8-25 | SWITCH AND RELAY, INSTRUMENT PANEL
DMAX
D-MAX 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 573 | I8-97507 148-0 | SWITCH, 4WD | 1 | 2311- | (D-MAX 2024) | |||
| 10 | I8-98192 450-0 | SCREW, POWER WINDOW SW | 3 | 2311- | (D-MAX 2024) | |||
| 798 | I8-98164 677-0 | CLIP | 1 | 2311- | (D-MAX 2024) | |||
| 99 | I8-97481 470-0 | UNIT, FLASHER | 1 | 2311- | (D-MAX 2024) 12V PANASONIC | |||
| 263 | I8-97472 039-3 | COVER, SW | 1 | 2311- | (D-MAX 2024) (B) BLACK | |||
| 8 | I8-97478 560-5 | SWITCH, POWER WINDOW | 1 | 2311- | (D-MAX 2024) (C) BLACK | |||
| 360 | I8-97507 127-1 | SWITCH ASM, DIFF LK | 1 | 2311- | (D-MAX 2024) | |||
| 268 | I8-98164 677-0 | CLIP | 1 | 2311- | (D-MAX 2024) | |||
| 249 | I8-98394 521-2 | SWITCH, HAZARD | 1 | 2311- | (D-MAX 2024) | |||
| 263 | I8-97472 033-2 | COVER, SW | 1 | 2311- | (D-MAX 2024) (c) BLACK | |||
| 8 | I8-97464 938-0 | SWITCH, POWER WINDOW | 2 | 2311- | (D-MAX 2024) (B) BLACK | |||
| 752 | I8-98394 537-1 | COVER, CONSOLE | 2 | 2311- | (D-MAX 2024) | |||
| 8 | I8-97464 938-0 | SWITCH, POWER WINDOW | 1 | 2311- | (D-MAX 2024) (D) BLACK | |||
| 676 | I8-97266 101-0 | SWITCH, DRIVE SELECTOR | 1 | 2311- | (D-MAX 2024) | |||
| 759 | I8-97464 935-4 | SWITCH ASM, WINDOW | 1 | 2311- | (D-MAX 2024) (B) BLACK | |||
| 30 | I8-98394 408-0 | SCREW, DOOR SW | 4 | 2311- | (D-MAX 2024) | |||
| 755 | I8-98394 525-1 | SWITCH, ESC OFF | 1 | 2311- | (D-MAX 2024) | |||
| 263 | I8-97472 035-2 | COVER, SW | 1 | 2311- | (D-MAX 2024) (D) BLACK | |||
| 1 | I7-55193 900-1 | SWITCH, COMB | 1 | 2311- | (D-MAX 2024) | |||
| 29 | I8-98394 409-0 | SWITCH, DOOR | 4 | 2311- | (D-MAX 2024) | |||
| 789 | I8-98394 531-1 | SWITCH, HILL START ASSIST | 1 | 2311- | (D-MAX 2024) | |||
| 263 | I8-97472 460-3 | COVER, SW | 1 | 2311- | (D-MAX 2024) (B) BLACK | |||
| 566 | I8-98394 529-1 | SWITCH, MIRROR | 1 | 2311- | (D-MAX 2024) | |||
| 436 | I8-98394 523-2 | SWITCH, HEADLAMP LEVELING | 1 | 2311- | (D-MAX 2024) |
