
|
JET, OIL,TIMING CHAIN |
1 |
2311- |
|
C |
|
| 71 |
I8-97144 584-0 |
|
SEAT, SPR |
16 |
2311- |
|
C |
(B) LOWER OD=31 |
| 198 |
I8-97495 394-0 |
|
GUIDE, TIMING CHAIN |
1 |
2311- |
|
c |
|
| 307 |
I8-98351 820-0 |
|
ROTOR, CAM ANGLE SENSOR |
1 |
2311- 1 |
|
A B |
(D-MAX 2024) |
| 5 |
I8-97309 677-1 |
|
VALVE, EXH |
8 |
2311- |
|
C |
|
| 190 |
I0-91180 206-0 |
|
NUT, PULLEY |
2 |
2311- |
|
c |
(D-MAX 2024) M6 FLANGE |
| 300 |
I8-97495 395-0 |
|
LEVER, TENSION,TIMING CHAIN |
1 |
2311- |
|
C |
|
| 252 |
I8-97312 316-1 |
|
FLANGE, IDLE SHAFT |
1 |
2311- |
|
C |
(A) |
| 252 |
I8-98248 173-0 |
|
FLANGE, IDLE SHAFT |
2 |
2311- |
|
AB |
(D-MAX 2024) (C) |
| 346 |
I0-41010 618-0 |
|
STUD, ACL |
2 |
2311- 1 |
|
C |
M6X18 L=27 |
| 196 |
I1-09587 002-1 |
|
RING, SNAP |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 226 |
I8-98204 889-0 |
|
SPRING, CMPR,ROCKER ARM |
8 |
2311- 1 |
|
C |
|
| 31 |
I8-98247 667-1 |
|
SPROCKET, CM/SHF |
1 |
2311- |
|
A B |
(D-MAX 2024) Z=38 |
| 53 |
I8-98244 914-0 |
|
SHAFT, ROCKER ARM |
2 |
2311- |
|
C |
|
| 68 |
I8-98250 115-1 |
|
SPRING, VLV |
8 |
2311- |
|
A B |
(D-MAX 2024) INLET H=51 |
| 65 |
I8-98250 250-0 |
|
COLLAR, SPLIT |
32 |
2311- |
|
AB |
(D-MAX 2024) |
| 109 |
I8-97312 319-1 |
|
SHAFT, IDLE GEAR |
1 |
2311- |
|
C |
EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) |
| 119 |
I0-91180 114-0 |
|
NUT, LEVER TO SHAFT |
1 |
2311- |
|
B |
(D-MAX 2024) EUROO SPECIFICATIONS),EUR02 SPECIFICATION(NT2) M14FLANGE |
| 119 |
I8-97141 154-0 |
|
NUT, LWR LINK TO FRT C/MBR |
1 |
2311- |
|
A |
(D-MAX 2024) M18 |
| 112 |
I8-97490 753-2 |
|
GEAR, IDLE |
1 |
2311- |
|
C |
EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) (C) Z=34 |
| 185 |
I8-98248 163-2 |
|
TENSIONER, CHAIN |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 65 |
I8-94239 501-0 |
|
COLLAR, SPLIT |
32 |
2311- |
|
C |
|
| 72 |
I8-97328 647-0 |
|
SEAL, VLV GUIDE |
16 |
2311- |
|
C |
|
| 107 |
I8-98351 840-0 |
|
SHAFT, IDLE GEAR |
1 |
2311- |
|
AB |
(D-MAX 2024) (C) |
| 64 |
I8-98248 261-0 |
|
ADJUSTER, VLV LASH |
16 |
2311- |
|
AB |
(D-MAX 2024) |
| 133 |
I8-97312 336-0 |
|
GASKET, CHAIN TENSIONER |
1 |
2311- |
|
C |
|
| 78 |
I8-98204 885-1 |
|
ARM, ROCKER |
16 |
2311- |
|
C |
|
| 359 |
I8-97947 983-0 |
|
SLEEVE, GEAR |
1 |
2311- |
|
C |
|
| 5 |
I8-98247 696-1 |
|
VALVE, EXH |
8 |
2311- |
|
AB |
(D-MAX 2024) |
| 71 |
I8-98250 252-0 |
|
SEAT, SPR |
16 |
2311- |
|
AB |
(D-MAX 2024) (D) LOWER OD=22.6 |
| 347 |
I8-98486 074-0 |
|
SPROCKET, I/PUMP |
1 |
2311- 1 |
|
C |
|
| 112 |
I8-98351 801-1 |
|
GEAR, IDLE |
1 |
2311- |
|
A B |
(D-MAX 2024) (D) Z=66 |
| 166 |
I0-58330 616-0 |
|
BOLT, SPROCKET TO LAYSHAFT |
6 |
2311- |
|
C |
M6X16 HEX SOCKET |
| 349 |
I8-97312 328-0 |
|
PIVOT, CHAIN LEVER |
1 |
2311- |
|
C |
|
| 162 |
I8-97312 331-1 |
|
SPROCKET, IDLE |
1 |
2311- |
|
C |
|
| 329 |
I8-97679 824-0 |
|
GEAR, INJ PUMP |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) Z=57 |
| 133 |
I9-09571 422-0 |
|
PACKING |
1 |
2311- |
|
AB |
(D-MAX 2024) ID=22.5 |
| 114 |
I0-28061 060-0 |
|
BOLT, HOOK TO FRAME |
2 |
2311- |
|
C |
(b) M10X60 FLANGE |
| 71 |
I8-98250 251-0 |
|
SEAT, SPR |
16 |
2311- |
|
AB |
(D-MAX 2024) (C) UPPER od=17.6 |
| 300 |
I8-97533 957-2 |
|
LEVER, TENSION,TIMING CHAIN |
1 |
2311- |
|
A |
|
| 104 |
I0-28151 020-0 |
|
BOLT, ADAPTER |
2 |
2311- |
|
AB |
(D-MAX 2024) M10X20 FLANGE |
| 72 |
I8-98250 249-0 |
|
SEAL, VLV GUIDE |
16 |
2311- |
|
AB |
(D-MAX 2024) |
| 329 |
I8-98486 076-2 |
|
GEAR, INJ PUMP |
1 |
2311- |
|
C |
Z=44 |
| 329 |
I8-98375 729-1 |
|
GEAR, INJ PUMP |
1 |
2311- |
|
A |
Z=57 |
| 114 |
I8-98176 233-0 |
|
BOLT, BRG CAP |
1 |
2311- |
|
C |
(C) M12X75 FLANGE |
| 362 |
I8-98233 620-1 |
|
PLATE |
6 |
2311- |
|
C |
|
| 2 |
I8-98331 641-1 |
|
CAMSHAFT, INL |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 68 |
I8-98306 921-1 |
|
SPRING, VLV |
8 |
2311- |
|
A B |
(D-MAX 2024) EXHAUST H =57 |
