0-42 | FUEL PUMP AND PIPE
DMAX
D-MAX 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 263 | I8-98312 896-0 | GASKET, BRKT | 1 | 2311- | B | (D-MAX 2024) | ||
| 243 | I8-98357 011-0 | STUD, BRKT | 1 | 2311- | A | (D-MAX 2024) | ||
| 243 | I8-98357 011-0 | STUD, BRKT | 1 | 2311- | B | (D-MAX 2024) EUR04 SPECIFICATI0N(NT4),EUR05 SPECIFICATION(NT5) | ||
| 148 | I0-28050 612-0 | BOLT, STAY,PRESSURE REG | 1 | 2311- | AB | (D-MAX 2024) (A) M6X12 FLANGE | ||
| 148 | I0-28050 845-0 | BOLT, PIPE CLIP | 2 | 2311- | C | (D-MAX 2024) (C) M8X45 FLANGE | ||
| 190 | I8-98351 331-0 | SENSOR, FUEL TEMP | 1 | 2311- | C | |||
| 148 | I0-28050 816-0 | BOLT, BRKT,FLEX HOSE,P/S | 2 | 2311- | C | (D-MAX 2024) (B) M8X16 FLANGE | ||
| 92 | I8-97495 801-0 | BRACKET, FUEL PIPE | 1 | 2311- | C | |||
| 263 | I8-98332 461-0 | GASKET, BRKT | 1 | 2311- | A | |||
| 148 | I0-28050 816-0 | BOLT, BRKT,FLEX HOSE,P/S | 1 | 2311- | B | (D-MAX 2024) EUROO SPECIFICATIONS),EUR02 SPECIFICATION(NT2) (B) M8X16 FLANGE | ||
| 340 | I8-98388 204-3 | BRACKET, REGULATOR,CNG | 1 | 2311- | ABC | (D-MAX 2024) | ||
| 148 | I0-28050 816-0 | BOLT, BRKT,FLEX HOSE,P/S | 1 | 2311- | A | (D-MAX 2024) (B) M8X16 FLANGE |
