| 2 |
I8-94463 608-4 |
|
BUSHING, DRIVEN GEAR,SPEEDOMETER |
1 |
2311- |
|
BCDE F |
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> |
| 22 |
I0-28051 200-0 |
|
BOLT, STARTER TO TRANS CASE |
1 |
2311- |
|
C E |
(D-MAX 2024) RZ4E-TC ENG(RDZ) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) (B) M12X100 FLANGE |
| 3 |
I9-09921 100-0 |
|
GASKET, BUSHING |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) EXC. 4 WHEEL ANTI LOCK BRAKE<JE5>D=21.7 0D=28.7 |
| 22 |
I0-28051 200-0 |
|
BOLT, STARTER TO TRANS CASE |
1 |
2311- |
|
B D F |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) M/T MVL 6 SPEED 6Y(Y6P),M/T MVL 6 SPEED 6S(Y6S) (B) M12X100 FLANGE |
| 22 |
I0-28051 250-0 |
|
BOLT, GEN |
9 |
2311- |
|
C E |
(D-MAX 2024) RZ4E-TC ENG(RDZ) (A) M12X50 FLANGE |
| 14 |
I8-98278 957-0 |
|
COVER, UNDER,TRANS |
1 |
2311- |
|
ABCDE F |
(D-MAX 2024) A/T 6 SPEED AISIN(Y6A) |
| 10 |
I8-97131 328-1 |
|
SEAL, OIL,DRIVE GEAR |
1 |
2311- |
|
BCDE F |
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> NOK |
| 101 |
I9-09921 100-0 |
|
GASKET, BUSHING |
1 |
2311- |
|
D E F |
(D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5>D=21.7 0D=28.7 |
| 22 |
I0-28051 250-0 |
|
BOLT, GEN |
8 |
2311- |
|
BCDE F |
(D-MAX 2024) 4JJ3 ENG(LNG) (a) M12X50 FLANGE |
| 22 |
I0-28051 250-0 |
|
BOLT, GEN |
9 |
2311- |
|
B D F |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (A) M12X50 FLANGE |
| 15 |
I0-28650 616-0 |
|
SCREW, TANK TO BRKT |
4 |
2311- |
|
ABCDE F |
(D-MAX 2024) A/T 6 SPEED AISIN(Y6A) M6X16 FLANGE |
| 80 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
1 |
2311- |
|
D E F |
(D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> M8X20 FLANGE |
| 4 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
1 |
2311- |
|
BCDE F |
(D-MAX 2024) EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> M8X20 FLANGE |
| 22 |
I0-28051 250-0 |
|
BOLT, GEN |
8 |
2311- |
|
A |
(D-MAX 2024) 4JJ3 ENG(LNG) A/T 6 SPEED AISIN(Y6A) (A) M12X50 FLANGE |
| 11 |
I8-94446 571-1 |
|
FILTER, BUSHING,SPEEDOMETER DRIVEN GEAR |
1 |
2311- |
|
BCDE F |
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> |
| 84 |
I8-98103 318-0 |
|
CAP, BUSH,SPEEDOMETER GEAR |
1 |
2311- |
|
D E F |
(D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> |
| 1 |
I8-97238 583-0 |
|
GEAR, DRIVEN,SPD |
1 |
2311- |
|
BCDE F |
EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> Z=17 |
