| 33 |
I5-09500 013-0 |
|
WASHER, EXH PIPE |
8 |
2311- |
|
C |
(D-MAX 2024) ID=10.5 |
| 1 |
I8-98247 605-3 |
|
MANIFOLD, EXHAUST |
1 |
2311- |
|
B |
(D-MAX 2024) |
| 58 |
I8-98360 821-0 |
|
STUD, HEAT PROTECTOR |
1 |
2311- |
|
B |
EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) M8X25 L=33 |
| 58 |
I0-41010 825-0 |
|
STUD, EXH MANIF |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) M8X25 L=37 |
| 3 |
I8-97541 163-1 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
B |
EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATION(NT2) (B) |
| 2 |
I8-98229 782-0 |
|
GASKET, EXH MANIF TO HD |
1 |
2311- |
|
C |
|
| 3 |
I8-97536 753-0 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
C |
EUR05 SPECIFICATION(NT5) (D) |
| 21 |
I0-28050 812-0 |
|
BOLT, CLIP,FUEL HOSE |
2 |
2311- |
|
C |
(D-MAX 2024) (A) M8X12 FLANGE |
| 18 |
I8-97309 942-0 |
|
NUT, TURBOCHARGER |
7 |
2311- |
|
AB |
(D-MAX 2024) M10 FLANGE |
| 23 |
I5-09500 013-0 |
|
WASHER, EXH PIPE |
10 |
2311- |
|
A B |
(D-MAX 2024) ID=10.5 |
| 15 |
I8-98032 158-0 |
|
BOLT, EXH MANIF |
3 |
2311- |
|
A B |
(D-MAX 2024) M10X30 FLANGE |
| 3 |
I8-98247 218-3 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
AB |
(D-MAX 2024) (C) |
| 21 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
2 |
2311- |
|
AB |
(D-MAX 2024) (B) M8X20 FLANGE |
| 65 |
I8-97662 227-0 |
|
PROTECTOR, HEAT |
1 |
2311- |
|
C |
EUR02 SPECIFICATION(NT2) |
| 3 |
I8-97537 190-0 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
C |
EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) (A) |
| 3 |
I8-97536 754-1 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
C |
EUROS SPECIFICATION(NT5) (E) |
| 3 |
I8-98345 824-2 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
A |
(D-MAX 2024) (F) |
| 58 |
I8-98360 821-0 |
|
STUD, HEAT PROTECTOR |
1 |
2311- |
|
A |
M8X25 L=33 |
| 18 |
I8-97381 617-0 |
|
NUT, EXH MANIF |
2 |
2311- |
|
C |
M10 FLANGE |
| 3 |
I8-98345 824-2 |
|
PROTECTOR, HEAT,EXH MANIF |
1 |
2311- |
|
B |
(D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) (F) |
| 1 |
I8-97535 872-0 |
|
MANIFOLD, EXHAUST |
1 |
2311- |
|
C |
EUR05 SPECIFICATION(NT5) |
| 15 |
I8-98032 158-0 |
|
BOLT, EXH MANIF |
6 |
2311- |
|
C |
(D-MAX 2024) M10X30 FLANGE |
| 19 |
I8-97379 383-0 |
|
STUD, MANIF TO CYL HD |
2 |
2311- |
|
C |
(D-MAX 2024) M10X33 L=48 |
| 2 |
I8-98247 606-3 |
|
GASKET, EXH MANIF TO HD |
1 |
2311- |
|
A B |
(D-MAX 2024) |
| 21 |
I0-28151 016-0 |
|
BOLT, STAY |
2 |
2311- |
|
C |
EUR02 SPECIFICATI0N(NT2),EUR05 SPECIFICATION(NT5) (C) M10X16 FLANGE |
| 22 |
I8-98307 650-0 |
|
SPACER, EXH MANIF BRKT |
2 |
2311- |
|
A B |
(D-MAX 2024) |
| 1 |
I8-98480 918-0 |
|
MANIFOLD, EXHAUST |
1 |
2311- |
|
C |
EUR02 SPECIFICATI0N(NT2),EUR04 SPECIFICATION(NT4) |
| 21 |
I0-28050 812-0 |
|
BOLT, CLIP,FUEL HOSE |
1 |
2311- |
|
AB |
(D-MAX 2024) (A) M8X12 FLANGE |
| 1 |
I8-97533 377-0 |
|
MANIFOLD, EXHAUST |
1 |
2311- |
|
A |
|
