| 42 |
I8-98154 210-0 |
|
SWITCH, CLU |
1 |
2311- |
|
BC D E F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) |
| 40 |
I8-97312 338-0 |
|
PIN, CLU PEDAL |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) OD=7.9 L=27.5 |
| 45 |
I8-97942 314-0 |
|
BUSHING, ASSIST SPRING,CLU PEDAL |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) |
| 353 |
I8-97279 740-0 |
|
PLATE ASM, CLUTCH PEDAL |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) EXC.DENTIFICATION LABEL FOR KD<6UT>,PLANTMCT GATEWAY THAILAND<8PV> |
| 11 |
I8-98007 161-0 |
|
PIN, SNAP,PUSH ROD TO PEDAL |
1 |
2311- |
|
BC D E F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) |
| 353 |
I8-97553 119-0 |
|
PLATE ASM, CLUTCH PEDAL |
1 |
2311- |
|
BCDE F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) PLANTMCT GATEWAY THAILAND<8PV> EXC.DENTIFICATION LABEL FOR KD<6UT> |
| 360 |
I8-97664 080-0 |
|
PEDAL ASM, CLUTCH |
1 |
2311- |
|
BCDE F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) PLANTMCT GATEWAY THAILAND<8PV> EXC.DENTIFICATION LABEL FOR KD<6UT> |
| 45 |
I8-97942 313-0 |
|
BUSHING, ASSIST SPRING,CLU PEDAL |
2 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) (A) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) (B) |
| 32 |
I0-91180 108-0 |
|
NUT, FLEX HOSE,CLU CONT |
2 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) M8 FLANGE |
| 13 |
I8-97942 312-0 |
|
SPRING, ASSIST,CLU PEDAL |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) |
| 353 |
I8-97553 119-0 |
|
PLATE ASM, CLUTCH PEDAL |
1 |
2311- |
|
BC D E F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S)DENTIFICATION LABEL FOR KD<6UT> |
| 2 |
I8-97318 799-0 |
|
COVER, CLU PEDAL |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) |
| 4 |
I8-97947 783-0 |
|
STOPPER, CLU PEDAL |
1 |
2311- |
|
BC D E F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) |
| 360 |
I8-97272 102-0 |
|
PEDAL ASM, CLUTCH |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) EXC.DENTIFICATION LABEL FOR KD<6UT>,PLANTMCT GATEWAY THAILAND<8PV> |
| 360 |
I8-97664 080-0 |
|
PEDAL ASM, CLUTCH |
1 |
2311- |
|
BC D E F |
M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S)DENTIFICATION LABEL FOR KD<6UT> |
| 242 |
I0-28050 612-0 |
|
BOLT, STAY,PRESSURE REG |
2 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) M6X12 FLANGE |
| 31 |
I0-91180 108-0 |
|
NUT, FLEX HOSE,CLU CONT |
3 |
2311- |
|
BCDE F |
(D-MAX 2024) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) M8 FLANGE |
