| 8 |
I9-41519 155-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.22 |
| 1 |
I8-97481 628-0 |
|
DRIVE ASM, FINAL,FRT |
1 |
2311- |
|
E |
(D-MAX 2024) FINAL GEAR RATIO 43/11 (GW1) 43/11 |
| 35 |
I5-41562 007-1 |
|
WASHER, THRUST,SIDE GEAR |
2 |
2311- |
|
D E F |
(D-MAX 2024) T=1.10 |
| 8 |
I9-41519 169-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.50 |
| 8 |
I9-41519 172-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.56 |
| 37 |
I8-97079 518-0 |
|
GEAR, PINION DIFF |
2 |
2311- |
|
DE FZ=10 |
(D-MAX 2024) |
| 11 |
I8-97481 632-1 |
|
CAGE, DIFF |
1 |
2311- |
|
D E F |
FINAL GEAR RATIO 41 /11 (GT4) |
| 21 |
I8-98104 945-2 |
|
GEAR SET, FINAL DRIVE,FRT |
1 |
2311- |
|
D E F |
(D-MAX 2024) FINAL GEAR RATIO 41/10(GT5) 41/10 |
| 1 |
I8-97481 630-0 |
|
DRIVE ASM, FINAL,FRT |
1 |
2311- |
|
D F |
FINAL GEAR RATIO 43/10(GY2) 43/10 |
| 12 |
I8-97130 386-0 |
|
SHIM, DIFF SIDE BRG |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=0.10 |
| 8 |
I9-41519 157-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.26 |
| 8 |
I9-41519 158-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.28 |
| 8 |
I9-41519 166-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.44 |
| 8 |
I9-41519 164-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.40 |
| 2 |
I8-94376 262-0 |
|
NUT, FINAL DRIVE PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) M18 LOCK NUT |
| 4 |
I8-97798 061-0 |
|
COUPLING, FINAL DRIVE PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) |
| 21 |
I8-98104 933-2 |
|
GEAR SET, FINAL DRIVE,FRT |
1 |
2311- |
|
E |
(D-MAX 2024) FINAL GEAR RATIO 43/11 (GW1) 43/11 |
| 8 |
I9-41519 160-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.32 |
| 11 |
I8-97241 652-0 |
|
CAGE, FINAL PINION |
1 |
2311- |
|
E |
(D-MAX 2024) FINAL GEAR RATIO 43/12(GM0),FINAL GEAR RATIO 41/10(GT5),FINAL GEAR RATIO 43/11(GW1) |
| 8 |
I9-41519 168-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.48 |
| 12 |
I9-41519 109-0 |
|
SHIM, DIFF SIDE BRG |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=0.24 |
| 14 |
I8-97241 636-0 |
|
CARRIER ASM, FINAL DRIVE,FRT AXLE |
1 |
2311- |
|
D F |
(D-MAX 2024) FINAL GEAR RATIO 41/10(GT5),FINAL GEAR RATIO 43/10(GY2) |
| 19 |
I9-00093 621-1 |
|
BEARING, FINAL PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) NSK |
| 35 |
I5-41562 005-1 |
|
WASHER, THRUST,SIDE GEAR |
2 |
2311- |
|
D E F |
(D-MAX 2024) T=1.00 |
| 34 |
I9-41521 044-1 |
|
PIN, CROSS,DIFF PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) |
| 8 |
I9-41519 159-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.30 |
| 21 |
I8-98104 950-2 |
|
GEAR SET, FINAL DRIVE,FRT |
1 |
2311- |
|
D F |
FINAL GEAR RATIO 43/10(GY2) 43/10 |
| 8 |
I9-41519 165-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.42 |
| 35 |
I5-41562 006-1 |
|
WASHER, THRUST,SIDE GEAR |
2 |
2311- |
|
D E F |
(D-MAX 2024) T=1.05 |
