| 11 |
I8-98030 682-0 |
|
CLIP, HOSE,BYPASS |
4 |
2311- |
|
C |
(D-MAX 2024) (B) ID=16 |
| 11 |
I8-98008 165-0 |
|
CLIP, HOSE |
4 |
2311- |
|
C |
(D-MAX 2024) (A) ID=13 |
| 1 |
I8-98393 849-1 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (F) |
| 106 |
I8-98393 851-1 |
|
PIPE ASM, OIL,COOLER TO UNION |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (A) INLET |
| 106 |
I8-98393 852-1 |
|
PIPE ASM, OIL,COOLER TO UNION |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (B) RETURN |
| 90 |
I8-98393 864-0 |
|
PIPE ASM, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (A) |
| 106 |
I8-98393 853-1 |
|
PIPE ASM, OIL,COOLER TO UNION |
1 |
2311- |
|
C |
4X2(TFB***) 4JJ3 ENG(LNG) (C) INLET |
| 1 |
I8-97538 580-0 |
|
HOSE, ATF |
2 |
2311- |
|
C |
(D-MAX 2024) (E) |
| 106 |
I8-98393 854-1 |
|
PIPE ASM, OIL,COOLER TO UNION |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) (D) RETURN |
| 90 |
I8-98393 867-1 |
|
PIPE ASM, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) (D) |
| 1 |
I8-98393 861-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TC ENG(RDZ) HIGH ALTITUDE COMPENSATOR<EE2> EUR04 SPECIFICATION(NT4) (B) |
| 15 |
I8-98393 848-0 |
|
BRACKET, ATF PIPE |
1 |
2311- |
|
C |
(D-MAX 2024) |
| 211 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
3 |
2311- |
|
C |
(D-MAX 2024) M8X20 FLANGE |
| 14 |
I8-98232 374-0 |
|
CLIP, PIPE TO ENG SIDE |
2 |
2311- |
|
C |
(D-MAX 2024) (B) |
| 14 |
I8-94417 626-0 |
|
CLIP, BREATHER HOSE |
2 |
2311- |
|
C |
(D-MAX 2024) (A) ID=13 & 21 |
| 1 |
I8-98393 861-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TC ENG(RDZ) EUR05 SPECIFICATION(NT5) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (B) |
| 21 |
I8-98395 586-0 |
|
BRACKET, COOLER |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) |
| 1 |
I8-98393 858-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (A) |
| 243 |
I8-98393 882-1 |
|
COOLER ASM, A/T SECONDARY |
1 |
2311- |
|
C |
(D-MAX 2024) |
| 260 |
I0-91180 108-0 |
|
NUT, FLEX HOSE,CLU CONT |
2 |
2311- |
|
C M8 FLANG |
(D-MAX 2024) |
| 212 |
I8-97944 127-0 |
|
CLIP, HTR HOSE |
8 |
2311- |
|
C |
(D-MAX 2024) ID=20.8 |
| 1 |
I8-98393 869-2 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (C) |
| 1 |
I8-98393 872-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) 0) |
| 90 |
I8-98393 865-0 |
|
PIPE ASM, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (B) |
| 248 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
1 |
2311- |
|
C |
(D-MAX 2024) M8X20 FLANGE |
| 1 |
I8-98393 862-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) HEATER & DEFROSTER(C42),AIR CONDITIONER MANUAL CONT(C60),AIR CONDITIONER AUTOMATIC CONT(C61 ) (G) |
| 108 |
I0-91180 108-0 |
|
NUT, FLEX HOSE,CLU CONT |
2 |
2311- |
|
C |
(D-MAX 2024) M8 FLANGE |
| 1 |
I8-98393 863-1 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) |
| 1 |
I8-98393 871-3 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) (I) |
| 1 |
I8-98393 859-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
RZ4E-TC ENG(RDZ) EUROO SPECIFICATI0N(K75),EUR02 SPECIFICATI0N(NT2),EUR04 S P ECIFICATIO N ( NT4) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (B) |
| 21 |
I8-98395 587-0 |
|
BRACKET, COOLER |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) |
| 50 |
I0-28050 820-0 |
|
BOLT, BRKT,FLEX HOSE,P/S |
2 |
2311- |
|
C |
(D-MAX 2024) M8X20 FLANGE |
| 1 |
I8-98393 850-2 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) (K) |
| 106 |
I8-97540 854-0 |
|
PIPE ASM, OIL,COOLER TO UNION |
1 |
2311- |
|
C |
4X4(TFS***) 4JJ3 ENG(LNG) (C) INLET |
| 1 |
I8-98393 860-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) COOLER W/FRESH AIR(C65) (G) |
| 1 |
I8-98393 870-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC),RZ4E-TC ENG(RDZ) (D) |
| 90 |
I8-98393 866-0 |
|
PIPE ASM, ATF |
1 |
2311- |
|
C |
4JJ3 ENG(LNG) (C) |
| 1 |
I8-98393 861-0 |
|
HOSE, ATF |
1 |
2311- |
|
C |
(D-MAX 2024) RZ4E-TCX HI-POWER ENG(LNC) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (B) |
