| 126 |
I1-09661 026-0 |
|
CONNECTOR; ELBOW |
2 |
2302- |
|
FVZ-N |
(A) DIN12X2 & PT3/8 DOUBLE ELBOW |
| 009 |
I8-97609 249-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
2302- |
|
FVZ-N |
(A) STAMP 5.5 |
| 166 |
I8-97609 249-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
2302- |
|
FVZ-N |
(B) STAMP 5.5 |
| 166 |
I8-98346 869-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
2302- |
|
FVZ-N |
(A) THREAD R1/4 SENSOR AIR METER |
| 045 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
12 |
2302- |
|
FVZ-N |
(A) M10 FLANGE |
| 028 |
I8-98136 697-A |
|
BRACKET; AIR TANK |
1 |
2302- |
|
FVZ-N |
(D) EXC. MIXER CHASSIS; AIR SUSP AIR TANK |
| 037 |
I0-28651 440-0 |
|
BOLT; BRKT TO FRAME |
2 |
2302- |
|
FVZ-N |
|
| 005 |
I1-09660 959-0 |
|
CONNECTOR; BRK VALVE |
3 |
2302- |
|
FVZ-N |
(A) DIN12 & R3/8 ELBOW |
| 064 |
I8-97649 461-0 |
|
STAY; AIR TANK,MAIN |
1 |
2302- |
|
FVZ-N |
|
| 008 |
I1-09660 959-0 |
|
CONNECTOR; BRK VALVE |
1 |
2302- |
|
FVZ-N |
|
| 005 |
I1-09660 957-0 |
|
CONNECTOR; BRK VALVE |
1 |
2302- |
|
FVZ-N |
(C) DIN8 & R3/8 ELBOW |
| 067 |
I8-97556 120-0 |
|
STAY; SUB TANK |
1 |
2302- |
|
FVZ-N |
|
| 038 |
I8-97556 116-0 |
|
BAND; AIR TANK |
2 |
2302- |
|
FVZ-N |
(B) |
| 010 |
I9-09204 517-0 |
|
PLUG; AIR TANK |
1 |
2302- |
|
FVZ-N |
(B) PT3/8 |
| 007 |
I1-09630 145-0 |
|
GASKET; DRAIN COCK |
1 |
2302- |
|
FVZ-N |
ID=14 |
| 028 |
I7-20801 389-A |
|
BRACKET; AIR TANK |
2 |
2302- |
|
FVZ-N |
(F) EXC. MIXER CHASSIS; AIR SUSP AIR TANK |
| 126 |
I1-09660 693-0 |
|
CONNECTOR; BRK VALVE |
2 |
2302- |
|
FVZ-N |
(E) PT1/4 & PT1/4 2WAY |
| 005 |
I1-09660 965-0 |
|
CONNECTOR; BRK VALVE |
2 |
2302- |
|
FVZ-N |
(B) DIN12 & R3/8 STRAIGHT |
| 104 |
I0-91180 108-0 |
|
NUT; OIL PAN |
2 |
2302- |
|
FVZ-N |
M8 FLANGE |
| 038 |
I8-97556 117-0 |
|
BAND; AIR TANK |
2 |
2302- |
|
FVZ-N |
(A) |
| 241 |
I0-28650 820-0 |
|
BOLT; GEAR CASE COVER |
2 |
2302- |
|
FVZ-N |
M8X20 FLANGE |
| 126 |
I8-98166 127-0 |
|
CONNECTOR; ELBOW |
2 |
2302- |
|
FVZ-N |
(F) R3/8 & RC3/8 & RC1/4 3WAY |
| 006 |
I1-48312 015-0 |
|
COCK; DRAIN,AIR TANK |
1 |
2302- |
|
FVZ-N |
|
| 003 |
I1-48320 031-1 |
|
VALVE; CHECK,AIR TANK |
1 |
2302- |
|
FVZ-N |
(A) R3/8 & RC3/8 CHECK VALVE |
| 010 |
I9-99204 513-0 |
|
PLUG; AIR TANK |
4 |
2302- |
|
FVZ-N |
(A) PT1/4 |
| 178 |
I8-98150 355-0 |
|
CLIP; HOSE |
1 |
2302- |
|
FVZ-N |
(A) ID=21 |
