3-58 | FIXING PARTS, OIL PIPING
DMAX
D-MAX 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 20 | I8-98113 391-0 | CLIP, BRK PIPE | 2 | 2311- | BC D E F | EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> (J) ID=4.76X3 8< 6.35 OR 10X1 | ||
| 20 | I8-98113 388-0 | CLIP, BRK PIPE | 2 | 2311- | A | (D-MAX 2024) (C) ID=4.76X3 | ||
| 20 | I8-98113 389-0 | CLIP, BRK PIPE | 2 | 2311- | D E F | (D-MAX 2024) ELECTRONIC TRACTION CONTROL<NW9>,ELECTRONIC TRACTION CONTROL W/OFF-ROAD MODE<8YP> (D) ID=4.76X3 & 6.35X1 OR 10X1 | ||
| 20 | I8-94487 369-0 | CLIP, PIPE TO FRAME | 2 | 2311- | A BC D E F | (D-MAX 2024) (A) ID=4.8X3 | ||
| 20 | I8-98113 388-0 | CLIP, BRK PIPE | 2 | 2311- | D E F | (D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. ELECTRONIC TRACTION CONTROL<NW9>,ELECTRONIC TRACTION CONTROL W/OFF-ROAD MODE<8YP> (C) ID=4.76X3 | ||
| 20 | I8-97249 906-1 | CLIP, FUEL PIPE | 1 | 2311- | A BC D E F | (D-MAX 2024) (F) ID=10& 6.8X2 OR 8.4X3 | ||
| 20 | I8-98113 390-0 | CLIP, BRK PIPE | 2 | 2311- | BCDE F | EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> (I) ID=4.76X2 & 6.35X1 | ||
| 20 | I8-97216 721-1 | CLIP, BRK PIPE | 1 | 2311- | ABCDE F | (D-MAX 2024) (B) ID=4.76X3 | ||
| 16 | I0-28650 820-0 | BOLT | 2 | 2311- | | A BC D E F | (D-MAX 2024) M8X20 FLANGE | ||
| 20 | I8-98113 394-0 | CLIP, BRK PIPE | 2 | 2311- | ABCDE F | (D-MAX 2024) (H) ID=6.8X2 & 8.4 OR 10X2 & 12 OR 14X1 | ||
| 20 | I8-98113 389-0 | CLIP, BRK PIPE | 2 | 2311- | BC | (D-MAX 2024) ELECTRONIC TRACTION CONTROL<NW9> (D) ID=4.76X3 & 6.35X1 OR 10X1 | ||
| 9 | I0-28650 825-0 | BOLT, BATTERY CABLE | 2 | 2311- | BC D E F | (D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> M8X25 FLANGE | ||
| 9 | I0-28650 825-0 | BOLT, BATTERY CABLE | 2 | 2311- | A | (D-MAX 2024) M8X25 FLANGE | ||
| 20 | I8-98113 389-0 | CLIP, BRK PIPE | 2 | 2311- | BC | (D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. ELECTRONIC TRACTION CONTROL<NW9> (D) ID=4.76X3 & 6.35X1 OR 10X1 | ||
| 20 | I8-98113 388-0 | CLIP, BRK PIPE | 2 | 2311- | BC | (D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. ELECTRONIC TRACTION CONTROL<NW9> (C) ID=4.76X3 | ||
| 20 | I8-97251 124-0 | CLIP, BRK PIPE | 7 | 2311- | A BC D E F | (D-MAX 2024) (G) ID=6.8X2 | ||
| 20 | I8-97300 443-0 | CLIP, BRK PIPE | 1 | 2311- | ABCDE F | (D-MAX 2024) (E) ID=4.76 | ||
| 20 | I8-98113 389-0 | CLIP, BRK PIPE | 2 | 2311- | D E F | (D-MAX 2024) 4 WHEEL ANTI LOCK BRAKE<JE5> EXC. ELECTRONIC TRACTION CONTROL<NW9>,ELECTRONIC TRACTION CONTROL W/OFF-ROAD MODE<8YP> (D) ID=4.76X3 & 6.35X1 OR 10X1 | ||
| 20 | I8-98113 388-0 | CLIP, BRK PIPE | 2 | 2311- | BC | (D-MAX 2024) ELECTRONIC TRACTION CONTROL<NW9> (C) ID=4.76X3 | ||
| 22 | I5-09707 027-0 | CLIP, ENG CONT CABLE | 1 | 2311- I | ABCDE F | (D-MAX 2024) ID=9 | ||
| 20 | I8-98113 389-0 | CLIP, BRK PIPE | 2 | 2311- | A | (D-MAX 2024) (D) ID=4.76X3 & 6.35X1 OR 10X1 | ||
| 20 | I8-98113 388-0 | CLIP, BRK PIPE | 2 | 2311- | D E F | (D-MAX 2024) ELECTRONIC TRACTION CONTROL<NW9>,ELECTRONIC TRACTION CONTROL W/OFF-ROAD MODE<8YP> (C) ID=4.76X3 |
