8-26 | ELECTRICAL CONTROL AND OTHER PARTS
GIGA E4
GIGA FVZ-N HP E4
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 485 | I8-98232 695-0 | CONTROL UNIT; SPEED SENSOR | 1 | 2302- | FVZ-N | |||
| 485 | I8-98232 695-0 | CONTROL UNIT; SPEED SENSOR | 1 | 2302- | FVZ-N | |||
| 756 | I8-98056 411-3 | BRACKET; ECU,BCM | 1 | 2302- | FVZ-N | |||
| 609 | I8-98169 737-1 | BRACKET ASM; ELEC UNIT,AIR SUS | 1 | 2302- | FVZ-N | |||
| 380 | I1-76798 019-1 | SEAL | 1 | 2302- | FVZ-N | |||
| 757 | I0-28650 616-0 | BOLT; CONT UNIT | 2 | 2302- | FVZ-N | M6X16 FLANGE | ||
| 756 | I8-98056 411-3 | BRACKET; ECU,BCM | 1 | 2302- | FVZ-N | |||
| 491 | I8-98054 651-A | PLUG; HOLE,CONT UNIT | 1 | 2302- | FVZ-N | OD=60 | ||
| 264 | I8-98246 453-0 | BRACKET; CONT UNIT | 1 | 2302- | FVZ-N | |||
| 158 | I8-98335 053-0 | CONTROLLER; ABS | 1 | 2302- | FVZ-N | |||
| 420 | I8-94122 971-0 | GROMMET; AIR PIPE | 1 | 2302- | FVZ-N | OD=35 | ||
| 491 | I8-98054 651-A | PLUG; HOLE,CONT UNIT | 1 | 2302- | FVZ-N | OD=60 | ||
| 608 | I0-28650 616-0 | BOLT; CONT UNIT | 5 | 2302- | FVZ-N | M6X16 FLANGE | ||
| 021 | I8-98025 954-1 | COVER; SW | 1 | 2302- | FVZ-N | |||
| 608 | I0-28650 616-0 | BOLT; CONT UNIT | 5 | 2302- | FVZ-N | M6X16 FLANGE | ||
| 158 | I8-98335 053-0 | CONTROLLER; ABS | 1 | 2302- | FVZ-N | |||
| 380 | I1-76798 019-1 | SEAL | 1 | 2302- | FVZ-N | |||
| 609 | I8-98169 737-1 | BRACKET ASM; ELEC UNIT,AIR SUS | 1 | 2302- | FVZ-N | |||
| 420 | I8-94122 971-0 | GROMMET; AIR PIPE | 1 | 2302- | FVZ-N | OD=35 | ||
| 264 | I8-98246 453-0 | BRACKET; CONT UNIT | 1 | 2302- | FVZ-N | |||
| 021 | I8-98025 954-1 | COVER; SW | 1 | 2302- | FVZ-N | |||
| 069 | I0-91180 106-0 | NUT; CLIP | 1 | 2302- | FVZ-N | M6 FLANGE | ||
| 757 | I0-28650 616-0 | BOLT; CONT UNIT | 2 | 2302- | FVZ-N | M6X16 FLANGE | ||
| 068 | I0-28650 616-0 | BOLT; CONT UNIT | 1 | 2302- | FVZ-N | (A) M6X16 FLANGE | ||
| 069 | I0-91180 106-0 | NUT; CLIP | 1 | 2302- | FVZ-N | M6 FLANGE | ||
| 657 | I8-97515 717-0 | CONTROL UNIT; MIMAMORI | 1 | 2302- | FVZ-N | (B) | ||
| 657 | I8-97515 717-0 | CONTROL UNIT; MIMAMORI | 1 | 2302- | FVZ-N | (B) | ||
| 068 | I0-28650 616-0 | BOLT; CONT UNIT | 1 | 2302- | FVZ-N | (A) M6X16 FLANGE |