| 045 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
2 |
2302- |
|
FVZ-N |
(B) M8 FLANGE |
| 348 |
I9-09204 517-0 |
|
PLUG; AIR TANK |
1 |
2302- |
|
FVZ-N |
|
| 203 |
I0-91180 114-0 |
|
NUT; GEAR,P/S PUMP |
4 |
2302- |
|
FVZ-N |
|
| 177 |
I0-03566 300-0 |
|
HOSE; RUBBER,DRAIN |
1 |
2302- |
|
FVZ-N |
L=60 SERVICED BY L=3000 |
| 126 |
I1-09660 959-0 |
|
CONNECTOR; BRK VALVE |
3 |
2302- |
|
FVZ-N |
(C) DIN12 & R3/8 ELBOW |
| 080 |
I0-28650 820-0 |
|
BOLT; GEAR CASE COVER |
1 |
2302- |
|
FVZ-N |
|
| 001 |
I8-98327 442-0 |
|
TANK ASM; AIR |
1 |
2302- |
|
FVZ-N |
(A) |
| 041 |
I8-97556 121-0 |
|
PIN; BAND FIX |
2 |
2302- |
|
FVZ-N |
|
| 058 |
I0-91110 508-0 |
|
NUT; STOPPER |
8 |
2302- |
|
FVZ-N |
|
| 176 |
I1-09660 693-0 |
|
CONNECTOR; BRK VALVE |
2 |
2302- |
|
FVZ-N |
(B) PT1/4 & PT1/4 2WAY |
| 028 |
I8-97556 118-0 |
|
BRACKET; AIR TANK |
2 |
2302- |
|
FVZ-N |
(A) |
| 126 |
I1-09660 965-0 |
|
CONNECTOR; BRK VALVE |
1 |
2302- |
|
FVZ-N |
(D) DIN12 & R3/8 STRAIGHT |
| 172 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
1 |
2302- |
|
FVZ-N |
M10 FLANGE |
| 203 |
I0-91180 214-0 |
|
NUT; GEAR |
4 |
2302- |
|
FVZ-N |
M14 FLANGE |
| 213 |
I1-48317 087-2 |
|
BOLT; U AIR TANK |
2 |
2302- |
|
FVZ-N |
L=303; EXC. MIXER CHASSIS; AIR SUSP AIR TANK |
| 006 |
I1-48312 015-0 |
|
COCK; DRAIN,AIR TANK |
5 |
2302- |
|
FVZ-N |
|
| 119 |
I0-28651 025-0 |
|
BOLT; ACL BRKT |
1 |
2302- |
|
FVZ-N |
M10X25 FLANGE |
| 028 |
I7-20801 379-A |
|
BRACKET; AIR TANK |
1 |
2302- |
|
FVZ-N |
(E) EXC. MIXER CHASSIS; AIR SUSP AIR TANK |
| 001 |
I7-55205 283-0 |
|
TANK ASM; AIR |
1 |
2302- |
|
FVZ-N |
(F) EXC. MIXER CHASSIS; AIR SUSP AIR TANK |
| 080 |
I0-28651 230-0 |
|
BOLT; TIRE HANGER |
4 |
2302- |
|
FVZ-N |
|
| 126 |
I1-09661 005-0 |
|
CONNECTOR; ELBOW |
1 |
2302- |
|
FVZ-N |
(H) DIN12X2 & R3/8 3WAY |
| 007 |
I1-09630 145-0 |
|
GASKET; DRAIN COCK |
5 |
2302- |
|
FVZ-N |
ID=14 |
| 043 |
I0-28651 025-0 |
|
BOLT; ACL BRKT |
1 |
2302- |
|
FVZ-N |
M10X25 FLANGE |
| 009 |
I8-98346 869-0 |
|
SWITCH; LOW PRESSURE GAGE,AIR TANK |
1 |
2302- |
|
FVZ-N |
(B) THREAD R1/4 SENSOR AIR METER |
| 001 |
I8-98327 443-0 |
|
TANK ASM; AIR |
1 |
2302- |
|
FVZ-N |
(B) |
| 054 |
I7-05110 010-A |
|
NUT; HEAT PROTECTOR |
1 |
2302- |
|
FVZ-N |
M10 FLANGE |
| 176 |
I8-98166 127-0 |
|
CONNECTOR; ELBOW |
1 |
2302- |
|
FVZ-N |
(A) R3/8 & RC3/8 & RC1/4 3WAY |