| 8 |
I9-41519 162-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.36 |
| 21 |
I8-98104 915-2 |
|
GEAR SET, FINAL DRIVE,FRT |
1 |
2311- |
|
E |
FINAL GEAR RATIO 43/12(GM0) 43/12 |
| 8 |
I9-41519 161-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.34 |
| 8 |
I9-41519 153-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.18 |
| 11 |
I8-97241 652-0 |
|
CAGE, FINAL PINION |
1 |
2311- |
|
D F |
(D-MAX 2024) FINAL GEAR RATIO 41/10(GT5),FINAL GEAR RATIO 43/10(GY2) |
| 36 |
I8-97481 633-0 |
|
GEAR, SIDE,DIFF |
2 |
2311- |
|
DE FZ=17 |
(D-MAX 2024) |
| 7 |
I8-94472 100-1 |
|
BEARING, FINAL PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) JTEKT |
| 7 |
I8-94472 099-0 |
|
BEARING, FINAL PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) NSK |
| 8 |
I9-41519 154-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.20 |
| 14 |
I8-98104 910-2 |
|
CARRIER ASM, FINAL DRIVE,FRT A |
1 |
2311- |
|
D E F |
FINAL GEAR RATIO 41 /11 (GT4) |
| 1 |
I8-97481 629-0 |
|
DRIVE ASM, FINAL,FRT |
1 |
2311- |
|
D E F |
(D-MAX 2024) FINAL GEAR RATIO 41/10(GT5) 41/10 |
| 8 |
I9-41519 167-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.46 |
| 14 |
I8-97241 636-0 |
|
CARRIER ASM, FINAL DRIVE,FRT AXLE |
1 |
2311- |
|
E |
(D-MAX 2024) FINAL GEAR RATIO 43/12(GM0),FINAL GEAR RATIO 41/10(GT5),FINAL GEAR RATIO 43/11(GW1) |
| 69 |
I9-00093 074-1 |
|
BEARING, DIFF CAGE |
2 |
2311- |
|
D E F |
(D-MAX 2024) NSK |
| 39 |
I9-09878 096-0 |
|
PIN, LK,CROSS PIN |
1 |
2311- |
|
D E F |
(D-MAX 2024) OD=5 L=35 |
| 1 |
I8-97481 627-0 |
|
DRIVE ASM, FINAL,FRT |
1 |
2311- |
|
D E F |
FINAL GEAR RATIO 41 /11 (GT4) 41/11 |
| 12 |
I8-97130 387-0 |
|
SHIM, FINAL PINION CAGE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=0.50 |
| 12 |
I9-41519 111-0 |
|
SHIM, DIFF SIDE BRG |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=0.15 |
| 37 |
I6-97079 518-0 |
|
GEAR, PINION DIFF |
2 |
2311- |
|
DE FZ=10 |
(IADG) |
| 8 |
I9-41519 171-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.54 |
| 110 |
I8-97038 065-0 |
|
BOLT, FINAL PINION CAGE |
10 |
2311- |
|
D E F |
(D-MAX 2024) I M10X17 |
| 8 |
I9-41519 156-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.24 |
| 1 |
I8-97481 626-0 |
|
DRIVE ASM, FINAL,FRT |
1 |
2311- |
|
E |
FINAL GEAR RATIO 43/12(GM0) 43/12 |
| 6 |
I8-94318 520-2 |
|
SEAL, OIL,FINAL PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) |
| 30 |
I8-94376 322-0 |
|
BOLT, BRG CAP |
4 |
2311- |
|
D E F |
(D-MAX 2024) M12X62 |
| 8 |
I9-41519 163-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.38 |
| 21 |
I8-98104 929-2 |
|
GEAR SET, FINAL DRIVE,FRT |
1 |
2311- |
|
D E F |
FINAL GEAR RATIO 41 /11 (GT4) 41/11 |
| 9 |
I8-94472 118-0 |
|
COLLAR, DIST,PINION |
1 |
2311- |
|
D E F |
(D-MAX 2024) |
| 8 |
I9-41519 170-1 |
|
SHIM, PINION,FINAL DRIVE |
AR |
2311- |
|
D E F |
(D-MAX 2024) T=2.52 |
