| Key |
PART NO |
ITC |
DESCRIPTION |
QTY |
APP DATE |
LR |
MODEL |
REMARKS |
|
|
|
|
|
|
|
|
|
| 60 |
I8-97555 414-0 |
|
BOOT KIT, STRG HSG |
1 |
|
|
B |
(B) |
| 88 |
I8-97555 421-0 |
|
PIPE, HSG TO VLV |
1 |
|
|
B |
(A) |
| 18 |
I8-97539 190-0 |
|
ROD ASM, INNER |
2 |
|
|
A B |
|
| 39 |
I8-97555 415-0 |
|
ROD END ASM, OUTER |
2 |
|
|
B |
|
| 71 |
I8-97304 904-0 |
|
COVER, DUST,STRG UNIT |
1 |
|
|
A |
|
| 207 |
I8-97539 196-0 |
|
HARNESS, MCU |
1 |
|
|
A | |
|
| 185 |
I8-97555 418-0 |
|
BRACKET, P/S |
1 |
|
|
B |
|
| 88 |
I8-97503 138-0 |
|
PIPE, HSG TO VLV |
1 |
|
|
C |
(D-MAX 2024) (B) |
| 71 |
I8-98164 972-0 |
|
COVER, DUST,STRG UNIT |
1 |
|
|
C |
(D-MAX 2024) |
| 18 |
I8-97503 139-0 |
|
ROD ASM, INNER |
2 |
|
|
C |
(D-MAX 2024) |
| 60 |
I8-97945 423-1 |
|
BOOT KIT, STRG HSG |
2 |
|
|
C |
(D-MAX 2024) (C) |
| 20 |
I8-97503 135-0 |
|
RUBBER, MTG |
1 |
|
|
C |
(D-MAX 2024) |
| 115 |
I8-97555 420-0 |
|
PIPE, HSG TO VLV |
1 |
|
|
B |
(A) |
| 115 |
I8-97503 137-0 |
|
PIPE, HSG TO VLV |
1 |
|
|
C |
(D-MAX 2024) (B) |
| 185 |
I8-97503 134-0 |
|
BRACKET, P/S |
1 |
|
|
C |
(D-MAX 2024) |
| 71 |
I8-98165 054-0 |
|
COVER, DUST,STRG UNIT |
1 |
|
|
B |
|
| 20 |
I8-97555 416-0 |
|
RUBBER, MTG,PINION SIDE |
1 |
|
|
B |
|
| 60 |
I8-97555 413-0 |
|
BOOT KIT, STRG HSG |
1 |
|
|
B |
(A) |
| 60 |
I8-97539 198-0 |
|
BOOT KIT, STRG HSG |
2 |
|
|
A |
(D) |
| 39 |
I8-97539 199-0 |
|
ROD END ASM, OUTER |
2 |
|
|
A |
|
